Clearing Password Check and BIOS Recovery

This section provides users with the standard operating procedures of clearing password and
BIOS recovery for the Aspire7750/7750G. The machine provides one Hardware Open Gap on
main board for clearing password check, and one Hotkey for enabling BIOS Recovery.

Clearing Password Check

NOTE:
NOTE:
The following procedure is only for clearing BIOS Password (Supervisor Password and
User Password).

Steps for Clearing BIOS Password Check

If users set BIOS Password (Supervisor Password and/or User Password) for a security
reason, BIOS will ask the password during systems POST or when systems enter to BIOS
Setup menu. However, once it is necessary to bypass the password check, users need to
short the HW Gap to clear the password by performing the following:
1. Remove power from the system.
2. Remove HDD, AC and Battery.
3. Disconnect the RTC Battery
4. Locate the RTCRST# jumper.
5. Use an electric conductivity tool to short the two points of the RTCRST# jumper.
6. Plug in AC, keeping the RTCRST# jumper shorted.
7. Press Power Button until BIOS POST is finished, then remove the conductivity tool from
the RTCRST# jumper.
8. Restart the system. Press F2 to enter BIOS Setup menu.
9. If there is no Password request, BIOS Password is cleared.
10. If a password is requested, repeat Steps 1 thru 9.
Jumper and Connector Locations
