Volvo 2009 S40 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

VOLVO S40
Owner's manual
Web Edition

Advertisement

Table of Contents
loading

Related Manuals for Volvo 2009 S40

Summary of Contents for Volvo 2009 S40

  • Page 1 VOLVO S40 Owner's manual Web Edition...
  • Page 3 Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. We encourage you to familiarize yourself with the equipment descriptions and operating instructions in this manual.

  • Page 4: Table Of Contents

    Contents 00 Introduction General information... 10 Volvo and the environment... 12 Important warnings... 13 01 Safety Occupant safety... 16 Seat belts... 18 Supplemental Restraint System... 21 Occupant Weight Sensor (OWS)... 26 Side impact protection airbags... 29 Volvo Inflatable Curtain (VIC)... 30 Whiplash Protection System...
  • Page 5 03 Climate General information... 92 Air vents... 94 Manual climate control... 95 Electronic Climate Control (ECC) – option... 98 Air distribution... 101 04 Interior Front seats... 104 Interior lighting... 107 Storage compartments... 109 Rear seat... 113 Trunk ... 115 Contents 05 Locks and alarm Remote control and key blade...
  • Page 6 Contents 06 Starting and driving General information... 136 Fuel requirements... 140 Ignition switch... 143 Starting the vehicle... 144 Starting the vehicle with keyless drive (option as available)... 146 Manual transmission, 5-speed (certain markets only)... 147 Manual transmission, 6-speed (certain markets only)... 148 Automatic transmission (option)...
  • Page 7 09 Maintenance and servicing Volvo maintenance... 210 Maintaining your car... 212 Hood... 214 Engine compartment... 215 Engine oil... 216 Fluids... 218 Wiper blades... 220 Battery... 221 Replacing bulbs... 223 Fuses... 230 10 Audio Audio functions... 240 Radio functions... 244 CD player/CD changer... 249 Audio menu...
  • Page 8 Contents 12 Index Index... 276...
  • Page 9 Contents...

  • Page 10: Introduction

    • Volvo reserves the right to make model changes at any time, or to change spec- ifications or design without notice and without incurring obligation.
  • Page 11 WARNING If your vehicle is involved in an accident, unseen damage may affect its driveability and safety. WARNING CALIFORNIA proposition 65 Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the state of Cali- fornia to cause cancer, and birth defects or other reproductive harm.

  • Page 12: Volvo And The Environment

    Introduction Volvo and the environment Volvo is committed to the well being of its cus- tomers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environ- mental impact.

  • Page 13: Important Warnings

    Additionally, a trained and qualified Volvo service technician knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult a trained and qualified Volvo serv- ice technician before installing any acces- sory in or on your vehicle.
  • Page 14 Occupant safety... 16 Seat belts... 18 Supplemental Restraint System... 21 Occupant Weight Sensor (OWS)... 26 Side impact protection airbags... 29 Volvo Inflatable Curtain (VIC)... 30 Whiplash Protection System... 32 Crash mode... 34 Child safety... 35 Child restraint systems... 37 Infant seats... 38 Convertible seats...
  • Page 15 S A F E T Y...

  • Page 16: 01 Safety

    Occupant safety Volvo's concern for safety Safety is Volvo's cornerstone. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy- absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
  • Page 17 If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform Trans- port Canada in addition to notifying Volvo Cars of Canada Corp. To contact Transport Canada, call (800) 333-0510, or (613) 993-9851 if you are calling from the Ottawa region.

  • Page 18: Seat Belts

    Children should be prop- erly restrained, using an infant, car, or booster seat determined by age, weight and height. Volvo also believes no child should sit in the front seat of a vehicle. Most states and provinces make it mandatory for occupants of a vehicle to use seat belts.
  • Page 19 WARNING • Never repair the belt yourself; have this work done by a trained and qualified Volvo service technician only. • Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection avail- able to you in the event of a collision.
  • Page 20 01 Safety Seat belts belts are not fastened. These signals will last for approximately 6 seconds. Rear seats The seat belt reminder in the rear seat has two additional functions: • It provides information about which seat belts are fastened in the rear seat. A mes- sage will appear in the information display when a belt is being used or if one of the rear doors has been opened.

  • Page 21: Supplemental Restraint System

    Supplemental Restraint System (SRS) SRS warning light As an enhancement to the three-point seat belts, your Volvo is equipped with a Supple- mental Restraint System (SRS). Volvo's SRS consists of seat belt pretensioners, front air- bags, side impact airbags, the occupant weight sensor, and inflatable curtains.
  • Page 22 01 Safety Supplemental Restraint System The front airbag system The front airbags supplement the three-point seat belts. For these airbags to provide the protection intended, seat belts must be worn at all times. The front airbag system includes gas genera- tors surrounded by the airbags, and decelera- tion sensors that activate the gas generators, causing the airbags to be inflated with nitrogen...
  • Page 23 This is a normal characteristic and does not indicate fire. • Volvo's front airbags use special sen- sors that are integrated with the front seat buckles. The point at which the air- bag deploys is determined by whether or not the seat belt is being used, as well as the severity of the collision.
  • Page 24 Customer Care Center P.O. Box 914 Rockleigh, New Jersey 07647-0914 1-800-458-1552 www.volvocars.us In Canada Volvo Cars of Canada Corp. National Customer Service 175 Gordon Baker Road North York, Ontario M2H 2N7 1-800-663-8255 www.volvocanada.com See also the Occupant Weight Sensor information on page 26.
  • Page 25 • Never try to open the airbag cover on the steering wheel or the passenger's side dashboard. This should only be done by a trained and qualified Volvo service technician. • Failure to follow these instructions can result in injury to the vehicle occupants.

  • Page 26: Occupant Weight Sensor (Ows)

    Disabling the passenger's side front airbag Occupant Weight Sensor (OWS) indicator light Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the rear seat of any vehi- cle with a passenger's side front airbag, and be properly restrained.
  • Page 27 Volvo recommends that children always be properly restrained in appropriate child restraints in the rear seats. Do not assume that the passenger's side front airbag is disabled unless the PASSENGER AIRBAG OFF indicator lamp is lit.
  • Page 28 Occupant Weight Sensor (OWS) example by altering or adapting the driver's or front passenger's seat(s) and/or airbag sys- tems, please contact Volvo at: In the USA Volvo Cars of North America, LLC Customer Care Center P.O. Box 914 Rockleigh, New Jersey 07647-0914 1-800-458-1552 In Canada Volvo Cars of Canada Corp.

  • Page 29: Side Impact Protection Airbags

    Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician. • In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright posi- tion with the seat belt properly fastened.

  • Page 30: Volvo Inflatable Curtain (Vic)

    01 Safety Volvo Inflatable Curtain (VIC) The Volvo Inflatable Curtain system This system consists of inflatable curtains located along the sides of the roof liners, stretching from the center of both front side windows to the rear edge of the rear side door windows.
  • Page 31 01 Safety Volvo Inflatable Curtain (VIC) WARNING In order for the VIC to provide its best pro- tection, both front seat occupants and both outboard rear seat occupants should sit in an upright position with the seat belt prop- erly fastened; adults using the seat belt and children using the proper child restraint sys- tem.

  • Page 32: Whiplash Protection System

    • If your car has been involved in a rear- end collision, the front seat backrests must be inspected by a trained and qualified Volvo service technician, even if the seats appear to be undamaged.
  • Page 33 Certain components in the WHIPS sys- tem may need to be replaced. • Do not attempt to service any compo- nent in the WHIPS system yourself. WARNING Any contact between the front seat backr- ests and the folded rear seat could impede the function of the WHIPS system.

  • Page 34: Crash Mode

    • Restoring the vehicle to normal operat- ing mode should only be done by a trained and qualified Volvo service tech- nician. • After CRASH MODE SEE MANUAL has been displayed, if you detect the...

  • Page 35: Child Safety

    Children should be seated safely Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car. Your car is also equipped with ISOFIX/LATCH attachments, which make it more convenient to install child seats.
  • Page 36 Volvo's recommendations Why does Volvo believe that no child should sit in the front seat of a car? It's quite simple really. A front airbag is a very powerful device designed, by law, to help protect an adult.

  • Page 37: Child Restraint Systems

    • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.

  • Page 38: Infant Seats

    01 Safety Infant seats Securing an infant seat with a seat belt Do not place the infant seat in the front passeng- er's seat NOTE Refer to pages 43–45 for information on securing a child restraint using ISOFIX lower anchors and/or top tether anchorages. WARNING •...
  • Page 39 Pull out the shoulder section of the seat belt 4. Pull the shoulder section of the seat belt out as far as possible to activate the belt's automatic locking function. NOTE The locking retractor will automatically release when the seat belt is unbuckled and allowed to retract fully.

