Summary of Contents for Ford 2001 Escort

  • Page 1: Table Of Contents

    All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

  • Page 2: Introduction

    Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

  • Page 3: Breaking-In Your Vehicle

    INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation. EMISSION WARRANTY The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L...

  • Page 4: Vehicle Symbol Glossary

    Introduction These are some of the symbols you may see on your vehicle. Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows Front/Rear...
  • Page 5 Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Vehicle Symbol Glossary Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature...

  • Page 6: Instrumentation

    Instrumentation Foglamp control * (pg. 45) Headlamp/turn signal control (pg. 44) MIRROR Power side view mirrors* (pg. 18) Instrument panel dimmer switch (pg. 17) Instrument cluster FUEL FILL FUEL Speed control* (pg. 46) (pg. 8) THEFT 0 0 0 1 1 3 Driver air bag (pg.

  • Page 7: Passenger Air Bag

    Windshield wiper/washer control (pg. 51) SEEK TRACK SCAN TUNE DISCS PUSH ON SIDE 1-2 Passenger air bag (pg. 80) TAPE BASS PREMIUM SOUND DOLBY B NR COMP SHUF Climate controls (pg. 38) Instrumentation TREB FADE R.DEF Audio system (pg. 19) *if equipped...

  • Page 8: Warning Lights And Chimes

    Instrumentation WARNING LIGHTS AND CHIMES Base instrument cluster FUEL FILL SERVICE ENGINE SOON FUEL BRAKE ZX2 coupe instrument cluster FUEL FILL FUEL – BRAKE CHECK SERVICE FUEL ENGINE SOON Low fuel Illuminates as an early reminder of a low fuel condition indicated on the fuel gauge (refer to Fuel gauge in this chapter for more information).

  • Page 9: Service Engine Soon

    Instrumentation Service engine soon Your vehicle is equipped with a SERVICE computer that monitors the engine’s ENGINE emission control system. This SOON system is commonly known as the On Board Diagnostics System (OBD II). The OBD II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
  • Page 10 Instrumentation Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the first available opportunity. Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.
  • Page 11 Instrumentation Anti-lock brake system (ABS) (If equipped) Momentarily illuminates when the ignition is turned to the ON position to ensure the circuit is functional. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with the parking brake released.
  • Page 12 Instrumentation Engine oil pressure Momentarily illuminates when the ignition is turned to the ON position and the engine is off. Illuminates when the oil pressure falls below the normal range. Stop the vehicle as soon as safely possible and switch off the engine immediately. Check the oil level and add oil if needed.

  • Page 13: Headlamps On Warning Chime

    Key-in-ignition warning chime Sounds when the key is left in the ignition in the OFF/LOCK or ACC position and the driver’s door is opened. Headlamps on warning chime Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened.
  • Page 14 Instrumentation Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or after refueling. The ignition should be in the OFF position while the vehicle is FUEL being refueled.
  • Page 15 Speedometer Indicates the current vehicle speed. Odometer Registers the total kilometers (miles) of the vehicle. Instrumentation 0 0 0 0 0 km/h 0 0 0 0 0 0 0 0 0 km/h 0 0 0...
  • Page 16 Instrumentation Trip odometer Registers the kilometers (miles) of individual journeys. To reset, depress the control. 0 0 0 0 0 0 km/h 0 0 0 0 Tachometer (if equipped) Indicates the engine speed in revolutions per minute. THEFT Driving with your tachometer pointer in the red zone may damage RPMx1000 the engine.

  • Page 17: Panel Dimmer Control

    PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp and parklamp operation. Coupe Rotate up to brighten. Rotate down to dim. Sedan Rotate left to brighten Rotate right to dim The dome lamp will not illuminate if the control switch is in the OFF position.

  • Page 18: Power Side View Mirrors (If Equipped)

    Controls and features POWER SIDE VIEW MIRRORS (IF EQUIPPED) The ignition must be in ACC or ON position to adjust the power side view mirrors. To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2.

  • Page 19: Using Your Audio System

    USING YOUR AUDIO SYSTEM AM/FM Stereo/Cassette SEEK TUNE Volume/power control Press the control to turn the audio system on or off. Turn control to raise or lower volume. SCAN DOLBY B NR PUSH ON SIDE 1-2 Controls and features TAPE BASS TREB FADE...
  • Page 20 Controls and features If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. If you wish to maintain your preset volume level, turn the audio system off with the power control before switching off the ignition.
  • Page 21 Tune adjust in radio mode Press the to move to the next frequency down the band (whether or not a listenable station is located there). Hold to move through the frequencies quickly. Press the to move to the next frequency up the band (whether or not a listenable station is located there).
  • Page 22 Controls and features Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the control again to stop the scan mode. Scan function in tape mode Press the SCAN control to hear a short sampling of all selections on the tape.
  • Page 23 Speaker balance/fade adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control. Toggle between the + and — control to adjust the speaker sound. Speaker sound can be adjusted between the front and rear speakers.
  • Page 24 Controls and features Fast forward The fast forward control works in tape mode. In the tape mode, tape direction will automatically reverse when the end of the tape is reached. Tape side select Press this control to play the alternate side of a tape. Eject function Press the control to stop and eject a tape.

