X62
Multimedia Projector
Operator's Guide
Thank you for purchasing this projector.
WARNING
Guide" and related manuals to ensure the proper use of this product. After
reading them, store them in a safe place for future reference.

About this manual

Various symbols are used in this manual. The meanings of these symbols are
described below.
WARNING This symbol indicates information that, if ignored, could possibly
result in personal injury or even death due to incorrect handling.
CAUTION
This symbol indicates information that, if ignored, could possibly
result in personal injury or physical damage due to incorrect
handling.
Please refer to the pages written following this symbol.
NOTE • The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in this manual.
• The reproduction, transfer or copy of all or any part of this document is not permitted
without express written consent.
Trademark acknowledgment
• VGA and XGA are registered trademarks of International Business Machines Corporation.
• Apple and Mac are registered trademarks of Apple Computer, Inc.
• VESA and SVGA are trademarks of Video Electronics Standard Association.
• Windows is a registered trademark of Microsoft Corporation.
All other trademarks are the properties of their respective owners.
Before using this product, please read the "Product Safety
© 3M 2006. All Rights Reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X62 and is the answer not in the manual?

Questions and answers

Related Manuals for 3M X62

Summary of Contents for 3M X62

  • Page 1: About This Manual

    • Apple and Mac are registered trademarks of Apple Computer, Inc. • VESA and SVGA are trademarks of Video Electronics Standard Association. • Windows is a registered trademark of Microsoft Corporation. All other trademarks are the properties of their respective owners. © 3M 2006. All Rights Reserved.

  • Page 2: Table Of Contents

    Phenomena that may be easy to be mistaken for machine defects ..58 Technical (English only) ..A-1 © 3M 2006. All Rights Reserved... . . 61...

  • Page 3: Projector Features

    Lens cover, Rivet and Strap WEEE Statement Projector features / Preparations STANDBY/ON AUTO BLANK Power cord VOLUME MUTE (US, UK, EUROPE) KEYSTONE MENU RESET Component cable © 3M 2006. All Rights Reserved. VGA cable USB cable Video/Audio cable Soft case...

  • Page 4: Part Names

    Bottom side WARNING lamp and vents of the projector. ( ) It could cause a burn. Control buttons ( Front-Right side © 3M 2006. All Rights Reserved. Remote sensor ( Speaker Security bar ( (Use for attaching a commercial anti-theft chain or wire.)
  • Page 5 RGB IN2 RGB OUT AUDIO IN1 AUDIO IN2 CONTROL USB port ( CONTROL port ( Kensington lock slot © 3M 2006. All Rights Reserved. Part names AC inlet ( Elevator button ( Elevator foot ( AUDIO OUT port AUDIO OUT Ports...

  • Page 6: Control Buttons

    PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE MENU POSITION ENTER RESET © 3M 2006. All Rights Reserved. 56, 57) LAMP indicator ( 56, 57) TEMP indicator ( POWER indicator ( INPUT button ( STANDBY/ON button ( AUTO button ( BLANK button (...

  • Page 7: Setting Up

    Fix the strap to the strap ring of the lens cover. Put the strap into the groove on the rivet. Push the rivet into the strap hole. Strap ring © 3M 2006. All Rights Reserved. Setting up Strap hole Bottom side...

  • Page 8: Arrangement

    4.9 (192) 5.8 (230) (12) 274 (108) 6.5 (256) 7.8 (307) (15) 343 (135) 8.1 (320) 9.8 (384) -10 (18) 411 (162) 9.8 (384) 11.7 (461) -12 © 3M 2006. All Rights Reserved. 16 : 9 screen (c) Screen height [cm (inch)] max.

  • Page 9: Adjusting The Projector's Elevator

    Raise or lower the projector to the desired height and release the elevator buttons. When you release the elevator buttons, the elevator feet will lock into position. the elevator feet by hand. Elevator feet Elevator button © 3M 2006. All Rights Reserved. Setting up...

  • Page 10: Using The Security Bar

    An anti-theft chain or wire can be attached as shown in the illustration. (Anti-theft chains or wires of up to 10mm in diameter can be used) © 3M 2006. All Rights Reserved. Security Bar Anti-theft chain or wire [sold separately]...

