BASE CAMP TV GAMING BED
I MPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE
Dimensions
Width - 205 cm
Depth - 95.7 cm
Height - 91.5 cm
Need Help? Contact X Rocker at:
www.xrockeruk.com/pages/support
IMPORTANT: You must keep your original retail receipt as proof of purchase.
1
LZL00-09/26/2020
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for X Rocker BASE CAMP 2020122
Summary of Contents for X Rocker BASE CAMP 2020122
- Page 1 I MPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE Dimensions Width - 205 cm Depth - 95.7 cm Height - 91.5 cm Need Help? Contact X Rocker at: www.xrockeruk.com/pages/support IMPORTANT: You must keep your original retail receipt as proof of purchase. LZL00-09/26/2020...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Assemble on a soft level Make sure you have enough components and tools listed on surface to avoid damaging the space to layout the parts before the following pages.
- Page 3 Components - Panels Please check you have all the panels listed below PARTS...
- Page 4 Components - Panels Please check you have all the panels listed below HeadboardX 1 Post X 2 Footboard X 1 Side rail 02 x 1 Side rail 01 x 1 Side rail 03 x 1 Side rail 04 x 1 Plastic Plug Leg X 2 Brace X 1...
- Page 5 Components - Panels Please check you have all the panels listed below Cap x 1 Right Mesh Panel x 1 Left Mesh Panel x 1 Rear Mesh Panel x 1 Mounting seat X 1 Mounting sleeve X 1 TV mount X 1 Bottom Mesh Panel x 1 Buckle X 1...
- Page 6 Components - Fittings Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied are required. 22mm M6 Bolt x 20 17mm M6 Bolt x 14 10mm M6 Bolt x 4 Nut M6 X 1 M8 Spring washer x 8...
- Page 7 Assembly Instructions Step Insert Post x 2 into Headboard with M6 x 17mm Step B X 2 I X 1 Insert Side rail 03 into Side rail 02 with Insert Side rail 04 into Side rail 01 with M6 x 17mm I X 1 B X 4...
- Page 8 Assembly Instructions Step Attach Leg x 2 to Brace with M6 x 22mm Step A X 4 I X 1 Attach Brace to Side rail and Side rail 02 with M6 x 22mm I X 1 A X 4...
- Page 9 Assembly Instructions Step Attach Footboard Side rail 01 and Side rail with D F G H Attach Headboard Side rail 02 and Side rail with I X 1 Plastic M8 Spring M8 Metal washer washer washer M8 x 22 mm Step H x 8 D X 8...
- Page 10 Assembly Instructions Step Attach Bottom Mesh Panel to Right Mesh Panel /Left Mesh Panel rear Mesh Panel with M6 x 22mm Step I X 1 A x 7 Attach Right Mesh Panel to Side rail 03 and Left Mesh Panel to Side rail with M6 x 17mm...
- Page 11 Assembly Instructions Step a: Secure the slats x24 to Side rail 01 /Side rail 02 /Side rail 03 and Side rail b: Secure the plastic plug x48 to Side rail 01 /Side rail 02 /Side rail 03 Side rail 04...
- Page 12 Assembly Instructions Step Attach EVA 01 to the middle of footboard shown. at the middle outside Footboard EVA 01 Step K X 1 at the middle inside buckle Attach EVA 02 to the middle of buckle as shown. EVA 02 L X 1...
- Page 13 Assembly Instructions Step a:Attach Mounting sleeve to Mounting seat with b:Attach Mounting seat to Footboard with c:Insert TV mount Buckle d:Insert TV mount Mounting sleeve e:Attach Buckle Footboard with f:Connect TV mount Mounting sleeve with M6 x 10 mm Nut M6 M6 x 22mm M6 x 17mm C X 4...
- Page 14 Assembly Instructions Step a: Cable (not provided) to pass through the TV mount from top of the pole. Please note: A minimum power cable length of 1.4m is required to connect the mounted TV to the undercarriage of the bed. Please check your TV cable length before installation to ensure fit.