  • Page 40: Convertible Seats

    WARNING A small child's head represents a consider- able part of its total weight and its neck is still very weak. Volvo recommends that chil- dren up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recom- mends that children should ride rearward facing, properly restrained, as long as pos- sible.
  • Page 41 Fasten the seat belt 2. Attach the seat belt to the convertible seat according to the manufacturer's instruc- tions. 3. Fasten the seat belt by inserting the latch plate into the buckle (lock) until a distinct click is audible. 4. Pull the shoulder section of the seat belt out as far as possible to activate the belt's automatic locking function.

  • Page 42: Booster Cushions

    01 Safety Booster cushions Securing a booster cushion Position the child correctly on the booster cushion and fasten the seat belt WARNING A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the Passenger airbag off symbol near the rear-view mirror is illuminated (on vehicles...

  • Page 43: Isofix Lower Anchors

    Using the ISOFIX lower child seat anchors ISOFIX lower child restraint anchors Lower anchors for ISOFIX-equipped child seats are located in the rear, outboard seats, hidden below the backrest cushions. Symbols on the seat back upholstery mark the anchor positions (see the illustration). To access the anchors: 1.
  • Page 44 01 Safety ISOFIX lower anchors WARNING Be sure to fasten the attachment correctly to the anchor (see the illustration). If the attachment is not correctly fastened, the child restraint may not be properly secured in the event of a collision.

  • Page 45: Top Tether Anchors

    Top tether anchors Top tether anchorage points Volvo vehicles are equipped with child restraint top tether anchorages in the rear seating posi- tions. They are located on the rear sides of the backrests. Using the top tether anchorages 1. Place the child restraint on the rear seat.

  • Page 46: Child Restraint Registration And Recalls

    01 Safety Child restraint registration and recalls Registering a child restraint Child restraints could be recalled for safety reasons. You must register your child restraint to be reached in a recall. To stay informed about child safety seat recalls, be sure to fill out and return the registration card that comes with new child restraints.
  • Page 47 01 Safety...
  • Page 48 Instrument overview... 50 Instrument panel... 53 Indicator and warning symbols... 55 Symbols – instrument panel... 57 Information display... 60 12-volt sockets... 62 Lighting panel... 63 Left-side steering wheel lever... 66 Trip computer... 68 Cruise control (option)... 70 Right-side steering wheel lever... 72 Steering wheel adjustment, Hazard warning flashers...
  • Page 49 I N S T R U M E N T S A N D C O N T R O L S...

  • Page 50: 02 Instruments And Controls

    02 Instruments and controls Instrument overview...
  • Page 51 Steering wheel adjustment Hood opener Controls in front doors (see page 52) Left steering wheel lever Lighting panel, fuel filler door opener Door open handle and locking but- Climate system air vent Side window air vent Cruise control Horn, airbag Main instrument panel Audio controls (option) Right steering wheel lever...
  • Page 52 02 Instruments and controls Instrument overview Control panel in driver's door Lockout switch for rear windows Power windows Door mirror button, driver's side Door mirror adjustment control Door mirror button, passenger's side...

  • Page 53: Instrument Panel

    Instrument panel Speedometer Turn signal, left Warning symbol – See the following pages for additional information. Information display – The display presents information and warning messages, the ambient temperature, clock, etc. When the ambient temperature is between 23 °F and 36 °F (–5 °C and +2 °C), a snowflake sym- bol is shown in the display.
  • Page 54 02 Instruments and controls Instrument panel odometer, trip odometers, optional rain sensor, and cruise control. Trip odometer reset button – The trip odometers are used to measure short dis- tances. Press the button briefly to switch between the odometer for the car's total mileage and the two trip odometers, T1 and T2.

  • Page 55: Indicator And Warning Symbols

    2. Read the message in the information dis- play. 3. Follow the instructions provided, or con- tact a trained and qualified Volvo service technician. Erase the message by pressing READ, see page 60. Information symbol The yellow information symbol...
  • Page 56 02 Instruments and controls Indicator and warning symbols This symbol may also light up in combination with other indicator or warning symbols. NOTE The car can still be driven after the informa- tion symbol has come on. The car can be driven for 1–2 weeks after service-related information has been displayed.

  • Page 57: Symbols - Instrument Panel

    When this happens, please have your car checked by a trained and qualified Volvo service technician as soon as possible. A CHECK ENGINE light may have many cau- ses.
  • Page 58 Have the system(s) inspected by a trained and qualified Volvo service technician as soon as possible. 4. Oil pressure warning light If the light comes on while driving,...
  • Page 59 Brake failure – Service urgent message is displayed in the infor- mation display: DO NOT DRIVE. Have the car towed to a trained and qualified Volvo service technician and have the brake sys- tem inspected. If the BRAKES and ABS warning lights come on at the same time, this could indicate a fault in the brake system.

  • Page 60: Information Display

    SAFELY prevent the risk of seri- ous damage. SERVICE Take your car to a trained and qualified URGENT Volvo service techni- cian for inspection immediately. Refer to your owner's SEE MANUAL manual. For additional information, please contact your Volvo retailer.
  • Page 61 Message Meaning TIME FOR This message is affec- ted by the number of REGULAR MAINTE- miles/km driven, by the number of months, or NANCE by the number of engine hours since the service reminder was reset at the most recent regu- larly scheduled service.

  • Page 62: 12-Volt Sockets

    The cover should be kept on when the aux- iliary socket is not in use. Auxiliary equipment The buttons to the left of the 12-volt socket can be used for Volvo-installed optional or auxiliary equipment. 12-volt socket (rear seat) NOTE The 12-volt socket in the rear seat cannot function as a cigarette lighter.

  • Page 63: Lighting Panel

    Pos. Lighting Daytime running lights off. High beam flash only. Parking lights Daytime running lights. High beams and high beam flash can be used in this position. On Canadian models, the daytime running lights will remain on with the light switch in this position. 02 Instruments and controls Parking lights The front and rear parking lights can be turned...
  • Page 64 02 Instruments and controls Lighting panel Headlight pattern with ABL deactivated (left) and activated (right) NOTE • This function can only be activated in twilight or dark conditions, and only when the vehicle is in motion. • If the indicator light flashes, this indi- cates a fault in the ABL system.
  • Page 65 02 Instruments and controls Lighting panel Unlocking the fuel filler door With the ignition switched off, press button (4) to unlock the fuel filler door. Please note that the fuel filler door will remain unlocked until the car begins to move forward. An audible click will be heard when the fuel filler door re-locks.

  • Page 66: Left-Side Steering Wheel Lever

    02 Instruments and controls Left-side steering wheel lever Lever positions Turn signals, lane change position Turn signals, position for normal turns High beam flash Toggle between high and low beams, Home Safe lighting Factory setting Turn signals When turning Move the lever as far up or down as pos- sible (to position 2) to start the turn signals.
  • Page 67 02 Instruments and controls Left-side steering wheel lever preferences by using the Personal Settings function, see page 83 for more information.

  • Page 68: Trip Computer

    02 Instruments and controls Trip computer READ (press to acknowledge/confirm/ erase a message) Thumb wheel (used to scroll among the trip computer menus) RESET The trip computer stores information gathered from several systems in your car and has four menus (five on Canadian models) that can be shown in the information display.
  • Page 69 ACTUAL SPEED (Canadian models only) This function provides the driver with an instan- taneous conversion of the car's current speed from km/h to mph. NOTE Trip computer readings may vary slightly depending on the circumference of the tires on the car, tire inflation, or driving style. 02 Instruments and controls Trip computer...

  • Page 70: Cruise Control (Option)

    02 Instruments and controls Cruise control (option) Engaging the cruise control function The cruise control buttons are located on the left side of the steering wheel hub. NOTE This does not set the vehicle's speed. 1. Press the CRUISE button. CRUISE appear in the function display in the center of the instrument panel.
  • Page 71 • During wheel spin or wheel lock-up. • If the vehicle's speed is increased by using the accelerator pedal for more than 1 minute. Returning to the set speed Press the button to resume the previously set speed. CRUISE will be displayed. Disengaging cruise control Cruise control can also be disengaged by: •...

  • Page 72: Right-Side Steering Wheel Lever

    02 Instruments and controls Right-side steering wheel lever Windshield wipers Windshield/headlight washers Rain sensor (option) – on/of, see page 72 Thumb wheel Windshield wipers off The windshield wipers are off when the lever is in position 0. Manual wiper function From position 0, move the lever upward.
  • Page 73 B – Rain sensor (option) The rain sensor regulates windshield wiper speed according to the amount of water on the windshield. The sensitivity of the rain sensor is adjusted by moving the thumb wheel (C in the illustration on the previous page) up (the wipers will sweep the windshield more frequently) or down (the wipers will sweep the windshield less frequently).

