Panasonic CS-XE15SKUA Install Manual
Hide thumbs Also See for CS-XE15SKUA:

Advertisement

Quick Links

INSTALL MANUAL
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturer's specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of
manufacturer.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
CS-XE15SKUA
A I R C O N D I T I O N E R
M O D E
A U T O
E C O N A V I
C O M F O R T
O FF/O N
O FF/O N
M O D E
R F P
TEMP
TEMP
POWERFUL/
A IR SW IN G
QUIET
FANSPEED
T I M E R
T I M E R
O N
O N
S E T
S E T
1
1
2
2
3
3
CANCEL
O F F
O F F
AC
RC
SET
CHECK
CHECK
CLOCK
RESET
WARNING
IMPORTANT SAFETY NOTICE
PRECAUTION OF LOW TEMPERATURE
Order No: PAPAMY1608072AE
Air Conditioner
Indoor Unit
CU-XE15SKUA
© Panasonic Corporation 2016.
Outdoor Unit
Destination
U.S.A.
Canada
in the Schematic
!

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic CS-XE15SKUA

  • Page 1 Do not modify the original design without permission of manufacturer. PRECAUTION OF LOW TEMPERATURE In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit. © Panasonic Corporation 2016.
  • Page 2: Installation Instruction

    11. Installation Instruction 11.1 Select the Best Location 11.1.3 Indoor/Outdoor Unit Installation Diagram 11.1.1 Indoor Unit Do not install the unit in excessive oil fume area Piping direction Do not bend up (Front side) drain hose such as kitchen, workshop and etc. Right Rear There should not be any heat source or steam...
  • Page 3: Indoor Unit

    11.2 Indoor Unit The mounting wall shall be strong and solid enough to prevent it from vibration. Wall Wall Wall More than 1 More than 1 More 2 screw than 2 " (128 mm) DISTANCE TO PIPE HOLE CENTER 128 mm "...
  • Page 4: Indoor Unit Installation

    11.2.2 Indoor Unit Installation Use shock absorber Do not turn over the unit during pulling out without it’s shock absorber the piping to protect during pulling out the piping. the intake grille from It may cause intake grille damage. damage. Piping Piping Shock absorber...
  • Page 5 Replace the drain hose Rear view for left piping installation Connection cable Piping Drain hose More than 45 " (1150 mm) Connection cable Drain hose Drain hose Drain cap Sleeve for piping hole Adjust the piping slightly downwards. • • How to pull the piping and drain hose out, in case How to insert the connection cable and drain hose in the case of left...
  • Page 6: Connect The Cable To The Indoor Unit

    11.2.3 Connect the Cable to the Indoor Unit The inside and outside connection cable can be connected without removing the front grille. Conduit Unscrew the conduit cover and fix the conduit Connector Conduit Cover connector to conduit cover with lock nut, then Lock Nut secure it against chassis.
  • Page 7: Outdoor Unit

    11.3 Outdoor Unit 11.3.1 Install the Outdoor Unit After selecting the best location, start installation according to Indoor/Outdoor Unit Installation Diagram. Fix the unit on concrete or rigid frame firmly and horizontally with a bolt nut ø13/32" (ø10 mm). When installing at roof, please consider strong wind and earthquake. Please fasten the installation stand firmly with bolt or nails.
  • Page 8: Evacuation Of The Equipment

    11.3.3 Evacuation of the Equipment WHEN INSTALLING AN AIR CONDITIONER, BE SURE TO EVACUATE THE AIR INSIDE THE INDOOR UNIT AND PIPES in the following procedure. Liquid side Indoor unit Two-way valve Outdoor unit Close Gas side Three-way valve Close Vacuum pump Connect a charging hose with a push pin to the Low side of a charging set and the service port of the 3-way...
  • Page 9: Piping Insulation

    Indoor Unit Outdoor Unit 208/230V min AWG16 208/230V min AWG16 208/230V min AWG16 Grounding wire min AWG16 Disconnect Switch Field supply Power Supply Single Phase 208/230V 60Hz min AWG14 Grounding wire Secure the wire onto the control board with the holder (clamper). Terminal Board 10 After completing wiring connections, reattach...
  • Page 10: Disposal Of Outdoor Unit Drain Water

    11.3.6 Disposal of Outdoor Unit Drain Water The unit should be mounted on a stand that suits to a local environmental requirement. When the Drain elbow being used, please ensure to:- Provide a minimum clearance of 2" (50mm) to access the bottom of base pan. Seal the four 25/32"...
