Instruments and controls
Saab 9-3 Audio System
Interior equipment, trunk
Maintenance and owner assistance
Owner's Manual
Saab 9-3 M2002
Safety
Security
Convertible
OnStar - Telematics
Starting and driving
Car care
Technical data
Index
1
11
35
47
59
93
111
123
145
185
229
233
247

Advertisement

Table of Contents
loading

Related Manuals for Saab 2002 9-3

Summary of Contents for Saab 2002 9-3

  • Page 1 © Saab Automobile AB 2001 Service Readiness, Saab Automobile AB, Trollhättan, Sweden Printed in Sweden Owner’s Manual Saab 9-3 M2002 Instruments and controls Saab 9-3 Audio System OnStar - Telematics Interior equipment, trunk Starting and driving Maintenance and owner assistance...
  • Page 2 NOTE texts warn of potential damage to the car if the recommendations are not followed. Since the policy at Saab is one of continual improvement, we retain the right to incorpo- rate modifications and to alter specifications during production without prior notice.

  • Page 3: Table Of Contents

    Fuel gauge __________________ 68 Temperature gauge ____________ 67 Ashtrays (accessory) __________ 135 Cigarette lighter (accessory) ____ 135 Trip computer (Saab Information Display, SID) __ 69 Night panel __________________ 73 Clock _______________________ 74 Washers and wipers ______ 78 Rear-window wiper _______ 79...
  • Page 4 Exterior Sunroof _______________ 132 Convertible _____________ 48 Washing the car ________ 220 Waxing and polishing ____ 221 Touching-up of paintwork _ 221 Anticorrosion treatment ___ 222 Taillights ______________ 202 Stop lights _____________ 202 Light switches ___________ 75 Changing bulbs _________ 200 Towing ________________ 179 Towrope attachment eyes _ 179 Towing a trailer _________ 173...
  • Page 5 Interior Power steering _________ 241 Steering-wheel adjustment 131 Airbag _________________ 28 Seat adjustment ________ 124 Safety belts _____________ 12 Seat heating ___________ 129 Rear seat _____________ 138 Folding down the rear seat Child seats _____________ 19 Upholstery: cleaning _____ 219 Internal rearview mirror ________ 137 Door mirrors ________________ 137 Vanity mirror ________________ 134...
  • Page 6 Engine bay Warning labels ___________ 7 V.I.N. number __________ 243 Engine number _________ 243 Gearbox number ________ 243 Color coding ___________ 243 Ignition system _________ 240 Drive belt ______________ 197 Alternator _____________ 197 Spark plugs ____________ 240 Catalytic converter ______ 150 Simple fault tracing (A/C, ACC) ____________ 226 Turbo-compressor ________ 67...

  • Page 7: Warning Labels

    The A/C system complies with SAE J639. Refrigerant: 770 g of R134a. Compressor oil: 150 cc PAG Oil SP-10, or SAAB oil 4759106 SP-10. • AVOID SPARKS, AVOID OPEN FLAMES, NO SMOKING • PROTECT YOUR EYES • KEEP OUT OF REACH OF CHILDREN •...
  • Page 8 • Sit as far back as possible from the air bag. • ALWAYS use SEAT BELT and CHILD RESTRAINTS Wheel changing: Intended for the Saab 9-5 and 9-3. Use the jack only on firm, level ground. Use blocks. Max. jack load: 2200 lbs. (1000 kg). For further information, see the manual.
  • Page 9 Soft top, Saab 9-3 Convertible Do not lean over top or sit in the rear seat while activated. Brake fluid Clean filler cap before removing. Use only Dot 4 fluid from sealed container. Soft top, Saab 9-3 Convertible Push the handle in before driving away.
  • Page 10 (This page has been left blank).
  • Page 11 Safety Safety belts... Head restraint... Child safety... Airbag (Supplemental Restraint System "SRS")

  • Page 12: Safety Belts

    Safety Safety belts WARNING Safety belts must be worn at all times by all car occupants. Child safety, see page Check that the locking tongue is properly locked in the belt lock. Three-point inertia-reel safety belts are pro- vided for all seats. The results of studies show that it is equally important to wear safety belts in the rear seat as in the front seats.
  • Page 13 If the car is involved in a crash, the safety belts, belt pretensioners and other com- ponents must be inspected by an autho- rized Saab dealer and replaced as neces- sary. Never make any alterations or repairs to the safety belt yourself but visit an author- ized Saab dealer.
  • Page 14 Safety • Children who have grown out of a child seat should be restrained by the car’s standard three-point belts. Make sure that the shoulder belt is not in contact with the neck or throat. If it is, a booster seat/cush- ion may be necessary.
  • Page 15 The belt guide on the door pillar Belt height adjustment The belt guide on the door pillar can be set to five different heights. Set the guide as high as possible without causing the belt to chafe against the throat. In the case of a short person the guide can be lowered until the belt comes about an inch (a few centimetres) from the throat but...
  • Page 16 Safety Safety belts, rear seat (the central head restraint is an accessory) Safety belts, rear seat Three-point safety belts are provided for all three rear-seat passengers (2 for Convert- ible models). Fasten the belts by pulling the belt across you and inserting the tongue into the buckle. Check that it is securely fastened.
  • Page 17 WARNING Safety belts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable; wearing the lap section of the belt across the abdominal area must be avoided.

  • Page 18: Head Restraint

    Safety Head restraint The front seats in the Saab 9-3 are equipped with Saab Active Head Restraints (SAHRs). These reduce the risk of whiplash injury if the car is hit from behind. In the event of a rear-end crash, the body is forced back against the backrest.

  • Page 19: Child Seats

    Child safety WARNING • NEVER put a rear-facing child seat in the front. • Children must always be suitably restrained in the car. All child restraints and booster seats are designed to be secured in vehicle seats by the lap belt of a lap-shoulder belt or LATCH.
  • Page 20 Safety The same attention must be given to child safety in the car as is given to adults. Saab recommends rearward facing child restraints for children up to 3 years old. Children travel most safely when properly restrained, but restraints must be suitable for the size of the child.
  • Page 21 Top tether are upper attachments located between belt beam and parcel shelf, see page 23 and 24. Saab recommends rearward facing child restraints for children 3 and under. ISOFIX attachment points in the rear seat, 9-3 Convertible...
  • Page 22 Safety LATCH installation To facilitate the proper fitting of new spe- cially-designed child restraints rigid lower anchorages (ISOFIX) have been installed to the vehicle that shall be used with the top tether anchorages in the two outboard rear seating positions. There is an additional top tether anchorage for the center rear seating position used together with the safety belt.
  • Page 23 Child tether anchorages, Coupé and 5-door models Child restraints with a tether strap must be anchored according to law. WARNING Child tether anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult safety belts.
  • Page 24 Safety Child tether anchorages, Convert- ible models Child restraints with a tether strap must be anchored according to law. WARNING Child tether anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult safety belts.
  • Page 25 Saab recommends rearward facing child restraints be used for children up to 3 years of age.
  • Page 26 Safety Integrated booster seat (accessory) Integrated booster seat is available as part of the rear seat backrest. This child restraint is designed for use by children who weigh between 33 and 80 lbs. (15 and 36 kg) and are between 38 and 54 inches (970 and 1370 mm) in height.
  • Page 27 Folding booster seat • Pull the upper part of the release strap out and fold up the seat itself. Make sure that it is locked firmly in its folded-up position. • Press the booster seat’s headrest all the way down. •...

  • Page 28: Airbag

    Safety Airbag (Supplemental Restraint System "SRS") WARNING To reduce risk of injury: • Always wear your safety belt. • Always adjust your seat so that you are as far back as possible but still able to reach the steering wheel and controls comfortably.
  • Page 29 Saab dealer. The warning light could signify that the airbags may not inflate in a crash, or they could...
  • Page 30 Safety Front passenger seat WARNING Never secure a rear-facing child seat in the right front seat of a car equipped with a passenger airbag. Inflation of the airbag in the event of a crash could seriously injure or kill a child. The airbags are interconnected and have a common warning light, AIR BAG.
  • Page 31 • Improvement of the anticorrosion treatment of the doors should only be carried out by an authorized Saab dealer. Otherwise there is a risk that the side impact sensor and the mois- ture barrier in the door could be dam- aged.
  • Page 32 Safety AIR BAG warning light WARNING • If the airbag readiness light stays on after you start your vehicle, it means the airbag system may not be working properly. See page 62. • The airbags in your vehicle may not inflate in a crash, or they could even inflate without a crash.
  • Page 33 Recline the seat back to increase the dis- tance between you and the airbag. For short drivers, special accessory pedal extensions are available through your Saab dealer. Airbags inflate extremely rapidly and with great force - to be fast enough to protect an adult in the seat.
  • Page 34 You should therefore take the car to an authorized Saab dealer as soon as possible. WARNING To reduce the risk of head injuries in the...
  • Page 35 Security Security Doors... Central locking ... Car alarm ...

