- Page 1 For Our Home Energy Independence. www.huayu-solar.com info@huayu-energy.com Huayu(Ningbo)New Energy Technologies Co., Ltd.
-
Page 2: Table Of Contents
4.3 The Working/Warning/Fault Code Explanation 1.1 Validity 1.2 Target Group 5. Start UP and Shutdown 1.3 Storage of the Manuals 5.1 Start-UP the HYH-3.6K-AC System 1.4 Additional Information 5.2 Shutdown the HYH-3.6K-AC System 1.5 Safety 1.5.1 Symbols Explanation 6. Troubleshooting& Maintenance 1.5.2 Safety Warning... -
Page 3: About This Manual
It calls attention to a procedure or practice, which, if not correctly performed or adhered to, could result in damage to or destruction of part or all of Huayu New Energy equipment and/or other equipment connected to the Huayu New Energy equipment or personal injury. -
Page 4: Safety Warning
LCD operation, monitoring website or the APP. output of the HYH-3.6K-AC. As the HYH-3.6K-AC used with PV inverters in the system, so the PV inverters are of important loads. (Notice that it's required to enable the... -
Page 5: Installations & Connection
3. Installations & Connection Forbidden System Connections 3.1 Packing List HYH-3.6K-AC HYH-3.6K-AC HYH-3.6K-AC Please check to make sure all the components as below are in good condition. USER MANUAL Battery EPS side can’t connect to Grid Without the micro-grid mode version hardware and firmware, EPS side should not be paralleling connected. -
Page 6: Product Overview And Connection Overview
Lithium Battery Battery RS485/CAN Grid DIP1 Battery Input + 1 2 3 4 5 Inverter HYH-3.6K-AC GT Mode Communication Port DIP2 1 2 3 4 5 Battery Input - Lead-acid Battery NTC DRMS Inverter Interface DRMS Input (Only for Australia) This diagram is for Australian and New Zealand grid system 3.2 Installation... -
Page 7: Clearance Requirements
Step1: Position the machine's probably size onto the wall; the thickness of wall for HYH-3.6K-AC at least 60mm. Step2: Drill four Ф8 holes at the marked point, the depth is not less than 50mm... - Page 8 Push threaded sleeve on to connection terminal Assemble the AC connector and make sure until both are locked tightly that the rib of the terminal block and the groove on the housing engage perfectly. M6 Explosion screw Step4: Mount the inverter onto the four explosion screws Step5: Lock the nut of setscrew and finish the inverter installation.
-
Page 9: Wiring The Whole System
(+) of the inverter, 2.As the HYH-3.6K-AC used with PV inverters in the system, so the PV inverters are connect negative pole (-) of battery cable to creating residual current too, in order to prevent unwanted triggering during operation, battery negative terminal (-).mind that the OT... - Page 10 Rubber stopper Cable gland...
-
Page 11: Install Wifi Module
Step2 Remove 3 plug-columns from the rubber Step1 Unscrew the swivel nut from the cable gland Step7: If lithium battery connecting the Battery communication cable the side with label of “Battery”(lithium stopper and others reserved battery ) to the lithium battery communication port .If lead-acid battery, just let the NTC near the lead-acid Waterproof cover battery surface. -
Page 12: Display, Setting And Operation
Display the grid information of voltage, frequency, input or output power, switch period of 1s Working mode settings area When make settings on the Huayu AC-coupled inverter through the LCD, this area will display the AC Charge, Force Discharge, Charge First option for setting on those working modes. -
Page 13: Start The Settings
Enter button to start the settings on selected setting options. 4.2.3 Time Settings To set the time of the Huayu AC-coupled inverter, please follow below steps: Set the Day: When finished the months setting then the day number will flashing, press UP and Down buttons to change the day number, and press Enter button to confirm and finish the day setting. -
Page 14: Battery Settings
4.2.4 Battery Settings For Lithium-ion Battery: Select the Li-ion option and press Enter button to confirm the battery type, then the battery brand area will Press Return button, then press UP or Down buttons to select area ③ (when area ③ is flashing), then press Enter flashing, press UP and Down button to select the battery brand number ( see the list battery brand number button to start the battery settings. -
Page 15: Ac Charge Settings
Press Return button to get into setting mode, then press UP and Down button to select the area ⑤ 4.2.6 AC Charge Settings (when area ⑤ is flashing), then press Enter button to start the UPS settings. Enable/Disable UPS Function: Press UP and Down buttons to select the Disable or Enable option when they are flashing, and press Enter button to enable or disable the UPS function. -
Page 16: Force Discharge Settings
PV connection and UPS connection are all disconnected by turning off the relevant breakers and switches. Step2:Wait for 5mins and the HYH-3.6K-AC is shut down completely The rest of setting of Force Discharge is the same as AC Charge settings. - Page 17 1.Check UPS L,N connection. UPS short circuit 2.Disconnect the UPS connector, if the error still exist, contact us. UPS power reversed...
- Page 18 For detailed information please refer to the warranty card in the packaging of the inverter or contact our service center via email, web message or phone call. Contact Huayu(Ningbo)New Energy Technologies Co., Ltd. Add:No.456 Xingning Road, Ningbo 315100, P.R.China Add:+86-574-8925 8801 Mail: info@huayu-energy.com...
