HDSL640
ADSL USB Modem
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDSL640 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hamlet HDSL640

Summary of Contents for Hamlet HDSL640

  • Page 1 HDSL640 ADSL USB Modem User’s Manual...

  • Page 2: Table Of Contents

    1.3 The Front LEDs 1.4 Information from ISP CHAPTER 2 NSTALLATION 2.1 Installing the HDSL640 ADSL USB Modem 2.2 Installing the HDSL640 ADSL USB Modem Drivers 2.2.1 For Windows 98 2.2.2 For Windows Me 2.2.3 For Windows 2000 2.2.4 For Windows XP...

  • Page 3: Introduction

    Chapter 1 Introduction 1.1 HDSL640 ADSL USB Modem Features The HDSL640 ADSL USB Modem provides the following features: ♦ Bus-powered USB modem for broadband ADSL. ♦ Downstream data rate up to 8 Mbps and upstream up to 1 Mbps. ♦...

  • Page 4: Package Contents

    HDSL640 ADSL USB Modem 1.2 Package Contents The product package comes with the following accessories: One HDSL640 ADSL USB Modem One installation CD with drivers and online manual One RJ-11 ADSL telephone cable One USB cable One Quick Start Guide 1.3 The Front LEDs...
  • Page 5 Chapter 1 Introduction Gather the information as illustrated in the following table and keep it for reference. If your ISP provides PPPoE or PPPoA connection method, please select “USB ADSL WAN Adapter” to install driver. If your ISP provides RFC1483 Bridged or Routed or IPoA, please select “USB ADSL LAN Adapter”...

  • Page 6: Installation

    Chapter 2 Installation 2.1 Installing the HDSL640 Please refer to the following instructions and figures: Connect ADSL telephone cable to the LINE RJ-11 jack. Connect the USB cable to the USB port and connect the other end to the PC.

  • Page 7: Installing The Hdsl640 Adsl Usb Modem Drivers

    Chapter 2 Installation 2.2 Installing the HDSL640 Drivers 2.2.1 For Windows 98 Start Windows. After the opening banner, Windows will tell you that the new device has been detected. You will then see the following screen. Click “Next >”. In the next window, select “Search for the best driver for your...
  • Page 8 HDSL640 ADSL USB Modem Insert the installation CD into the CD-ROM drive and check “Specify a location”. Click “Browse…” to specify the driver directory such as F:\Driver\LAN for installing an USB ADSL LAN Adapter or F:\Driver\WAN for installing an USB ADSL WAN Adapter. (Please refer Information from ISP section for more details.) Click...
  • Page 9 Chapter 2 Installation Continuing through the Wizard, click the “Next >” button. Windows will start copying files to your system. Then, click “Finish”. You will see the following screen prompting for the path of the Windows source files. Please specify a location. Click “OK”.
  • Page 10 The HDSL640 ADSL USB Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. The HDSL640 ADSL USB Modem icon is installed in the Control Panel. Go to the Device Manager, the “USB ADSL LAN Adapter”...

  • Page 11: For Windows Me

    Chapter 2 Installation 2.2.2 For Windows Me Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Select “Specify the location of the driver” and click “Next >”.
  • Page 12 HDSL640 ADSL USB Modem Insert the installation CD into the CD-ROM drive and check “Specify a location”. Click “Browse…” to specify the driver directory such as F:\Driver\LAN for installing an USB ADSL LAN Adapter or F:\Driver\WAN for installing an USB ADSL WAN Adapter. (Please refer Information from ISP section for more details.) Click...
  • Page 13 Chapter 2 Installation Continuing through the Wizard, Windows will start copying files to your system. Then, click “Finish”.
  • Page 14 The HDSL640 ADSL USB Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. The HDSL640 ADSL USB Modem icon is installed in the Control Panel. Go to the Device Manager, the “USB ADSL LAN Adapter”...

  • Page 15: For Windows 2000

    Chapter 2 Installation 2.2.3 For Windows 2000 Start Windows. After the opening banner, Windows will show the new device has been detected. Click “Next>”.
  • Page 16 HDSL640 ADSL USB Modem Select “Search for a suitable driver for my device”. Click “Next>”. Then, insert the installation CD into the CD- ROM drive. In next window, check “Specify a location” and click “Next>”.
  • Page 17 Chapter 2 Installation Click “Browse…”. In the Locate File window, specify the driver directory such as F:\Driver\LAN\CxtCAFEU for installing ADSL Adapter F:\Driver\WAN\CxtCAFEU for installing an USB ADSL WAN Adapter. (Please refer Information from ISP section for more details.) Click “Open” and then “Next>“ to continue.
  • Page 18 HDSL640 ADSL USB Modem Press “Finish”. The HDSL640 ADSL USB Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. The HDSL640 ADSL USB Modem icon is installed in the Control Panel.
  • Page 19 Chapter 2 Installation Go to the Device Manager, the “USB ADSL LAN Adapter” is under the Network Adapters, and the “HDSL640 ADSL USB Modem” is under the Universal Serial Bus Controllers for USB ADSL LAN driver installation. Go to the Device Manager, the “USB ADSL WAN Adapter”...