  • Page 36: Central Locking

    If one is lost, contact your authorized Saab dealer to obtain a replacement. If an additional key is to be added, all of the original keys must be brought to the dealer so that the control module can ‘’learn”...

  • Page 37: Interior Locking Buttons

    ON position. The car can now be started. Contact your local Saab workshop to have the system checked and rectified. Security Locking / unlocking by remote control...
  • Page 38 Security Central locking 1 To lock 2 To unlock Locking by key (1) Turn the key clockwise: all doors and trunk lid locked. The trunk lid cannot be opened now from inside using the switch on the driver’s door. Unlocking by key (2) Turn the key counterclockwise once: the driver´s door unlocked.

  • Page 39: Child Safety Lock Catch

    SID to acknowledge this message. You must then replace the battery without delay to avoid malfunctions. The life of the battery is normally 4 years.Contact a Saab dealer to have the battery replaced. Child safety lock catch 1 Engaged...

  • Page 40: Trunk Lock

    Security Trunk switch Trunk lock The trunk does not unlock when the other doors are unlocked. The trunk button on the driver’s door is inoperative when the car is locked or moving at a speed greater than 2.7 mph (4 km/h). 9-3 Convertible: When unlocked the bootlid opens slightly.

  • Page 41: Car Alarm (Anti-Theft System)

    The car alarm may not have been activated and you should get in touch with an authorized Saab dealer. Be sure everyone using the car is familiar with how both the car alarm and the locking system work.
  • Page 42 In this case, you can still start the car if you turn the ignition key to ON and press one of the buttons on the key. Take the car to an authorized Saab dealer to have the system checked. The LED on the top of the dash dou-...
  • Page 43 Alarm signals When the car alarm is armed, it will be trig- gered if any door, the trunk lid or hood, is opened, or if a window is broken. The alarm will also be triggered if an attempt is made to bypass or short-circuit the igni- tion switch, or to disconnect the battery.
  • Page 44 Alarm signals may differ between model variants for different coun- tries. Some of the car alarm functions can be reprogrammed – con- sult your Saab dealer for further details (see page 245).
  • Page 45 Security Reason/action Probably a faulty sensor or siren. Have the car checked by an author- ized Saab dealer. Fault in key transmitter or in igni- tion-switch receiver. Turn ignition switch to ON and press one of the buttons on the remote control. Start the engine.
  • Page 46 Security This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) must accept any interference received, including interference that may cause undesired oper- ation.

  • Page 47: Convertible

    Convertible Convertible General safety instruc- tions ... Folding the soft top ... Raising the soft top ... Manual raising of the soft top ... Fault messages in SID... Central operation of the windows, 9-3 Convertible Trunk, 9-3 Convertible ... Rear seat... Cleaning the soft top, 9-3 Convertible ...

  • Page 48: Convertible

    This applies to carwashes that use mechanical feelers bearing against the body. We advise against washing a Saab 9-3 Con- vertible in automatic carwashes. • Note that certain automatic car washes can cause water to leak in places that nor- mally would not leak.

  • Page 49: Folding The Soft Top

    Folding the soft top Before operating the soft top, read through the section ” General safety instructions” on page 48. WARNING • Do not touch the hinges or struts of the soft top during folding, because of the pinch hazard. •...
  • Page 50 Convertible Switch for operating the soft top 1 Lowering 2 Raising 3 Slide the ROOF button backwards until the soft top is completely folded away, the tonneau cover is closed and the SID has given an OK signal (beep). Slide the ROOF button backwards a second time to lower the windows.

  • Page 51: Raising The Soft Top

    The front-edge locking of the tonneau cover Raising the soft top WARNING • Do not touch the hinges or struts of the soft top during rasing the top, because of the danger of being injured. • Do not operate the soft top with pas- sengers in the rear seat or bystanders right next to the car, because of the risk of head injuries.

  • Page 52: Manual Raising Of The Soft Top

    Convertible 4 Raise the side windows by sliding the ROOF button forward a second time. Alternatively, use the central operating switch for the side windows. 5 Check that there are no fault messages on the SID; see page 54. Manual raising of the soft top WARNING Manual operation of the soft top must be...
  • Page 53 18 Take the tool out. The soft top system must be checked and repaired by an authorized Saab dealer as quickly as possible.

  • Page 54: Fault Messages In Sid

    Convertible Fault messages in SID The following CHECK messages are included in the soft top system and can be displayed on the SID together with a beep. SID displays Cause CHECK SOFT • The soft top storage bag is hooked up. •...

  • Page 55: Central Operation Of The Windows, 9-3 Convertible

    The following fuses should be checked if the soft top cannot be operated and no fault messages are shown by the SID: • MAXI-fuse 5 in the engine bay, see page 207. • 7, 14, 21 and 23 in the fuse panel on the end of the instrument panel, see page 208.

  • Page 56: Trunk, 9-3 Convertible

    Convertible Suspending top bag Trunk, 9-3 Convertible Hooking up top storage bag More space in the trunk can be obtained by lifting the top storage bag up by the straps under it and hooking them in the eyelets at the top of the bag. The top storage bag can only be hooked up in this way when the top is raised.

  • Page 57: Cleaning The Soft Top

    This applies to washes that have mechani- cal feelers in contact with the body- work. We advise against washing a Saab 9-3 Convertible in automatic car washes. • Park in the shade if possible. Long standing in strong sunlight can affect the color and material of the soft top.

  • Page 58: Interior Lighting

    Convertible Use mild soap, lukewarm water and a sponge for washing. Rinse the top thoroughly with plain water to get rid of all the soap. Flush the cleaning agent off the bodywork as well, since it can cause discoloration if it is left to dry on the paintwork.
  • Page 59 Instruments and controls Warning and indicator lights ... Instruments ... Trip computer SID... Switches ... Wipers and washers ... Manual climate-control system... Automatic climate control (ACC) ...

  • Page 60: Warning And Indicator Lights

    Instruments and controls Main instrument panel Main instrument panel 1 Tachometer 2 Indicator and warning lights 3 Speedometer 4 Indicator and warning lights 5 Pressure gauge 6 Fuel gauge 7 Engine temperature gauge 8 Trip meter reset button 9 Odometer and trip meter Warning and indicator lights A number of warning and indicator lights will...

  • Page 61: Instruments And Controls

    WARNING Never drive the car when these warning lights are on. Danger of brake failure! Have the brake system checked at once by an authorized Saab dealer. Instruments and controls Parking brake warning light The light will show when the parking brake is on (see page 168.)
  • Page 62 Now check the level again. If the level is still normal, you may drive the car, with considerable cau- tion, to the nearest authorized Saab dealer to have the brake system checked. WARNING • If the ABS is inoperative, there is a...
  • Page 63 While your car may be able to be driven with the CHECK ENGINE indicator light illuminated (limp-home mode), you are advised to have your car serviced at an authorized Saab dealer as soon as possible. Continued driving without this problem being corrected might cause serious fur- ther damage to your car and create unsafe driving conditions.
  • Page 64 Even if the fault persists, it is still possible in most cases to drive the car. Have the automatic transmission checked by an authorized Saab dealer as soon as possible. NOTE If the control module has actuated the...
  • Page 65 TCS is switched off by means of the TCS button. If a fault is indicated, have the system checked at an authorized Saab workshop. See also the section Traction Control Sys- tem, on page 166.

  • Page 66: Instruments

    Instruments and controls Instruments Tachometer The tachometer indicates the engine speed in thousands of revolutions per minute. The needle may be allowed to enter the broken red zone on the dial only for an instant. A safety cut-out function (in the fuel system) prevents the engine speed exceeding approximately 6,200 rpm (2.0 Turbo) and 6,400 rpm (2.3 Turbo).

  • Page 67: Temperature Gauge

    Temperature gauge The temperature gauge shows the temper- ature of the coolant. The needle should be in the middle of the scale when the engine is at normal operating temperature. If the needle enters the red zone, the warning light will come on and an alarm chime will sound.

