Step 3. Connect the external antenna
Connect external antenna to the VPOS Touch.
Step 4. Secure rear cover
Secure the rear cover to the VPOS Touch.
Step 5. Back plate
Attach the back plate and the VPOS Touch with the help of 4 screws.
Device Dismantling
To unplug the VPOS Touch connector, you must press both sides of the releasing bridge at the same
time to avoid damaging the releasing bridge.
Pro Tip
You may need a swiss spanner wrench / Philips screwdriver
for dismantling purposes.
VPOS Touch Installation Guide
VPOS_Touch_Installation_Guide.docx
Page 9
