Saab 2007 9-5 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
©
Saab Automobile AB 2006
Service Readiness, Saab Automobile AB, Trollhättan, Sweden
Printed in Sweden
Saab 9-5, Model Year 2007
Instruments and controls
Saab 9-5 Audio System 3
Interior equipment and trunk 113
Car care and technical information 189
Customer Assistance and Information 251
Owner's Manual
Safety
Security
Starting and driving 139
Specifications 257
1
11
43
57
90
Index 271

Advertisement

Table of Contents
loading

Related Manuals for Saab 2007 9-5

Summary of Contents for Saab 2007 9-5

  • Page 1 © Saab Automobile AB 2006 Service Readiness, Saab Automobile AB, Trollhättan, Sweden Printed in Sweden Owner’s Manual Saab 9-5, Model Year 2007 Instruments and controls Saab 9-5 Audio System 3 Interior equipment and trunk 113 Starting and driving 139 Car care and technical information 189...

  • Page 2: Saab Automobile Ab

    NOTICE texts warn of potential damage to the car if the recommendations are not followed. Since the policy at Saab is one of continual improvement, we retain the right to incorpo- rate modifications and to alter specifications during production without prior notice.

  • Page 3: Instrument Panel

    (SportCombi) 3_________ Rain sensing wipers 3 ____ Washers _______________ 203 Wipers and washers______ 202 Hazard warning lights_____ Saab 9-5 Audio System 3 _ Steering wheel controls 3 _ Automatic climate control (ACC) ________________ Air conditioning (ACC) ____ 243 Power Outlet 3________________...

  • Page 4: Table Of Contents

    Exterior Moonroof 3 _____________ 123 Washing the car _________ 241 Waxing and polishing _____ 242 Touching up the paint _____ 242 Anti-corrosion treatment ___ 245 Headlights ______________ Rear light cluster, 9-5 Sedan 208 Rear lights clusters, 9-5 SportCombi _________ 210 Changing bulbs __________ 204 Towing a trailer 3 ________ 174 Towing the car ___________ 183...
  • Page 5 Interior Steering wheel adjustment _ 114 Airbag _________________ Power steering fluid_______ 198 Steering wheel controls 3 __ Sentronic, manual mode 3 3 156 Seats__________________ Heated front seats 3 ______ Head restraint 3 _________ Safety belts _____________ Child safety _____________ Folding the rear seat, 9-5 Sedan _____________ 129 Folding the rear seat, 9-5 SportCombi _________ 132...
  • Page 6 Engine compartment Warning labels __________ V.I.N. number ___________ 268 Engine number __________ 268 Gearbox number _________ 268 Color code______________ 268 Tire and Loading Information Label _________________ 231 Power steering fluid_______ 198 Steering, technical data ___ 265 Ignition switch ___________ 140 Drive belts ______________ 201 Spark plugs _____________ 263 Catalytic converter _______ 145...

  • Page 7: Warning Labels

    The A/C system complies with SAE J639. Charge: 825 g of R134a. Compressor oil: PAG oil SP-10 alt. Saab oil 4759106 Oil amount: See workshop manual. • AVOID SPARKS AND OPEN FLAMES, NO SMOKING • WEAR EYE PROTECTION •...
  • Page 8 Contact a Saab dealer if a xenon headlight requires replacement. This label is only found on cars with xenon head- lights. WARNING EVEN WITH ADVANCED AIR BAGS • Children can be killed or seriously injured by the air bag. • The back seat is the safest place for children.
  • Page 9 Examples of symbols that can be found in your car No sparks, fla- mes or smo- Buckle up king. Use protective Airbag goggles Never place a Keep out of rear-facing reach of child seat in children. this seat. Battery acid Electric contains windows...
  • Page 10 (This page has been left blank)
  • Page 11 3 Asterisk means: equipment not fitted in all cars (can depend on model variant, engine variant, market specification, options or accessories). Safety Seats _______________ Head restraint ________ Safety belts __________ Child safety __________ Airbag_______________...