  • Page 68: Fuel Gauge

    2.5 gal. (10 liters), a warning light on the main instrument panel will come on (see page 62). Use the Saab Information display (SID) to check the approximate distance that can be travelled on the remaining fuel (see page 69).

  • Page 69: Trip Computer Sid

    The driver’s attention can oth- erwise easily be distracted from the road. The car is equipped with SID (Saab Information Display). This instrument con- tains a varying number of functions depend- ing on the standard of equipment and the model variant.
  • Page 70 Instruments and controls Entering values for the functions Values can be entered for the following functions: SPD (SPEED AVERAGE , DIST, ARRIV, ALARM and SPD W. 1 Select the desired function using 2 Press the SET button for at least one second (figures start to flash and a chime sounds).
  • Page 71 Calculation of arrival time and average speed The settings must be made before the jour- ney is started. Calculation of arrival time: 1 Select DIST using the button. 2 Hold SET until display starts flashing. 3 Set the destination distance using 4 Press SET to store settings.
  • Page 72 Instruments and controls Calculating the requisite average speed: 1 Press to select DIST. 2 Hold the SET button for two seconds. 3 Set the distance to be covered using 4 Press SET to store settings. 5 Press to select ARRIV. 6 Hold the SET button for two seconds.

  • Page 73: Night Panel

    365 days have elapsed since the last service. The message should be cleared at the time of that service (see the Saab Warranties & Service Record Booklet). This message can also be deleted by first...

  • Page 74: Clock

    Instruments and controls Units and language versions The SID has four sets of units: METRIC IMP. 1 IMP. 2 miles miles miles km/h litres gallons gallons gallons °C °F °C °F 24 hours 12 hours 12 hours 12 hours CHECK messages can be displayed in six language options: English, Swedish, German, French, Italian and Spanish.

  • Page 75: Light Switches

    Switches Daytime running lights The parking lights and daytime running lights come on automatically when the igni- tion switch is in the ON position. Note to owners in the U.S.: If you do not want Daytime Running Lights, this feature can be disconnected: switch off the engine and remove fuse No.

  • Page 76: Hazard Warning Lights

    Instruments and controls Courtesy Headlamp Feature A delay function allows the headlights to remain on low beam for about 30 seconds after the driver’s door has been closed. To activate this function, • Switch off the ignition and remove the key •...

  • Page 77: Rear Fog Light

    Rear fog light Your Saab is equipped with one rear fog light and this is located on the driver´s side in the rear taillight housing. Press the button to switch on the rear fog light, which will only come on if the head- lights or front fog lights are on.

  • Page 78: Wipers And Washers

    Instruments and controls Instrument lighting The brightness of the instrument lighting can be varied by means of the dimmer switch adjacent to the headlight switch, the ignition switch shall be in position ON. (See also Night panel on page 73). In daylight or other equally bright light, the instrument and switch illumination is auto- matically extinguished.

  • Page 79: Rear-Window Wiper

    Control for setting wiper delay 1 Long delay 2 Short delay Rear-window wiper Rear-window washing and wiping are car- ried out using the same stalk switch as for washing and wiping the windshield and headlights. This stalk has two additional switches, ON/OFF and The ON position gives intermittent wiping.

  • Page 80: Manual Climate-Control System

    Instruments and controls Manual climate-control system The air is drawn in through an intake at the bottom edge of the windshield. It passes through an efficient filter before being routed through the climate-control system and into the cabin. The cabin discharge vent is located on the right behind the rear bumper.
  • Page 81 Defroster Floor incl. rear side windows Panel incl. rear center vent As the winter comfort setting we recommend that the distribution knob be turned two steps to the left from the Defroster position. Instruments and controls Settings for various weather conditions Winter - defroster Winter - comfort...
  • Page 82 Instruments and controls Air vent at rear side window Air conditioning (A/C) The air conditioning is combined with the conventional climate-control system and is switched on by pressing the button, provided that the fan control is in position 1-4. The incoming air is treated in three stages: first it passes through a filter;...
  • Page 83 Electrically heated rear window/external mirrors The button is located on the climate-control panel. An LED in the button is lit as long as heating is on. Switch off the heating as soon as the rear window is clear. It will go off automatically after about 10 minutes.

  • Page 84: Automatic Climate Control (Acc)

    Instruments and controls Automatic climate control (ACC) The air is drawn in through an intake at the bottom edge of the windshield. It passes through an efficient filter before being routed through the climate-control system and into the cabin. The cabin discharge vent is located on the right behind the rear bumper.
  • Page 85 1 Sun sensor 2 Interior-temperature sensor The system uses five sensors: • Outside-air temperature. • Cabin-air temperature. • Sun sensor. • Blended-air temperature (located in the heater unit). • Coolant temperature. The sun sensor is centrally located on the dashboard panel between the defroster nozzles.
  • Page 86 Instruments and controls Functions The function you have manually selected will be locked in, while other functions remain automatic. Temperature maintenance, except in positions HI and LO, is, there- fore always automatic. The active function is shown in the display. A manual selection is cancelled by pressing AUTO or by repeated pressing of the button used to make the manual choice.
  • Page 87 Button Display One touch: When Defroster is manually selected you will get demisting of all windows (the air flow to the rear side windows will be shut off) by high fan speed. Air will be routed to the defroster noz- zles.
  • Page 88 Instruments and controls Button Display Press simulta- neously Panel - floor (front and rear) and center rear vent Electrically heated rear window/elec- trically heated door mirrors are con- trolled automatically, though they can also be programmed for manual control; see ”Programming II”, page 91.
  • Page 89 Starting in cold weather: The automatic climate control system selects the defroster position, max. heating and low fan speed to begin with. As the engine temperature rises, the fan speed is increased and air is routed towards the floor. As the temperature inside the car nears the selected value, both the fan speed and the heat will be decreased to a level determined by the system.
  • Page 90 Instruments and controls Calibration If the battery has been disconnected or has run flat, the system will recalibrate automatically. Manual calibration: 1 Start the engine. 2 Press at the same time. The ACC display flashes once to indicate that calibration and self-testing have started. During calibration the display indicates the figure 0 or the fault codes (01-23) that have been found.
  • Page 91 Programming II It is also possible to customize the ACC system to adapt to driving and weather conditions. Function Operation in AUTO mode after Programming II The A/C compressor is not switched on until the out- side temperature goes above +55°F (+13°C). –...
  • Page 92 All manual selections are possible with the exception of electric rear window. Saab recommends leaving the ACC setting on ECON when the soft top is folded down to improve fuel economy and unnecessary running of the A/C compressor.
  • Page 93 Saab 9-3 Audio System Saab 9-3 Audio System Quick guide to the Saab 9-3 Audio System ... Sound controls... Radio ... CD player ... CD changer... General functions ... Steering-wheel controls .. Security lock... Technical data ... Fault codes ...

  • Page 94: Audio System

    Saab 9-3 Audio System Saab 9-3 Audio System The Saab 9-3 Audio System comes in two levels, Premium and Prestige. They are specially adapted to the cabin space in the Saab 9-3. The Saab 9-3 Audio System consists of a main unit with a radio and an in-dash CD player.

  • Page 95: Quick Guide To The Saab

    Quick guide to the Saab 9-3 Audio System Radio, see page 98 To switch the system ON, press the volume but- PUSH PULL ton. The last settings used will be activated. If the Audio System is switched on when the igni-...
  • Page 96 Saab 9-3 Audio System CD player. See page 100 Touch: change to CD playback when other sound source is active. Press and hold briefly (a chime will sound): random playback. Touch: SEEK at either end to change track. Press and hold briefly: fast playback or fast SEEK track changes.

  • Page 97: Sound Controls

    The Bass and Treble controls must be pressed first to release them. FAD - Fader The fader control adjusts the balance between the front and rear sets of speakers. The Fader control must be pressed first to release it. Saab 9-3 Audio System...

  • Page 98: Radio

    Saab 9-3 Audio System Radio Press the RADIO button to switch to the radio when another source is active. Preset station buttons (1) Press once (release within a second) to select a preset station, e.g. The small figure on the far right of the dis- play is the number of the preset button selected.
  • Page 99 Saab 9-3 Audio System find six stations with good reception, the remaining preset buttons will be empty. If one of these empty buttons is pressed, FM or AM**** will appear on the display. When the system leaves the AS mode, it returns to the station that was selected before the AS mode was activated.

