Programming the Device

Setting Treatment Parameters

Programming the Empi Continuum is designed to be intuitive. The Empi
Continuum has been engineered to guide the clinician through the
programming process. The clinician will first set up the parameters for
treatment and then proceed to restrict the user's ability to reprogram the
unit. In essence, the clinician will set up the device such that the user has
only to press one button before starting the treatment.
NMES Parameters
1. Power ON the device by depressing the ON/OFF ( ) button.
2. Press the top soft key on the left to select "NMES" programming.
3. Select the Muscle Type – either Large or Small Muscle.
4. Select Treatment type – Atrophy, Spasm, Point, or Custom.
5. Using left side soft key, scroll to the desired parameter item.
6. Using right side soft keys, scroll parameter value up or down.
7. Press the Home button to get back to the Option menu.
8. Press the soft key labeled "CONFIG. "
9. Press right side soft key labeled "LOCKS. "
10. Using left soft keys, scroll to desired item "NMES L.MUSCLES" or
"NMES S.MUSCLES. "
11. Press the upper right soft key until a locked icon displays.
12. Press Home button to accept the change.
13. Press the "NMES" button, a lock must be visible beside the previously
selected item ("LARGE MUSCLE" or "SMALL MUSCLE").
14. Select the locked treatment to go to the "In-Progress" screen.
15. Set up patient with electrodes and ramp-up intensity.
TENS Parameters
1. Power ON the device by pressing the ON/OFF ( ) button.
2. Press bottom soft key on the left to select TENS programming.
3. Select the body part by scrolling thru options and press "OK. "
4. Using left side soft key, scroll to the desired parameter item.
5. Using right side soft keys, scroll parameter value up or down.
6. Press the Home button to get back to the Option menu.
7. Press soft key labeled "CONFIG. "
8. Press right side soft key labeled "LOCKS. "
9. Using lower left soft key, scroll to item "TENS. "
10. Press the upper right soft key until a locked icon displays.