  • Page 25: Setting The Clock

    Setting the clock To set the hour, press the hour (h) control and press : (+) to increase hour and (−) to decrease hour To set the minute, press the minute (m) control and press: (+) to increase minutes and (−) to decrease minutes.
  • Page 26 Controls and features Volume/power control Press the control to turn the audio system on or off. Turn control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
  • Page 27 AM/FM select in tape mode Press this control to stop tape play and begin radio play. AM/FM select in CD mode Press this control to stop CD play and begin radio play. You can switch from CD play to tape play by simply inserting a tape into the cassette deck.
  • Page 28 Controls and features Tune adjust for CD mode (if equipped) Press the to select the previous disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode. Refer to Shuffle feature for more information.
  • Page 29 Press to seek forward to the next track of the current disc. After the last track has been completed, the first track of the current disc will automatically replay. Scan function The scan function works in radio, tape or CD mode (if equipped). Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band.
  • Page 30 Controls and features 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected. Bass/treble adjust The bass adjust control allows you to increase or decrease the audio system’s bass output.
  • Page 31 Tape play select Insert a tape to begin tape play. Push only slightly when inserting a cassette tape (with the open edge to the right). A cassette deck loading mechanism pulls the tape in the rest of the way. Rewind The rewind control works in tape and CD modes (if equipped).
  • Page 32 Controls and features Eject function Press the control to stop and eject a tape. DOLBY B NR Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise...
  • Page 33 Shuffle feature The shuffle feature operates in CD mode (if equipped) and plays all tracks on the current disc in random order. If equipped with the CD changer, the shuffle feature continues to the next disc after all tracks are played. Press the SHUFFLE control to start this feature.
  • Page 34 Controls and features CD changer (if equipped) The CD changer is located in the trunk of your vehicle. Slide the door to access the CD changer magazine. Press to eject the magazine. Make sure only one disc is inserted in each slot. Each disc must be inserted with the label surface upward.
  • Page 35 The magazine does not need to be full for the changer to operate. Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove box when not being used. The CD magazine may be inserted or ejected with the radio power off. ONLY use the magazine supplied with the CD changer, other types will damage the unit.
  • Page 36 Controls and features A disc with format and dimensions not within industry standards is inserted. Cleaning compact discs Inspect all discs for contamination before playing. If necessary, clean discs only with an approved CD cleaner and wipe from the center out to the edge.
  • Page 37 Radio frequency information The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission(CRTC) establish the frequencies AM and FM stations may use for their broadcasts. Allowable frequencies are: AM 530, 540–1600, 1610 kHz FM 87.7, 87.9–107.7, 107.9 MHz Not all frequencies are used in a given area.

  • Page 38: Climate Control System

    Controls and features CLIMATE CONTROL SYSTEM Heater only system (if equipped) Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. On heater-only systems, the air cannot be cooled below the outside temperature.
  • Page 39 -Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. Operating tips In humid weather, place the climate control system in driving. This will reduce fogging on your windshield. Once the windshield has been cleared, select any desired position.
  • Page 40 Controls and features Manual heating and air conditioning system (if equipped) Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle.
  • Page 41 Controls and features A/C-Uses outside air to cool the vehicle. It is quieter than MAX A/C but not as economical. Airflow will be from the instrument panel registers. (Panel)-Distributes outside air through the instrument panel registers. However, the air will not be cooled below the outside temperature because the air conditioning does not operate in this mode.
  • Page 42 Controls and features To reduce humidity buildup inside the vehicle in cold weather conditions, don’t drive with the climate control system in the OFF or MAX A/C position. To reduce humidity buildup inside the vehicle in warm weather conditions, don’t drive with the climate control system in the OFF position.

  • Page 43: Rear Window Defroster

    To aid in side window defogging/demisting in cold weather conditions: 1. Select 2. Set the temperature control to full heat 3. Set the fan speed to HI 4. Direct the outer panel vents towards to side windows To increase airflow to the outer panel vents, close the central panel vents.

  • Page 44: Positions Of The Ignition

    Controls and features POSITIONS OF THE IGNITION 1. LOCK, locks the steering wheel, gearshift lever (automatic transaxle only) and allows key removal. On vehicles with a manual transaxle push the key in while turning to lock. 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running.
  • Page 45 High beams Push forward to activate. Pull toward you to deactivate. Flash to pass Pull toward you to activate and release to deactivate. Foglamp control (if equipped) Rotate forward to activate. Controls and features...

  • Page 46: Turn Signal Control

    Controls and features TURN SIGNAL CONTROL Push down to activate the left turn signal. Push up to activate the right turn signal. SPEED CONTROL (IF EQUIPPED) To turn speed control on Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph).
  • Page 47 To set a speed Press SET ACC. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
  • Page 48 Controls and features To set a higher set speed Press and hold SET ACC. Release the control when the desired vehicle speed is reached or Press and release SET ACC to operate the Tap-Up function. Each press will increase the set speed by 1.6 km/h (1 mph) or Accelerate with your accelerator pedal.
  • Page 49 Depress the brake pedal. When the desired vehicle speed is reached, press SET ACC. To disengage speed control Depress the brake pedal or Depress the clutch pedal (if equipped). Disengaging the speed control will not erase the previously programmed set speed. Controls and features...
  • Page 50 Controls and features Pressing OFF will erase the previously programmed set speed. To return to a previously set speed Press RSM. For RSM to operate, the vehicle speed must be faster than 48 km/h (30 mph). TILT STEERING (IF EQUIPPED) Pull the tilt steering control down to move the steering wheel up or down.