  • Page 100: Cd Player

    Saab 9-3 Audio System CD player NOTE Do not use writable CDs in your audio system, as in certain cases these types of CD are only suitable for home use and can therefore cause operational prob- lems (overheating). To select the CD mode, load a CD into the deck or, if one is already loaded, press the CD/RDM button.
  • Page 101 Touch to repeat the current track during random playback. Pressing and holding start Rapid play. Saab 9-3 Audio System Eject (3) Touch to remove the disc. If you press the eject button to open the tray but fail to remove the disc, the CD player will...

  • Page 102: Cd Changer

    Saab 9-3 Audio System CD changer (accessory) NOTE Do not use writable CDs in your audio system, as in certain cases these types of CD are only suitable for home use and can therefore cause operational prob- lems (overheating). Important! Always keep the sliding cover...
  • Page 103 Press the button for the cor- responding CD. If the selected CD is already being played, playback will restart from the first track. Saab 9-3 Audio System If the selected CD-tray, e.g. 3, is empty, the following will appear on the display:...
  • Page 104 Saab 9-3 Audio System After two seconds, the status of the trays in the magazine (i.e. loaded or empty) will be shown on the display, e.g.: If for some reason the CD selected by the preset button cannot be played, playback of the current CD will continue.

  • Page 105: General Functions

    To change the volume setting: The default setting for this function is ON. – Press and hold the BAND button at the Saab 9-3 Audio System same time as you switch on the Audio System. – Select SP D VOL using –...

  • Page 106: Steering-Wheel Controls

    If a CD changer is to be installed or if you wish to move the main audio-system module and/or CD changer to another car (Saab 9-3), you must consult an authorized Saab dealer so that the modules can be given the correct security codes.

  • Page 107: Technical Data

    Crossover frequency _____________ • These specifications comply with the new IHF Standard • Since the policy at Saab is one of continual improvement, we retain the right to alter specifications and design without prior notice. Changes or modifications not expressly approved by the manufacturer for compliance could void the user´s authority to operate the equipment.
  • Page 108 (Convertible: pillar trims and header trims). These areas must not be modified in any way. Work on these areas must only be carried out at an authorized Saab dealer.

  • Page 109: Fault Codes

    NOTE Great care should be exercised in trying to rectify a fault. If you are at all unsure, contact an authorized Saab dealer. The Audio System has a built-in diagnostics function. If a fault is detected, a fault code is generated to help dealer technicians to diagnose the fault.
  • Page 110 Saab 9-3 Audio System (This page has been left blank)
  • Page 111 Using OnStar... OnStar is Easy... OnStar Services Button... Emergency button ... White dot button ... System status light ... The OnStar Center... Connecting to the OnStar center Your personal identification number (PIN) ... The OnStar Safety and Security Plan... Automatic notification of air bag deployment ...

  • Page 112: Using Onstar

    OnStar - Telematics Your new vehicle comes equipped with advanced telematics hardware and one full year of Onstar Premium Service. Saab Telematics is a sophisticated in-vehicle system allowing convergence of wireless communications, GPS (Global Positioning System) satellites and advanced vehicle electronics.

  • Page 113: Emergency Button

    OnStar system is operating prop- erly. If you cannot contact the OnStar Cen- ter, please take your car to the nearest Saab dealer for diagnosis and service. OnStar - Telematics The OnStar Center is the heart of your ser- vice —...

  • Page 114: The Onstar Center

    OnStar - Telematics The OnStar Center Connecting to the OnStar center In addition to using the 3-button system found in your Saab, there are two other ways to connect to the OnStar Center. Toll-Free Call To take advantage of your OnStar services...

  • Page 115: Roadside Assistance

    ATMs and airports — more than 250 service categories in all. OnStar advisors can even assist you with hotel and restau- rant reservations. *All Saab models come with one full year of Premium Service. New retail deliveries only.

  • Page 116: Concierge Services

    OnStar. Once you sign up for OnStar Personal Calling, you will be given your own personal phone number that others can use to call into your Saab. To sign up for Personal Calling, simply •...
  • Page 117 Receiving a Call If someone calls your wireless phone num- ber, the entertainment system in your Saab will mute (if it is on), and you will hear a phone ringing sound. To answer the call, simply press the White dot button.
  • Page 118 OnStar - Telematics Storing/Deleting Numbers in Memory (Nametags) Storing a number Your OnStar system can store up to 20 numbers (up to 32 digits each) in memory that can be dialed by simply repeating the ”nametag.” To store a number: 1 Press the OnStar will respond OnStar White...
  • Page 119 You will need your OnStar Personal Identi- fication Number (PIN) to authorize the charge to your credit card on file. If you are not in your Saab, you may call an OnStar Advisor at 1-888-4-ONSTAR (1-888-466-7827) to request unit replenish- ment.

  • Page 120: Virtual Advisor

    OnStar - Telematics Virtual Advisor Once you have activated Personal Calling, you can enjoy your time in your Saab even more with the OnStar Virtual Advisor. This service allows you to listen to your favorite news and information topics, such as weather reports, stock quotes and sports scores.

  • Page 121: Onstar Subscriber Website

    OnStar. You can also act like an OnStar advisor and pinpoint your Saab. To access the sub- scriber website, simply go to www.onstar.com, and then click on the OnStar subscriber link. The OnStar Sub- scriber website is a secured site that is password protected.

  • Page 122: Additional Information

    Your trust is what we most value. Transferring OnStar Because your OnStar 3-button system is an integral part of your Saab, it cannot be trans- ferred to another vehicle. Each OnStar system stays with the original car or truck in which it was installed.
  • Page 123 Interior equipment, trunk Interior equipment, trunk Seats ... Steering-wheel adjust- ment ... Electrical windows... Sunroof ... Interior lighting... Cup holder ... Ashtrays (accessory)... Glove compartment ... Rearview mirrors... Trunk, Coupé and 5-door Tools and spare wheel ... Manually opening the fuel filler door ...

  • Page 124: Seats

    Interior equipment, trunk Seats The following seat adjustments can be made to achieve a comfortable driving position: • Height (driver´s seat) • Legroom • Backrest rake angle • Lumbar support • Head-restraint height We recommend that adjustments to the driver’s seat be performed in the following order: 1 Height 2 Legroom...
  • Page 125 Adjusting the backrest 1 Catch, backrest (Coupé and Convertible versions) Backrest rake angle To find the most comfortable position, turn the knob to provide stepless adjustment of the backrest. WARNING The backrest should be upright during driving, so that the safety belt, airbag and backrest can provide optimum protection in the event of emergency braking or a crash.
  • Page 126 Interior equipment, trunk Manually adjustable front seats with ”Easy Entry” function, Coupé and Convertible versions Manual seats have a feature called ”Easy Entry”, which facilitates movement to and from the rear seat. Activate ”Easy Entry” as follows: 1 Raise the release lever and hold it in its uppermost position until the backrest is tipped forward.
  • Page 127 Electrically adjustable front seats (certain variants) WARNING The seats are actuated by powerful motors. Bear this in mind when adjusting the seat, and make sure that nothing gets caught and damaged. Bear in mind that children can be injured if they play with the electrically-operated seats.
  • Page 128 Interior equipment, trunk Backrest rake angle Push the rear lever forward or rearward to adjust the rake angle of the backrest. Memory function (certain variants) In some variants the electrically adjustable driver’s seat has a memory function. Three different settings can be programmed. 1 Make the desired adjustments to the seat setting.
  • Page 129 Interior equipment, trunk Electrically heated front seats (option on some model vari- ants/markets) Both front seats can be equipped with heat- ing for the seat cushion and backrest. It is switched on and off using the buttons on the instrument panel. The heating is thermostatically controlled.

  • Page 130: Electrical Windows

    Interior equipment, trunk Electrical windows WARNING • Bear in mind the pinch hazard when the side windows are being raised. Make sure that all passengers keep their heads, hands and fingers clear of the window openings before you begin raising the windows. Serious personal injury may otherwise be caused.

  • Page 131: Steering-Wheel Adjustment

    Child safety: rear windows (ON/OFF) The window switches on the rear doors can be rendered inoperative by the ON/OFF switch in the panel on the center console. When the switch is ON, the rear side win- dows can be operated by the switch on each rear door.

