Philips 170S7 Service Manual page 104

17" LCD Color Monitor
MODE NO.
RESOLUTION
Dot clock(MHz)
f h
A ( us )
B ( us )
C ( us )
D ( us )
E ( us )
f v
O (ms )
P ( ms )
Q (ms )
R ( ms )
S ( ms )
SYNC. H/V
POLARITY
SEP . SYNC
MODE NO.
RESOLUTION
Dot clock(MHz)
f h
A ( us )
B ( us )
C ( us )
D ( us )
E ( us )
f v
O (ms )
P ( ms )
Q (ms )
R ( ms )
S ( ms )
SYNC. H/V
POLARITY
SEP . SYNC
13
832 x 624
57.28
49.7kHz
20.11(1152 dots) 20.677(1344 dots)
1.117(64 dots) 2.092(136 dots)
3.91(224 dots) 2.462(160 dots)
14.52(832 dots) 15.754(1024 dots)
0.563(32 dots) 0.369(24 dots)
75Hz
13.41(667 lines) 16.666(806 lines)
0.06(3 lines) 0.124(6 lines)
0.784(39 lines) 0.600(29 lines)
12.55(624 lines) 15.880(768 lines)
0.016(1 lines) 0.062(3 lines)
+/+
Y
17
1024 x 768
83.096
61.1kHz
16.367 (1360dots) 14.561(1376 dots)
1.348 ( 112 dots) 1.016 ( 96 dots)
2.022 ( 168 dots) 2.201 ( 208 dots)
12.323(1024 dots) 10.836(1024 dots)
0.674 ( 56 dots) 0.508 ( 48 dots)
76Hz
13.142 (803 lines) 11.765 (808 lines)
0.049 ( 3 lines) 0.044 ( 3 lines)
0.507 ( 31 lines) 0.524 ( 36 lines)
12.57 (768 lines) 11.183 (768lines)
0.016 ( 1 line ) 0.014 (1 line )
+ / +
Y
14
1024 x 768 1024 x 768
65
48.363kHz 56.5kHz
17.707(1328 dots)
1.813(136 dots)
1.920(144 dots)
13.653(1024 dots)
0.321 (24 dots)
60.004Hz 70.004Hz
14.272(806 lines)
0.106(6 lines)
0.514(29 lines)
13.599(768 lines)
0.053(3 lines)
- / -
Y
18
1024 x 768 1152 x 864
94.5
68.7kHz 54.0kHz
18.523(1480 dots)
1.952(156 dots)
1.352(108 dots)
14.418(1152 dots)
0.801(64 dots)
85Hz
16.671(900lines)
0.148(8 lines)
0.445(24 lines)
16.004(864 lines)
0.074(4 lines)
+ / +
Y
104
15 16
1024 x 768
75 78.75
60kHz
16.66 (1312dots)
1.219 ( 96 dots)
2.235 ( 176 dots)
13.003(1024 dots)
0.203 ( 16 dots)
75Hz (75.000)
13.328 (800 lines)
0.05(3 lines)
0.446 ( 28 lines)
12.80 (768 lines)
0.017 (1 line )
-/- + / +
Y Y
19 20
1152 x 864
79.9 94.5
63.9kHz
15.661(1480 dots)
1.016(96 dots)
1.116(105 dots)
12.19(1152 dots)
1.339(127 dots)
60Hz 70Hz
14.283(912lines)
0.047(3lines)
0.689(44 lines)
13.531(864 lines)
0.016(1 lines)
+/+ +/+
Y Y
170S7