  • Page 51: Hazard Flasher

    Never adjust the steering wheel when the vehicle is moving. HAZARD FLASHER For information on the hazard flasher control, refer to Hazard flasher in the Roadside emergencies chapter. WINDSHIELD WIPER AND WASHER For intermittent wiping, move the control down one position and rotate the wiper switch to the desired position.

  • Page 52: Moonroof (If Equipped)

    Controls and features To spray the washer fluid, pull the wiper control toward you. MOON ROOF (IF EQUIPPED) Press and hold OPEN to raise the moon roof to the vent position. Press OPEN again to fully open the moon roof. Press the opposite end of the toggle control to close the moon roof from either position.
  • Page 53 Controls and features INTERIOR LAMPS Dome lamp and map lamps (if equipped) The dome lamp is located overhead between the driver and passenger seats. The dome lamp will stay on if the control is moved to the ON position. When the control is moved to the DOOR position, the lamp will only come on if a door is opened.

  • Page 54: Power Door Locks - If Equipped

    Controls and features POWER DOOR LOCKS (IF EQUIPPED) Press U to unlock all doors and L to lock all doors. CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked.

  • Page 55: Power Windows - If Equipped

    POWER WINDOWS (IF EQUIPPED) Press and hold the rocker switches to open and close windows. Press the top portion of the rocker switch to close. Press the bottom portion of the rocker switch to open. Express down To make the driver window open fully without holding the window control, press the top portion of the driver window control completely...

  • Page 56: Interior Luggage Compartment Release

    Controls and features POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal.

  • Page 57: Remote Entry System

    Keep vehicle doors and luggage compartment locked and keep keys out of a child’s reach. Unsupervised children could lock themselves in an open trunk and risk injury. Children should be taught not to play in vehicles. On hot days, the temperature in the trunk or vehicle interior can rise very quickly.
  • Page 58 Controls and features The driver’s door only entry system allows you to: lock the driver’s door unlock the driver’s door only without a key. activate the panic alarm. open the trunk The remote entry features only operate with the ignition in the LOCK position.
  • Page 59 Controls and features Locking the doors Press this control to lock all doors. On vehicles equipped with the driver’s door only remote entry system, only the driver’s door will lock. To confirm doors are closed and locked, press the lock control a second time within three seconds.
  • Page 60 Controls and features Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON. Replacing the battery The remote transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent.
  • Page 61 Replacing lost transmitters If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: Take all your vehicle’s transmitters to your dealer for programming, or Perform the programming...
  • Page 62 Controls and features Illuminated entry Interior lamps will illuminate when UNLOCK or PANIC control is pressed. The lamps will illuminate for approximately 20 seconds or until the key is inserted in the ignition and turned to ON or until LOCK control is pressed.
  • Page 63 Identifying an armed system While the system is arming, the THEFT light in the instrument cluster will illuminate for 30 seconds. After 30 seconds, THEFT will flash, indicating the system is armed. If the system is arming with the doors open, the THEFT light will stay illuminated until all the doors are closed and then illuminate for 30 seconds and begin flashing.
  • Page 64 Controls and features Pressing the trunk control will prevent the alarm from sounding until the trunk is closed again. Using the ignition key to unlock doors/trunk will not disarm the anti-theft system. Disarming a triggered anti-theft system Press either the unlock or panic control to disarm the system.

  • Page 65: Seating And Safety Restraints

    Seating and safety restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
  • Page 66 Seating and safety restraints Adjusting the front manual seat Never adjust the driver’s seat or seatback when the vehicle is moving. Do not pile cargo higher than the seatbacks to reduce the risk of injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
  • Page 67 Seating and safety restraints Driver seat memory recliner (if equipped) Pull control to adjust seatback. To retain selected seatback position, release seatback by moving memory recliner control forward to release seatback. Push seatback rearward until the seatback latches. This will be the first position selected.
  • Page 68 Seating and safety restraints Folding rear seats (if equipped) Folding down the rear seats To fold the seatback down: Press the latch control downward or pull up on strap and Pull the seatback forward and down. Returning the seat to the upright position Check to see that the seat and seatback is latched securely in position.
  • Page 69 SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving.
  • Page 70 Seating and safety restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
  • Page 71 Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 8 km/h (5 mph) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers.
  • Page 72 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
  • Page 73 Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions. Front safety belt height adjustment (if equipped) Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder.
  • Page 74 Seating and safety restraints Lap belts (if equipped) Adjusting the lap belt The lap belt does not adjust automatically. The lap belt should fit snugly and as low as possible around the hips, not across the waist. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from).
  • Page 75 Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position...
  • Page 76 Seating and safety restraints The purpose of the Belt Minder is to remind occasional wearers to wear safety belts all of the time. The following are reasons most often given for not wearing safety belts: (All statistics based on U.S. data) Reasons given...
  • Page 77 Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the Belt Minder feature please follow the directions stated below. One time disable Any time the safety belt is buckled and then unbuckled during an ignition ON cycle, Belt Minder will be disabled for that ignition cycle only.
  • Page 78 (if equipped), LATCH child seat tether anchors and lower anchors (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.