  • Page 20: For Windows Xp

    HDSL640 ADSL USB Modem 2.2.4 For Windows XP Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Select “Install from a list or specific location” and click “Next >”.
  • Page 21 Chapter 2 Installation Insert the installation CD into the CD-ROM drive and select “Include this location in the search”. Click “Browse” to specify the driver directory such as F:\Driver\LAN for installing an USB ADSL LAN Adapter or F:\Driver\WAN for installing an USB ADSL WAN Adapter. (Please refer Information from ISP section for more details.) Click “OK”...
  • Page 22 HDSL640 ADSL USB Modem...
  • Page 23 Chapter 2 Installation When windows titled “Hardware Installation” or “Software Installation” appear, press “Continue Anyway” to go on. Then, click “Finish”.
  • Page 24 HDSL640 ADSL USB Modem Wait a few moments. Windows will show the new device, USB ADSL LAN (or WAN) Adapter, has been detected. Select “Install from a list or specific location” and click “Next >”.
  • Page 25 Chapter 2 Installation Click “Next >” when the following figure appears. When windows titled “Hardware Installation” appears, press “Continue Anyway”. Then, click “Finish” to end installation.
  • Page 26 HDSL640 ADSL USB Modem The HDSL640 ADSL USB Modem driver is successfully installed and the Status Task Bar will appear in the System Tray. 10. The HDSL640 ADSL USB Modem icon is installed in the Control Panel.
  • Page 27 Chapter 2 Installation 11. Go to the Device Manager, the “USB ADSL LAN Adapter” is under the Network Adapters, and the “HDSL640 ADSL USB Modem” is under the Universal Serial Bus Controllers for USB ADSL LAN driver installation. Go to the Device Manager, the “USB ADSL WAN Adapter”...

  • Page 28: Configuration

    Chapter 3 Configuration Follow the instructions below to configure your HDSL640 ADSL USB Modem. Click the HDSL640 ADSL USB Modem icon in the Control Panel or ADSL Configuration icon on the desktop. The status of ADSL connection will be displayed.
  • Page 29 Chapter 3 Configuration Press [Alt]+[P] on keyboard, the following figure appears. Select the Protocol Setup tag, please set the value of “VPI”, “VCI” and “Encapsulation Mode”. Then, click “OK”.

  • Page 30: Usb Adsl Lan Adapter Configuration

    HDSL640 ADSL USB Modem 3.1 USB ADSL LAN Adapter Configuration 3.1.1 For Windows 98 / Me Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. Select TCP/IP USB ADSL LAN Adapter. Then, click...
  • Page 31 Chapter 3 Configuration Select the IP Address tab. In this page, click the Specify an IP address radio button and enter the “IP address” and “Subnet Mask” provided by your ISP. Select the Gateway tab. Enter the “gateway” provided by your ISP and click Add.
  • Page 32 HDSL640 ADSL USB Modem In the DNS Configuration page, click the Enable DNS radio button. Enter the “Host” name and “DNS Server IP address” provided by your ISP. Then, press the Add button.

  • Page 33: For Windows 2000 / Xp

    Chapter 3 Configuration 3.1.2 For Windows 2000 / XP Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. Right–click on Local Area Connection that is using the USB ADSL LAN Adapter and then click “Properties”.
  • Page 34 HDSL640 ADSL USB Modem Select Internet Protocol (TCP/IP). Then, click “Properties”.
  • Page 35 Chapter 3 Configuration Select Use the following IP address, and then enter the “IP address”, “Subnet mask”, and “Default gateway” provided by your ISP. Select Use the following DNS server addresses and then enter the provided DNS server IP address.

  • Page 36: Usb Adsl Wan Adapter Configuration

    HDSL640 ADSL USB Modem 3.2 USB ADSL WAN Adapter Configuration Click ADSL Access icon on the desktop. Then, the following window appears. Enter the “Username” and “Password” provided by your ISP. Let the Phone number field be blank.
  • Page 37 Chapter 3 Configuration Click Connect and get ready to surf the Internet!
