- Page 1 Refrigerator Use & Care Guide Model: HRB208N6BSE For questions about features, operation/performance, parts or service, call: 1-877-465-3566...
-
Page 2: Table Of Contents
Table of Contents Brief introduction ........................1 Important safety instructions ....................2 Installing your new appliance ....................4 Description of the appliance ....................11 Display controls ........................12 Using your appliance ......................14 Cleaning and care ....................... 16 Helpful hints and tips ...................... -
Page 3: Brief Introduction
Brief Introduction Thank you for your choosing Hisense. We Kitchen areas in shops, offices and other are sure you will find your new refrigerator working environments. a pleasure to use. Before you use the Hotels, motels and other residential appliance, we recommend that you environments. -
Page 4: Important Safety Instructions
Important Safety Instructions General safety and daily use Don’t place items on top of the appliance as this could cause injury should they fall off. It is important to use your appliance safely. We recommend that you follow the Never allow children to play with the guidelines below. - Page 5 If the fitted plug is not suitable for your To avoid eye injury, do not look directly socket outlets, it should be cut off and into the LED light located in the refrigerator carefully disposed of. To avoid a compartment. If it is not functioning possible shock hazard, do not insert the correctly, consult a qualified, registered discarded plug into a socket.
-
Page 6: Installing Your New Appliance
Installing Your New Appliance Before using the appliance for the first time, you should be informed of the following tips. 1/2'' WARNING For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring. - Page 7 Handle Installation Leveling of appliance Take out the screw hole covers on the doors, install the handle supports(C). Place the handle (A) on the door by fitting the handle over the handle supports (C), then fasten the screws (B) with (5/32'',3mm) Allen wrench (provided in plastic bag).
- Page 8 5. oosen the two screws(G) on the right bottom of the fridge door,then take out the right stopper block(H) and the right door stopper(I).Then install the left stopper block(K) and the left door stopper(J) (provided in the plastic bag)
- Page 9 Put out the left upper hinge (o) from plastic bag provided Then put it on the top left side refer to step 3. Put out the left hinge cover ( P ) from...
- Page 10 Disassembling the freezer door Remove the lower freezer drawer (S) 1. Pull out the freezer door and the upper by lifting it up. freezer drawer (Q) to the final position. Take out the ice storage box (R) by Remove the 4 screws attached to lifting it up in the direction of the arrow.
- Page 11 Re-assembling the freezer door 4.You need to purchase several item to compalet this connection.You may find To reattach the drawer after you moved these items sold as a kit at local hardware the appliance to its final location, assemble the parts in reverse order. store.
- Page 12 Flush the tubing. Turn the main water 6. Turn the water on and check supply on and flush out the tubing until for leakage. the water is clear. Then, shut the water off at the water valve after about a quart of water has flushed through the tubing.
-
Page 13: Description Of The Appliance
Description of the Appliance Control Panel Refrigerator LED Light Glass Shelves Fruit and Vegetables Crisper Full Width Pantry Door Bin Gallon Storage Bin Ice maker (inside) Ice bucket (inside) Freezer LED Light Freezer Storage Drawer Freezer Storage Compartment Leveling Leg... -
Page 14: Display Controls
Display Controls Your product has one control panel which is installed on the top cover. Use your appliance according to the following control guidelines. When the appliance is powered on for the first time, the backlighting of the icons on the display panel start working. If no buttons have been touched or the Note: doors are closed, the backlighting will... - Page 15 2. Press Freezer repeatedly to cycle through Super the available temperature settings,from Cool 5°F to -10°F or from -15°C to -23°C. NOTE:Such as °C scenario,each press NOTES: advances the setting by one degree(-18→-19→-20→-21→-22→-23→-1 • When the refrigerator is in Super Cool 5 →-16→-17→-18).
-
Page 16: Using Your Appliance
Demo mode (Freezer/ Fridge Temperature Indicator moving) Demo mode is for store display, and it prevents the refrigerator from generating cool air. In this of Cooling off Mode, the refrigerator may seem like it is working but it will not make cool air. - Page 17 Using the freezer compartment Vegetable and fruit crispers The freezer compartment is provided with The crispers are suitable for storage of an upper drawer, a lower drawer and an vegetables and fruit. To take them out, ice box. To remove all of them, refer to open the door to the final location first.
-
Page 18: Cleaning And Care
Cleaning and Care Interior cleaning For hygienic reasons the appliance (including exterior and interior accessories) should be cleaned at least You should clean the appliance interior every two months. regularly. It will be easier to clean when food stocks are low. Wipe the inside of WARNING! the fridge and freezer with a weak solution of backing soda and water, and... - Page 19 Replacing the LED light WARNING! Do not use sharp objects to WARNING! remove frost from the freezer compartment. Only after the The LED light must be replaced interior is completely dry should by a competent person. If the the appliance be switched back LED light is damaged, follow the on and plugged back into the steps below：...
-
Page 20: Helpful Hints And Tips
Helpful Hints and Tips Energy Saving Tips Hints for refrigeration We recommend that you follow the tips For Meat: (all types) wrap in cling wrap below to save energy. and place on the glass shelf above the vegetable drawer. Always follow food Try to avoid keeping the door open for storage times and use by dates long periods in order to conserve energy. - Page 21 Iced products (ice cubes, popsicles): if consumed immediately after removal from the freezer compartment, will probably cause frost burns to the skin. It is recommended to label and date each frozen package in order to keep track of the storage time. Hints for the storage of frozen food Ensure that frozen food has been stored...
-
Page 22: Troubleshooting
Troubleshooting If you experience a problem with your appliance or are concerned that the appliance is not functioing correctly, you can carry out some easy checks before calling for service, please see below. WARNING 1.Don’t try to repair the appliance yourself. If the problem persists after you have made the checks mentioned below, contact a qualified electrician, authorized service technician or the shop where you purchased the product. - Page 23 It is normal to frequently hear the sound of the motor, it will need to run more when in following circumstances: • Temperature setting is set colder than necessary. Large quantity of warm food has recently been stored • The motor runs within the appliance.
- Page 24 • Did you wait for 12 hours after installation of the water supply line before making ice? If it is not sufficiently cool, it may take longer to make ice, such as when first installed. • Is the water line connected and the water valve open? •...
-
Page 25: Disposal Of The Appliance
Disposal of the Appliance DANGER It is prohibited to dispose of this appliance as household waste. Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a suitable waste collection container to recycle it. Before disposal of the appliance 1. - Page 26 Copyright Statement © 2019 Hisense Company Ltd. All Rights Reserved. All material in this User Manual is the property of Hisense Company Ltd. and its subsidiaries, and is protected under US, CANADA, MEXICO and International copyright and/or other intellectual property laws.