  • Page 12: Safety Belts

    15 mph (25 km/h). The text Use your seatbelts. is lit on the Saab Information Display (SID) and the symbol will flash. If the belt is not fastened then an audible signal will come on after 30 seconds.
  • Page 13 • Children up to 6 years of age must always be seated in a child seat. Saab recom- mends the use of a child seat for children up to the age of 10.
  • Page 14 To fasten the belt Front safety belts Fasten the belt by pulling the belt and insert- ing the tongue in the buckle. Check that it is securely fastened. Grasp the shoulder belt close to the buckle and pull the belt towards the shoulder to tighten the lap belt part.
  • Page 15 If the car is involved in a crash, the safety belts, belt pretensioners and other com- ponents must be inspected by an autho- rized Saab dealer and replaced as neces- sary. Never make any alterations or repairs to the safety belt yourself. Visit an autho- rized Saab dealer for any necessary repairs.
  • Page 16 Safety Three-point safety belts are provided for all three rear seat passengers. Fasten the belt by pulling out the strap care- fully and inserting the tongue in the lock. Check that it is securely fastened. Then grip the diagonal part of the strap near the lock and pull the belt upwards towards the shoulder to tighten the lap strap.
  • Page 17 WARNING • Safety belts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable; wearing the lap section of the belt across the abdominal area must be avoided.
  • Page 18 Seats WARNING The seats are actuated by powerful motors. Bear this in mind when adjusting the seat, and make sure that nothing gets caught and damaged. Ensure that noth- ing can be trapped when adjusting the seat. Bear in mind that children can be injured if they play with the electrically-operated seats.
  • Page 19 Legroom adjustment To adjust the legroom, push the lower con- trol forward or back. Backrest rake angle To adjust the backrest, move the upper con- trol forward or back. WARNING The backrest should be upright during driving, so that the safety belt, airbag and backrest can provide optimum protection in the event of emergency braking or a crash and in particular a rear-end...
  • Page 20 To save the settings, press and hold the M button and, at the same time, press one of the preselect buttons (1, 2 or 3). The Saab Information Display (SID) will chime to con- firm that the settings have been saved.

  • Page 21: Head Restraint

    • Raise the head restraints in the seat that are occupied. The front seats in the Saab 9-5 are equipped with Saab Active Head Restraints (SAHRs). These reduce the risk of whiplash injury if the car is hit from behind.

  • Page 22: Child Safety

    Child safety WARNING • Children must always be suitably restrained in the car. • ALWAYS use SAFETY BELTS and CHILD RESTRAINTS. • NEVER put a rear-facing child seat in the front. • DEATH or SERIOUS INJURY can occur. • Children 12 and under or shorter than 55 inches (140 cm) can be killed by the airbag.
  • Page 23 Only use the attach- ments and straps provided with the child restraint. If you have any questions regarding LATCH anchors, please contact your Saab dealer. WARNING If a LATCH-type child restraint is not attached to its anchor points, the restraint will not be able to protect the child cor- rectly.
  • Page 24 Safety Location of lower anchors Rigid 2-point lower attachment with top tether Semi-rigid 2-point lower attachment with top tether Lower anchor and top tether anchor loca- tions.

  • Page 25: Securing A Child Restraint Designed For The Latch System

    The child restraint shall be firmly attached to the vehicle. Child tether anchorages, Saab 9-5 Sport- Combi WARNING Make sure the child restraint anchorages...
  • Page 26 7 Push and pull the child restraint in differ- ent directions to be sure it is secured at the lower anchors/safety belt and the top tether anchor. The child restraint shall be firmly attached to the vehicle. Child tether anchorages in parcel shelf, Saab 9-5 Sedan...
  • Page 27 Lockable latch plate In fitting a child seat that is intended to be secured in position by the lap portion of the safety belt, make use of the locking function of the latch plate. This function is available on all seats in the second row. Locking the lap portion of the belt lessens the risk that the seat will work loose while the car is in motion.
  • Page 28 When a rear-facing child seat is fitted in the center position of the rear seat in the Saab 9-5 Sedan the center armrest must be secured in place with this strap. If this is not done, the center armrest could swing down in the event of a frontal crash and cause injury to the child.
  • Page 29 Airbag WARNING To reduce risk of injury: • Always wear your safety belt. • Always adjust your seat so that you are as far back as possible but still able to operate the pedals and reach the steering wheel and controls com- fortably.
  • Page 30 We recommend that you contact an authorized Saab dealer. The warning light could signify that the airbags may not inflate in a crash, or they could even inflate with-...
  • Page 31 Moment of impact. The sensors detect deceleration and send a signal via the cen- tral sensor to the gas generator that inflates the airbag. AIRBAG system with belt pretensioners 1 Central sensor 2 Belt pretensioners (for both front safety belts) The inflating airbag 3 Steering wheel with integral airbag cushions the driver.
  • Page 32 Front passenger seat WARNING Never secure a rear-facing child seat in the right front seat of a car equipped with a passenger airbag. Inflation of the airbag in the event of a crash could seriously injure or kill a child. The airbags are interconnected and have a common warning light.