  • Page 79: Air Bag Supplemental Restraint System (Srs)

    This information will assist Ford in the servicing of your vehicle and may help Ford better understand real world collisions and further improve the safety of future vehicles.
  • Page 80 Seating and safety restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag...
  • Page 81 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. Se your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and tow hooks may affect the performance of the air bag sensors increasing the risk of injury.
  • Page 82 Seating and safety restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
  • Page 83 The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the air bag.
  • Page 84 Seating and safety restraints If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.

  • Page 85: Safety Restraints For Children

    SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Air Bag Supplemental Restraint System (SRS) in this chapter for special instructions about using air bags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S.

  • Page 86: Safety Seats For Children

    To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
  • Page 87 (passenger side front and outboard rear seating positions) (if equipped) section in this chapter. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
  • Page 88 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
  • Page 89 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
  • Page 90 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
  • Page 91 The tether strap anchors in your vehicle are in the following positions (shown from top view): Coupe Sedan Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor. 1.
  • Page 92 Seating and safety restraints 4. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. For further instructions to secure the child safety seat, refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter.

  • Page 93: Preparing To Start Your Vehicle

    PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
  • Page 94 Starting 2. Make sure the headlamps and vehicle accessories are off. 3. Make sure the parking brake is set. If starting a vehicle with an automatic transaxle: Make sure the gearshift is in P (Park). If starting a vehicle with a manual transaxle: Push the clutch pedal to the floor.
  • Page 95 4. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely. This condition may occur when: front wheels are turned front wheel is against the curb steering wheel is turned when getting in or out of the vehicle...

  • Page 96: Starting The Engine

    Starting STARTING THE ENGINE NOTE: Whenever you start your vehicle, release the key as soon as the engine starts. Excessive cranking could damage the starter. 1. Turn the key to 4 (START) without pressing the accelerator pedal and release as soon as the engine starts.
  • Page 97 Guarding against exhaust fumes Although odorless and colorless, carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes.

  • Page 98: Driving

    Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
  • Page 99 ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...
  • Page 100 Driving The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released. The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency.
  • Page 101 If the steering wanders or pulls, the condition could be caused by any of the following: underinflated tire(s) on any wheel(s) uneven vehicle loading high crown in center of road high crosswinds wheels out of alignment loose or worn suspension components TRANSAXLE OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents...
  • Page 102 Driving 3. Push and hold the thumb button. 4. Move the gearshift lever. If it is necessary to use the above procedure to move the gearshift lever, it is possible that a fuse has blown and the vehicle’s brakelamps may not be operating properly. Refer to Fuses and relays in the Roadside emergencies chapter.
  • Page 103 Understanding gearshift positions Hold the brake pedal down while you move the gearshift lever from P (Park) to another position. If you do not hold the brake pedal down, your vehicle may move unexpectedly and injure someone. P (Park) Always come to a complete stop before shifting into P (Park).
  • Page 104 Driving N (Neutral) With the gearshift lever in the N (Neutral) position, the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. (Overdrive) The overdrive position is the normal driving position for an automatic overdrive transaxle.
  • Page 105 D (Drive) D (Drive) eliminates the needless shifting between third and fourth gears that your vehicle may do when driving in hilly terrain. It also gives more engine braking than overdrive to slow your vehicle on downgrades. L (Low) Use L (Low) when added engine braking is desired or when descending steep hills.
  • Page 106 Driving Using the clutch Vehicles equipped with a manual transaxle have a starter interrupt interlock that prevents cranking of the engine unless the clutch pedal is depressed. When starting a vehicle with a manual transaxle, you must: 1. Put the gearshift lever in the neutral position.
  • Page 107 Parking your vehicle 1. Apply the brake and shift into the neutral position. 2. Set the parking brake. 3. Shift into 1 (First). Driving...
  • Page 108 Driving 4. Turn engine off and remove the key. Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Recommended shift speeds Upshift according to the following charts for best fuel economy: Upshifts when accelerating (recommended for best fuel economy) Upshifts when cruising (recommended for best fuel economy) Reverse...

  • Page 109: Vehicle Loading

    Put the gearshift lever into the neutral position and wait at least three seconds before shifting into R (Reverse). You can shift into R (Reverse) only by moving the gearshift lever from left of 3 (Third) and 4 (Fourth) gears before you shift into R (Reverse). This is a special lockout feature which prevents you from shifting into R (Reverse) when you downshift from 5 (Fifth).
  • Page 110 Driving Maximum Trailer Weight Rating: Maximum weight of a trailer the vehicle is permitted to tow. The maximum trailer weight rating is determined by subtracting the vehicle curb weight for each engine/transmission combination, any required option weight for trailer towing and the weight of the driver from the GCWR for the towing vehicle.

  • Page 111: Trailer Towing

    TRAILER TOWING Your vehicle is capable of towing a trailer up to 454 kg (1 000 lbs.) gross trailer weight with a maximum tongue load of 45 kg (100 lbs.). Do not tow a trailer until your vehicle has been driven at least 800 km (500 miles).
  • Page 112 Driving Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.

