  • Page 6 060010 x5 PCH-SWG11 x40 060011 x5 PCH-SW A17 x6 060025 x1 PCH-WRC03 x6 060026 x1 060040 x1 060037 x2 PCH-SWG11 20pcs 2offs 060037 PCH-SWA 17 1pcs 2offs 060010 1pc 5offs PCH-WRC03 1pcs 2offs 060011 1pc 5offs PCH-WRC03 1pcs 2offs PCH-SWA 17 1pcs 2offs 060026 PCH-WRC03...
  • Page 7 060008 x1 PCH-NTA01 PCH-SWE02 x20 PCH-SWG07 x10 PCH-WRC01 x20 PC-RE01 x10 PCH-NTA01 2pcs 10offs PC-RE01 10pcs 2pcs 10offs PCH-WRC01 060008 PCH-SWE02 2pcs 10offs PCH-SWG07 10pcs...
  • Page 8 060019 x4 PCH-SWA08 x16 060035 x1 PCH-WRC01 x16 060036 x1 PC-RE09 x4 060032 x1 060035 PC-RE09 060032 4pcs 060019 4pcs 060036 PCH-WRC01 2pcs 8offs PCH-SWA08 2pcs 8offs...
  • Page 9 060025 x1 PCH-SWA17 x4 060026 x1 PCH-WRC03 x4 060034 x1 PCH-WRC03 1pc 2offs PCH-SWA17 1pc 2offs 060025 060034 PCH-WRC03 1pc 2offs PCH-SWA17 1pc 2offs 060026...
  • Page 10 PCH-SWA17 PCH-SWH01 x8 PCH-WRC03 x3 PCH-SWH01 4pcs 2offs PCH-SWA17 3pcs PCH-WRC03 3pcs...
  • Page 11 060020 x2 PCH-BTD62 x4 060021 x2 PCH-NTA03 x4 PCH-NTB02 x4 PCH-WRC03 x4 PCH-NTB02 060021 1pc 4offs 1pc 2offs 060020 PCH-NTA03 1pc 2offs 1pc 4offs PCH-WRC03 1pc 4offs PCH-BTD62 1pc 4offs...
  • Page 12 060028 x1 PCH-SWA08 x24 060029 x1 PCH-SWA13 x4 060030 x1 PCH-WRC01 x24 060031 x1 PCH-WRC03 x4 060030 060031 060028 060029 PCH-WRC03 1pc 4offs PCH-SWA13 1pc 4offs PCH-SWA08 6pcs 4offs PCH-WRC01 6pcs 4offs...
  • Page 13 060009 x4 PCH-SWG11 x48 060012 x6 060002 x2 060009 PCH-SWG11 4pcs 4pcs 12offs 060012 6pcs 060002 2pcs...
  • Page 14 060014 x1 PCH-SWF11 x8 PCH-SWG07 x12 PCH-WRC01 x8 PC-BRC03 PCH-SWF11 4pcs 2offs PCH-SWG07 PCH-WRC01 12pcs 4pcs 2offs PC-BRC03 2pcs 060014...
  • Page 15 060004 x4 PCH-NTB02 x2 PCH-WRC01 x2 060005 x1 PCH-NTC02 x2 PCH-WRC03 x3 060018 x1 PCH-SWA08 x2 PCH-WRE03 x2 060039 x1 PCH-SWA13 x1 PCH-WRC04 x2 PCH-SWG07 x18 PCH-BTC41 x2 PCH-WRC03 PCH-SWG07 PCH-WRC04 1pc 2offs 2pcs 9offs PCH-WRE03 1pc 2offs 1pc 2offs 060018 PCH-NTC02 1pc 2offs...
  • Page 16 060013 x1 PCH-SWA08 x4 PCH-WRC04 x2 060027 x1 PCH-WRC01 x4 PCH-WRE03 x2 060038 x1 PCH-SWA13 x2 PCH-NTB02 x2 PCH-WRC03 x4 PCH-NTC02 x2 PCH-BTC41 x2 060013 PCH-BTC41 1pc 2offs PCH-SWA08 2pcs 2offs PCH-SWA13 PCH-WRC04 1pc 2offs 1pc 2offs PCH-WRC03 1pc 2offs PCH-WRC01 060038 2pcs 2offs...
  • Page 17 PCH-BTD48 x1 PCH-WRC03 x3 060001 x2 060007 x1 PCH-NTA03 x1 PCH-WRE03 x1 060015 x1 PCH-SWA14 x2 PCH-SWG11 x12 060017 x1 PCH-SWF11 x6 PCH-WRC01 x6 PCH-WRC01 PCH-SWG11 6pcs PCH-SWF11 060007 2pcs 2offs 6pcs PCH-NTA03 060001 1pc 2offs 060017 PCH-WRC03 PCH-BTD48 PCH-WRE03 060015 PCH-SWG11 2pcs 4offs...