  • Page 132: Sunroof

    Interior equipment, trunk Sunroof WARNING • Bear in mind the pinch hazard when operating the sunroof. Make sure that all passengers keep their heads, hands and fingers clear of the opening before operating the sunroof. Serious personal injury may otherwise be caused.

  • Page 133: Interior Lighting

    1 Interior lighting is off 2 Lighting comes on when a door is opened 3 Interior lighting on continuously Interior lighting The interior lighting consists of one dome light in the front and one in the back. The switch for the interior lighting is on the over- head panel next to the rearview mirror.

  • Page 134: Cup Holder

    Interior equipment, trunk Sun visor with vanity mirror Cup holder in fascia Cup holder There are two cupholders, one in the fascia under the SID unit and one in the cen- ter-console compartment between the front seats on certain models. Next to the cup holder between the front seats is a coin tray.

  • Page 135: Ashtrays (Accessory)

    Front ashtray Ashtrays (accessory) The car can be equipped with two ashtrays. One is positioned low down on the dash and the other on the back of the center console. Open the front ashtray by lightly pressing on the front. Remove it by depressing the catch on the underside.
  • Page 136 Interior equipment, trunk In the doors Center console between the seats Front edge of front seats Center console on passenger side Front seat backrests...

  • Page 137: Rearview Mirrors

    Rearview mirror 1 Day position 2 Night position Rearview mirrors The rear-view mirror has day/night positions that can be selected by means of a knob beneath the mirror. Adjust the mirror for best vision in the day position and pull the tab on the bottom of the mirror toward you for the night position.

  • Page 138: Trunk Lid Lock

    Interior equipment, trunk Trunk, Coupé and 5-door WARNING When the back seat has been put back in place, make certain that the belt beam is locked firmly on both sides (the red warning tabs must go down). This is vital since the upper anchorages for the safety belts are located in the belt beam.
  • Page 139 4 Lower the entire backrest cushion by pulling this same handle (item 3) forward. At the same time, pivot the beam backwards. IMPORTANT: When you replace the belt beam using the handle (item 3), you must verify that it is properly locked and that the two red "warning tabs"...
  • Page 140 Interior equipment, trunk To provide more flexibility, the rear seat is divided so that you can lower the narrower (right) part separately. 1 Tilt the seat cushion forward by pulling the loop located between the backrest and the seat cushion. 2 Stand the seat cushion on end behind the front seats.

  • Page 141: Trunk

    Removing the parcel shelf 1 Open the trunk lid. 2 Unhook the rubber ties. 3 Lift the rear parcel shelf and pull it away from the guide pins in the front edge of the shelf support. Interior equipment, trunk Load opening (trunk pass through) A load opening is provided in the backrest so that you can carry long narrow objects.
  • Page 142 Interior equipment, trunk Tie downs Four tie downs for securing the load are fitted inside the trunk. Place the load as far in as possible. Trunk lighting To the left in the trunk is a light which goes on and off when the trunk lid is opened and closed.

  • Page 143: Spare Wheel

    Interior equipment, trunk Rear spoiler, Saab 9-3 Viggen. WARNING Saab 9-3 Viggen Coupé: Avoid placing your hands on the upper part of the rear fender when the tailgate is to be closed because of the risk of getting finger caught between the spoiler and the fender.

  • Page 144: Manually Opening The Fuel Filler Door

    2 Unscrew the retaining screws some- what and back them out through the screw holes, whereupon the lock motor will be released from the door. Have an authorized Saab dealer investigate the problem. Manually opening the fuel filler door, Con- vertible, see page 58.
  • Page 145 Ignition switch ... Starting the engine... Important considerations for driving... Refueling ... Engine Break-in Period... Manual transmission ... Automatic transmission . Cruise Control ... Braking ... Traction Control System Parking ... Economical motoring ... Starting and driving Starting and driving Driving in cold weather ...

  • Page 146: Ignition Switch

    Starting and driving Ignition switch The single lock used for both the ignition and gear/selector lever is in the center con- sole located between the front seats. Before you can remove the key, the car must be in reverse gear (manual gearbox cars) or the Parking (P) position (cars with automatic transmission).

  • Page 147: Starting The Engine

    (the LED on top of the dash stops flashing). • Start the engine. Try the other key. If it works, the trouble is in the first key. Call on an authorized Saab dealer for inspection and correction. Starting the engine WARNING • When starting the engine: –...

  • Page 148: Important Considerations For Driving

    Important considerations for driving The engine-management system in the Saab 9-3 is called Saab Trionic T7. The system manages the ignition, fuel injection and turbo boost pressure. The Trionic T7 system developed by Saab is an intelligent engine-management system designed to achieve optimum drive- ability under differing driving conditions.
  • Page 149 Saab 9-3 Viggen: The Saab 9-3 Viggen has a high-performance engine which means that a certain amount of care should be exercised, in particular when accelerating in the lower gears.

  • Page 150: Catalytic Converter

    (not running on all cylinders) and any loss of power or performance. At the first sign of a malfunction, reduce speed and take the car to an authorized Saab dealer as soon as possible. Engine-management system with catalytic converter...

  • Page 151: Fuel Filler Door

    Gasoline fuels are highly explosive. Only fuel from well-known oil companies should be used. All Saab gasoline engines can be driven on fuel of grade AON 87-93. For optimum performance we recommend: • AON 90 for 2.0 Turbo 185 hp.
  • Page 152 United States and Canada, but particularly in geographic areas and cities that have high carbon mon- oxide levels. Saab approves the use of such "reformulated" gasolines in its products, which help in reducing pollution from all...
  • Page 153 Engine malfunction (CHECK ENGINE) lamp , thus indicating a fault that must be checked by your Saab dealer, see page 63. NOTE: always observe the following two measures: • Make sure that the fuel filler cap is screwed on correctly before the engine is started.
  • Page 154 (MMT); ask your service station operator whether or not the fuel contains MMT. Saab does not recommend the use of such gaso- lines. If fuels containing MMT are used, spark plug life may be reduced and your emission control system performance may be affected.

  • Page 155: Engine Break-In Period

    Engine Break-in Period Pistons, cylinder bores and bearings need time to obtain uniform, wear-resistant sur- faces. If a new engine is driven too hard, this grad- ual process of bedding-in will not be possi- ble and the life of the engine will be short- ened.

  • Page 156: Automatic Transmission

    Starting and driving Automatic transmission WARNING • Make it a habit to keep your foot on the brake when selecting a drive position, to prevent the car from creeping for- ward (or backwards if reverse is selected). • The car must be at a standstill before P, R or N is selected.
  • Page 157 Indication of gear position on the main instrument panel The detent button on the selector lever has to be pressed before the selector can be moved between certain positions. Three modes for the automatic transmis- sion can be selected: Normal, Sport and Winter.
  • Page 158 If the problem was cured by changing the fuse or battery, you do not have to contact a Saab dealer. If the fuse blows again as soon as the Shift Lock feature is activated you should contact your Saab dealer.
  • Page 159 As the transmission fluid temperature increases, its useful service life is reduced. Contact an authorized Saab dealer (see also page 173). WARNING Remember to use engine-braking (selec-...
  • Page 160 Starting and driving Selector positions To shift out of the P position you must depress the brake pedal and the ignition must be OFF. The parking position (P) must only be selected when the car is at a complete standstill. The selec- tor lever is locked and the transmission is mechanically immobilized.
  • Page 161 If the gear selector lever is moved from position D to 1, a change-down to 3rd gear will occur at about 110 mph (180 km/h). A change-down to 2nd gear will occur at about 75 mph (120 km/h) and to 1st gear at about 40 mph (65 km/h). When position 1 is selected, all the other gears will be locked out.
  • Page 162 Starting and driving The SPORT and WINTER modes To select Sport mode, press the ”S” button on the selector lever when the selector lever is in position N, D, 3, 2 or 1. In this mode, gear changes will take place at higher engine speeds than in Normal mode, in other words, the transmission will shift up later and shift down earlier for the same throttle (accel-...

  • Page 163: Cruise Control

    Cruise Control WARNING • Do not use the Cruise-control system on wet or icy roads, in dense traffic or on winding roads • To prevent the system being activated inadvertently, set the control to OFF when you do not want to use the system For safety reasons (brake system func- tion) the brakes must be applied once,...

