Model name:
RBC-AMS55E-ES
RBC-AMS55E-EN
• Read this manual before using the RBC-
AMS55E-ES, RBC-AMS55E-EN remote
controller.
• Refer to the Installation Manual supplied with the
indoor unit for any installation instructions other
than operations of the remote controller.
Installation Manual
Wired Remote Controller
English
Advertisement
Table of Contents
Related Manuals for Toshiba RBC-AMS55E-ES
Summary of Contents for Toshiba RBC-AMS55E-ES
- Page 1 Installation Manual Wired Remote Controller Model name: RBC-AMS55E-ES RBC-AMS55E-EN • Read this manual before using the RBC- AMS55E-ES, RBC-AMS55E-EN remote controller. • Refer to the Installation Manual supplied with the indoor unit for any installation instructions other than operations of the remote controller.
-
Page 2: Table Of Contents
Installation Manual Contents Precautions for Safety ........... . 2 Accessory Parts . -
Page 3: Precautions For Safety
Installation Manual Precautions for Safety • Read these “Precautions for Safety” carefully before installation. • The precautions described below include important items regarding safety. Observe them without fail. Understand the following details (indications and symbols) before reading the body text, and follow the instructions. -
Page 4: Accessory Parts
Installation Manual Accessory Parts Part name Quantity Screws M4 x 20 Wood screws M3.8 x 16 Owner’s Manual Installation Manual (This manual) CD-ROM – 3 –... -
Page 5: Installation
Installation Manual Installation Requirements to install the remote controller ◆ Installation place • Install the remote controller at a height of 1 to 1.5 m from the floor so that the average temperature in the room can be detected. •... - Page 6 Installation Manual ◆ Remote control wiring and inter-unit wiring between indoor units Do not allow the wire for the remote controller (communication wire) and the wire for AC220-240 V to come into contact or put them together in one electrical conduit; otherwise, the control system may have trouble due to noise. * Varies depending on the type of remote controller used.
-
Page 7: Install The Remote Controller
Installation Manual Install the remote controller NOTE • Wiring for the remote controller should not be bundled or installed in the same conduit with a power cable.; otherwise, malfunction may result. • Install the remote controller away from sources of electrical interference and electromagnetic fields. Wood screw x 2 Wall Rear case... -
Page 8: Wire The Remote Controller
Installation Manual Wire the remote controller Wiring diagram Terminal block for the remote control wiring on the indoor unit Remote control wiring (procured locally) Remote controller * Terminals of A and B Terminal block for have no polarity. the remote control wiring * Use wire of 0.5 mm to 2.0 mm... - Page 9 Installation Manual Basic wiring diagram NOTE Terminals of A and B have no polarity. To diverge from the indoor unit To diverge from the Header remote controller Remote controller Remote controller Remote controller Remote controller (Header) (Follower) (Header) (Follower) (Sold (Sold separately) separately)
-
Page 10: For First Use
Installation Manual For first use It takes some time before the remote controller becomes operable when the remote controller is used for the first time. This is not a malfunction. <When the power is turned on for the first time after installation> It takes about 5 minutes before the remote controller becomes operable. -
Page 11: Part Names And Functions
Installation Manual Part Names and Functions Room A 12:00 Cool Mode Fan Speed Temperature sensor ∨ MONITOR] button ] button Displays the monitoring screen. During normal operation: adjusts the temperature. On the menu screen: selects a menu item. MENU] button F1] button Displays the menu screen. -
Page 12: Monitor Screen
Installation Manual Monitor screen Check the current usage status. Push [ MONITOR] button. Room A 12:00 The monitor screen appears. Push [ CANCEL] button to return. Cool Mode Fan Speed Monitor (1) Displays the set temperature. (2) Displays the temperature measured by the indoor Set temp. -
Page 13: Initial Setting
Installation Manual Initial setting Push the [ MENU] button to display the menu screen. Initial setting(1/2) 1.Clock ∧ ∨ 2.Name of room Push the [ ] / [ ] button to select 3.Screen contrast “10.Initial setting”on the menu screen, then 4.Backlight 5.Key lock push the “... -
Page 14: Name Of Room
Installation Manual To adjust the clock Clock ∧ ∨ Push the [ ] / [ ] button to select “1. Clock” on the “Initial setting” screen, Month then push the “ Set” [ Year 2018 button. Hour Minute ∧ ∨ Push the [ ] / [ ] button to select... -
Page 15: Screen Contrast
Installation Manual B e d r o o “ ” To delete a character, highlight ABCDE Z & / : · uvwxy push [ MENU] button. FGH I J abcde z–+!? KLMNO f g h i j 12345 PQRST klmno 67890 UVWXY p q r s t... -
Page 16: Backlight
Installation Manual 4. Backlight Turn on or off the back light of the LCD. Initial setting(1/2) ∧ ∨ Push the [ ] / [ ] button to select 1.Clock “4. Backlight” on the “Initial setting” screen, 2.Name of room then push the “ Set”... -
Page 17: Key Lock
Installation Manual 5. Key lock Select whether to lock / unlock [ON / OFF], [ ], [MODE](F1) and [FAN SPEED](F2). Initial setting(1/2) ∧ ∨ Push the [ ] / [ ] button to select 1.Clock “5. Key lock” on the “Initial setting” screen, 2.Name of room then push the “... -
