Sirena FieldServer FS-X20 Series Startup Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This manual provides instructions for the following FieldServer products:
FS-X20 Series
The instructions are effective for the above as of February 2005
All manuals and user guides at all-guides.com
FieldServer Technologies
A Sierra Monitor Corporation Company
1991 Tarob Court, Milpitas, California 95035 USA
Phone: (408) 262-2299
Toll Free: (888) 509-1970
Fax: (408) 262-2296
Email: support@fieldserver.com
Web Site: www.fieldserver.com
FS-X20 Series
FS-X20 Start-up Guide
APPLICABILITY & EFFECTIVITY
Description
FieldServer
Applicability and Effectivity
Instruction Manual Part Number: T17005
Rev. D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FieldServer FS-X20 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sirena FieldServer FS-X20 Series

Summary of Contents for Sirena FieldServer FS-X20 Series

  • Page 1 All manuals and user guides at all-guides.com FieldServer Technologies A Sierra Monitor Corporation Company 1991 Tarob Court, Milpitas, California 95035 USA Phone: (408) 262-2299 Toll Free: (888) 509-1970 Fax: (408) 262-2296 Email: support@fieldserver.com Web Site: www.fieldserver.com FS-X20 Series FS-X20 Start-up Guide APPLICABILITY &...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com FS-X20 Series FieldServer Start-up Guide Table of Contents TABLE OF CONTENTS PRE-INSTALLATION CHECK LIST ................2 1.1. Supplied equipment ....................2 1.2. Start-up........................2 PRODUCT DESCRIPTION ..................... 3 2.1. Specifications......................3 2.2. Mounting ........................3 2.3.

  • Page 3: Pre-Installation Check List

    All manuals and user guides at all-guides.com Start-up guide 1. Pre-Installation Check List Driver Manual(s) Utilities manual. • 1.1. Supplied equipment power socket mates with • The following components are supplied: pluggable terminal block, connector, that FS-X20 Series FieldServer, loaded with •...

  • Page 4: Product Description

    All manuals and user guides at all-guides.com Start-up guide 2. Product Description 2.1. Specifications Power requirements (power supply is external) X20 power supply P/N 69155 Input voltage: 9-30VDC, 8W; 24VAC Floating. Voltage variation of ±10% tolerated. Output voltage / current: 24VDC @ 0.5A Physical Dimensions(excluding the external power supply) (WxDxH): 3.82 x 4.08 x 1.7 inches (9.70 x 10.36 x 4.31 cm)
  • Page 5 All manuals and user guides at all-guides.com Start-up guide INPUT: Serial Power OK 9-30Vdc,1A FieldBus Active 24Vac, 50/60HZ, 1A Class 2 (LPS) Frame Ground EIA232 Ethernet EIA485 Figure 2-1: Diagram of FS-X20 showing Connection Ports INPUT: 9-30Vdc,1A 24Vac, 50/60HZ, 1A Class 2 (LPS) Frame Ground FieldServer...

  • Page 6: Supplied Connector Kit (Fs-8915-11)

    All manuals and user guides at all-guides.com Start-up guide 2.4. Supplied Connector Kit (FS-8915-11) In order to facilitate RS-232 communications on the RJ-45 RS-232 port, a connector kit is supplied containing one of each of the connectors shown in the diagram below. The tables in the diagram show the functions applied to each of the RJ-45 pins by the FieldServer to assist in determination of the required pinout configuration for connection to the third party device.
  • Page 7 All manuals and user guides at all-guides.com Start-up guide Note: FS-X20 Series RS-232 numbering convention is reverse to the 10BaseT numbering convention. RJ45 Female Modular Jack RJ45 M ale M odular Jack Figure 2-5 RS-232/Cat 5 Wire Functions/Connections PIN DESCRIPTION From DCE To DCE Frame Ground Transmitted Data...
  • Page 8 All manuals and user guides at all-guides.com Start-up guide Serial FS-X20 RJ45 Male Modular Jack ORANGE/WHITE (RJ45-08) BROWN (RJ45-01) FS-8917-16 BLUE/WHITE (RJ45-04) Figure 2-8: - RS-485 Connection pinouts on the serial RJ45 port. Page 7 FS-X20 Series FieldServer Start-up Guide (07-2005)

  • Page 9: Operation

    All manuals and user guides at all-guides.com Start-up guide 3. Operation Confirm that there is an Ethernet • adapter installed in the PC’s Device Manager List, and that it is configured to 3.1. Install and Run the Utility run the TCP/IP protocol. Software If using Windows XP, ensure that the •...

  • Page 10: Change The Configuration File To Meet The Application

    All manuals and user guides at all-guides.com Start-up guide 3.6. Change the Configuration File Note: Wait until the utility indicates • that download is complete before to Meet the Application resetting the FieldServer or you Refer to the Configuration Manual in could corrupt the FieldServer.

  • Page 11: Appendix A. Limited Warranty

    All manuals and user guides at all-guides.com Start-up guide Appendix A. Limited Warranty FieldServer Technologies warrants its products to be free from defects in workmanship or material under normal use and service for two years after date of shipment. FieldServer Technologies will repair or replace without charge any equipment found to be defective during the warranty period.

  • Page 12: Appendix B. Led Functions

    All manuals and user guides at all-guides.com Start-up guide Appendix B. LED Functions Configuration Error Serial Power OK FieldServer Running Comm Error FieldBus Active Hot Standby Active System Error Node Offline IP Request EIA232 Ethernet EIA485 Light Description This light relates to the Ethernet network port provided on the FieldServer. The Ethernet Link OK light shows steady green when the physical connection to the network hub is healthy.
  • Page 13 All manuals and user guides at all-guides.com Start-up guide THIS PAGE INTENTIONALLY LEFT BLANK. Page 12 FS-X20 Series FieldServer Start-up Guide (07-2005)