  • Page 164: Brakes And Braking

    New pads should be installed without delay. Brake pads should only be replaced by an authorized Saab dealer. To ensure optimum brake performance, it is recommended that you use only Saab original brake pads.
  • Page 165 ABS brakes WARNING • The additional safety afforded by the ABS system is not designed to allow drivers to drive faster but to make normal driving safer. • To stop as quickly as possible, without loss of directional stability, whether the road surface is dry, wet or slippery, press the brake pedal down hard without letting up (do not pump the...

  • Page 166: Traction Control System

    Starting and driving Traction Control System How the system works The traction control system (TCS) is designed to minimize wheelspin. This enables the car to achieve the best possible grip and, hence, maximum tractive effort, together with greater stability. The TCS system uses information from the ABS system’s wheel sensors to detect when the front (driving) wheels are rotating faster then the rear wheels.
  • Page 167 Starting and driving Turning the TCS off is switched on automatically when the engine is started. The system can be switched off manually by the TCS button, whereupon on the main instrument panel will come on. The TCS system cannot be switched off if the car is travelling faster than 35 mph (60 km/h).

  • Page 168: Parking

    P (Park)), and remove the ignition key. Lock the car. NOTE Saab 9-3 Viggen: The body design together with the relatively low ground clearance of the car means that great care must be taken during parking to avoid damage to the under part of the bumper.
  • Page 169 1 Pointing downhill and 2 Pointing uphill and against the curb against the curb – Turn the wheels into the – Turn the wheels away curb and edge the car for- from the curb and edge the ward until the wheels touch car back until the wheels the curb.

  • Page 170: Fuel Economy

    Starting and driving Economical motoring Factors affecting fuel consumption Fuel consumption is greatly affected by the general driving conditions, the way in which the car is driven and at what speeds, the weather, the state of the road, the condition of the car, etc.

  • Page 171: Driving In Cold Weather

    Increased consumption can indicate that something is wrong and that the car needs to be checked by an authorized Saab dealer. Practical tests on the roads have demon- strated that substantial savings in fuel con- sumption can be made if the above advice is heeded.
  • Page 172 Studded tires are not allowed in some countries. If winter tires are installed, the same type must be installed on all wheels. Your Saab dealer will be pleased to advise you on the best tires for your car. Remember that tires age. It may therefore...

  • Page 173: Towing A Trailer

    Use only the electrical trailer hitch connec- tor provided in the trailer hitch kit. Saab recommends: • Use a Saab original hitch kit attachment which is designed and tested by Saab. • Consult your Saab dealer for the right hitch kit for your car.
  • Page 174 Starting and driving Maximum recommended trailer weights for different gradients NOTE Saab 9-3 Viggen cannot be equipped with a trailer hitch because of the design of the body and chassis. Trailer weight Maximum recommended trailer weights for different gradients, for best comfort and driveability for manual and automatic cars, are shown in the drawing.
  • Page 175 ecommendations for driving in hilly terrain The following time limits are based on the capacity of the cooling system in warm weather, i.e. approximately 86 F (30 C). Gradient Maximum Maximum dura- of hill, % trailer tion, minutes weight, lbs. (kg) 3330 (1500) Unlimited 3330 (1500) 15 max.

  • Page 176: Driving With A Roof Rack Load

    220 lbs (100 kg). Note that the roof load is included in the car’s maximum permissible load (see page 235). Strong, sturdy roof carriers designed spe- cially for the car are available from your Saab dealer. Always secure the roof load safely.
  • Page 177 Installing the roof carriers (acces- sory) The carrier feet are marked with a top view of the car and an arrow indicating their positions. 1 Slip the plastic cover onto the adjustable foot of the carrier (the foot with a knob for tightening) to protect the paintwork during assembly.

  • Page 178: Driving With A Load

    Starting and driving Driving with a load The driving characteristics of the car are affected by the way it is loaded. • Place heavy loads as far forward and as low as possible in the trunk. • Secure the load to the tie downs, see page 142.

  • Page 179: Towing

    Driving with the trunk lid open Avoid driving with the trunk lid partly or fully open, since exhaust fumes can be drawn into the cabin. If you must drive with the trunk lid open, all windows and the sunroof (if fitted) must be closed and the cabin fan on at its highest speed setting.
  • Page 180 Starting and driving Rear towing eye Front towing eye, Saab 9-3 Viggen Saab 9-3 Viggen The front towing eye is stored in a storage bag beside the spare wheel. Remove the plastic cover with a screwdriver from the car’s toolkit, and screw in the towing eye.

  • Page 181: Jump Starting

    Starting and driving Jump starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your Saab. Follow the steps below to do it safely. WARNING Batteries can cause injury. They can be dangerous because: •...
  • Page 182 Starting and driving NOTE Ignoring these steps could result in costly damage to your vehicle that would not be covered by your warranty. Trying to start your car by pushing or pull- ing it could damage your vehicle, even if you have a manual transmission.
  • Page 183 You can suffer burns or be blinded. Use a flashlight if you need more light. Be sure the battery has enough water. The battery installed in your new Saab has filler caps. Be sure the right amount of water is there. Add distilled or boiled water if the level is too low.

  • Page 184: Driving Considerations With Compact Spare Wheel/Tire Fitted

    For long trips Before starting off on a long journey, it is advisable to have your car inspected by your Saab dealer. Obtain a few important items to take along on your journey such as spare bulbs, wiper blades, fuses, a Poly-V belt and the like.

  • Page 185: Car Care

    Car care Hood release handle ... Engine ... Engine bay ... Engine oil ... Transmission fluid ... Coolant ... Air filter ... Brake- clutch fluid and brake pads ... Power steering ... Battery ... Drive belt... Wipers and washers ... Wiper blades ...

  • Page 186: Hood Release Handle

    Car care Hood release handle The handle of the hood lock is located on the left under the instrument panel. Open the hood in the following way: 1 Pull the release handle. 2 The hood moves to the half-locked posi- tion and is stopped by a safety catch at the front edge.

  • Page 187: Engine Bay

    Car care Engine bay 1 Engine-oil dipstick 2 Brake-fluid reservoir 3 Power-steering fluid reservoir 4 Fuse box 5 Coolant reservoir 6 MAXI fuses 7 Washer-fluid reservoir 8 Battery 9 Drive belt 10 Air filter...

  • Page 188: Engine

    The gearbox, located on the right (viewed from the front), is integrated with the engine. Engine families Saab cars imported into the United States and Canada meet all applicable emission control standards. The engine family and appropriate tune-up specifications are iden- tified on a label affixed to the left front inner fender.
  • Page 189 ENGINE light in the main instrument illu- minates, the Trionic ECM has detected a problem. The car will continue to operate, but performance may be diminished. You should have your car checked by a Saab dealer as soon as possible. Car care ORVR (Onboard Refueling Vapor...

  • Page 190: Engine Oil

    Car care Engine oil Checking the fluid level Regularly check the oil level in the engine. Do this with the car standing on level ground with the engine warm, 2-5 minutes after it has been turned off. Take the dipstick out and wipe it off with a clean rag before carry- ing out the check.

  • Page 191: Manual Transmission

    Dextron III (synthetic fluid) auto- matic transmission fluid can be used. If so, the car should be taken to an authorized Saab dealer as soon as possible to have the reason for low fluid level corrected and orig- inal fluid installed.

  • Page 192: Coolant

    Top up as necessary with equal parts of clean water and coolant. Use only coolant approved by Saab. If the expansion tank is empty when coolant is added, run the engine to normal temper- ature and top up again, as necessary.

  • Page 193: Air Filter

    This type of coolant has a reddish colour and should not be mixed with other types of coolant. Saab Original coolant should be used all year round. Only use coolant approved by Saab.

  • Page 194: Brake- Clutch Fluid And Brake Pads

    Check that there are no leaks in the brake system. Changing of the brake fluid should be carried out by an authorized Saab dealer. The vehicle´s regular braking system is adjusted automatically, but the parking brake has to be adjusted manually. This...

  • Page 195: Power Steering

    Power steering WARNING Do not fill the power steering fluid to above the MAX mark. Too much fluid can result in leakage. Power steering fluid on hot engine com- ponents constitutes a fire risk. Check the level of the power-steering fluid in the reservoir regularly, in accordance with the service program.
  • Page 196 Car care Correct fluid level in the battery The liquid level in the car battery must be checked at regular intervals. NOTE Never use tap water to top up the battery. Use distilled or boiled water. Tap water contains salts and minerals that accelerate the corrosion of the battery elec- trodes, which can shorten the life of the bat- tery.

