U-Line UHWC024 User Manual & Service Manual page 30

USER GUIDE
Parts
1
2
24
18
29
12
17
11
27
13
23
26
4
3
6
10
5
Parts
7
16
8
15
25
9
19
1 ANTI TIP BRACKET
2 BACK PANEL
3 COMPRESSOR ELECTRICALS
4 COMPRESSOR
5 CONDENSER ASSY
6 CONDENSER FAN
7 DISPLAY ASSEMBLY W/OVERLAY
8 DOOR ASSEMBLY
9 DOOR GASKET
10 DRAIN PAN
11 DRIER
12 EVAPORATOR ASSY
EVAPORATOR FAN WITH COVER &
13
SCREWS
14 EVAPORATOR COVER
15 GRILLE ASSY
16 HI TEMP THERMISTOR
17 HINGES
18 LED LIGHT STRIP & COVER
14
19 LEG LEVELERS ( 4)
20 MAIN BOARD/DISPLAY, BLACK
21 PACKAGING*
22 POWER CORD*
23 RACK ASSY
24 REED SWITCH
25 ROCKER SWITCH
26 SLIDE ASSY
20
27 THERMISTOR
28 WIRE HARNESS*
29 WOOD FRONT
* Not Pictured
30
UHWC024-SG01A
80-54239-00
80-54204-00
80-54150-00
80-54149-00
80-54801-00
80-54014-00
80-55594-00
80-55593-00
80-54213-00
80-54217-00
80-54055-00
80-55422-00
80-54151-00
80-55550-00
80-55597-00
80-54070-00
80-55595-02
80-54000-00
80-54019-00
80-55610-00
80-54209-00
80-55424-00
80-54269-00
80-54284-00
80-55603-00
80-54219-00
UNLESS OTHERWISE SPECIFIED 80-54006-00
ALL DIMENSIONS ARE IN INCHES
80-55424-00
REMOVE BURRS AND SHARP EDGES 80-54283-01
INTERPRET DIM AND TOL PER
DO NOT SCALE DRAWING
MODEL
CHECKED BY
u-line.com