Page 18: Header/Follower
Return Note for the Header/Follower setting • Set the RBC-AMS55E-ES, RBC-AMS55E-EN remote controller as the Header remote controller when the dual remote controller system is used. • The RBC-AMS55E-ES, RBC-AMS55E-EN remote controller can be used as the Follower remote controller when the dual remote controller system is used that consists of two RBC-AMS55E-ES, RBC-AMS55E-EN remote controllers. -
Page 19: Language
] / [ ] button to select Return a language. Push the [ MENU] button. The screen text changes to the selected language. The factory default is English. These two screens appear for RBC-AMS55E-ES. Language(1/2) English French Français German Deutsch Spanish Español Portuguese Português... -
Page 20: Press & Hold 4Sec
Installation Manual 8. Press & hold 4sec. Set the “Press & hold 4 sec.” operation for the [ ON / OFF] button. ∧ ∨ Push the [ ] / [ ] button to select Initial setting(2/2) “8. Press & hold 4sec.” on the “Initial 6.Header/Follower setting”... -
Page 21: Clock Display
Installation Manual NOTE • When “Shift Time” is ON and the time in “Start Date” is reached, the time setting in the remote controller shifts by 1 hour, and when the time in “End Date” is reached, the time setting returns to the original time. •... -
Page 22: Field Setting Menu
Installation Manual Field setting menu Push the [ MENU] button to display the menu screen. Field setting menu(1/2) 1.Test mode 2.Register service info. Push and hold the [ MENU] button and 3.Alarm history ∨ the [ ] button at the same time to 4.Monitor function 5.Setting louver position display the “Field setting menu”. - Page 23 Installation Manual CAUTION Do not perform the forced test mode for purposes other than the test mode because it applies an excessive load to the devices. Field setting menu(1/2) ∧ ∨ Push the [ ] / [ ] button to select 1.Test mode “1.
-
Page 24: Register Service Info
Installation Manual Using the Service monitor with the [ MONITOR] button during the test mode Room A 12:00 Test Cool Mode Fan Speed Push the [ MONITOR] button Monitor function Code Data 0024 Return Refer to “4. Monitor function” (page 28) for details. When the group control is used, select the unit to monitor in the unit selection screen before displaying the monitoring display. - Page 25 Installation Manual Entering information manually Register service info. ∧ ∨ Push the [ ] / [ ] button to select 1.Service contact tel No. “2. Register service info.” on the Field 2.Outdoor model name setting menu screen. 3.Outdoor unit serial No. 4.Indoor model name Push the “...
- Page 26 Installation Manual Entering the model name and serial number Enter the model name and serial number manually for a Light commercial outdoor unit. Information data is loaded automatically for Light commercial indoor units, VRF indoor units (excluding large capacity air discharge type and duct type), and VRF outdoor units.
- Page 27 Installation Manual Outdoor model name ∧ ∨ Push the [ ] / [ ] button to select 1.Manual model name input “1. Manual model name input” on the 2.Model name selection “Outdoor model name” screen, then push Outdoor model name the “...
-
Page 28: Alarm History
Installation Manual Checking the model name or serial number The model name or serial number to be displayed on the Outdoor (Indoor) model name or Outdoor (Indoor) unit serial No. screen is displayed. Outdoor model name 1.Manual model name input 2.Model name selection Outdoor model name Appears here. -
Page 29: Monitor Function
Installation Manual 4. Monitor function The sensor temperature or operational status of indoor unit, outdoor unit, or remote controller can be monitored. Monitor function ∧ ∨ Push the [ ] / [ ] button to select “4. Monitor function” on the “Field setting Code Data menu”... -
Page 30: Setting Louver Position
Installation Manual 5. Setting louver position The louver indication setting can be changed. Setting louver position ∧ ∨ Push the [ ] / [ ] button to select 1.Fixed position indication “5. Setting louver position”, then push the / OFF “... -
Page 31: Setting Timer Operation Mode
Installation Manual 6. Setting timer operation mode Set the operation mode setting in the setting timer operation mode. Setting timer operation mode ∧ ∨ Push the [ ] / [ ] button to select Operation mode switching “6. Setting timer operation mode”, then push the “... -
Page 32: Dn Setting
Installation Manual 7. DN setting Perform the advanced settings for the air conditioner. Carry out the setting operation while the indoor unit is stopped. (Turn off the air conditioning unit before starting the setting operation.) DN setting ∧ ∨ Push the [ ] / [ ] button to select Code... -
Page 33: Reset Power Consumption Data
Installation Manual 8. Reset power consumption data Power consumption data saved in the remote controller can be reset. Reset power consumption data ∧ ∨ Push the [ ] / [ ] button to select “8. Reset power consumption data” on the “Field setting menu”... - Page 34 Installation Manual ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................– 33 –...
- Page 35 Installation Manual ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................– 34 –...
- Page 36 EH97069201...
