Introduction
Truck
Introduction
Dear user,
This manual provides the user of the Spierings folding crane SK375-AT3 with information concerning the truck's
construction, function and operation. Also detailed, technical descriptions and maintenance instructions are given in
the maintenance section of this manual.
SPIERINGS MOBILE CRANES
P.O. Box 24
5340 AA OSS
The Netherlands
Merwedestraat 15
5347 KZ OSS
The Netherlands
Fax +31 412 67 12 20
Phone number daytime:
Phone number evening time:
www.spieringscranes.com
© 2014 Copyright Spierings Mobile Cranes. All rights reserved.
No part of this publication may be reproduced or published, in any form or in any way, by print, photo print, microfilm or any other
means without prior permission from the manufacturer.
+31 412 69 77 77
+31 655 78 24 85
SPIERINGS MOBILE CRANES USER MANUAL V 0.0
