3. The partial or total non-respect of the safety instructions in the present
instruction manual will automatically release Singer of any type of
responsibility in case of malfunction of the machine or injuries to persons
or animals.
4. In case of manipulation, repairing or any modifi cation of the machine made
by unqualifi ed persons or in case of improper use, the guarantee will be
automatically cancelled.

PARTS DESCRIPTION

E
D
C
B
A
A: Soleplate
B: Water Tank
C: Water Spray Nozzle
D: Water Fill Cover
E: Steam Knob
F: Water Spray & Burst of Steam Buttons
G: Cord Guard
H: Temperature Dial
I: Self-Clean Button
F
H
I
5
ENGLISH
G