  • Page 197: Drive Belt

    Drive belt WARNING • Keep hands and clothing clear of drive belts when engine is running. • Always stop the engine before inspecting drive belts. • The fan can start even when the engine is switched off. NOTE Serious damage can occur to the car’s electrical system if an alternator lead is disconnected while the engine is running.

  • Page 198: Headlamp Wipers

    We recommend Saab washer fluid for cleaning. If poor wiper performance is experienced, clean the windshield with Saab washer fluid. This is particularly important if the car has been through an automatic car wash, as this sometimes leave a wax coating on the wind- shield.

  • Page 199: Washer Fluid

    LEVEL LOW" appears there is about 1.5 quarts (1.4 litres) left. Fill with quality washer fluid, available from your Saab dealer and follow the instructions on the package to reduce the risk of freez- ing. Note: If the reservoir is run dry and the car...

  • Page 200: Changing Bulbs

    Car care Changing bulbs WARNING Before changing a bulb in the engine bay, switch off the engine to avoid the danger of fingers and hands being injured by moving parts. The radiator fan can cut in even when the engine is switched off. NOTE Switch off the ignition before changing a bulb, to avoid possible short-circuiting.
  • Page 201 1 Retaining screw 2 Turn signal bulb Front turn signal bulb To change the bulb, the complete lamp unit has to be removed. 1 Loosen the screw (1). There is no need to remove it completely. 2 Carefully remove the complete lamp unit. 3 Grasp the two plastic tabs and turn the bulb holder counterclock- wise.

  • Page 202: Direction Indicators

    Car care Front fog lights 1 Slightly turn the bulb holder counter- clockwise. 2 Unplug the connector. 3 Remove the bulb. WARNING • Never crawl under a car that is supported only by a jack. • Use axle stands; for further informa- tion about jacking up the car, see page 216.
  • Page 203 Reversing lights and rear fog light 1 Open the hatch on the inside of the trunk. 2 Press down the plastic tab that secures the bulb holder. 3 Carefully pull the entire bulb holder out of the lamp unit. Replace the dead bulb. 4 When refitting the bulb holder, fit it in first at the lower edge.
  • Page 204 Replace the bulb holder in its bracket and refit the entire lamp unit. Other lighting If any other bulbs need changing, you are advised to take the car to an authorized Saab dealer.
  • Page 205 Bulb table No. Cap Wattage 60/55 Headlight Front fog light W1,2W Ashtray; cigarette lighter; warning light for safety belts P21W Rear fog light; reversing light P21/5W 21/5 Stop/taillight PY21W Direction indicator, front/rear Reading lamps, rear (Coupé and 5-door) R10W Dome light; trunk; glove compart- ment WY5W Side indicators (yellow bulb);...

  • Page 206: Fuses

    To avoid the risk of short-circuiting and/or fire breaking out in the electrical system, the following advice should be heeded: • Always consult an authorized Saab dealer before modifying or adding any electrical equipment. Failure to do so can result in the electrical system being damaged.
  • Page 207 If a fault occurs in any of these components, diagnostic faults codes are set in the rele- vant control module, which enhances fault diagnosis at the Saab dealer. The scan tool connector for fault diagnosis is located under the instrument panel on the...
  • Page 208 Car care Fuse holder on the end of the instrument panel Fuses No. Amp Function – – Stop lights, trailer Cabin fan, ACC Electrically heated rear window and rear-view mir- rors Direction indicators Cabin fan, A/C Trunk light; switch illumination; electrically powered radio antenna Electrically operated front seat, right 2 3 4 5 6...
  • Page 209 No. Amp Function Switch, manual A/C; soft top (Convertible) Direction indicators; Cruise Control Soft top (Convertible); telephone 7.5 Radio Central locking; amplifier 30 Control module, engine management system High beam flash; ACC Control module, engine management system Right parking light; license plate lighting Left parking light Reversing light;...

  • Page 210: Relays

    Car care Fuses and relays Fuse panel in engine bay Function – – Front fog lights Radiator fan, low speed Vacuum pump A/C-compressor Left low beam Right low beam Left high beam Right high beam 7.5 Headlight wipers – – –...

  • Page 211: Tires & Rims

    Alternative wheels and tires If you wish to fit other tires or wheels than those supplied with the car, consult your Saab dealer first as to the possibilities avail- able. Wheels/tires combinations that are not approved by Saab can negatively affect the car´s directional stability, steering and brak-...
  • Page 212 Your Saab dealer can advise you of to the correct size tire for your car (if different from the original size) and also supply Saab approved winter tires pre-mounted on steel or alloy rims. Tire quality grading (cars sold in U.S.)
  • Page 213 Uniform Tire Quality Grading (US) Quality grades can be found where applica- ble on the tire sidewall between tread shoul- der and maximum section width. For exam- ple: Treadwear 200 Traction AA Temperature A Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.

  • Page 214: Compact Spare Wheel

    Car care Date code Date code Tires should be regarded as perishable goods. As the tires age, the rubber becomes progressively harder, and the roadholding ability of the tires diminishes. This is partic- ularly true on winter tires. Tires now have a date-code marking for the year of manufacture.

  • Page 215: Changing A Wheel

    Spare wheel (under the carpet in the trunk), Saab 9-3 Viggen When changing a wheel, take the tool kit out first, then the spare wheel. NOTE To avoid damaging an alloy wheel with a flat tire, this can be placed outside up in the spare-wheel well but only while driv- ing to the closest workshop.
  • Page 216 1 Put the car in 1st gear (automatic trans- mission: move selector to the P position) and apply the parking brake. Saab 9-3 Viggen: The front and rear jacking points are located behind covers that must be removed. See page 217.
  • Page 217 Position for jack, Saab 9-3 Viggen. The front and rear jacking points are located behind covers that must be removed. Remove the covers by taking hold of the lower edge and pulling outwards. When replacing the covers, fit the catches along the top edge first and then press home the cover.

  • Page 218: Safety Belts

    Car care Removing the wheel cover Tightening sequence, wheel bolts Flat spotting All tires get hot, especially on long journeys or when the car is driven hard. After the car has been parked with hot tires and the tires have cooled down, a flat spot can form in the tire, where it is in contact with the ground.

  • Page 219: Upholstery And Trim

    In very warm, dry climates the leather may need more regular reconditioning. Recom- mended conditioner - Saab Leather Care Lotion. Do not use unknown harsh polishing agents, cleaning agents, sprays, coarse soap or hot water.

  • Page 220: Washing The Car

    Do not use gasoline as a cleaning agent or solvent when carrying out repairs or mainte- nance. Saab recommends the use of envi- ronmentally safe degreasing agents. Washing The bodywork must be washed frequently.

  • Page 221: Waxing And Polishing

    • Fixed antennas must be removed when going through an automatic car wash. • Saab 9-3 Viggen: If you wash the car in an automatic car wash, you must first remove the roof-mounted antenna, otherwise it will be damaged.

  • Page 222: Anticorrosion Treatment

    Car care Two-coat enamel As the name implies, two-coat enamel is applied in two operations. The first coat, the base color, contains the pigment, metal flakes and binder. The second coat consists of a clear enamel, which provides the final gloss for the paintwork and protects the base from moisture and environmental con- taminants.
  • Page 223 Drainage holes in doors What causes rust? Steel body panels of automobiles are sub- ject to rusting whenever air and moisture manage to penetrate the protective finish. Body panels may rust through if the process is unchecked. Rusting can occur wherever water is trapped or where the car’s panels are continuously damp.

  • Page 224: Recovery And/Or Recycling Of Automotive Materials

    While the Saab 9-3 was still at the draw- ing-board stage, Saab engineers were giving serious consideration to how the maximum quantity of materials could be reclaimed from the car on its eventual scrapping.
  • Page 225 1 A-pillar trim: PC/ABS. 2 Windshield trim: PP, PP/EPDM. 3 Seals: EPDM. 4 Rear-window casing PUR. 5 Trim panel ABS. 6 C/D-pillar trim PP. 7 Rear light cluster: PMMA. 8 Corner filler panel PPO/PA. 9 Rear bumper Expanded PP core PP/EPDM sheathing.

  • Page 226: Air Conditioning (A/C System)

    • All repairs and adjustments on the A/C system must be carried out by a Saab dealer authorized for this kind of work. • Never mix R134a and R12 refriger- ants.

