RiseAtlas450T/RiseAtlas625T
with SmartPark-function
SystemRoMedic
TM
RiseAtlas450T/625T is a safe and easy-to-use stationary ceiling lift unit which can be used in all settings and in all types
of rooms, both on permanent rail systems and on portable, freestanding lift stands. When used with the appropriate
lifting accessories, RiseAtlas450T/625T provides secure, comfortable and individually adapted lifting of users in
connection with seated or horizontal transfers to and from the bed, wheelchair or toilet. RiseAtlas450T/625T offers a
large lifting area and the possibility of both very low and very high lifting, making it an excellent solution also for lifting
from the floor and for gait training and standing training. RiseAtlas450T/625T can also be used for convenient transfer of
users from one room to another. RiseAtlas450T/625T with SmartPark-function is equipped with a built-in transfer motor.
The SmartPark-function allows the lift unit to be returned to the parking place and charging position with a simple touch
of the hand control.
Functional inspection
Visual inspection
Inspect lift functions regularly. Check to ensure that product is free from damage.
Before use
Ensure that the product is correctly mounted in the trolley.
Check rail end stops.
Check sling bar connection and safety latch function.
Check lifting movement.
Inspect the lift for signs of wear and damage.
Check the hand control cable for signs of wear.
Check to ensure that hand control markings coincide with lift functions.
Check battery charge level.
Always read the user manual
Always read the user manuals for all assistive devices used during a transfer.
Keep the user manual where it is accessible to users of the product.
Under no circumstances may the lift be used by persons who have not received instruction in the operation of the lift.
It is strongly prohibited to modify the original product.
Manual nr: 708-En Ver. 6 150504
User manual - English
50100052 (RiseAtlas450T)
50100053 (RiseAtlas625T)
SWL:
RiseAtlas450T: 205 kg/450 lbs
RiseAtlas625T: 285 kg/625 lbs
Advertisement
Table of Contents
Related Manuals for SystemRoMedic RiseAtlas450T
Summary of Contents for SystemRoMedic RiseAtlas450T
- Page 1 RiseAtlas625T: 285 kg/625 lbs RiseAtlas450T/625T is a safe and easy-to-use stationary ceiling lift unit which can be used in all settings and in all types of rooms, both on permanent rail systems and on portable, freestanding lift stands. When used with the appropriate lifting accessories, RiseAtlas450T/625T provides secure, comfortable and individually adapted lifting of users in connection with seated or horizontal transfers to and from the bed, wheelchair or toilet.
-
Page 2: Table Of Contents
- Preventive service maintenance .............12 - Emergency stop ...................13 - Electrical emergency lowering ...............13 - Manual emergency lowering/raising ............13 - Trouble-shooting ..................14 Accessories ..................15 Maintenance ..................16 Technical information ............17-18 - Detailed description ................18 SystemRoMedic M A N U A L... -
Page 3: Installation
Incorrect installation may cause short-circuiting and damage the charger. Alteration of the charging method must be performed by authorized personnel according to instructions issued by Handicare AB. SystemRoMedic M A N U A L... - Page 4 The strap is cut with scissors and singed at the end as to prevent unravel. Handicare recommends a height of 180 cm/70 inches above the floor. SystemRoMedic M A N U A L...
- Page 5 6) Connect the red cable to the charger contact on the right side, the charger plate’s plus side (positive), and the black cable on the left side (negative), according to fig 6. 7) Install the end-stop on the rail. Spring pin + Plus SystemRoMedic M A N U A L...
-
Page 6: Different Rail Systems
RiseAtlas is shipped with the emergency stop activated to prevent battery discharge during transport or long-term storage. Always keep the key for the emergency lowering close to the lift. All personnel who use the lift must be informed of where the key is kept. SystemRoMedic M A N U A L... -
Page 7: Using The Product
- Inspect the lift for signs of wear and damage. - Check the hand control cable for signs of wear. - Check to ensure that hand control markings coincide with lift functions. - Check battery charge level. SystemRoMedic M A N U A L... -
Page 8: Safe Working Load
ISO 10535:2006 with CSA-C22.2 No. 60601-1:08 Symbols on the product Battery status Emergency stop The lift requires service or Directional indication, transfer maintenance motor Overload Warning! Read the user manual Read user manual SystemRoMedic M A N U A L... -
Page 9: Charging The Lift Unit
For maximum service life, charge batteries regularly. Do not allow the battery charge level to fall below 25% (orange symbol on control panel). Emergency stop must not be activated during charging. Batteries may only be replaced by authorized personnel. SystemRoMedic M A N U A L... -
Page 10: Smartpark-Function
10 kg when SmartPark is activated. Activation SmartPark is activated by pressing the left and right arrows simultaneously. Hold the buttons in until a beep is heard (about 4-5 seconds). SystemRoMedic M A N U A L... -
Page 11: Hand Control
When the top limit switch has been activated it will reverse the strap 5 mm to clear the pressure from the switch. This action will take place after the up button has been deactivated. SystemRoMedic M A N U A L... -
Page 12: Information Panel
Preventative service/maintenance The symbol for service/maintenance lights up automatically when the lift unit has been in service for 12 months. Contact an authorized Handicare service technician for maintenance and resetting. SystemRoMedic M A N U A L... -
Page 13: Emergency Stop
Turn it counter-clockwise to lower and clockwise to raise the sling bar. Always ensure that emergency lowering is done in an appropriate location. NOTE! Lowering is very slow. Re-setting manual emergency lowering/raising: Contact an authorized Handicare service techni- cian. Do not use the lift unit. Allen key SystemRoMedic M A N U A L... -
Page 14: Trouble-Shooting
- Prevents the lift from lifting more than the maximum load. If this happens A symbol for overload and a warning triangle light up (amber) a signal is heard. If this symbol is activated, the user is too heavy. SystemRoMedic M A N U A L... -
Page 15: Accessories
Parking Placard, article no.: 50400048 Lifting slings Handicare’s SystemRoMedic™ line includes a wide range of functional and comfortable, high-quality lifting slings that are adapted for all types of lifting and for users with different needs. The lifting slings are available in several materials and in sizes ranging from XXS to XXL. -
Page 16: Maintenance
700 and 1060 hPa. Let the lift reach room temperature before the batteries are charged or the lift is used. 1060 hPa +50 °C -10 °C 700 hPa Service agreements Handicare offers service agreements for maintenance and regular testing of your lift unit. Contact your local Handicare representative. SystemRoMedic M A N U A L... -
Page 17: Technical Information
10, though not more than 2 min. Expected service life: 10 years Pressure hand control: SWL RiseAtlas450T: 205 kg, 450 lbs SWL RiseAtlas625T: 285 kg, 625 lbs Medical Device Class I. The product complies with the requirements of the Medical Devices Directive 93/42/EEC. -
Page 18: Detailed Description
5. Manual emergency lowering/raising (inside cover) 6. Control panel A. Rail 6.4-16.0 cm/2,5-6,2 inch B. Lift unit overall height 16.0 cm/6,2 inch C. Installation height 23.0 cm/9 inch Installation height on SlingBar M, 32,7 cm/12,8 inch SystemRoMedic M A N U A L... - Page 19 SystemRoMedic M A N U A L...
- Page 20 SystemRoMedic™ is a complete solution that provides for the majority of patient transfer or manual handling requirements. From the simplest to the most complex scenarios, from the lightest to the heaviest. The concept encompasses assistive devices for four different categories of transfers: •...