  • Page 11: Connecting Your Devices

    RGB IN1 port (DDC 2B compatible). Plug-and-Play may not work properly if any other type of connection is attempted. • Please use the standard drivers in your computer as this projector is a Plug-and-Play monitor. © 3M 2006. All Rights Reserved. Setting up...

  • Page 12: Examples Of Connection With A Computer

    RGB cable AUDIO IN3 VIDEO S-VIDEO RGB cable AUDIO IN3 Audio in VIDEO S-VIDEO Stereo mini audio cable © 3M 2006. All Rights Reserved. RGB IN1 RGB IN2 RGB OUT AUDIO OUT AUDIO IN1 AUDIO IN2 CONTROL RGB IN1 RGB IN2...

  • Page 13: Video Out

    AUDIO IN3 AUDIO IN2 VIDEO S-VIDEO Audio cable AUDIO IN3 AUDIO IN2 VIDEO S-VIDEO Video © 3M 2006. All Rights Reserved. Setting up RGB IN1 RGB IN2 RGB OUT AUDIO OUT AUDIO IN1 CONTROL RGB IN1 RGB IN2 RGB OUT...

  • Page 14: Connecting Power Supply

    Connect the connector of the power cord to the AC inlet of the projector. Firmly plug the power cord's plug into the outlet. AC inlet Connector of the power cord © 3M 2006. All Rights Reserved.

  • Page 15: Remote Control

    Align and insert the two AA batteries according to their plus and minus terminals as indicated in the remote control. Close the battery cover. Replace the battery cover in the direction of the arrow and snap it back into place. © 3M 2006. All Rights Reserved. Remote control...

  • Page 16: Using The Remote Control

    • Since the remote control uses infrared light to send signals to the projector (Class1 LED), be sure to use the remote control in an area free from obstacles that could block the remote control’s output signal to the projector. 30º 30º © 3M 2006. All Rights Reserved.

  • Page 17: Power On/Off

    Make sure that the power indicator lights in steady orange, and set the power switch to the OFF position. The POWER indicator will go off. Attach the lens cover. STANDBY/ON button POSITION 18). © 3M 2006. All Rights Reserved. Power on/off POWER indicator STANDBY/ON VIDEO SEARCH...

  • Page 18: Operating

    RGB IN1 RGB IN2 when TURN ON is selected for the AUTO SEARCH item in the OPTION menu the projector will check the RGB IN2 port. RGB IN2 COMPONENT VIDEO © 3M 2006. All Rights Reserved. STANDBY/ON SEARCH VIDEO BLANK ASPECT...

  • Page 19: Searching An Input Signal

    Adjusting the zoom and focus Use the zoom ring to adjust the screen size. Use the focus ring to focus the picture. S-VIDEO VIDEO COMPONENT VIDEO SMALL SMALL Focus ring © 3M 2006. All Rights Reserved. Operating STANDBY/ON SEARCH VIDEO BLANK ASPECT AUTO STANDBY/ON...

  • Page 20: Using The Automatic Adjustment Feature

    To complete this operation, press the POSITION button again. Even if you don’t do anything, the dialog will automatically disappear after a few seconds. may appear outside a picture. . For a component video © 3M 2006. All Rights Reserved. STANDBY/ON SEARCH VIDEO...

  • Page 21: Correcting The Keystone Distortions

    To exit the MAGNIFY mode and restore the screen to normal, press the OFF button of MAGNIFY on the remote control. changed, or when the display condition is changed. will be restored when the projector exits the MAGNIFY mode. © 3M 2006. All Rights Reserved. Operating PAGE UP VOLUME...

  • Page 22: Freezing The Screen

    To exit the blank screen and return to the input signal screen, press the BLANK button again. the projector’s buttons or the remote control buttons is pressed or one of the commands (except get commands) is transmitted from the control port. © 3M 2006. All Rights Reserved. MAGNIFY HOME PAGE UP...

  • Page 23: Operating The Computer Screen

    Press keyboard’s PAGE UP key ENTER Press keyboard’s PAGE DOWN key RESET Press keyboard’s ESC key Move pointer © 3M 2006. All Rights Reserved. Operating Remote control operation Press ENTER button Press RESET button Press HOME button Press END button...