  • Page 74: Steering Wheel Adjustment, Hazard Warning Flashers

    02 Instruments and controls Steering wheel adjustment, Hazard warning flashers Steering wheel adjustment Both the height and the reach of the steering wheel can be adjusted to a comfortable posi- tion for the driver. 1. Pull down the lever on the steering column to release the steering wheel.

  • Page 75: Parking Brake

    Parking brake (hand brake) The parking brake lever is located between the front seats. NOTE The indicator light will illuminate even if the parking brake has only been partially applied. When applying the parking brake 1. Press firmly on the brake pedal. 2.

  • Page 76: Power Windows

    02 Instruments and controls Power windows Operation Control panel in driver's door Open/close front windows Open/close rear windows The power windows are controlled by buttons in the arm rests. • The ignition must be ON (ignition key in position I, II or the engine running) for the power windows to function.
  • Page 77 buttons on the rear door armrests or with the buttons on the driver's door armrest. If the light in the switch is ON: The rear door windows can only be raised or lowered with the buttons on the driver's door. Power window control –...

  • Page 78: Mirrors

    02 Instruments and controls Mirrors Rearview mirror Day/night control Normal position Night position, reduces glare from follow- ing traffic Night position To reduce glare from the headlights of follow- ing vehicles, use control (1) to switch between the normal and night-driving positions. Auto-dim function (option) An optional integrated sensor reacts to head- lights from following traffic and automatically...
  • Page 79 Magnetic zones 3. Press button (1) for at least 3 seconds to display the number of the current magnetic zone. 4. Press button (1) repeatedly until the num- ber for the required geographical area – ) is displayed. " " will be displayed again.
  • Page 80 02 Instruments and controls Mirrors Folding the mirrors in 1. Press down the L and R mirror control but- tons on the driver's door at the same time. 2. Release them after approximately one sec- ond. The mirrors automatically fold in to the fully retracted position.

  • Page 81: Power Moonroof (Option)

    Operating the moonroof To operate the moonroof, the ignition key must first be turned to the intermediate or drive posi- tion (position I, II or the engine running). The moonroof can be opened in two ways: Tilt position Sliding moonroof 02 Instruments and controls Moonroof control in the ceiling console Auto open...
  • Page 82 02 Instruments and controls Power moonroof (option) CAUTION • Remove ice and snow before opening the moonroof. • Do not operate the moonroof if it is fro- zen closed. • Never place heavy objects on the moonroof. WARNING • If the moonroof is obstructed during auto-close operation, it will automati- cally reverse direction and return to its starting position.

  • Page 83: Personal Settings

    Control panel Display Menu button Exit button Enter button Menu navigation controls 02 Instruments and controls Personal settings can be made for some of the car's functions, such as the central locking system, climate control, and the audio system. Please refer to page 241 for more information on the audio functions that can be adjusted.
  • Page 84 02 Instruments and controls Personal settings • Global (All doors) – unlocks all doors and the trunk with one press on the remote control. • Two Step (Two-stage unlocking) – This alternative unlocks the driver's door with one press on the remote control. A second press unlocks the passenger's door and the trunk Automatically folding the door mirrors...
  • Page 85 • Both front doors – both front doors are unlocked together. • One front door – either of the front doors can be unlocked separately Reset to factory settings Use this alternative to return to the default cli- mate system settings. Factory default.

  • Page 86: Homelink® Wireless Control System (Option)

    02 Instruments and controls HomeLink® Wireless Control System (option) Introduction The HomeLink Wireless Control System pro- vides a convenient way to replace up to three hand-held radio-frequency (RF) transmitters used to activate devices such as gate opera- tors, garage door openers, entry door locks, security systems, even home lighting.
  • Page 87 NOTE Some devices may require you to replace this Programming Step 2 with procedures noted in the “Gate Operator / Canadian Pro- gramming” section. If the HomeLink indica- tor light does not change to a rapidly blinking light after performing these steps, contact HomeLink at www.homelink.com.
  • Page 88 02 Instruments and controls HomeLink® Wireless Control System (option) Erasing HomeLink Buttons To erase programming from the three Home- Link buttons (individual buttons cannot be erased but can be “reprogrammed” as outlined below), follow the step noted: • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 10 seconds.
  • Page 89 02 Instruments and controls...
  • Page 90 General information... 92 Air vents... 94 Manual climate control... 95 Electronic Climate Control (ECC) – option... 98 Air distribution... 101...
  • Page 91 C L I M A T E...

  • Page 92: 03 Climate

    Special tools and equipment are required to maintain and carry out repairs on the climate system. Work of this type should only be done by a trained and qualified Volvo service tech- nician. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant –...
  • Page 93 For information about how to make these set- tings, see the Personal settings section on page 83. Models equipped with ECC (option) Sensors • The sunlight sensor is on the upper side of the dashboard • The passenger compartment temperature sensor is located behind the climate sys- tem control panel.

  • Page 94: Air Vents

    03 Climate Air vents Air vents in the dashboard Open Closed Horizontal air flow Vertical air flow Direct the outer air vents toward the side win- dows to defrost.

  • Page 95: Manual Climate Control

    Climate system control panel Blower speed Recirculation Defroster Airflow controls A/C – ON/OFF Heated driver's seat Heated front passenger's seat Rear window and door mirror defrosters Temperature selector Manual climate system functions 1. Blower The blower speed can be increased or decreased by turning the knob.
  • Page 96 03 Climate Manual climate control Timer The timer function minimizes the risk of mist- ing, or stale air when the recirculation function is selected, see page 83 for information on set- ting the recirculation timer. Recirculation is always disengaged when you select Defroster (3).
  • Page 97 03 Climate Manual climate control 9. Temperature selector The knob with the thermome- ter symbol is used to select cooling or heating for both the driver's and passenger's sides of the car.

  • Page 98: Electronic Climate Control (Ecc) - Option

    03 Climate Electronic Climate Control (ECC) – option Auto – On/Off Blower speed Recirculation Defroster Airflow controls A/C – ON/OFF Heated driver's seat Heated front passenger's seat Rear window and door mirror defrosters Temperature selector ECC functions 1. Auto – On/Off The AUTO function automat- ically regulates climate con- trol to maintain the desired...
  • Page 99 3. Recirculation This function can be used to shut out exhaust fumes, smoke, etc from the passen- ger compartment. The air in the passenger compartment is then recirculated, i.e. no air from outside the car is taken into the car when this function is activated. If the air in the car recirculates for too long, there is a risk of condensation forming on the insides of the windows, especially in winter.
  • Page 100 03 Climate Electronic Climate Control (ECC) – option 9. Rear window and door mirror defrosters Press to defrost the rear win- dow and door mirrors. The rear window and door mirrors are defrosted simulta- neously if the switch is pressed once. The defrost function is active if the LED in the switch is illu- minated.

  • Page 101: Air Distribution

    Air distribution Use: Defroster. Defrost/de-fog the wind- shield and front side win- Air is not recirculated in dows. this mode. Air conditioning is always engaged. There is also a certain amount of airflow to the panel air vents. Air to windshield and front Prevents fogging in cold side windows.
  • Page 102 Front seats... 104 Interior lighting... 107 Storage compartments... 109 Rear seat... 113 Trunk ... 115...
  • Page 103 I N T E R I O R...

  • Page 104: 04 Interior

    04 Interior Front seats Manual seat adjustment The driver's and passenger's seats can be adjusted in a number of ways to provide a comfortable driving and sitting position. Forward-rearward: Pull the lever up and slide the seat to the position of your choice. Use this control to raise or lower the front edge of the seat cushion.
  • Page 105 WARNING Cover sharp edges on the load to help pre- vent injury to occupants. Secure the load to help prevent shifting during sudden stops. Power seats (option) The power driver's seat can be adjusted: • If the ignition key is in position I or II. •...
  • Page 106 04 Interior Front seats Three different seating positions can be stored in the seat's memory. The memory buttons are located on the outboard side of the driver's seat (see the illustration above). The following example explains how memory button 1 can be programmed.

  • Page 107: Interior Lighting

    Interior lighting Front courtesy lights and reading lights Front driver's side reading light, on/off Courtesy lighting Front passenger's side reading light, on/off The front and rear reading lights can be acti- vated when the ignition key is position I or II, or when the engine is running.
  • Page 108 04 Interior Interior lighting The rear reading lights can be switched on or off by pressing the respective buttons, and function if the ignition key is in positions I, II, or if the engine is running. The courtesy lighting can be switched on or off within 30 minutes after the engine has been switched off, or after a door has been opened or closed.

