Refrigerator-Freezer
MODEL
MR-WX470F
OPERATING INSTRUCTIONS
R600a

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric MR-WX470F

Summary of Contents for Mitsubishi Electric MR-WX470F

  • Page 1 Refrigerator-Freezer MODEL MR-WX470F OPERATING INSTRUCTIONS R600a...
  • Page 2 Store food in the best way for consumption Place food and drinks in the compartments suitable for preserving them. Convenient functions can be easily set by simply touching icons on the operation panel. Refrigerator Compartment  Pages 12 - 13 Operation Panel to 6 About...

  • Page 3: Table Of Contents

    Contents (Pages) Safety Precautions …………………… 4-7 From Installation to Operation …… 8-9 Energy Saving Mode  Page 22 How to Use the Operation Panel … 10-11 ENERGY Refrigerator Compartment / Sliding Cases … 12-13 energy saving mode SAVING Safety Ice Making Compartment … 14-15 Supercool Freezing Compartment …...

  • Page 4: Safety Precautions

    Doing so may result in injury. If the power cord is damaged, purchase a new Do not use flammable sprays near the refrigerator. cord from MITSUBISHI ELECTRIC SERVICE Sparks from an electrical contact may cause an CENTRE or its service agent. Make sure that the power cord is designed for this model.
  • Page 5 If an abnormality or malfunction occurs, stop operation immediately and contact the retail store where you purchased the refrigerator or MITSUBISHI ELECTRIC SERVICE CENTRE or its service agent. Warning Caution When Using When Installing/Carrying the Refrigerator Do not use in a shed or garage.
  • Page 6 Safety Precautions (Continued)  If the power cord is damaged, contact MITSUBISHI ELECTRIC SERVICE CENTRE or its service agent for the replacement.  WARNING: fill with potable water only.  For Installation, Handling & Servicing of the appliance, please refer to section “From Installation to operation”, “How to Use the Operational Panel”...
  • Page 7 Safety • Thoroughly ventilate the room in which the appliance is located for several minutes. • Notify MITSUBISHI ELECTRIC SERVICE CENTRE or its service agent for necessary action and advice. • The room for installing the appliance must be at least 1 cubic metre per 8 grams of refrigerant.

  • Page 8: From Installation To Operation

    *The rear can be placed directly against If the power cord is damaged, purchase a new cord from MITSUBISHI ELECTRIC SERVICE CENTRE or its the wall. Leave some space if sound or service agent. Make sure that the power cord is designed stain is a concern.
  • Page 9 Adjustment and Anchoring (To prevent vibration, noise, movement, and doors left ajar) Turn the adjustable supports to the floor and anchor them so that the refrigerator will not move. Turn the adjustable supports in the Bottom front of refrigerator arrow direction until they touch the floor.

  • Page 10: How To Use The Operation Panel

    How to Use the Operation Panel will cause the operable icons to light up. Touching To save power, all displays other than are usually turned off (it turns off if there is no operation for about 30 seconds). When operating, be sure to touch the buttons with your fingers. ECO GUIDE Detail Setting The refrigerator's ECO level is...
  • Page 11 Operation Example (When Setting Supercool Chilling) Touch When you keep the door of the refrigerator open, touch for about 1 second. (until the buzzer sounds once) Operable icons light Detail Setting Touch the icon to set Pages 23 - 27 Here touch The text above the touched icon lights up.

  • Page 12: Refrigerator Compartment / Sliding Cases

    The height can be changed Uses 6 LEDs. upward and downward. If the interior light is damaged, contact MITSUBISHI ELECTRIC Slide Glass Shelf (Front) (Back) SERVICE CENTRE or its service agent for the replacement, in order to avoid a hazard.
  • Page 13 Sliding Cases At the time of purchase, the lower case is not set to Supercool Chilling. When setting Supercool Chilling, use the following settings. Upper Case Lower Case • Processed food such as sausage, ham and dairy Supercool Chilling can be set with products can be preserved.

  • Page 14: Ice Making Compartment

    Compartment Introduction Ice Making Compartment If water is put into the refrigerator compartment's water tank, ice will be made in the ice making compartment. Clean the ice maker periodically to ensure that the ice is pure and delicious.  Pages 28 - 29 Water Tank Tank Cap (About 1.2L)
  • Page 15 Quick Ice Making Rapid Ice RAPID (Quick Ice Making) The ice making time for a single batch can be shortened. Touch on the operation panel Repeatedly touch to display  Pages 23 - 24 RAPID Repeatedly touch to light up The display changes each time the button is touched.