  • Page 227: Headlight Aiming

    If your headlight is damaged in a crash, the headlight aim may be affected. If you believe your headlights need to be re-aimed, we recommend that you take it to your Saab dealer for service. However, it is possible for you to re-aim your headlights as described in the following procedure.
  • Page 228 Car care Open the hood and locate the vertical aim level (B) that you can see through the top of the headlight lens. If you find that the headlight needs adjust- ment follow these steps: 1 Locate the vertical aiming device (A) located behind and below the outer headlight assembly.
  • Page 229 Maintenance and owner assistance Maintenance and owner assistance Maintenance schedule... Owner assistance ... Reporting Safety Defects (U.S.A.) ... Reporting Safety Defects to the Canadian govern- ment ...

  • Page 230: Maintenance Schedule

    Maintenance schedule The Maintenance Schedule prescribes a service program to the purchaser/operator of a Saab that is reasonable and necessary to ensure the proper emission control sys- tems function, safety and reliability of the Saab automobile in normal use. Additional...

  • Page 231: Owner Assistance

    1-800-955-9007. In Canada, please call the Saab Customer Assistance Centre at 1-800-263-1999. A list of authorized Saab sales and service dealers is available for those planning to travel in the United States and Canada. Canadian or U.S. travelers may call the Customer Assistance Center in the country in which they are traveling.

  • Page 232: Reporting Safety Defects (U.s.a.)

    Two change of address cards are provided at the end of the Warranties and Service Record Booklet. Knowing your current address allows Saab to contact you in the event of a recall or service campaign. Please help us keep our records up to date for your own peace of mind.

  • Page 233: Technical Data

    Technical data Technical data General dimensions... Engine ... Engine oil... Fuel... Engine variants ... Electrical system... Drive belts... Manual transmission ... Automatic transmission .. Suspension... Steering... Brake system... Rims and tires ... Plates and labels...

  • Page 234: Maximum Loads

    Technical data General dimensions Overall length, with bumper(s): Coupé/5-door/Convertible____________ 182.3" (4629 mm) Viggen __________________________ 182.7” (4639 mm) Overall width, including door mirrors _____ 76.2" (1936 mm) Maximum height ____________________ 56.2" (1428 mm) Maximum height when the soft top is being operated (Convertible) ______________ Wheelbase ________________________ 102.6"...
  • Page 235 Weight ready for driving (i.e. with full fuel tank, washer- fluid reservoir, standard tools and spare wheel) Coupé ___________________________ 2980-3170 lbs. Viggen, Coupé ____________________ 3130-3160 lbs. 5-door ___________________________ 3020-3220 lbs. Viggen, 5-door ____________________ 3170-3210 lbs Convertible _______________________ 3110-3300 lbs. Viggen, Convertible ________________ 3250-3260 lbs. Gross vehicle weight (GVW) Coupé___________________________ Viggen, Coupé...
  • Page 236 Recommended towbar-ball load ______ Maximum towing speed, trailer with brakes __________________________ The above max. weights and speed limit are those which Saab Automobile AB permits. Note that the national rules may set lim- its to permitted weights and speed; see also page 173.

  • Page 237: Engine

    We recommend the use of oils that are available from your 16 valves and 2 bal- Saab dealer, for regular oil changes. These oils fulfill the most ancer shafts stringent requirements set by API and ACEA classifications. Basic recommendations for Saab engines •...
  • Page 238 Technical data Oil specification Oil for gasoline engines is classified by the API (American Pe- troleum Institute) and ACEA (European Automobile Manufac- turers Associations) standards. API classifies engine oil into grade classes SH (since 1993) and SJ (since 1996). The SJ class fulfils more stringent require- ments and has lower phosphorous level.

  • Page 239: Fuel Grade

    Fuel Fuel-tank capacity __________________ 17 U.S. gal. (64 l) For optimum performance, we recommend the following: 2.0 Turbo 185 bhp *) ________________ 90 AON, unleaded 2.0 Turbo 205 bhp and Viggen ________ 93 AON**), *) Offered in Canada only **) If the car is filled with 90 AON gasoline and the outdoor temperature is above 77-86°F (25-30°C), a slight decrease in engine performance may be noticeable.

  • Page 240: Electrical System

    Cars without A/C compressor __________ 1805 mm Drive belt Manual transmission Type _____________________________ 5-speed, fully Oil type (for topping-up) ______________ Saab synthetic man- Oil capacity _______________________ 1.8 qts. (1.8 l) Speed (mph/km/h) at 1000 rpm in 5th gear 26/42 Automatic transmission Type _____________________________ (0.03740”)

  • Page 241: Suspension

    Suspension Spring type, front and rear ____________ Coil springs Maximum deflection of springs: front, Coupé/5-door/Convertible _______ 6.4" (163 mm) front, Viggen ______________________ 6.5” (165 mm) rear, Coupé/5-door/Convertible _______ 8.3" (212 mm) rear, Viggen ______________________ 7.9” (200 mm) Dampers, front and rear ______________ Gas-filled tele- Steering Steering __________________________ Number of turns, lock to lock __________...

  • Page 242: Rims And Tires

    6.5 x 15________195/60 R15 (not Viggen) 6.5 x 16________205/55 R16 or 205/55 R16 M+S Max. speed is 30 mph (50 km/h). Consult your authorized Saab dealer of approved snow chains. NOTE 195/60 R15 M+S Coupé/5-door/Convertible: Bigger rims than 17” must not be used.

  • Page 243: Plates And Labels

    Plates and labels In contacts with your Saab dealer it may sometimes be necessary to quote the car’s chassis, engine and gearbox numbers. 1 Modification identity plate (in the spare wheel compartment). 2 V.I.N. number inside windshield. 3 Certification label.
  • Page 244 Y = Northern Europe ____________ 2 - Country _______ S = Sweden 3 - Manufacturer ___ 3 = Saab Automobile AB 4 - Product line ____ D = 9-3 5 - Model series ___ D = 9-3 with driver’s and passenger’s airbag...
  • Page 245 Several of the systems in your Saab car may be adjusted to better fit your individual needs Some functions are governed by legal requirements and cannot therefore be reprogrammed. Consult an authorized Saab dealer for fur- ther information. Car alarm/central locking system: •...
  • Page 246 Technical data Saab 9-3 Audio System: The following functions can be adjusted by the driver (see page 105): • Maximum starting volume (when the radio is switched on). • Telephone volume (if the car is equipped with a phone connected to the audio sys- tem).
  • Page 247 Index A/C system, fault diagnosis ________226 A/C system, maintenance _________226 ACC __________________________84 ACC, useful tips _________________92 Adjustment, steering wheel ________131 Air conditioning (A/C), fault diagnosis and maintenance ______________226 Airbag _________________________28 Alarm __________________________41 Alarm functions __________________44 Alarm signals ___________________44 Anti-corrosion treatment __________222 Anti-theft system _________________41 Ashtray _______________________135 Audio System ___________________93...
  • Page 248 Index Electrically adjustable seats _______127 Electrically heated front seats ______129 Electrically heated rear window _____83 Electronic starting interlock _________37 Emergency opening, fuel filler door _144 Emergency operation of the soft top, Convertible ____________________52 Emergency operation of the sunroof _132 Emission control systems _________188 Engine bay ____________________187 Engine bay, cleaning _____________220 Engine break-in period ______ 155...
  • Page 249 Running-in ____________________ 155 SAHR, head restraint ____________ 18 SID (Side Instrument Display) ______ 69 SRS (airbag) ___________________ 28 Saab Audio System ______________ 93 Saab Trionic engine management system ______________________ 189 Safety belts ____________________ 12 Safety belts, care of _____________ 218...
  • Page 250 Index Storage compartments ___________136 Sunroof _______________________132 Switches _______________________75 Tachometer _____________________66 Technical data __________________233 Telematics _____________________111 Temperature gauge ______________67 Textile carpeting, cleaning ________219 Through-load hatch ______________141 Tie-down eyes __________________142 Tipping the rear seat _____________138 Tire markings __________________212 Tire pressure ___________________178 Tire pressures __________________211 Tires and wheels, sizes ___________242 Tools _________________________143 Top tether ______________________23...
  • Page 251 Notes Notes...
  • Page 252 Notes...
  • Page 253 Notes...
  • Page 254 Notes...
  • Page 255 Notes...
  • Page 256 Notes...

This manual is also suitable for:

Saab 9-3 m2002

Table of Contents
