- Page 1 ALP1A2812/A1 Information LED panel for rolling stock Operation manual Version 1.02 alp1a2812a1_g_en_102...
- Page 2 ALP1A2812/A1 AMiT, spol. s r. o. does not provide any warranty concerning the contents of this publication and reserves the right to change the documentation without obligation to inform anybody or authority about it. This document can be copied and redistributed under following conditions: 1.
-
Page 3: Table Of Contents
ALP1A2812/A1 Contents History of revisions ..................4 Related documentation ................... 4 Introduction ..................5 Technical parameters ................6 2.1. Dimensions ..................... 8 2.2. Recommended drawing symbol ..............8 2.3. Temperature dependence ................8 Labelling ....................9 3.1. Manufacturer type plate .................. 9 Conformity assessment .............. -
Page 4: History Of Revisions
10. 01. 2018 O. Rott Changes in chapters 2 Technical parameters 4 Conformity assessment. 18. 01. 2018 M. Uhlář Ingress protection rate correction IP50 -> IP40 Related documentation ALP1A2812/A1 – Information LED panel for rolling stock – Datasheet file: alp1a2812a1_d_en_xxx.pdf alp1a2812a1_g_en_102 4/21... -
Page 5: Introduction
ALP1A2812/A1 1. Introduction ALP1A2812/A1 is an external information LED panel intended to be built-in to rolling stock interior. Device is designed in accordance with EN 50155:2007 standard. LED panel is shipped from production with loader and AMiT software. (804 × 124) mm ▪... -
Page 6: Technical Parameters
ALP1A2812/A1 2. Technical parameters (804 × 124) mm Viewing zone Viewing area (200 × 30) pixels Resolution LED grid 4 mm LED colour Yellow, 590 nm typ. Luminance Typ. 800 cd/m 120 ° *) Viewing angle Note: *) Luminance drop to 50 % at viewing angle border. - Page 7 ALP1A2812/A1 Mechanics Mechanical design Metal cover + tempered glass Surface finish – front panel Powder coating – rear cover Powder coating – front panel Colour Black, RAL 9005, fine matte – rear cover Black, RAL 9005, fine matte 4 × M6 nuts on the sides Mounting 4 ×...
-
Page 8: Dimensions
ALP1A2812/A1 2.1. Dimensions Fig. 1 - Information panel ALP1A2812/A1 dimensions in mm 2.2. Recommended drawing symbol Following drawing symbol recommended information panel ALP1A2812/A1. ALP1A2812/A1 Fig. 2 - Recommended drawing symbol for ALP1A2812/A1 2.3. Temperature dependence Information panel is equipped with internal temperature sensor; depending on measured temperature is controlled the maximum brightness according to following table. -
Page 9: Labelling
ALP1A2812/A1 3. Labelling Type identification plate is placed on the back side of the ALP1A2812/A1 information panel. For exact location of labels see Fig. 3 - Labelling of ALP1A2812/A1 . TYPE ALP1A2812/A1 AB12345 APP x.xx / LDR x.xx POWER: 16.8 to 33.6 V DC / 3 A WEIGHT: x.xx kg... - Page 10 ALP1A2812/A1 ALP1A2812/A1 TYPE AB12345 MAC: xx-xx-xx-xx-xx-xx APP x.xx / LDR x.xx POWER: 16.8 to 33.6 V DC / 2.65 A WEIGHT: x.xx kg TEST: OK-VS HiPot: HiPot - OK DATE: xx.xx.xxxx Fig. 4 - Example of manufacturer’s type plate alp1a2812a1_g_en_102...
-
Page 11: Conformity Assessment
ALP1A2812/A1 4. Conformity assessment The equipment meets the requirements of NV117/2016 Czech governmental decree. The compliance assessment with NV117/2016 has been performed in accordance with harmonized standard EN 50121-3-2:2006. Tested in accordance Type of test Classification with standard EN 55011:2009... -
Page 12: Other Tests
ALP1A2812/A1 4.1. Other tests This product was assessed and approved for use in railway applications according to standards: Tested in accordance Type of test Classification with standard Railway applications – Electronic EN 50155:2007 Complies equipment used on rolling stock S1, S2, C1 Railway applications –... -
Page 13: Power Supply
ALP1A2812/A1 5. Power supply Information panel ALP1A2812/ is equipped with M12 A-coded, 4-pin connector labelled as PWR. It is used as a power supply connector. Note Matching counterpart is contained in package (Conec 43-00421). For proper contact connection use crimping tool 360X10329X with crimping insert 360X20069X. -
Page 14: Communication Lines And Peripherals
▪ Light sensor 6.1. Ethernet The 10/100 Mbps Ethernet interface allows connecting of ALP1A2812/A1 computer to LAN network. Panel computer ALP1A2812/A1 is equipped with one Ethernet interface with M12-4pin Harting push-pull connector. Fig. 7 - Location of Ethernet line connector On next figure is presented a front view on Ethernet socket. -
Page 15: Light Sensor
ALP1A2812/A1 6.2. Light sensor Information panel is equipped with light sensor that is used for measuring of ambient light. Thanks to this sensor, information panel can regulate brightness to optimal value, according to ambient conditions. For panel correct operation the sensor must be exposed to the ambient light, and must not be covered anything. -
Page 16: Mounting
ALP1A2812/A1 7. Mounting Information panel is designed to be mounted onto rail coach interior with four mounting holes located on the panel sides, or with four mounting holes located on the panel back. Information panel is attached by bolts, fastened to M6 nuts. -
Page 17: Ordering Information, Package Contents
Certificate of product quality and completeness 8.2. Accessories Following accessories can be ordered: Part ID Part description Quantity 43-00421 Power supply connector counterpart Note *) For more information about storage sizes please contact technical support at email address support@amit.cz. 17/21 alp1a2812a1_g_en_102... -
Page 18: Packaging
ALP1A2812/A1 9. Packaging Front panel Display area including front panel is protected by plastic foil against scratches protection and dirt. This foil is recommended to stay on the device during mounting to the vehicle and must be removed before using the device. -
Page 19: Storage
ALP1A2812/A1 10. Storage To prevent any damage to the device please keep the following rules. Packed The computer in the original box must be stored only under environmental computer conditions defined in technical parameters. The device must be kept away from water, oil or any other liquid which can damage the packing. -
Page 20: Maintenance
ALP1A2812/A1 11. Maintenance Warning Maintenance mentioned below can be performed only by manufacturer or authorized service. 11.1. Cleaning According to cleanliness of the environment, where the computer is installed, it is necessary to remove dust and dirt from the panel computer. -
Page 21: Waste Disposal
ALP1A2812/A1 12. Waste disposal Electronics The disposal of electronic equipment is subject to the regulations on handling disposal electrical waste. The equipment must not be disposed of in common public waste. It must be delivered to places specified for that purpose and recycled.