  • Page 109: Storage Compartments

    04 Interior Storage compartments...
  • Page 110 04 Interior Storage compartments Storage pocket (on the rear side of the front seats) Compartment in door panel Storage pocket (on the front side of the front seat cushion) Glove compartment Storage compartment for e.g., CDs and cup holders Jacket hanger (intended for light garments only) Rear seat storage compartment and cup holders...
  • Page 111 Storage under the front, center armrest There are two storage compartments under the front, center armrest. • Press the smaller button on the front edge of the armrest and lift the armrest cover to access a shallow storage compartment. • Press the larger button and lift the entire armrest to access a deeper compartment.
  • Page 112 04 Interior Storage compartments Storage compartment behind the gear lever If the buttons for optional equipment are not installed, the recess behind the gear lever can be used as a storage compartment for coins, etc.

  • Page 113: Rear Seat

    Rear seat head restraints Adjust the head restraint vertically Each of the rear seat head restraints can be adjusted vertically to suit the height of the pas- senger. The upper edge of the head restraint should be on a level with the midpoint of the rear side of the passenger's head (see illustra- tion).
  • Page 114 04 Interior Rear seat To fold down one or both sections: 1. Grasp the rear edge of the seat cushion and pull it forward. 2. Pull the catch on the upper outboard edge of the backrest upward and forward to release the backrest lock.

  • Page 115: Trunk

    04 Interior Trunk Load anchoring eyelets The eyelets in the trunk can be used to fasten accessory load and lashing straps, load nets, and other load anchors.
  • Page 116 Remote control and key blade... 118 Valet locking ... 122 Keyless drive (option as available)... 123 Locking and unlocking... 127 Child safety locks... 129 Alarm (option)... 130...
  • Page 117 L O C K S A N D A L A R M...

  • Page 118: 05 Locks And Alarm

    Loss of a remote control If either of the remote controls is lost, the other must be taken with the car to a Volvo retailer. As an anti-theft measure, the code of the lost remote control must be erased from the sys- tem.
  • Page 119 NOTE The car can also be locked if a door is open (does not apply to vehicles with the optional keyless drive). Unlock – Press the Unlock button on the remote once to unlock the driver's door. After a short pause, press the Unlock but- ton a second time within 10 seconds to unlock the other doors and the trunk.
  • Page 120 5. Press the cover back into place. The old battery should be disposed of properly at a recycling center or by a trained and quali- fied Volvo service technician. Key blade Removing the key blade The key blade can be removed from the remote control.
  • Page 121 Reinserting the key blade in the remote control 1. Hold the remote control with the pointed end down. 2. Carefully slide the key blade into its groove. 3. Gently press the key blade in the groove until it clicks into place. Unlocking the doors with the detached key blade Insert the key blade as far as possible in the...

  • Page 122: Valet Locking

    05 Locks and alarm Valet locking Locking points Remote control: Normal locking/unlocking points By utilizing the remote control without the key blade, the valet locking feature enables you to block access to the trunk and glove compart- ment for e.g., valet parking or when the car is brought to the retailer for service.

  • Page 123: Keyless Drive (Option As Available)

    Keyless locking and unlocking Range of the keyless drive remote control–5 ft (1.5 meters) This system makes it possible to unlock and lock the vehicle without having to use the remote control. It is only necessary to have a keyless drive remote control in your posses- sion to operate the central locking system.
  • Page 124 05 Locks and alarm Keyless drive (option as available) Locking or unlocking the vehicle with the key blade Keyless drive keyhole cover The driver's door on vehicles equipped with keyless drive can be locked or unlocked with the remote control's detachable key blade if necessary, see page 120 for information on removing the key blade from the remote con- trol.
  • Page 125 CAUTION • Keyless drive remote controls should never be left in the vehicle. In the event of a break-in, a remote found in the vehicle could make it possible to start the engine. • Electromagnetic fields or metal obstructions can interfere with the key- less drive system.
  • Page 126 05 Locks and alarm Keyless drive (option as available) WARNING People with implanted pacemakers should not allow the pacemaker to come closer than 9 inches (22 cm) to any of the keyless drive system's antennas. This is to help pre- vent interference between the pacemaker and the keylesss drive system.

  • Page 127: Locking And Unlocking

    Locking/unlocking the vehicle from the inside The switches near the door opening handles on the driver's and front passenger's doors can be used to lock or unlock all doors and the trunk, open the side windows , and to set the alarm. •...
  • Page 128 05 Locks and alarm Locking and unlocking Locking the glove compartment The glove compartment can only be locked and unlocked using the detachable key blade on the remote control, see page 120 for infor- mation on removing the key blade from the remote control.

  • Page 129: Child Safety Locks

    Manual child safety locks, rear doors The controls are located on the rear inside edges of the doors, and are only accessible when the doors are open. 1. Remove the key blade from the remote control, see page 120. 2. Turn the control with the key blade. The door cannot be opened from the inside.

  • Page 130: Alarm (Option)

    Fault in the alarm system: If a fault has been detected in the alarm system, a mes- sage will be shown in the information dis- play. Contact your Volvo retailer to have the alarm system inspected and repaired if necessary.
  • Page 131 Turning off (stopping) the alarm If the alarm is sounding, it can be stopped by pressing the UNLOCK button on the remote control or by inserting the key in the ignition switch. The driver's door must first be unlocked with the key blade. NOTE On vehicles equipped with the optional key- less drive, the start control must be...
  • Page 132 05 Locks and alarm Alarm (option) If you do not wish to deactivate the sensors, do not choose an alternative and lock the vehicle or press EXIT and lock the vehicle. CAUTION • The accessory sensors are automati- cally reconnected to the alarm system the next time the vehicle is unlocked and then locked again.
  • Page 133 05 Locks and alarm...
  • Page 134 General information... 136 Fuel requirements... 140 Ignition switch... 143 Starting the vehicle... 144 Starting the vehicle with keyless drive (option as available)... 146 Manual transmission, 5-speed (certain markets only)... 147 Manual transmission, 6-speed (certain markets only)... 148 Automatic transmission (option)... 149 Shiftlock override...
  • Page 135 S T A R T I N G A N D D R I V I N G...

  • Page 136: 06 Starting And Driving

    06 Starting and driving General information Economical driving conserves natural resources Better driving economy may be obtained by thinking ahead, avoiding rapid starts and stops and adjusting the speed of your vehicle to immediate traffic conditions. Observe the following rules: •...
  • Page 137 Synthetic oil is not used when the oil is changed at the normal maintenance intervals except at owner request and at additional charge. Please consult your Volvo retailer. CAUTION •...
  • Page 138 Avoid using de-icing sprays as they can cause damage to the locks. To prevent injury from contact with hot surfaces, do not inspect your vehicle's transmission fluid yourself. Have your vehicle's transmission fluid level inspected by a qualified Volvo service technician. Conserving electrical current...
  • Page 139 • Reflective warning triangles are legally required in some states/provinces. • Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel. • Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.

  • Page 140: Fuel Requirements

    Fuel requirements Octane rating Minimum octane Typical pump octane label Volvo recommends premium fuel for best per- formance, but using 87 octane or above will not affect engine reliability. Volvo engines are designed to achieve rated horsepower, torque, and fuel economy per- formance using premium 91 octane fuel.
  • Page 141 To meet sea- sonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the 06 Starting and driving Fuel requirements use of the following "oxygenated" fuels; how- ever, the octane ratings listed on this page must still be met.
  • Page 142 If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle’s performance will not be affected. Use only Volvo original or approved fuel filler caps.

  • Page 143: Ignition Switch

    Ignition switch positions 0 – Locked position Remove the key to lock the steering wheel . Never turn the key to position 0 while driving or when the vehicle is being towed. NOTE A ticking sound may be audible if the key is turned to a position between 0 and I.

  • Page 144: Starting The Vehicle

    06 Starting and driving Starting the vehicle To start the engine WARNING Before starting, check that the seat, steering wheel and mirrors are adjusted properly. Make sure the brake pedal can be depressed completely. Adjust the seat if necessary. 1. Fasten the seat belt. 2.
  • Page 145 WARNING Volvo's floor mats are specially manufac- tured for your car. They must be firmly secured in the clips on the floor so that they cannot slide and become trapped under the pedals on the driver's side. • Always place the gear selector in Park...

  • Page 146: Starting The Vehicle With Keyless Drive (Option As Available)

    06 Starting and driving Starting the vehicle with keyless drive (option as available) Starting a vehicle with keyless drive Starting a vehicle with keyless drive Keyless drive makes it possible to unlock, start and lock the vehicle without using a remote control.

  • Page 147: Manual Transmission, 5-Speed (Certain Markets Only)

    5-speed manual transmission (option on certain models) Depress the clutch pedal completely when changing gears Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. Clutch interlock: The clutch must be fully depressed before you can start your car.