  • Page 24: Multifunctional Settings

    10 seconds. when a certain input signal is displayed. MENU button ENTER button Cursor buttons RESET button on the projector or remote control, or the ENTER button © 3M 2006. All Rights Reserved. STANDBY/ON SEARCH VIDEO ASPECT AUTO BLANK...

  • Page 25: Easy Menu

    See the item BRIGHTNESS in the PICTURE menu ( Description NORMAL CINEMA DYNAMIC BOARD(GREEN) (GAMMA = #4 DEFAULT) (GAMMA = #4 DEFAULT) DEFAULT) 28) items in the PICTURE menu. © 3M 2006. All Rights Reserved. EASY Menu 30). 35). 48). 48). BOARD(BLACK) 27).
  • Page 26 ENTER button to use the menu of PICTURE, IMAGE, INPUT, Advanced Menu SETUP, SCREEN or OPTION. Description 48) will be displayed when projector is selects the LANGUAGE item to toggle 37). © 3M 2006. All Rights Reserved. 27). 28). 28). 28). 35). 36).

  • Page 27: Picture Menu

    Description #1 CUSTOM #2 DEFAULT #5 DEFAULT #4 CUSTOM Gray scale of 9 steps Ramp Gray scale of 15 steps © 3M 2006. All Rights Reserved. PICTURE Menu Dark Weak #2 CUSTOM #3 DEFAULT #4 DEFAULT #3 CUSTOM ENTER :...

  • Page 28: Color Temp

    Hi-BRIGHT-1 DEFAULT Hi-BRIGHT-2 DEFAULT Hi-BRIGHT-2 CUSTOM displays a dialog Gray scale of 9 steps Ramp Gray scale of 15 steps Weak Redish Weak © 3M 2006. All Rights Reserved. MID CUSTOM Hi-BRIGHT-1 CUSTOM ENTER : OFFSET GAIN COLOR TEMP [CUSTOM-1]...

  • Page 29: My Memory

    To load saved adjustment settings press the MEMORY button. When there are no saved adjustment settings the following dialog is displayed. Description LOAD1 LOAD2 LOAD3 SAVE4 SAVE3 SAVE2 © 3M 2006. All Rights Reserved. PICTURE Menu LOAD4 SAVE1...

  • Page 30: Image Menu

    It is not possible to adjust when the OVERSCAN is set to 10. Right H PHASE • This item can be selected only for an RGB signal or a component video signal. Description 16:9 SMALL 16:9 14:9 SMALL Down Right Left © 3M 2006. All Rights Reserved.

  • Page 31: Auto Adjust Execute

    For a component video signal The horizontal phase will be automatically set to default. • The automatic adjustment operation requires about 10 seconds. Also please note that it may not function correctly with some input. © 3M 2006. All Rights Reserved.

  • Page 32: Input Menu

    • The AUTO mode automatically selects the optimum mode. • The AUTO operation may not work well at some signals. In such a case, it might be good to select a suitable mode except AUTO. Description FILM TURN OFF SMPTE240 REC709 © 3M 2006. All Rights Reserved. REC601...
  • Page 33 In such a case, remove the signal connector so that no signal is received and turn SYNC ON G off, and then reconnect the signal. Description SCART RGB NTSC SECAM M-PAL NTSC4.43 TURN OFF RGB2 SYNC ON G OFF © 3M 2006. All Rights Reserved. INPUT Menu...
  • Page 34 *1 Not all resolutions are guaranteed. *2 For some pictures, this function may not work well. Description 43) will be 43) dialog has © 3M 2006. All Rights Reserved. RESOLUTION MENU INFORMATION RGB1 1280x 768@ 60 CUSTOM RESOLUTION...

  • Page 35: Setup Menu

    • This function will be unavailable when Transition Detector is on ( NORMAL WHISPER • When the WHISPER is selected, acoustic noise and screen brightness are reduced. Description Lower in the data WHISPER © 3M 2006. All Rights Reserved. SETUP Menu 48). 48).
  • Page 36 AUDIO audio ports do not work for the input port. (1) RGB1 (2) 1 Description H:INVERT V:INVERT 48) will be displayed when projector is RGB2 COMPONENT © 3M 2006. All Rights Reserved. S-VIDEO VIDEO...