  • Page 113: Driving Through Water

    The trailer tongue weight should be 10% of the loaded trailer weight. After you have traveled 80 km (50 miles), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. When stopped in traffic for long periods of time in hot weather, place the gearshift in P (Park) and increase idle speed.

  • Page 114: Roadside Emergencies

    Roadside emergencies Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: 24–hours, seven days a week for the Basic warranty period (Canada) or New Vehicle Limited Warranty period (U.S.) of three years or 60 000 km (36 000 miles),...
  • Page 115 Roadside coverage beyond basic warranty In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, for uninterrupted Roadside Assistance coverage, you may purchase extended coverage prior to your Basic Warranty’s Roadside...
  • Page 116 Roadside emergencies Right side of the trunk behind the trunk liner. Driver’s foot well, behind the kick panel. The fuel pump shut-off switch, depending on application, is located on the right side of the trunk behind the trunk liner or in the driver’s foot well, behind the kick panel.

  • Page 117: Fuses And Relays

    Roadside emergencies Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3. If no fuel leak is apparent, reset the fuel pump shut-off switch by pushing in on the reset button.
  • Page 118 Roadside emergencies Standard fuse amperage rating and color Fuse Mini rating fuses Grey Violet Pink 7.5A Brown Blue Yellow Natural Green — — — — — COLOR Standard Maxi fuses fuses Grey — Violet — Pink — — Brown — —...
  • Page 119 Passenger compartment fuse panel Coupe The fuses are coded as follows: Fuse/Relay Location HAZARD ROOM ENGINE RADIO DOOR LOCK HORN AIR COND METER Roadside emergencies (DRL) (DOOR LK) STOP HAZARD HORN (AIR COND) (SUN ROOF) ROOM (ASC) ENGINE METER RADIO WIPER Fuse Amp Passenger Compartment Fuse...
  • Page 120 Roadside emergencies Fuse/Relay Location WIPER STOP TAIL SUN ROOF P. WINDOW CIGAR AIR BAG AUDIO FUEL INJ. BLOWER Fuse Amp Passenger Compartment Fuse Rating Wiper/Washer, Blower Motor Relay Stop Lamps, Brake Pressure Switch Exterior Lamps, Instrument Illumination Power Moonroof Speed Control 30A CB Power Windows Cigar Lighter...
  • Page 121 Sedan The fuses are coded as follows: Fuse/Relay Location R.WIPER HAZARD ROOM ENGINE MIRROR DOOR LOCK HORN AIR COND METER WIPER Roadside emergencies R. WIPER (DOOR LK) STOP HAZARD HORN TAIL ROOM (AIR COND) SUNROOF ENGINE METER (ASC) MIRROR WIPER Fuse Amp Passenger Compartment Fuse Rating...
  • Page 122 Roadside emergencies Fuse/Relay Location STOP TAIL SUN ROOF CIGAR AIR BAG AUDIO FUEL INJECTOR P. WINDOW BLOWER Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads.

  • Page 123: Cooling Fan

    Coupe The high-current fuses are coded as follows. Fuse/Relay Location FUEL INJ. DEFOG MAIN COOLING FAN OBD-II FUEL PUMP HEAD RH HEAD LH * Fuse Link Cartridge **Fuse Roadside emergencies HEADLAMP RELAY HEAD LH 10A USE THE DESIGNATED FUSES ONLY Fuse Amp Rating 30A*...
  • Page 124 Roadside emergencies Sedan HEADLAMP The high-current fuses are coded as follows. Fuse/Relay Location FUEL INJ. DEFOG MAIN COOLING FAN OBD-II FUEL PUMP HEAD RH HEAD LH * Fuse Link Cartridge ** Fuse RELAY HEAD LH 10A USE THE DESIGNATED FUSES ONLY Fuse Amp Rating 30A*...

  • Page 125: Changing The Tires

    Relays Relays are located in the power distribution box and should be replaced by qualified technicians. CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road.
  • Page 126 Roadside emergencies Tire change procedure 1. Park on a level surface, activate hazard flashers and set the parking brake. When one of the front wheels is off the ground, the transaxle alone will not prevent the vehicle from moving or slipping off the jack, even if the vehicle is in P (Park) (automatic transaxle) or R (Reverse) (manual transaxle).
  • Page 127 Automatic Manual 3. Remove the jack, jack handle, lug wrench and spare tire. Roadside emergencies...
  • Page 128 Roadside emergencies 4. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 5. Put the jack in the jack notch next to the door of the tire you are changing.

  • Page 129: Jump Starting Your Vehicle

    JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes, and clothing, if contacted. Do not attempt to push-start your vehicle.
  • Page 130 Roadside emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
  • Page 131 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
  • Page 132 Roadside emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
  • Page 133 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.

  • Page 134: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.

  • Page 135: Maintenance And Care

    SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
  • Page 136 Maintenance and care 2. Turn off the engine and remove the key. 3. Block the wheels to prevent the vehicle from moving unexpectedly. Manual transaxle: 1. Set the parking brake, depress the clutch and place the gearshift in 1 (First). 2.
  • Page 137 Working with the engine on Automatic transaxle: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Block the wheels to prevent the vehicle from moving unexpectedly. NOTE:Do not start your engine with the air cleaner removed and do not remove it while the engine is running.