  • Page 16: Supercool Freezing Compartment

    Compartment Introduction Supercool Freezing Compartment The supercool freezing compartment can be switched between “Soft-Freezing” and “Freezer.” Placing food in the supercool freezing compartment and using “S-COOL FREEZE” or “HOT FREEZE” mode allows food to be frozen without losing its taste and texture. Soft-Freezing / Supercool Freezing ...
  • Page 17 To Use Supercool Freezing on Hot Cooked Foods such as Freshly Cooked Rice, Curry, and Sauces Hot or warm cooked foods such as freshly cooked rice, curry, and Hot Freezing sauces can be deliciously frozen. It can also be used to cool the food just after cooking. Place food in the supercool freezing compartment before setting.
  • Page 18 Freeze foods with their original flavors. The frozen foods do not have to be thawed before being consumed. Food can be frozen, while preserving its taste and texture. Significantly reduces dripping Things unsuitable for freezing such as Freshly cooked rice can during thawing and the loss potatoes and bamboo shoots can be also be frozen while hot...

  • Page 19: Soft-Freezing / Supercool Freezing

    Soft-Freezing / Supercool Freezing Handy Tricks for Supercool Freezing Can preserve for 2 to 3 weeks Raw food that is difficult to cut Make meals quickly when you are busy Plus it is easy to use can be easily cut in the morning Whitebait Lemon Slices...
  • Page 20 Soft-Freezing / Supercool Freezing (Continued) Easy Dessert Recipes with Supercool Freezing Strawberry and Kiwi Fresh Jam Ingredients (For an easy-to-make amount) Strawberries 1 Pack (About 300g) Kiwis 4 to 5 (About 300g) Sugar 60g to 100g (Respectively for the strawberries and for the kiwis) Procedure 1 Remove strawberry stems and peel off kiwi skin.

  • Page 21: Freezer Compartment

    Eat vegetables when they are as fresh as possible. * 1 If the orange LED is damaged, contact When a door is open, MITSUBISHI ELECTRIC SERVICE Vegetable Case you will be informed Keep Vegetables Moist CENTRE or its service agent for the with the door alarm.

  • Page 22: Energy Saving Mode

    Energy Saving Mode This mode learns each family's method of use and operates with the optimal state for each compartment. An appropriate timing is selected for each compartment and Energy the energy saving mode is performed automatically with a slightly high temperature setting. Saving To Set Mode...

  • Page 23: Performing Temperature Adjustment

    Detail Setting Performing Temperature Adjustment The temperature of each compartment can be adjusted. Use the refrigerator, freezer, and vegetable compartments set to "M" usually. Use the supercool freezing compartment in your preferred setting. This is displayed when setting the temperature of the supercool Temperature Adjustment freezing compartment.
  • Page 24 Detail Setting Performing Temperature Adjustment (Continued) Ice Making Compartment Settings Vegetable Compartment Temperature Settings The display changes each time is touched. The display changes each time is touched and temperature can be set to 5 different levels to keep vegetables moist. Operation Panel Application Compartment...

  • Page 25: Rapid Cool

    Detail Setting Rapid Cool When storing a large amount of food, protect the food's freshness by rapidly cooling it. When set: Blinking  Light on When cancelled: Light on Blinking  Rapid Cool Swiftly cool compartments (Refrigerator, Freezer, and Vegetable Compartments). when their doors are opened and closed To Set...

  • Page 26: Power Save Mode

    Detail Setting Power Save Mode The cold air in unused compartments is saved, allowing energy to be positively saved. Power Save Mode This function reduces freezing 2 3 4 3 capability of the ice making Blinks while being set. compartment and supercool After setting is completed, freezing compartment for the it lights up.
  • Page 27 Food that Can be Stored in Power Save Mode In Power Save Mode, food will be preserved between about -10°C and 0°C, so it is well suited to the preservation of foods such as dry goods and grains. Dry goods……......Coffee beans, seaweeds, nuts, dry noodles (pasta, vermicelli, fine noodles, etc.) etc. Seasonings……......Salt, sugar, spice powder, etc.
  • Page 28 Tank Cap Cleaning the Automatic Ice Maker To prevent the growth of limescale and mold, clean periodically. Do not use a dishwashing machine, because it may deform the parts. Tank Pipe Do not use the following for cleaning ・Items such as sponges or scrubbers that may Water Supply Pump Water Tank damage surfaces...
  • Page 29 Water Supply Pipe and Tank Holder Ice Tray Once a month 1 to 2 times a year Before cleaning, make sure to set "Stop Ice Pull out the water supply Water 　　　　　　　　　　　 Pages 23 - 24 Making." pipe and wipe the tank Supply Pipe holder with a clean cloth.