  • Page 37: Screen Menu

    ORIGINAL screens will change to the BLACK screen after several minutes. • For the MyScreen, please refer to the MyScreen item ( Description FRANÇAIS DEUTSCH ESPAÑOL NORSK NEDERLANDS PORTUGUÊS SUOMI ORIGINAL BLUE WHITE © 3M 2006. All Rights Reserved. SCREEN Menu ITALIANO SVENSKA POLSKI TÜRKÇE BLACK 38).

  • Page 38: Turn On Turn Off

    MyScreen Lock this function for protecting the current MyScreen. • This function will be unavailable when MyScreen Password in the Security Menu is on. Description ORIGINAL TURN OFF TURN OFF © 3M 2006. All Rights Reserved. below . For 37).

  • Page 39: Source Name

    (5) Select To revert to the previous name without and the INPUT button simultaneously. Description TURN OFF and press the ENTER or © 3M 2006. All Rights Reserved. SCREEN Menu 22). SOURCE NAME MENU *Right side of the menu is blank...

  • Page 40: Option Menu

    (except get commands) is transmitted from the control port during the corresponding time, projector will not be turned off. Description TURN OFF RGB IN2 COMPONENT VIDEO TURN OFF TURN OFF © 3M 2006. All Rights Reserved. S-VIDEO VIDEO 48). 41).
  • Page 41 • PICTURE MODE: Changes the PICTURE mode ( 41). Description Short (min. 0 minute = DISABLE) AUTO OFF ENABLE CANCEL CANCEL 35). © 3M 2006. All Rights Reserved. OPTION Menu AUTO OFF DISABLE 17). 50, 51). 52, 53). 43). 29).
  • Page 42 • Please use to avoid a mischief and touching accidentally. This function does not have any effect on the remote control. Description AUTO ADJUST GHOST FACTORY RESET INFORMATION NORMAL DISABLE 100h 200h 300h TURN OFF TURN OFF © 3M 2006. All Rights Reserved. FILTER MESSAGE KEY LOCK REMOTE FREQ.

  • Page 43: Factory Reset

    Note that the items LAMP TIME, FILTER TIME, LANGUAGE and OPTION_SECURITY are not reset. RESET Description 16). 2:HIGH INPUT-INFORMATION INPUT-INFORMATION S-VIDEO 1024x768 @60Hz SECAM FRAME LOCK AUTO CANCEL © 3M 2006. All Rights Reserved. OPTION Menu 16). INPUT-INFORMATION COMPONENT 576i @50 SCART RGB...

  • Page 44: Inputting The Password

    NOTE NEW PASSWORD BOX. NOTE : Please do not forget your PASSWORD. Description default PASSWORD to be changed as soon as possible. © 3M 2006. All Rights Reserved. ENTER PASSWORD SECURITY MENU ENTER NEW PASSWORD NEW PASSWORD AGAIN BOX...
  • Page 45 PASSWORD. Move the cursor to the right side of the ENTER PASSWORD BOX CHECK PASSWORD BOX, enter the same PASSWORD again. Description PASSWORD © 3M 2006. All Rights Reserved. OPTION Menu Inquiring Code (PASSWORD) MyScreen PASSWORD on/off menu ENTER PASSWORD...
  • Page 46 ENTER button to display the PIN LOCK on/off menu. menu to select TURN ON and the PIN BOX will be displayed. Description © 3M 2006. All Rights Reserved. PASSWORD BOX ENTER PASSWORD BOX (large) PIN LOCK on/off menu...
  • Page 47 NOTE: If there is no key input for about 5 minutes while the Inquiring Code is displayed the projector will turn off. 3.3-2 Contact your dealer with the 10 digit Inquiring Code. Your PASSWORD Description © 3M 2006. All Rights Reserved. OPTION Menu PIN BOX CONFIRMATION BOX (PIN BOX)

  • Page 48: Using The Transition Detector Function

    Pressing the ENTER button on the remote controll or the INPUT button on the projector will close the PASSWORD BOX. NOTE : Please do not forget your Transition Detector PASSWORD. Description Transition Detector Transition Detector PASSWORD © 3M 2006. All Rights Reserved. Function Transition Detector on/off menu Transition Detector Alarm Transition Transition...
  • Page 49 PASSWORD BOX (large). The 10 digit Inquiring Code will be displayed inside the BOX. 4.4-3 Contact your dealer with the 10 digit Inquiring Code. Your PASSWORD will be sent after your Description © 3M 2006. All Rights Reserved. OPTION Menu ENTER PASSWORD BOX (large)