  • Page 148: Manual Transmission, 6-Speed (Certain Markets Only)

    06 Starting and driving Manual transmission, 6-speed (certain markets only) 6-speed manual transmission (option on certain models) Depress the clutch pedal completely when changing gears Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th and 6th gears) should be used as often as possible to help improve fuel econ- omy.

  • Page 149: Automatic Transmission (Option)

    Shiftgate positions Depress the button on the front of the gear selector knob to move the selector between the R, N, D, and P positions. The gear selector can be moved freely between the Geartronic (manual shifting) and Drive (D) positions while driving.
  • Page 150 06 Starting and driving Automatic transmission (option) based on the level of acceleration and speed. The car must be at a standstill when shifting to position D from position R. Manual shifting – Geartronic The manual shifting mode (Geartronic) can be selected at any time to manually select forward gears, including while the car is moving.

  • Page 151: Shiftlock Override

    Overriding the shiftlock system Shiftlock prevents the gear selector from being moved out of Park unless the ignition key is in position II and the brake pedal is depressed. In certain cases it may be necessary to move the gear selector from the Park position man- ually.

  • Page 152: All Wheel Drive (Option)

    06 Starting and driving All Wheel Drive (option) All Wheel Drive (AWD) – general information Your Volvo can be equipped with permanent All Wheel Drive (option), which means that power is distributed automatically between the front and rear wheels. Under normal driving conditions, most of the engine's power is directed to the front wheels.

  • Page 153: Brake System

    If the fluid level is below the MIN mark in the reservoir or if a brake system message is shown in the information display, DO NOT DRIVE. Have the vehicle towed to a Volvo retailer and have the brake system inspec- ted.
  • Page 154 If the brake fluid level is normal in these circumstances, drive carefully to a trained and qualified Volvo service technician to have the brake system checked.

  • Page 155: Stability System

    Stability Traction Control (STC)/ Dynamic Stability Traction Control (DSTC) The stability system consists of a number of functions designed help reduce wheel spin, counteract skidding, and to generally help improve directional stability. A pulsating sound will be audible when the system is actively operating and is normal.
  • Page 156 If this light stays on after the engine has started or comes on while driving, there may be a fault in the stability system. Con- sult a trained and qualified Volvo service technician. • If Spin control has been intentionally...

  • Page 157: Towing

    Towing a vehicle with all four wheels on the ground WARNING Volvo does not recommend towing a disa- bled vehicle behind another vehicle. Signif- icant difficulty in steering and braking, combined with unfavorable weather, traffic, and road conditions may make it impossible to maintain vehicle control.
  • Page 158 159 for instructions on jump star- ting the vehicle. Towing vehicles with front wheel drive Volvo recommends the use of flat bed equip- ment for towing vehicles with front wheel drive. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the vehicle.

  • Page 159: Jump Starting

    Follow these instructions to jump start your vehicle's dead battery or to jump start another vehicle's dead battery using your vehicle. If the 12-volt auxiliary battery to be used is in another vehicle, check that the vehicles are not touch- ing to prevent premature completion of a cir- cuit.

  • Page 160: Towing A Trailer

    06 Starting and driving Towing a trailer General information • Volvo recommends the use of Volvo trailer hitches that are specially designed for the vehicle. CAUTION Models equipped with the B5244S7 engine (engine code 39 , which is the 6th and...
  • Page 161 (using too high a gear). • The drawbar assembly/trailer hitch may be rated for trailers heavier than the vehicle is designed to tow. Please adhere to Volvo's recommended trailer weights. • Avoid driving with a trailer on inclines exceeding 15%.

  • Page 162: Detachable Trailer Hitch

    06 Starting and driving Detachable trailer hitch Installing the ball holder Ball holder Locking bolt Cotter pin Hitch assembly Safety wire attachment 1. If necessary, remove the cotter pin from the locking bolt and slide the locking bolt out of the hitch assembly. 2.

  • Page 163: Transporting Loads

    • To avoid damaging your car and to achieve maximum safety when driving, we recom- mend using the load carriers that Volvo has developed especially for your car. • Volvo-approved removable roof racks are designed to carry the maximum allowable roof load for this vehicle: 165 lbs (75 kg).

  • Page 164: Blind Spot Information System (Blis)-Option

    "blind area". CAUTION The BLIS system should only be repaired by a trained and qualified Volvo service tech- nician. WARNING • BLIS is an information system, NOT a warning or safety system.
  • Page 165 When does BLIS function The system functions when your vehicle is moving at speeds above 6 mph (10 km/h). When you pass another vehicle: The system reacts when you pass another vehicle at a speed of up to 6 mph (10 km/h) faster than that vehicle.
  • Page 166 06 Starting and driving Blind Spot Information System (BLIS)–option Limitations In certain situations, the BLIS indicator light(s) may illuminate even when there are no other vehicles in the area monitored by the system. NOTE If the BLIS indicator lights illuminate occa- sionally even when there are no other vehi- cles in the blind area, this does not indicate a fault in the system.
  • Page 167 60, to erase the message. BLIS system messages Text in the System status display BLIS service BLIS not functioning properly. Contact an required authorized Volvo serv- ice technician. BLIS camera BLIS camera obscured. Clean the lenses. blocked BLIS ON BLIS system on BLIS OFF...

  • Page 168: Park Assist (Option/Accessory)

    NOTE Rear park assist is deactivated automati- cally when towing a trailer if Volvo genuine trailer wiring is used. Front park assist The distance monitored in front of the vehicle is approximately 2.5 ft (0.8 m).
  • Page 169 Consult a Volvo retailer or authorized Volvo service technician. CAUTION In certain circumstances, the park assist system may give unexpected warning sig-...
  • Page 170 06 Starting and driving Park assist (Option/accessory) Cleaning the sensors Park assist sensors The sensors must be cleaned regularly to ensure that they work properly. Clean them with water and a suitable car washing deter- gent. Ice and snow covering the sensors may cause incorrect warning signals.
  • Page 171 06 Starting and driving...
  • Page 172 General information... 174 Tire inflation... 176 Inflation pressure—U.S. models ... 178 Inflation pressure—Canadian models ... 179 Tire designations... 180 Glossary of tire terminology... 182 Vehicle loading... 183 Uniform tire quality gradings... 185 Snow chains, snow tires, studded tires... 186 Temporary spare... 187 Wheel nuts...
  • Page 173 W H E E L S A N D T I R E S...

  • Page 174: 07 Wheels And Tires

    WARNING • The wheel and tire sizes for your Volvo are specified to meet stringent stability and handling requirements. Unap- proved wheel/tire size combinations can negatively affect your vehicle's sta- bility and handling.
  • Page 175 Tread wear indicator The tires have wear indicator strips running across or parallel to the tread. The letters TWI are printed on the side of the tire. When approximately 1/16" (1.6 mm) is left on the tread, these strips become visible and indicate that the tire should be replaced.

  • Page 176: Tire Inflation

    07 Wheels and tires Tire inflation Inflation labels Tire inflation placard on U.S. models Check tire inflation pressure regularly. Tables listing the recommended inflation pres- sure for your vehicle can be found on page 178. A tire inflation pressure placard is also located on the driver's side B-pillar (the struc- tural member at the side of the vehicle, at the rear of the driver's door opening).
  • Page 177 Checking tire pressure Cold tires Inflation pressure should be checked when the tires are cold. The tires are considered to be cold when they have the same temperature as the sur- rounding (ambient) air. This temperature is normally reached after the car has been parked for at least 3 hours.

  • Page 178: Inflation Pressure-U.s. Models

    07 Wheels and tires Inflation pressure—U.S. models Tire inflation pressure table The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire infla- Tire size 205/55R16 91V M+S 205/50R17 93V Extra Load M+S 215/45R18 Extra load...

  • Page 179: Inflation Pressure-Canadian Models

    Tire inflation pressure table The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire infla- Tire size Cold tire pressures Up to five persons psi (kPa) Front 205/55R16 91V M+S 36 (250) 205/50R17 93V Extra Load...

  • Page 180: Tire Designations

    07 Wheels and tires Tire designations Tire designations Federal law mandates that tire manufacturers place standardized information on the sidewall of all tires (see the illustration). The following information is listed on the tire sidewall: The tire designation (the following figures are examples of a tire designation): 215: The width of the tire (in millimeters) from sidewall edge to sidewall edge.
  • Page 181 Maximum Load: Indicates the maximum load in pounds and kilograms that can be carried by the tire. Refer to the vehicle's tire information placard or the safety certifica- tion label, located on the B-Pillar or the driver's door or on the inside of the fuel filler door on Canadian models, for the correct tire pressure for your vehicle.

  • Page 182: Glossary Of Tire Terminology

    • Recommended tire inflation pressure: inflation pressure, established by Volvo, which is based on the type of tires that are mounted on a vehicle at the factory. This inflation pressure is affected by the number...

