ITEM NO.:A106005700
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
customer.care@sunjoygroup.com
1-(866)-578-6569
Country of Origin: China
Production Number: xxxxxxxxxx

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A106005700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sunjoy A106005700

  • Page 1 ITEM NO.:A106005700 WE HAVE YOU IN MIND, LET US SERVE YOU!  Questions? Issues? CONTACT US  24 hours / 7 days a week www.sunjoyonline.com customer.care@sunjoygroup.com 1-(866)-578-6569 Country of Origin: China Production Number: xxxxxxxxxx...
  • Page 2 2 / 7 Parts List Label Part# Description Image P000200395 Post P000100295 Base P006100151 Base Cover P000400798 Cross Beam 1 P000400799 Cross Beam 2 P000601206 Slant Beam P005800001 Hook P005600280 Corner Decor P000501030 Top Connector P000501029 Beam Connector P005000348 Corner Support P001100482 Canopy Country of Origin: China...
  • Page 3 3 / 7   Hardware Pack 1   Label Part# Description Image H010020012 M6X20 Bolt 48 PCS 112PCS H050010023 M6 Washer 72PCS H050020017 M6 Spring Washer H010020011 M6X15 Bolt 16PCS H010020001 M6X15 Bolt 32PCS H010020031 M6X20 Bolt 16PCS H090010009 M6 Wrench 1 PC Country of Origin: China...
  • Page 4 4 / 7 Step 1 Fig.3 Fig.5 Fig.8 Fig.4 Fig.6 Fig.2 Fig.7 Fig.1 Fig.2 Fig.1 BB AA Fig.1: Insert Base Cover (C) into Post (A), Fig.2: Attached Cross Beam1 (D1) then fixed Base (B) to bottom of Post (A) by and Cross Beam 2 (D2) to Beam bolt (AA) and Washer (BB) Connector (I) by Bolt (GG), Spring...
  • Page 5 5 / 7 Fig.4 Fig.3 CC BB D1/2 Fig.4: Attached the Slant Beam(E) to Fig.3: Attached Cross Beam1/2 Fig.5: Fix the assembled inclined Top Connector (H), fixed them by Bolt (D1/2) to Post (A) by Bolt (AA), beam(E) to the column with bolt Spring Washer (CC) and Washer (AA), Spring Washer (CC) and Washer (II),washer(BB) and corss beam(D1、...
  • Page 6 6 / 7 Hardware Pack 2 Label Part# Description Image P005100242 M6 Plum Knob 8PCS Φ6*230 floor stake H070010008 8PCS   Step 2 Fig.9 Fig.10 Fig.11 Fig.9 Fig.10 Fig.9: Spread the Canopy (I) to pergola top, Fig.10: Fix the Middle of the Cross Beam by then fixed each corner by Plum Knob (EE) Plum Knob (EE) Country of Origin: China...
  • Page 7  Use damp cloth to wipe off the stains as quickly as possible.   If necessary, wash with a mild solution of soap and water; rinse thoroughly and dry completely.   Periodically check and ensure that all bolts are well‐tighten during use  Limited Manufacturer’s Warranty Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a  period  of    1  year  from  the  date  of  purchase,  provided  the  item  was  factory‐sealed  at  the  time  of  purchase  and  is  maintained with care and used only for personal, residential purposes. Should any manufacturing defect arise within this  warranty period, Sunjoy Group will replace (at our option) any defective merchandise or parts upon proof of purchase;  however, transportation and delivery costs, as well as payments to a third party for assembly or disassembly of the item,  remain  the  responsibility  of  the  purchaser.  A  purchaser  of  an  "open  box,"  previously‐returned,  or  "clearance"  item,  as ...
