Rear ports
Figure 4. Rear view of the system with ports displayed
Table 5. Port descriptions
Identifier Description
1
Video Graphics Array (VGA)
Note: Cables up to 3 meters are supported.
2
Serial
Note: Cables up to 3 meters are supported.
3
Dedicated BMC Ethernet. Use this port for the BMC/IPMI interface (eth1).
4
Shared BMC Ethernet. (eth0)
5
USB 3.0
Note: Cables up to 3 meters are supported. The USB 3.0 port on the front of the system has
the same restriction.
©
Copyright IBM Corp. 2020, 2021
9