  • Page 33: Passenger Sensing System

    Passenger Airbag Status Indicator. Saab recommends that child restraints be secured in a rear seat, including an infant riding in a rear-facing infant seat, a child riding in a forward-facing child seat and an older child riding in a booster seat.
  • Page 34 If a child restraint has been installed (Saab recommends that child restraints be secured in the rear seat) and the on indica- tor is lit, turn the vehicle off.
  • Page 35 If the on indicator is still lit, secure the child in the child restraint in a rear seat position in the vehicle and check with your dealer. The passenger sensing system is designed to enable (may inflate) the right front pas- senger’s frontal airbag anytime the system senses that a person of adult size is sitting properly in the right front passenger’s seat.

  • Page 36: Side Airbags

    We recom- mend that you contact an authorized Saab dealer. Otherwise there is a risk that the side impact sensor and the moisture barrier in the front door could be damaged.
  • Page 37 Side airbag inflated Side airbag components 1 Side airbag 2 Sensor 3 Moisture barrier 4 Text on seat AIRBAG warning light WARNING • If the airbag readiness light stays on after you start your vehicle, it means the airbag system may not be working properly.
  • Page 38 What Will You See After an Airbag Inflates? After an airbag inflates, it quickly deflates, so quickly that some people may not even realize the airbag inflated. Some compo- nents of the airbag module - the steering wheel hub for the driver's frontal airbag, the instrument panel for the right front passen- ger's frontal airbag or the ceiling of your vehicle near the side windows - will be hot...
  • Page 39 • The headlining and roof pillar trim must not be modified in any way. Work on these areas must only be carried out at a Saab dealer.
  • Page 40 Recline the seat back to increase the dis- tance between you and the airbag. For short drivers, special accessory pedal extensions are available through your Saab dealer. Airbags inflate extremely rapidly and with great force – to be fast enough to protect an adult in the seat.
  • Page 41 The airbag cannot be relied on to operate as intended and it might even be activated erroneously. You should therefore take the car to an authorized Saab dealer as soon as possible. Adding Equipment to Your Airbag-Equipped Vehicle...
  • Page 42 Safety (This page has been left empty.)
  • Page 43 3 Asterisk means: equipment not fitted in all cars (can depend on model variant, engine variant, market specification, options or accessories). Security Doors _______________ Central locking _______ Car alarm ____________...

  • Page 44: Central Locking

    If you loose one key you should have this replaced as soon as possible by con- tacting your Saab dealer. When the new key is programmed into the system, the missing key is automatically erased.
  • Page 45 Key / Remote control 1 To lock 2 To unlock 3 Opening the trunk (9-5 Sedan) Unlocking the tailgate (9-5 SportCombi) Locking/unlocking the car When the car is locked and unlocked the theft alarm is also affected. Remote locking Press once on the control: all doors locked.
  • Page 46 The car can now be started. Contact a work- shop to have the system checked and repaired. We recommend that you contact an authorized Saab dealer. Locking by key (1) When the car is locked and unlocked the theft alarm is also affected.

  • Page 47: Child Safety Locks

    Child safety locks The rear doors are equipped with child safety locks that are operated by means of a catch adjacent to the door lock. Insert a key and turn the catch 45° clockwise or counterclockwise as indicated by the label on the door.

  • Page 48: Tailgate, 9-5 Sportcombi

    Unlocking The trunk lid is slightly opened/unlocked using: • The button on the key • The trunk lid switch on the inside of the driver’s door (if the car is unlocked and at a standstill) Remote unlocking is confirmed by the direc- tion indicators flashing three times.
  • Page 49 Saab dealer; see page 270. Changing the key battery When the battery voltage in the key falls below a predetermined level the Saab Infor- mation Display (SID) will issue the following message: ”Remote control battery low. Replace battery.”...