  • Page 138: Opening The Hood

    Maintenance and care 2. Block the wheels to prevent the vehicle from moving unexpectedly. NOTE:Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel.
  • Page 139 Maintenance and care 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood. 3. Lift the hood and secure it with the prop rod.

  • Page 140: Identifying Components In The Engine Compartment

    Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.0L SOHC I4 engine 1. Engine oil dipstick 2. Brake fluid reservoir 3. Transmission fluid dipstick (automatic transaxle) 4. Battery 5. Air filter assembly 6. Engine oil filler cap 7. Power steering fluid reservoir 8.
  • Page 141 Maintenance and care 2.0L DOHC Zetec engine 1. Transmission fluid dipstick (automatic transaxle) 2. Battery 3. Air filter assembly 4. Engine oil filler cap 5. Engine oil dipstick 6. Power steering fluid reservoir 7. Engine coolant reservoir 8. Windshield washer fluid reservoir 9.

  • Page 142: Engine Oil

    Maintenance and care ENGINE OIL Checking the engine oil Refer to the scheduled maintenance guide for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
  • Page 143 2.0L DOHC Zetec engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. If the oil level is between the ADD and FULL marks, the oil level is acceptable. DO NOT ADD OIL. If the oil level is below the ADD mark, add enough oil to raise the level within the ADD-FULL range.
  • Page 144 Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft or an equivalent oil meeting Ford specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
  • Page 145 Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.

  • Page 146: Clutch Fluid (If Equipped)

    Maintenance and care Do not let the fluid level in the reservoir for the master cylinder fall below the MIN mark. If master cylinder runs dry, this may cause the brakes to fail. CLUTCH FLUID (IF EQUIPPED) The clutch master cylinder and brake master cylinder are part of the same system;...

  • Page 147: Windshield Washer Fluid

    If the level is low, add enough fluid to fill the reservoir. In very cold weather, do not fill the reservoir all the way. Only use a washer fluid that meets Ford specifications. Refer to Lubricant specifications in the Capacities and specifications chapter.

  • Page 148: Engine Coolant

    Maintenance and care Note:Do not put washer fluid in the engine coolant reservoir. Washer fluid placed in the cooling system may harm engine and cooling system components. ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide.
  • Page 149 Coupe Sedan When the engine is cold, check the level of the engine coolant in the reservoir. The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
  • Page 150 The cooling system in your vehicle is filled with either green-colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir. Add Motorcraft Premium Engine Coolant (green-colored), VC-4–A (U.S.) or CXC-10 (Canada) or Motorcraft Premium...
  • Page 151 Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled Engine Coolant section). For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
  • Page 152 Operating an engine with a low level of coolant can result in engine overheating and possible engine damage. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored). However, not all coolant recycling processes produce coolant that meets Ford specification ESE-M97B44–A.

  • Page 153: Checking And Adding Power Steering Fluid

    Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate freeze protection at the temperatures in which you drive in the winter months. If you drive in extremely hot climates: It is still necessary to maintain the coolant concentration above 40%.

  • Page 154: Transmission Fluid

    Maintenance and care Sedan 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C). 2. While the engine idles, turn the steering wheel left and right several times.
  • Page 155 1. Drive the vehicle 30 km (20 miles) or until it reaches normal operating temperature. 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.
  • Page 156 Maintenance and care Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used. The type of fluid used is normally indicated on the dipstick and also in the Lubricant specifications section in the Capacities and specifications chapter.
  • Page 157 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to the Capacities and specifications chapter. BATTERY Your vehicle is equipped with a...
  • Page 158 Maintenance and care For longer, trouble-free operation, keep the top of the battery clean and dry. Also, make certain the battery cables are always tightly fastened to the battery terminals. If you see any corrosion on the battery or terminals, remove the cables from the terminals and clean with a wire brush.

  • Page 159: Air Filter Maintenance

    4. Allow the engine to idle for at least one minute. 5. Turn the A/C on and allow the engine to idle for at least one minute. 6. Drive the vehicle to complete the relearning process. The vehicle may need to be driven 16 km (10 miles) or more to relearn the idle and fuel trim strategy.

  • Page 160: Changing The Air Filter Element

    Maintenance and care CHANGING THE AIR FILTER ELEMENT 1. Release the clamp locking clip on the front portion of the air filter housing. 2. Then swing the left side open and remove the air filter element. 3. When installing the air filter element, ensure the nubs on the air filter element and the air filter housing are aligned.

  • Page 161: Information About Uniform Tire Quality Grading

    10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it.
  • Page 162 Maintenance and care Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
  • Page 163 SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
  • Page 164 Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over.

  • Page 165: Snow Tires And Chains

    SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.

  • Page 166: What You Should Know About Automotive Fuels

    Maintenance and care WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 167 Observe the following guidelines when handling automotive fuel: Extinguish all smoking materials and any open flames before fueling your vehicle. Always turn off the vehicle before fueling. Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
  • Page 168 If you must replace the fuel filler cap, replace it with a fuel filler cap that is designed for your vehicle. The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used.
  • Page 169 The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible...
  • Page 170 World-wide Fuel Charter. In Canada, look for fuels that display the Auto Makers’ Choice Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.