  • Page 183: Vehicle Loading

    Loading the vehicle Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle's weight ratings, with or without a trailer, from the vehicle's Federal/Canadian Motor Vehicle Safety Standards (FMVSS/ CMVSS) label, and the vehicle's tire informa- tion placard: Curb weight The weight of the vehicle including a full tank...
  • Page 184 07 Wheels and tires Vehicle loading WARNING • Exceeding the permissible axle weight, gross vehicle weight, or any other weight rating limits can cause tire over- heating resulting in permanent defor- mation or catastrophic failure. • Do not use replacement tires with lower load carrying capacities than the tires that were original equipment on the vehicle because this will lower the vehi-...

  • Page 185: Uniform Tire Quality Gradings

    Uniform tire quality gradings ALL PASSENGER VEHICLE TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS IN ADDITION TO THESE GRADES Quality grades can be found, where appli- cable, on the tire sidewall between the tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A...

  • Page 186: Snow Chains, Snow Tires, Studded Tires

    07 Wheels and tires Snow chains, snow tires, studded tires Snow chains Snow chains can be used on your Volvo with the following restrictions: • Snow chains should be installed on front wheels only. Use only Volvo approved snow chains.

  • Page 187: Temporary Spare

    In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING Current legislation prohibits the use of the "Temporary Spare"...

  • Page 188: Wheel Nuts

    07 Wheels and tires Wheel nuts Wheel nuts Low nut. High nut. There are two different types of wheel nut, depending on whether the wheels are steel or aluminum. Steel rims – low nut Steel rims are normally secured using the low type of nut, although steel rims may also use the high type.

  • Page 189: Tire Rotation

    The tires with the most tread should always be at the rear (to reduce the risk of skid- ding). • Contact a Volvo workshop if you are unsure about the tread depth. Tire rotation Your vehicle has no recommended tire rota- tion.

  • Page 190: Changing A Wheel

    07 Wheels and tires Changing a wheel Changing a wheel The spare tire, jack, and crank are located under the carpet on the floor of the trunk. To change a tire: 1. Apply the parking brake. 2. Put the gear selector in Park (P) or reverse on models with a manual transmission.
  • Page 191 WARNING • The jack must correctly engage the jack attachment. • Be sure the jack is on a firm, level, non- slippery surface. • Never allow any part of your body to be extended under a car supported by a jack.

  • Page 192: Tire Sealing System

    120 miles (200 km). • Have the tire inspected by a trained and qualified Volvo service technician as soon as possible to determine if it can be permanently repaired or must be replaced.
  • Page 193 WARNING Please keep the following points in mind when using the tire sealing system: • The sealing compound bottle (no. 8 in the illustration) contains 1.2-Ethanol and natural rubber-latex. These sub- stances are harmful if swallowed. • The contents of this bottle may cause allergic skin reactions or otherwise be potentially harmful to the skin, the cen- tral nervous system, and the eyes.
  • Page 194 Once in place, the bot- tle cannot be unscrewed. This must be done by a trained and qualified Volvo service technician. 7. Remove the valve cap from the tire’s infla- tion valve and screw the tire sealing sys- tem’s hose connector onto the valve as...
  • Page 195 • The empty bottle of sealing compound cannot be removed from the bottle holder. Consult a trained and qualified Volvo service technician to have the bottle removed and properly disposed WARNING If heavy vibrations, unsteady steering behavior, or noises should occur while driv- ing, reduce speed and park the vehicle in a safe place.
  • Page 196 • If the sealing compound bottle’s expi- ration date has passed, please take it to a Volvo retailer or a recycling station that can properly dispose of harmful substances. Inflating tires The tire sealing system can be used to inflate the tires.

  • Page 197: Tire Pressure Monitoring System (Tpms)

    Introduction The tire pressure monitoring system uses sen- sors mounted in the tire valves to check infla- tion pressure levels. When the vehicle is moving at a speed of approximately 20 mph (30 km/h) or faster, these sensors transmit inflation pressure data to a receiver located in the vehicle.
  • Page 198 20 mph (30 km/h) or faster to erase the message. • Volvo recommends that TPMS sensors be fitted on all wheels used on the vehicle. Volvo does not recommend moving sen- sors back and forth between sets of wheels.
  • Page 199 07 Wheels and tires...
  • Page 200 Washing and cleaning the car... 202 Paint touch up... 206...
  • Page 201 C A R C A R E...

  • Page 202: 08 Car Care

    When washing the car, remember to remove dirt from the drain holes in the doors and sills. Exterior components Volvo recommends the use of special cleaning products, available at your Volvo retailer, for cleaning colored plastic, rubber, or ornamental components such as chromed strips on the exterior of your vehicle.
  • Page 203 CAUTION • During high pressure washing, the spray mouthpiece must never be closer to the vehicle than 13" (30 cm). Do not spray into the locks. • Dirt, snow, etc., on the headlights can reduce lighting capacity considerably. Clean the headlights regularly, for example when refueling.
  • Page 204 08 Car care Washing and cleaning the car CAUTION Volvo does not recommend the use of long- life or durable paint protection coatings, some of which may claim to prevent pitting, fading, oxidation, etc. These coatings have not been tested by Volvo for compatibility with your vehicle's clear coat.
  • Page 205 Spots on textile mats can be removed with a mild deter- gent. For best protection in winter, Volvo rec- ommends the use of Volvo rubber floor mats. Consult your Volvo retailer.

  • Page 206: Paint Touch Up

    - when washing the vehicle for instance. Touch-up if necessary. Paint repairs require special equipment and skill. Contact a trained and authorized Volvo service technician for any extensive damage. Minor scratches can be repaired by using Volvo touch-up paint.
  • Page 207 08 Car care...
  • Page 208 Volvo maintenance... 210 Maintaining your car... 212 Hood... 214 Engine compartment... 215 Engine oil... 216 Fluids... 218 Wiper blades... 220 Battery... 221 Replacing bulbs... 223 Fuses... 230...
  • Page 209 M A I N T E N A N C E A N D S E R V I C I N G...

  • Page 210: 09 Maintenance And Servicing

    The maintenance services contain several checks that require special tools and training, and therefore must be performed by a qualified technician. To keep your Volvo in top condition, specify time-tested and proven Genuine Volvo Parts and Accessories. The Federal Clean Air Act – U.S...
  • Page 211 • law enforcement or government agencies • others who may assert a legal right to know, or who obtain your consent to know such information. 09 Maintenance and servicing Volvo maintenance...

  • Page 212: Maintaining Your Car

    Visually inspect battery terminals for cor- rosion. Corrosion may indicate a loose ter- minal connector, or a battery near the end of its useful service life. Consult a trained and qualified Volvo service technician for additional information. As needed: •...
  • Page 213 OBD II system to "ready" for inspection. A half-hour trip of mixed stop-and-go/high- way driving is typically needed to allow OBD II to reach readiness. Your Volvo retailer can provide you with more infor- mation on planning a trip. •...

  • Page 214: Hood

    09 Maintenance and servicing Hood Opening the hood To open the hood: 1. Pull the lever located under the left side of the dash to release the hood lock. 2. Lift the hood slightly. 3. Press up the release control located under the front edge of the hood (at the center) up to the right, and lift the hood.

  • Page 215: Engine Compartment

    Cooling system expansion tank Power steering fluid reservoir (concealed behind the headlight) Dipstick – engine oil Radiator Cooling fan Washer fluid reservoir Engine oil filler cap Brake/clutch fluid reservoir Battery 09 Maintenance and servicing Relay/fuse box Air cleaner WARNING The cooling fan may start or continue to operate (for up to 6 minutes) after the engine has been switched off.

  • Page 216: Engine Oil

    Volvo recommends Castrol. NOTE • Volvo does not recommend the use of oil additives. • Synthetic oil is not used when the oil is changed at the normal maintenance intervals except at owner request and at additional charge.
  • Page 217 Do not allow oil to spill onto or come into contact with hot exhaust pipe surfaces NOTE Volvo uses different systems to indicate a low oil level or pressure. Some models have an oil pressure sensor, in which case a warning symbol (see page 57) is used to indicate low oil pressure.

  • Page 218: Fluids

    Coolant Coolant reservoir Normally, the coolant does not need to be changed. If the system must be drained, con- sult a trained and qualified Volvo service tech- nician. CAUTION • If necessary, top up the cooling system...
  • Page 219 (mountain driving, etc), it may be necessary to replace the fluid more often. Consult your Volvo retailer. Always entrust brake fluid changing to a trained and qualified Volvo serv- ice technician. Power steering fluid The fluid level is checked at each service inter- val.