  • Page 50: Car Alarm

    1 Activate/lock 2 Deactivate/unlock 3 Unlock trunk/tailgate Unlocking the tailgate (9-5 SportCombi) Your Saab 9-5 is equipped with an Elec- tronic starting interlock (immobilizer), see page 51 for details. The car alarm is armed 10 seconds after the car has been locked by the remote control.
  • Page 51 ON and press one of the buttons on the key (providing that the receiver gets the right signal from the key). Take the car to an authorized Saab dealer to have the system checked. The LED double-flashes when the car is...

  • Page 52: Alarm Signals

    Alarm signals When the car alarm is armed, it will be trig- gered if any door, or the trunk lid or hood, is opened. The alarm will also be triggered if an attempt is made to bypass or short-circuit the igni- tion switch, or to disconnect the battery.
  • Page 53 Alarm signals may differ between model variants for different countries. Some of the car-alarm functions can be reprogrammed – con- sult your Saab dealer for further details (see page 270).
  • Page 54 Saab dealer. Turn the ignition key to position ON and then press the button for open- ing the trunk lid. Saab Information Display (SID) displays the number of keys and transmitters (transponders) coded to the car.
  • Page 55 Security This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) must accept any interference received, including interference that may cause undesired oper- ation.
  • Page 56 Security (This page has been left blank)

  • Page 57: Instruments And Controls

    3 Asterisk means: equipment not fitted in all cars (can depend on model variant, engine variant, market specification, options or accessories). Instruments and controls Indicator and warning lights ______________ Instruments __________ Saab Information Display (SID) _______________ Switches ____________ Automatic climate control (ACC) ______________...

  • Page 58: Indicator And Warning Lights

    ”Engine malfunction (CHECK ENGINE)” indicator light illuminated (Limp-home mode), you are advised to have your car serviced at an authorized Saab dealer as soon as possible. Continued driving without this problem being corrected might cause serious fur- ther damage to your car and create unsafe driving conditions.
  • Page 59 The car should be checked immediately at a workshop to prevent more serious faults from arising. We recommend that you contact an authorized Saab dealer. Warning, oil pressure (engine oil) This light will come on if the engine oil pres- sure is dangerously low.
  • Page 60 Now check the level again. If the level is still normal, you may drive the car, with considerable cau- tion, to the nearest authorized Saab dealer to have the brake system checked. WARNING • If the ABS is inoperative, there is a danger of the rear wheels locking up on hard braking.
  • Page 61 If the Xenon headlight fault indicator lights up, have your car checked as soon as possible a workshop. We recommend that you contact an authorized Saab dealer. If you do not rectify the problem, nighttime visibility will be poor since the range of the...
  • Page 62 Even if the fault persists, it is still possible in most cases to drive the car (see page 154). Have the automatic transmission checked by an authorized Saab dealer as soon as possible. NOTICE If the control module has actuated the...
  • Page 63 In this case the light cannot be turned off by means of the ESP button. If a fault is indicated, have the system checked by an authorized Saab dealer. See also Electronic Stability Program ®...

  • Page 64: Instruments

    1 Cars with automatic transmission Autochecking of lights, main instrument panel The above warning and indicator lights should come on when the ignition is switched on prior to starting. They should go out after about 3 seconds. The following lights light up until the engine is started, presuming that no fault exists: •...

  • Page 65: Fuel Gauge

    2.5 gal. (10 liters), a warning light on the main instrument panel will come on (see page 61). Use the Saab Information display (SID) to check the approximate distance that can be traveled on the remaining fuel (see page 68).

  • Page 66: Pressure Gauge

    – do not remove the cap. If the coolant level falls below the MIN mark, the Saab Information Display (SID) will dis- play the message ”Coolant level low. Refill.”.
  • Page 67 When the speed of the car exceeds 130 mph (210 km/h) acceleration is limited by a reduction in boost pressure. The turbo gauge will move to the middle field, indicat- ing a drop in engine output and conse- quently a reduction in vehicle speed. Selector lever indication 3 The display below the speedometer indi- cates the position of the selector lever.

  • Page 68: Saab Information Display

    The driver’s attention can oth- erwise easily be distracted from the road. The Saab Information Display (SID) shows CHECK messages and incorporates eight trip-computer functions. Use the i/SET button to browse the func- tions.