  • Page 30: Cleaning

    Cleaning Removing and Cleaning the Parts Remove the power plug before cleaning. Do not disassemble, repair, or alter. Otherwise an electric shock or injury may result. Do not use while parts are damaged. Doing so may cause injury, electric shock, or fire. Remove plug Prohibited * After cleaning, wait at least 10 minutes before reinserting the power plug into the socket.
  • Page 31 When attaching parts, use the backward procedures of removal. Glass Shelf Slide Glass Shelf (Front) (Back) 1 Lift the front of the shelf using both hands. 1 Slide out the projections on the front and back of the 2 Pull out to the front. slide glass shelf (front) along the grooves.
  • Page 32 Cleaning Removing and Cleaning the Parts (Continued) Lower Case Upper Case / Upper Case Cover 1 Fully pull out the lower case. 1 Lift up the upper case cover. 2 Lift the lower case out to the front. 2 Press on the tip of the  on the right side while pushing the upper case cover to the left to flex it and remove it.

  • Page 33: Other Issues

    Other Issues (Power Outages, Child Safety Lock, Setting Reset, When Lights Up) Power Outages  Minimize the frequency of opening the doors, and avoid adding more food.  Operation panel settings other than the temperature settings may change. Check the settings. (Child Safety Lock, etc.) To Prevent Accidental Button Operation (Child Safety Lock)

  • Page 34: Alarm Sounds

    Other Issues (Door Alarm, Mark, When Not Using the Refrigerator for a Long Time) When the Door Alarm Sounds and the Interior Light of the Refrigerator Compartment Blinks (Door Alarm) The door alarm (with alarm sound, interior light, and compartment display) is activated when a door is open for 1 minute or longer.

  • Page 35: To Move Or Carry The Refrigerator

    Other Issues (To Move or Carry the Refrigerator) To Carry the Refrigerator Empty any water or ice from the water tank, ice tray, and ice storage  Pages 28 - 29 box. Wear protective gear (gloves). Remove the adjustable support cover, and then rotate and raise the adjustable supports.

  • Page 36: To Control The Temperature More Precisely

    Other Issues (Temperature Fine Adjustment Mode) To Control the Temperature More Precisely (Temperature Fine Adjustment Mode) The temperature can be set to 19 different levels for the refrigerator compartment and freezer compartment, while it can be set to 24 different levels for the supercool freezing compartment (5 levels when set to Soft- Freezing and 19 different levels for Freezing).

  • Page 37: Troubleshooting

    Troubleshooting Before contacting MITSUBISHI ELECTRIC SERVICE CENTRE or its service agent or making a repair request, check the following. If the problem persists, contact the retail store where you purchased the refrigerator as soon as possible. Frequently asked questions in the initial period and in summer In Supercool Freezing Compartment...
  • Page 38 Troubleshooting (Continued) Problem Check Explanation and Action Overcooling Is the temperature setting of supercool Set the temperature of supercool freezing compartment to  Pages 23 - 24 freezing compartment set to “FRZ•H”? “FRZ•L” or “FRZ•M”. in the freezer compartment, though the temperature setting of freezer compartment...
  • Page 39 Problem Check Explanation and Action Cannot make ice Has enough time passed after It takes 4 to 5 hours for the refrigerator to cool, and installation? 24 hours or more in summer to make ice. Water in the tank Has food, the ice server, or another Remove food or other objects from the ice storage box.
  • Page 40 Troubleshooting (Continued) Problem Check Explanation and Action The operation lit? Cancel the Child Safety Lock. panel does not  Page 33 respond Are the user's fingers or the operation Wipe off the moisture and dirt on the operation panel and panel wet or dirty? fingers.

  • Page 41: Specifications

    Specifications  T his appliance is designed for use in Model MR-WX470F Compartment type Volume (Litres) Australia and New Zealand only and Refrigerator Fresh food cannot be used in any other country. No compartment (R) compartment servicing is available outside of Australia...

  • Page 42: Accessories

    Accessories Model MR-WX470F Parts Quantity Glass Shelf Slide Glass Shelf (Front) Slide Glass Shelf (Back) Upper Case Cover Upper Case Lower Case Water Tank (with Chlorine-Cleaning Filter) Adjustable Pocket (Large) Adjustable Pocket (Short, Large) Adjustable Pocket (Small) Adjustable Pocket (Short, Small)
  • Page 43 MEMO...
  • Page 44 If an abnormality or malfunction occurs, stop operation immediately and contact the retail store where you purchased the refrigerator or MITSUBISHI ELECTRIC SERVICE CENTRE or its service agent. SOLE AGENT in Australia SOLE AGENT in New Zealand MITSUBISHI ELECTRIC AUSTRALIA PTY LTD.