  • Page 171: Essentials Of Good Fuel Economy

    Fuel Filter For fuel filter replacement, see your dealer or a qualified service technician. Refer to the scheduled maintenance guide for the appropriate intervals for changing the fuel filter. Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used.
  • Page 172 Maintenance and care Allow no more than 2 automatic click-offs when filling. Always use fuel with the recommended octane rating. Use a known quality gasoline, preferably a national brand. Use the same side of the same pump and have the vehicle facing the same direction each time you fill up.
  • Page 173 Idling for long periods of time (greater than one minute) may waste fuel. Anticipate stopping; slowing down may eliminate the need to stop. Sudden or hard accelerations may reduce fuel economy. Slow down gradually. Driving at reasonable speeds (traveling at 88 km/h [55 mph] uses 15% less fuel than traveling at 105 km/h [65 mph]).

  • Page 174: Emission Control System

    If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine...
  • Page 175 Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the “Service Engine Soon” light, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power, could indicate that the emission control system is not working properly.
  • Page 176 Maintenance and care Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature. Once started, do not turn off the engine until the above driving cycle is complete. BULBS Replacing exterior bulbs It is a good idea to check the operation of the following lights frequently:...
  • Page 177 5. Remove the bulb retaining ring by rotating it counterclockwise. 6. Without turning, remove the old bulb from the lamp assembly by pulling it straight back out of the lamp assembly and replace. Handle a halogen headlamp bulb carefully and keep out of children’s reach.
  • Page 178 Maintenance and care Replacing foglamp bulbs 1. Remove the bulb socket from the foglamp by turning counterclockwise. 2. Disconnect the electrical connector from the foglamp bulb. 3. Connect the electrical connector to the new foglamp bulb. 4. Install the bulb socket in the foglamp turning clockwise.
  • Page 179 Maintenance and care Tail lamp/turn signal/backup lamp bulbs The tail/turn signal lamp and backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb. 1.

  • Page 180: Interior Bulbs

    Maintenance and care License plate lamps To change the license plate bulbs: 1. Remove two screws and the license plate lamp assembly from the rear bumper. 2. Carefully pull the bulb out from the lamp assembly and push in the new bulb.

  • Page 181: Aiming The Headlamps

    Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
  • Page 182 Maintenance and care Horizontal aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, locate the horizontal indicator and the adjusting screw. They are located below the viewing window at the rear of the headlamp assembly. 3.
  • Page 183 Maintenance and care Vertical aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, locate the bubble level and the vertical adjustment screw. The adjustment screw is located on the outboard side of the headlamp below the headlamp upper attachment.

  • Page 184: Cleaning And Caring For Your Vehicle

    Maintenance and care CLEANING AND CARING FOR YOUR VEHICLE Refer to the Customer Assistance chapter for a list of Ford-approved cleaners, polishes and waxes. Washing your vehicle Wash your vehicle regularly with cold or lukewarm water. Never use strong detergents or soap. If your vehicle is particularly dirty, use a quality car wash detergent.
  • Page 185 Ultra Touch Prep and Finishing Kit (F7AZ-19K507–BA), Lacquer Touch-up Paint (ALBZ-19500–XXXXA), or Exterior Acrylic Spray Lacquer (ALAZ-19500–XXXXA) from the Ford Car Care Chemicals line. Please note that the part numbers (shown as XXXX above) will vary with your vehicle’s specific coloring. Observe the application instructions on the products.
  • Page 186 Cleaning the exterior lamps Wash with the same detergent as the exterior of your vehicle. If necessary, use a tar remover such as Ford Extra Strength Tar and Road Oil Remover (B7A-19520–AA). To avoid scratching the lamps, do not use a dry paper towel, chemical solvents or abrasive cleaners.
  • Page 187 Cover the highlighted areas to prevent water damage when cleaning the engine. Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning the instrument panel Clean with a damp cloth, then dry with a dry cloth. Avoid cleaner or polish that increases the gloss of the upper portion of the instrument panel.
  • Page 188 For tougher soiling concerns, Ford recommends using the Deluxe Leather Care Kit F8AZ-19G253–AA, which is available from your Ford Dealer. This mild cleaner and special pad, cleans the leather and maintains its natural beauty. Follow the instructions on the cleaner label.

  • Page 189: Capacities And Specifications

    MOTOCRAFT PART NUMBERS Component Air filter element Fuel filter Battery Oil filter PCV valve Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. ** If a spark plug is removed for inspection, it must be reinstalled in the same cylinder.

  • Page 190: Refill Capacities

    Capacities and specifications REFILL CAPACITIES Ford Part Fluid Name Brake fluid High Performance DOT 3 Motor Vehicle Brake Fluid Engine coolant Motorcraft Premium Engine Coolant (green-colored) or Motorcraft Premium Gold Engine Coolant (yellow-colored) Engine oil Motorcraft SAE (includes filter 5W-20Super...

