Safety Advice Attention In some countries approval is needed to set up a marquee/tent larger than 75 m2. It is your responsibility to comply with local rules and regulations and to ensure that the marquee/tent is assembled correctly. In case of bad weather conditions, it is your responsibility to ensure the marquee/tent is safely secured and that the marquee/tent does not cause damage to others.
Page 3
4m storagetent manual Part Middle Leg 1880mm 50-50 Frame pole 1880mm 38-38 Frame pole 1880mm 38-38 Frame pole 1880mm 38-38 Frame pole 2030mm 50-50 Groundbar pipe Diagonal support 1174mm 25-25 Roof support 1652mm 25-25 Corner Leg 1880mm 50-50 Male doorbar Female doorbar Pillar Pillar...
Page 4
4m storagetent manual Part eiling rail 3-way 15-1 Connector 54-42 (A) 4-way 15-2 Connector 54-42 (B) 3-way Connector for corner 3-way Connector for corner 3-way Connector for sidewall Strengthen bar Bracket Groundbracket 400mm Spiral peg Long peg Small peg Bungeeball long Rope 11-12-2013-SH...
Page 5
4m storagetent manual Part Screw M6X30 Screw M6X45 M6 Wingnut Screw M8x50mm Screw M8X60mm M8 Nut Spanner Steel tension bar Turnbuckle Tit down Steel clip Endwall 11-12-2013-SH...
Page 6
Select a at ground for the tent, unpack the carton and check all the parts including tubes, tent and accessories… etc. are present and the same as the list. Assemble the framework of rooftop by joining the portion (15-1.15-2) together with poles (2.3-1.3-2.4) NO.3 is on four corners for diagonal pipe 15-2 15-2...
Page 7
Attach the another supported poles (1.8) to the joints, built-up the framework. 15-1 15-2 15-2 15-2 15-1 15-1 15-1 15-2 You facilitate the assembly and dismantling by pulling the roof with ropes ont tent frame. Use the steel clips to fasten the cover to the frame.
Page 8
Spread the wall panel and door panel attach to framework by using the bangee cords clasping the frame to grommets that is construct over the wall panel and door panel to ensure stability. Also use the short pegs to x the doors to the ground.
