VPOS Touch Installation
1. Remove Screws and Clear Plastic Cover
Use a Phillips head screw driver to remove the
screws holding the clear plastic cover in place.
3. Insert SIM card
Slip the SIM card into the cradle with the gold
chip facing down until it is all the way in the
cradle with the angled edge positioned at the
top left of the cradle.
|
www.nayax.com
Level 1, Suite 3, 2 Help Street, Chatswood, NSW, 2067
2. Lift SIM card slot
Pull the SIM card cradle toward you so to make
it accessible for the insertion of a SIM card.
4 Lock the SIM card into place
Push the cradle down onto the main board and
slip the silver clutch 'up' to lock the SIM card
into place.
|
02 8459 7207
|
au-info@nayax.com.au
Advertisement
Related Manuals for Nayax VPOS Touch
Summary of Contents for Nayax VPOS Touch
- Page 1 VPOS Touch Installation 1. Remove Screws and Clear Plastic Cover 2. Lift SIM card slot Use a Phillips head screw driver to remove the Pull the SIM card cradle toward you so to make screws holding the clear plastic cover in place.
- Page 2 7. Screw in the antenna and mount Screw the antenna onto the VPOS touch and mount the VPOs Touch onto the vending machine. www.nayax.com...
