3. Slide the charger into the battery pack until it is
fully seated (Figure
4. To remove the charger, slide the charger
backward out of the battery.
5. Refer to the following table to interpret the LED
indicator light on the battery charger.
Indicator Indicates
light
Off No battery pack inserted
Green Battery pack is charging
blinking
Battery pack is charged
Green
Red Battery pack and/or battery charger is over or under
the appropriate temperature range
Red Battery pack charging fault*
blinking
*Refer to Troubleshooting (page 11)
information.
Important:
The battery can be left on the charger
for short periods between uses.
If the battery will not be used for longer periods,
remove the battery from the charger; refer to
Storage (page 10).
8).
for more
