Roadside Emergencies
Fuse/Relay
Fuse Amp
Location
Rating
1
15A*
2
20A*
3
20A*
4
20A*
5
20A*
6
20A*
7
30A*
8
—
9
20A*
10
10A*
11
20A*
12
20A*
13
5A*
14
15A*
15
10A*
16
15A*
17
15A*
18
20A*
19
10A*
20
—
21
25A*
22
20A*
23
20A*
24
15A*
25
10A*
26
10A*
27
15A*
28
10A*
29
10A*
190
Passenger Compartment Fuse Panel
Description
Adjustable pedals
Power point - floor console
Power point – 3rd row
Power point - instrument panel
Power point - right rear quarter
Trailer tow turn/stop relay
High beam headlamps / Flash to pass
Not used
Heated mirrors
A/C clutch
Radio (main)
Cigar lighter / OBD II
Power mirrors/switches
Daytime running lamps
Driver's seat module memory
Rear seat controller
Exterior lamps
Turn lamps/Brake on-off switch (high)
Body security module/4x4 module
Not used
Rear wiper motor
Engine control
Engine control
Air suspension
4-Wheel Anti-Lock Brake System
(4WABS) module
Airbags
Ignition switch Run feed
EATC module module/Front blower relay
coil
Customer access