  • Page 220: Wiper Blades

    09 Maintenance and servicing Wiper blades Replacing windshield wiper blades 1. Fold out the wiper arm. 2. Press the button on the wiper blade attach- ment and pull straight out (1), parallel with the wiper arm. 3. Press a new wiper blade (2) until it clicks into place.

  • Page 221: Battery

    Battery maintenance Driving habits and conditions, climate, the number of starts, etc., all affect the service life and function of the battery. In order for your battery to perform satisfactorily, keep the fol- lowing in mind: Check the fluid level in each cell in the battery every 24 months or every 15,000 miles (24,000 km), whichever is sooner.
  • Page 222 6. Reinstall the cover over the battery. NOTE Used batteries should be properly disposed of at a recycling station or similar facility, or taken to your Volvo retailer. WARNING • Never expose the battery to open flame or electric spark.

  • Page 223: Replacing Bulbs

    The optional Bi-Xenon headlight bulbs contain trace amounts of mercury. These bulbs should always be disposed of by a trained and qualified Volvo service techni- cian. Certain bulbs should only be replaced by a trained and qualified Volvo service techni- cian: •...
  • Page 224 WARNING Bi-Xenon headlights (option) – due to the high voltage used by these headlights, these bulbs should only be replaced by a trained and qualified Volvo service techni- cian. Low beam bulb Cover with retaining clamps 1. Open the hood and remove the headlight housing (see page 223 for instructions).
  • Page 225 WARNING Bi-Xenon headlights (option) – due to the high voltage used by these headlights, the Bi-Xenon bulbs should only be replaced by a trained and qualified Volvo service tech- nician. 4. Driver's side headlight: Turn the bulb holder counterclockwise. Passenger's side headlight: Turn the bulb holder clockwise.
  • Page 226 09 Maintenance and servicing Replacing bulbs Turn signal 1. Open the hood. 2. Remove the headlight housing, see page 223. 3. Turn the bulb holder counterclockwise and remove it. 4. Remove the bulb from the holder by press- ing it in and twisting it counterclockwise. 5.
  • Page 227 If the message indicating a burned out bulb remains in the information display after the bulb has been replaced, consult a trained and qualified Volvo service technician. High-level brake light These bulbs should only be replaced by a trained and qualified Volvo service technician.
  • Page 228 09 Maintenance and servicing Replacing bulbs License plate lighting 1. Switch off all lights and turn the key to position 0. 2. Remove the screws with a screw driver. 3. Detach the entire bulb housing and care- fully pull it out. Turn the connector coun- terclockwise and pull out the bulb.
  • Page 229 Vanity mirror lighting 1. Insert a screwdriver under the center of the lower edge of the mirror, turn it, and care- fully pry up the lugs at the edge. 2. Move the screwdriver under the edge on the left and right-hand sides (near the black rubber sections) and pry carefully to release the lower edge of the mirror.

  • Page 230: Fuses

    (written on the fuse). If fuses burn out repeatedly, have the electrical system inspected by a trained and qualified Volvo service technician. WARNING Never use metal objects or fuses with higher amperage than those stated on the follow- ing pages.
  • Page 231 36 fuses. • Fuses 1–18 are relays/circuit breakers and should only be removed or replaced by an authorized Volvo service technician. • Fuses 19–36 may be changed at any time when necessary. Several extra fuses and a fuse removal tool to...
  • Page 232 09 Maintenance and servicing Fuses Fuses in the engine compartment Coolant fan (radiator) Power steering Feed to passenger com- partment fuse box Feed to passenger com- partment fuse box Element, climate unit Not in use ABS pump ABS valves Engine functions Climate system blower Headlight washers Feed to heated rear window...
  • Page 233 Not in use Not in use Ignition switch A/C compressor Not in use Front fog lights (option) Not in use Not in use Fuel injectors Heated oxygen sensor, vac- uum pump Ignition coils, climate unit pressure sensor Engine sensor valves, A/C relay, relay coil, PTC ele- ment oil trap, canister, mass air meter...
  • Page 234 09 Maintenance and servicing Fuses Fuse box in the passenger compartment The fuse box in the passenger compartment is located under the glove compartment. To access the fuses: 1. Remove the upholstery covering the fuse box by first pressing in the center pins in the mounting clips approximately 0.5 in (1 cm) with a small screwdriver and then pulling the pins out.
  • Page 235 Not in use Not in use Not in use Not in use Not in use Not in use Audio system, Volvo Navi- gation system (option) 09 Maintenance and servicing Supplemental Restrain Sys- tem (SRS), engine control module 12-volt socket in rear seat Lighting –...
  • Page 236 (option) Heated passenger's seat (option) Moonroof (option) Power window and door lock – rear passenger's side door Audio system, Volvo Navi- gation system (option) Audio system Audio system control mod- ule (ICM), climate system Not in use Cruise control Climate system, rain sensor...
  • Page 237 09 Maintenance and servicing...
  • Page 238 Audio functions... 240 Radio functions... 244 CD player/CD changer... 249 Audio menu... 253 Bluetooth hands-free connection... 254...
  • Page 239 A U D I O...

  • Page 240: 10 Audio

    10 Audio Audio functions Audio system controls VOLUME dial AM/FM – select a radio band MODE – select a sound source TUNING dial SOUND button Auxiliary connector Selecting a sound source • Press AM/FM (2) repeatedly to toggle between FM1, FM2, and AM. •...
  • Page 241 7. If there is distortion, lower your music play- er's headphone volume until the distortion goes away. 8. Finally, exit the menu and adjust the audio volume to a comfortable level. Volume Use the volume dial (1) or the buttons in the steering wheel keypad to adjust the volume level.
  • Page 242 10 Audio Audio functions Tracks can be selected in two ways: • Turn the Tuning knob (no. 4 in the illustra- tion on page 244) clockwise or counter- clockwise • Use the right or left arrow keys on the nav- igation control (no.
  • Page 243 Surround sound Surround sound settings are used to balance sound levels throughout the vehicle. Surround settings for the var- ious sound sources are made sepa- rately. NOTE • Dolby Surround Pro Logic II is only available on the Premium Sound sys- tem.

  • Page 244: Radio Functions

    10 Audio Radio functions Radio function controls 1. AM/FM1/FM2 selection 2. Station preset buttons 3. TUNING dial for selecting radio stations 4. SCAN 5. MENU NAVIGATION CONTROL–press the up or down arrow keys to scroll in a menu, or the keys on the left/right sides of the control to search for or change radio stations/CD tracks 6.
  • Page 245 To return to the Auto-store mode, press the AUTO button briefly and select a stored station by pressing one of the preset buttons (2). Saving auto-stored stations in the preset memory An auto-stored station can be saved in the memory for manually preset stations. 1.
  • Page 246 10 Audio Radio functions (see also "Selecting a channel" in the right column). 2. Call Sirius at 1-888-539-SIRIUS (7474). 3. When asked for the Sirius ID number press AUTO to display this number. It is also possible to retrieve the Sirius ID from the MENU.
  • Page 247 preset satellite channel stored on that but- ton, regardless of the currently selected channel category. Song Seek and Song Memory The Song Seek and Song Memory functions provide both audio and visual notification when Sirius is broadcasting your favorite songs. Song Seek enables you to store the name of the song for future advance notification when that song is being played.
  • Page 248 ENTER. 2. Press and hold the ENTER button for 2 seconds. 3. The current code will be displayed. Your Volvo retailer can also provide you with assistance. SIRUS ID This function displays the 12-digit Sirius acti- vation ID.

  • Page 249: Cd Player/Cd Changer

    CD function controls MENU NAVIGATION CONTROL–press the up or down arrow keys to scroll in a menu, or the keys on the left/right sides of the control to change CD tracks/fast for- ward/back Buttons for selecting a disc in the optional CD changer CD eject button CD slot...
  • Page 250 10 Audio CD player/CD changer NOTE • The EJECT ALL function can only be used while the vehicle is at a standstill and will be cancelled if the vehicle begins to move. • For reasons of traffic safety, the ejected CD must be removed within 12 seconds or it will be automatically drawn back into the slot and the CD player will enter...
  • Page 251 3. Select Disc Folder and press ENTER. Activating/deactivating the random function-CD changer If a normal CD is being played: 1. Press MENU followed by ENTER. 2. Select Random and press ENTER. 3. Select Single disc All discs and press ENTER. If a CD with audio files is being played: 1.
  • Page 252 • Use discs of the correct size only (3.5" discs should never be used). • Volvo does not recommend the use of plastic outer rings on the disc. • Condensation may occur on discs/optical components of the changer in cold winter weather.

  • Page 253: Audio Menu

    10 Audio Audio menu FM1/FM2 menu 1. RADIOTEXT ON/OFF 2. ADVANCED RADIO SETTINGS 3. AUDIO SETTINGS AM menu 1. AUDIO SETTINGS CD menu 1. RANDOM 2. AUDIO SETTINGS CD changer menu 1. RANDOM 2. DISC TEXT ON/OFF 3. AUDIO SETTINGS AUX menu 1.