  • Page 50: Maintenance

    When the pictures appear dark, or when the color tone is poor, please replace the lamp as soon as possible. Do not use old (used) lamps; this is a cause of breakage. HIGH VOLTAGE HIGH TEMPERATURE © 3M 2006. All Rights Reserved. HIGH PRESSURE gas containing...
  • Page 51 (3) Point at the “OPTION” in the left column of the dialog. It performs resetting the lamp time. NOTE • Please reset the lamp time only when you have replaced the lamp, for a suitable indication about the lamp. © 3M 2006. All Rights Reserved. Maintenance Lamp door Screw...
  • Page 52 When the projector is suspended from the ceiling, apply the vacuum cleaner to penetration of dust or the like. While supporting the projector with one cover forward in the direction of the arrow. © 3M 2006. All Rights Reserved. Handle Filter cover...

  • Page 53: Option Menu

    FILTER TIME function in the OPTION menu (1) Press the MENU button to display a menu. When the EASY MENU has appeared, please skip the next step (2). dialog will appear. locations. knob © 3M 2006. All Rights Reserved. Maintenance mark Filter cover...

  • Page 54: Other Care

    If soiling is severe, dip soft cloth in water or a neutral cleaner diluted in water, and wipe lightly after wringing well. Then, wipe lightly with a soft, dry cloth. © 3M 2006. All Rights Reserved.

  • Page 55: Troubleshooting

    If the same indication is displayed after the remedy, please set FAN SPEED of the SERVICE item in the OPTION menu to HIGH. Please immediately turn the power off, and clean or change © 3M 2006. All Rights Reserved. Troubleshooting 41).

  • Page 56: Regarding The Indicator Lamps

    45 minutes. After the projector has the attachment state of the lamp door. After performing any needed maintenance, turn the power on again. If the same indication is displayed after the remedy, please contact your dealer or service company. © 3M 2006. All Rights Reserved.
  • Page 57 ON. There is a possibility that the interior portion has become overcooled. Please use the unit within the usage temperature parameters (5°C to 35°C). After the treatment, reset the power to ON. © 3M 2006. All Rights Reserved. Troubleshooting...

  • Page 58: Phenomena That May Be Easy To Be Mistaken For Machine Defects

    The input changeover settings are mismatched. Select the input signal, and correct the settings. to reset all settings to factory default. Cases not involving a machine defect © 3M 2006. All Rights Reserved. Reference page 56, 57 12, 13 –...
  • Page 59 Color tone is COLOR SPACE setting is not suitable. poor. Change the COLOR SPACE setting to AUTO, RGB, SMPTE240, REC709 or REC601. Cases not involving a machine defect © 3M 2006. All Rights Reserved. Troubleshooting Reference page 12,13 12, 13...
  • Page 60 NOTE • Although bright spots or dark spots may appear on the screen, this is a unique characteristic of liquid crystal displays, and it does not constitute or imply a machine defect. Cases not involving a machine defect © 3M 2006. All Rights Reserved. Reference page 25, 26...

  • Page 61: Component Video

    Audio output: AUDIO OUT ...Stereo mini x1 Video input: COMPONENT VIDEO (Y, C S-Video ... Mini DIN x1 Video ... RCA x1 Communication port: CONTROL... D-sub 9pin x1 USB ...USB(B) x1 © 3M 2006. All Rights Reserved. )... RCA x3...
  • Page 62 3M™ Digital Projector X62 306mm © 3M 2006. All Rights Reserved.
  • Page 63 3M™ Digital Projector X62 © 3M 2006. All Rights Reserved.
  • Page 64 3M™ Digital Projector X62 Intended Use Before operating this machine, please read this entire manual thoroughly. The 3M indoors, using 3M lamps, 3M ceiling mount hardware, and nominal local voltages. The use of other replacement lamps, outdoor operation, or different voltages has not been tested and could damage the projector peripheral equip- ment and/or create a potentially unsafe operating condition.