  • Page 18 060003 x2 PCH-SWA08 x2 060004 x2 PCH-SWF11 x4 PCH-SWG07 x8 PCH-WRC01 x6 PC-BRC01 060004 1pc 2offs PCH-WRC01 1pc 2offs PCH-SWA08 1pc 2offs PCH-SWG07 2pcs 4offs PCH-WRC01 2pcs 2offs PC-BRC01 2pcs 060003 1pc 2offs PCH-SWF11 2pcs 2offs...
  • Page 19 PCH-BTC43 x10 PCH-WRE03 x2 060050 x1 PCH-NTB02 x10 PCH-SWA14 x1 PCH-NTC02 x2 PC-BRA02 PCH-NTD03 x8 PCH-WRD01 x10 PCH-WRC03 x11 PCH-BTC43 2pcs 5offs PCH-WRD01 2pcs 5offs PC-HG02 4pcs PC-BRA02 060050 PCH-WRC03 2pcs 4offs PCH-WRC03 1pc 2offs PCH-WRE03 PCH-NTD03 1pc 2offs 2pcs 4offs PCH-NTB02 PCH-NTC02 1pc 2offs...
  • Page 20 PCH-BTC13 x1 PCH-WRE04 x3 PCH-BTC02 x2 PCH-NTC03 x3 PCH-WRC06 x3 PCH-NTB03 x3 PCH-SWA14 x1 PCH-WRC03 x1 PCH-WRC04 x3 PCH-BTC13 PCH-BTC02 1pc 2offs PCH-WRC06 PCH-WRC06 1pc 2offs PCH-WRC03 PCH-WRC04 1pc 3offs PCH-SWA14 PCH-WRC04 1pc 3offs PCH-NTC03 1pc 3offs PCH-NTB03 1pc 3offs...
  • Page 21 060051 x2 PCH-SWA12 x6 PCH-SWA14 x2 060052 x1 PCH-WRC03 x12 PCH-WRE03 x2 PCH-NTC02 PCH-NTB02 x2 PCH-BTD54 x2 Note：Make the swing beam PCH-WRC03 parallel to the ground. 1pc 2offs PCH-BTD54 PCH-WRC03 1pc 2offs 1pc 2offs PCH-WRE03 1pc 2offs PCH-NTC02 1pc 2offs PCH-SWA12 1pc 2offs PCH-NTB02...
  • Page 22 Mount Telescope and Safety Handles PCH-SWF11 x8 PCH-WRC01 x8 PC-RE04 x4 PC-DT04 x1 PCH-WRC01 PCH-SWF11 2pcs 4offs 2pcs 4offs PC-DT04 PC-RE04 1pc 4offs...
  • Page 23 Attaching Climbing Net and Rail Handles PCH-SWF15 x6 PCH-WRC01 x6 PC-AD04 x1 PC-RE05 x3 PC-AD04 PC-RE05 1pc 3offs PCH-SWF15 2pcs 3offs PCH-WRC01 2pcs 3offs...
  • Page 24 PCH-SWA08 x6 PC-BH04 x4 PC-BH10 x6 PC-SB04 x1 PC-TZ05 x1 PC-BH04 2pcs 2offs PC-TZ05 PC-BH10 1pc 6offs PC-SB04 PCH-SWA08 1pcs 6offs Note: the wood screws (PCH-SWA08) are packed with ground anchors, not in fastener bags. Note: it is suggested to secure the ground anchors with cement in dimensions around 350x350x350mm.
  • Page 25 PCH-MSA01 x8 PC-RE07 x1 PC-RE07 PCH-MSA01 4pcs 2offs...
  • Page 26 PCH-SWF11 x2 PCH-WRC01 x2 PCH-SWF11 2pcs PCH-WRC01 2pcs...
  • Page 27 Note: the lumber pieces and fasteners to close the opening for slide is not included, you can refer to below list and buy from local store. Lumber List Accessories List PCH-SWA08 X12 PCH-WRC01 X12 060058 x3 predrill holes before screwing 1079 predrill holes before screwing 1118...
  • Page 28 Lumber Cutting List for Spiral Slide Note: the lumber pieces for assembling spiral slide are not included. Please refer to below lumber and fastener list to buy from local stores. predrill holes before screwing predrill holes before screwing predrill holes before screwing predrill holes before screwing 1079 predrill holes before screwing...
  • Page 29 Fastener and Part List for Spiral Slide Note: the fastener and steel brackets for assembling spiral slide are not included. Please refer to below list to buy from local stores. Ground Anchor w/ fastener to connect Safety handles x2 (optional for with playset 90°...