  • Page 254: Bluetooth Hands-Free Connection

    NOTE Not all cell phones are fully compatible with the hands-free system. A list of compatible phones is available at your Volvo retailer or at www.volvocars.com WARNING Never use the hands-free feature or any other device in your vehicle in a way that distracts you from the task of driving safely.
  • Page 255 > The audio system will search for cell phones that are in range. This search takes approximately 30 seconds. Any phones detected will be displayed with their Bluetooth names. The hands-free system’s Bluetooth name will appear in the cell phone’s display as My Car 4.
  • Page 256 10 Audio Bluetooth hands-free connection Call settings While a call is in progress, press MENU or ENTER on the center console to access the following functions: • Microphone off –mute the audio system’s microphone. • Transfer call to mobile –transfer the call from hands-free to the cell phone.
  • Page 257 audio system searches for the most recently connected phone, this phone’s name appears in the display. To manually connect a different cell phone, press EXIT. Manual connection To connect a phone other than the one that was most recently connected or to switch between cell phones that are already regis- tered in the hands-free system: 1.
  • Page 258 10 Audio Bluetooth hands-free connection Entering text Text is entered by using the number buttons in the center console. Press a button once to enter the first letter on the button, twice to enter the second letter, etc. Continue to press the button to display other characters.
  • Page 259 10 Audio...
  • Page 260 Label information... 262 Dimensions and weights... 264 Fuel, oils, and fluids... 267 Engine oil... 269 Engine specifications... 270 Electrical system... 272 Three-way catalytic converter... 274 Volvo programs... 275...
  • Page 261 S P E C I F I C A T I O N S...

  • Page 262: 11 Specifications

    11 Specifications Label information...
  • Page 263 Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certifi- cation label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.

  • Page 264: Dimensions And Weights

    11 Specifications Dimensions and weights Dimensions Position Dimension Wheelbase Length Load length, floor, seatback down Load length, floor Height Track, front Track, rear in. (mm) 103.9 in. (264 cm) 175.9 in. (447 cm) 68.7 in. (175 cm) 38.4 in. (98 cm) 57.2 in.
  • Page 265 Position Dimension Width Width encl. door mirrors Weights Category Gross vehicle weight FWD Turbo: 4320 lbs Capacity weight FWD: 800 lbs AWD: 800 lbs Permissible axle weight, front FWD: 2380 lbs FWD Turbo: 2380 lbs AWD Turbo: 2420 lbs Permissible axle weight, rear FWD: 2130 lbs FWD Turbo: 2130 lbs AWD Turbo: 2220 lbs...

  • Page 266: Dimensions And Weights

    11 Specifications Dimensions and weights Category Max. trailer weight (w/o brakes) Max. trailer weight (with brakes) Max. tongue weight FWD = Front Wheel Drive AWD = All Wheel Drive Models equipped with the B5244S7 engine (engine code 39, which is the 6th and 7th digits from the left in your vehicle's VIN number, see chapter Label information, for the location of the VIN plate), may not be used to tow trailers or vehicles of any kind.

  • Page 267: Fuel, Oils, And Fluids

    AKI 91 or above. See page 269 for information on engine oil specifications. Non-turbo engine: JWS 3309 BOT 130 Volvo original coolant/antifreeze (50/50 mixture of water and anti-freeze) DOT 4+ boiling point >536 °F (280 °C), P/N 9437433 WSS M2C204-A or equivalent...
  • Page 268 11 Specifications Fuel, oils, and fluids Category Washer fluid reservoir Air conditioning system NOTE The transmission oil does not normally need to be changed during the service life of the vehicle. However, it may be necessary to replace the oil if the vehicle is often driven in areas of sustained temperature extremes (hot or cold), when towing a trailer over long distances, for prolonged driving in moun-...

  • Page 269: Engine Oil

    Depending on your driving habits, premium or synthetic oils may provide superior fuel econ- omy and engine protection. Consult your Volvo retailer or a trained and qualified Volvo service technician for recommendations on premium or synthetic oils. Oil additives must not be used.

  • Page 270: Engine Specifications

    170/4400 2.44/148.6 2.44/148.6 83/3.27 83/3.27 90/3.54 90/3.54 10.3:1 10.3:1 Volvo kit no. 30650843 Volvo kit no. 30650843 (3x) 0.024 ± 0.004 in./0.6 (3x) 0.024 ± 0.004 in./0.6 ± 0.1mm ± 0.1mm 22.5 ft. lbs./30 Nm 22.5 ft. lbs./30 Nm B5254T7...
  • Page 271 11 Specifications Engine specifications Charge air cooler (Intercooler) Turbocharged engines employ a turbo-com- pressor to force air into the engine inlet mani- fold and a charge air cooler to cool the compressed inlet air. The resulting increase in air flow raises pressure in the intake manifold and increases engine power over that devel- oped by the normally-aspirated engine.

  • Page 272: Electrical System

    Capacity (Ah) Models equipped with the High Performance audio system Models equipped with the Premium Sound audio system, the Volvo Navigation System and/or keyless drive Bulbs used in the car Bulb Low beam headlight High beam headlight (applies to vehicles with halogen headlights)
  • Page 273 Front parking light, side turn signal Front fog light (option) Glove compartment light NOTE For information regarding any other bulbs not mentioned in this section, please con- tact your Volvo retailer or a trained and authorized Volvo service technician. 11 Specifications Electrical system Output Type...

  • Page 274: Three-Way Catalytic Converter

    11 Specifications Three-way catalytic converter Three-way catalytic converter – general information • Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three- way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating condi- tions, such as engine overheating or back-...

  • Page 275: Volvo Programs

    11 Specifications Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional informa- tion, features, and benefits are described in a separate information package in your glove compartment. If you require assistance, dial:...
  • Page 276 12 Index 1, 2, 3 ... 12-volt sockets... 62 A/C (air conditioning)... 92 ABS (anti-lock brake system)... 153 Active Bi-Xenon headlights... 63 Airbags front... 22 inflatable curtain... 30 side impact... 29 Airbag system... 22 Air conditioning... 92 Air distribution table... 101 Air vents...
  • Page 277 fluid... 219 general information... 153 Bulbs headlights... 223 list of... 272 Bulbs, replacing... 223 Capacities, fluids... 267 Capacity weight... 183, 265 Catalytic converter, three-way... 274 CD changer... 249 CD player... 249 Cell phone, hands-free connection... 254 Central locking system - remote control. 118 Chains...
  • Page 278 12 Index DSTC, stability system... 155 Economical driving... 136 Electrical current – conserving... 138 Electrically operated moonroof... 81 Electrical system... 272 Electronic Brake Force Distribution (EBD)... 154 Electronic Climate Control... 93 air distribution table... 101 Electronic Climate Control (ECC) - option. 98 Emergency brake...
  • Page 279 Hand brake (parking brake)... 75 Hands-free connection (cell phone) (Cell phone, hands-free connection)... 254 Hazard warning flashers... 74 Headlights... 63 Active Bi-Xenon (option)... 63 changing bulbs... 223 high and low beams... 66 high beam flash... 66 Headlight washers... 72 Head restraints, rear seat... 113 High beam flash...
  • Page 280 12 Index Long distance trips... 138 Lug nuts (wheel nuts)... 188 Maintenance... 210 performed by the owner... 212 Manual climate control... 95 Manual transmission... 147, 148 Mirrors... 78, 79 Model plate... 263 Moonroof... 81 Motor oil... 216, 269 checking... 216 Occupant safety...
  • Page 281 Reporting safety defects Canada... 17 USA... 16 Roof loads... 163 Rotating tires... 189 Safety, occupant... 16 Safety defects, reporting Canada... 17 USA... 16 Safety locks, child... 129 Seat belt reminder... 19 Seat belts... 18 Automatic locking retractor/Emergency locking retractor... 36 buckling...
  • Page 282 212 Vehicle towing... 157 Vehicle weights... 265 VIN (Vehicle Identification Number)... 263 Volvo Inflatable Curtain... 30 Volvo On Call Roadside Assistance... 275 Warning flashers, hazard... 74 Warning symbol... 55 Warranties... 210 Washer fluid... 218, 267 Washer fluid reservoir... 215, 218 Water, driving through...
  • Page 283 Windows power... 76 Windshield washer fluid reservoir... 215 Windshield wiper blades... 220 Windshield wipers... 72 rains sensor... 73 Winter tires... 186 Wiper blades replacing windshield wipers... 220 12 Index...
  • Page 284 12 Index...

This manual is also suitable for:

S40

Table of Contents