  • Page 191: Lubricant Specifications

    LUBRICANT SPECIFICATIONS Ford Part Item Name or Equivalent Brake fluid Motorcraft High Performance DOT 3 Motor Vehicle Brake Fluid Door latch, hood Multi-Purpose latch, auxiliary Grease hood latch, trunk latch, seat tracks. Lock cylinder Penetrating and Lock Lubricant Automatic Motorcraft...

  • Page 192: Engine Data

    Windshield Ultra-clear washer fluid Windshield Washer Concentrate DO NOT USE Ford Extended Life Engine Coolant F6AZ-19544-AA, meeting Ford specification WSS-M97B44-D (orange in color) Refer to Adding engine coolant, in the Maintenance and Care chapter. ENGINE DATA Engine Cubic inches Required fuel...

  • Page 193: Vehicle Dimensions

    VEHICLE DIMENSIONS Vehicle dimensions (1) Overall length (2) Overall width (3) Overall height (4) Wheelbase (5) Track - Front (5) Track - Rear Coupe model Capacities and specifications Coupe mm (in) 4 451.0 (175.2) 1 712.0 (67.4) 1 328.4 (52.3) 2 499.0 (98.4) 1 435.1 (56.5) 1 435.1 (56.5)
  • Page 194 Capacities and specifications Coupe model IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
  • Page 195 Capacities and specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block and transmission.

  • Page 196: Customer Assistance

    United States and Canada, provided by a network of more than 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information.
  • Page 197 Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
  • Page 198 Ford Motor Company of Canada, Limited P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: Your telephone number (home and business).

  • Page 199: The Dispute Settlement Board (U.s. Only)

    Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this service without notice and without incurring obligations per applicable state law.
  • Page 200 Ford Motor Company the names (if known) of all the people you contacted at the...
  • Page 201 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.

  • Page 202: Getting Assistance Outside The U.s. And Canada

    UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 203 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
  • Page 204 * May be sold with the Motorcraft name FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs;...
  • Page 205 Customer assistance Comfort and convenience Air conditioner Cargo net Cargo organizer Engine block heater Travel equipment Auto headlamps with daytime running lights (DRL) Console armrest Daytime running lights (DRL) Electrochromic inside mirror with compass Electrochromic inside mirror with compass and temperature display Highway safety kit First aid kit Removable luggage rack...

  • Page 206: Ordering Additional Owner's Literature

    (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment. ORDERING ADDITIONAL OWNER’S LITERATURE...

  • Page 207: In California (U.s. Only)

    Customer assistance Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer...

  • Page 208: Reporting Safety Defects

    However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.

  • Page 209: Index

    Air bag supplemental restraint system ...79–80 and child safety seats ...82 description ...80 disposal ...84 driver air bag ...82 indicator light ...10, 84 operation ...82 passenger air bag ...82 Air cleaner filter ...159–160, 189 Air conditioning ...38 Antifreeze (see Engine coolant) ...148 Anti-lock brake system (see Brakes) ...98–99...
  • Page 210 ...148 refill capacities ...152, 190 specifications ...191–192 Cruise control (see Speed control) ...46 Customer Assistance ...114 Ford accessories for your vehicle ...203 Ford Extended Service Plan ...196 Getting assistance outside the U.S. and Canada ...202 Getting roadside assistance ...114 Getting the service you need ...196...
  • Page 211 specifications ...191–192 Exhaust fumes ...97 Floor mats ...56 Fluid capacities ...190 Foglamps ...45 Fuel ...166 calculating fuel economy ...171 cap ...12, 168 capacity ...190 choosing the right fuel ...169 comparisons with EPA fuel economy estimates ...174 detergent in fuel ...170 filling your vehicle with fuel ...166, 168, 171 filter, specifications ...171, 189...
  • Page 212 Index Inspection/maintenance (I/M) testing ...175 Instrument panel ...8 cleaning ...187 cluster ...8, 187 lighting up panel and interior ...17 location of components ...8 Jack ...125 positioning ...125 storage ...125 Jump-starting your vehicle ...129 Keys key in ignition chime ...13 positions of the ignition ...44 Lamps bulb replacement specifications chart ...181...
  • Page 213 Panic alarm feature, remote entry system ...60 Parking brake ...99 Parts (see Motorcraft parts) ...189 Power distribution box (see Fuses) ...122 Power door locks ...54 Power steering ...100 fluid, checking and adding ...153 fluid, refill capacity ...190 fluid, specifications ...191–192 Radio ...19 Rear window defroster ...43 Relays ...117, 125...
  • Page 214 Index Towing ...111 trailer towing ...111 wrecker ...134 Transaxle automatic operation ...101 fluid, refill capacities ...190 lubricant specifications ...192 Transmission fluid, checking and adding (automatic) ...154 fluid, checking and adding (manual) ...156 lubricant specifications ...191 Trip odometer ...16 Trunk ...56 remote release ...18, 59 Turn signal ...11, 46 Vehicle dimensions ...193...

  • Page 216: Filling Station Information

    Manual transaxle capacity Use either green-colored Motorcraft Premium Engine Coolant or yellow-colored Motorcraft Premium Gold Engine Coolant. DO NOT USE Ford Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in the Maintenance and Care chapter. Information Unleaded fuel only - 87 octane 48.5L (12.8 gallons)

Table of Contents
