Camaro introduction HOW to Use Seats Part 1 Part 2 Features & Controls Comfort Controls & Audio Systems Part 3 Your Driving Part 4 Road Problems Part 5 Part 6 Service & Appearance Part 7 Maintenance Part 8 Customer Assistance Information Including “Reporting Safety Defects”...
Page 4: Camaro
How to Use This Manual important Notes about This Manual Please keep this manual in your Chevrolet, so it will be there if you ever need it when you’re on the road. If you sell the vehicle, please leave this manual in it so the new owner can use it.
Page 5 The Heritage of Chevrolet Louis Chevrolet, the other half of the team, at the wheel of his experimental “Classic which entered production in 191 2. That year 2999 vehicles were produced. Six,” The dynamic William C. “Billy” Durant shifted gears @om making carriages to...
Page 6 The legacy of America’s favorite sportscar began in 1953, when 31 9 hand-...
Page 7 American public-and was powered by available @el-injected V8. - - - - - - - - - - . Your new Chevrolet continues a tradition of quality and value. .. , . . . ,~ 5 . . .
Page 8: Part 1 Seats
Part 6 Service & Appearance Care: Here the manual tells you how to keep your Chevrolet running properly and looking good. Part 7 Maintenance Schedule: This part tells when to perform vehicle maintenance and what fluids and lubricants to use.
Page 9 Safefy Warnings and Symbols You will find a number of safety cautions in this book. We use a box with a gray background and the word CAUTION to tell you about things that could hurt you if you were to ignore the warning. In the gray caution area, we tell you what the hazard is.
Page 10 How to Use This Manual Vehicle Symbols These are some of the symbols you will find on your vehicle. For example, these symbols are used on an original battery: Caution Possible Injury Protect Eyes by Shielding Caustic Battery Acid Could Cause Burns Avoid Sparks or Flames Sparks or Flame could Explode Battery...
Page 11 Rear Window Defogger Ventilating Fan Bi-Level Vent Heater Blend These symbols are used on warning and indicator lights: Engine Coolant Temperature Battery Charging System Fuel Engine Oil Pressure Brake (Canada) Anti-Lock Brake System (Canada) Low Coolant Here are some other symbols you may see: Hatchflrunk Release Hood Release Lighter...
Page 12 How to Use This Manual . 1 0...
Page 13 H e r e you’ll find information about the seats in your Chevrolet and how to use your safety belts properly can also learn about some things you should do with safety belts Seats & Restraint Systems ..........
Page 14 Seats and Restraint Systems Seats and Seat Controls This section tells you about the seats how to adjust them, and also about reclining front seatbacks, seatback latches and the folding rear seatback. . 1 2 Manual Front Seat Move the lever under the passenger’s front seat to unlock it.
Page 15 CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s is moving. The seat while the vehicle sudden movement could startle and confuse you, or make you push pedal when you don’t want to. Adjust the driver’s seat only when the vehicle is not moving.
Page 16 Seats and Restraint Systems ..IThen back in the sit.wdl seat wear . 1 4 your safety belt properly. Front Seatback latches The front seatbacks fold forward to let people get into the back seat. To fold a seatback forward, push the seatback toward the rear as you lift this latch.
Page 17 Folding Rear Seatback The rear seatback in your Chevrolet folds down to provide more storage space. To fold the seatback down: 1. Pull forward on both levers. 2. Fold the seatback down.
Page 18 Seats and Restraint Systems Safety Belts: They’re for Everyone This part of the manual tells how to safety belts properly. It also tells some things should not do with safety belts, And it explains the Supplemental Inflatable Restraint, or “ a i r bag”...
Page 19 Why Safety Belts Work When you ride in or on anything, you go as fast as goes. For example, if the bike is going 10 mph 6 k m k ) , so is the child. __..,.. When the bike hits the block, it stops. But the child keeps going! Take the simplest vehicle.
Page 20 Seats and Restraint Systems ,..\-." .;- T - 2 . 4 m . S Put someone on . I 8 it up to speed. Then stop the vehicle. The rider doesn't stop. The person keeps going until stopped by something. In a real vehicle, it could be the windshield ...
Page 21 ..or the instrument panel or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense.
Page 22 Seats and Restraint Systems Q: Why don’t they just put in air bags so people won’t have to wear safety belts? A: Air bags, or Supplemental Inflatable Restraint systems, are in some vehicles today and will be in more of them in the future.
Page 23 And there are different rules for smaller children and babies. If a child will be riding in your Chevrolet, see the section after this one, called “Children.” Follow those rules for everyone’s protection. First, you’ll want to know which restraint systems your vehicle has.
Page 24 Seats and Restraint Systems Pick up the latch plate and pull the belt across you. Don’t let it get twisted. 4. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure.
Page 25 5. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder belt. ’he lap part of the belt should be worn ow and snug on the hips, just touching he thighs.
Page 26 Seats and Restraint Systems Q: What’s wrong with this? A: The belt is buckled in the wrong place. CAUTION: can be seriously injured if your belt is buckled in the wrong place like this. crash, the belt would up over your abdomen. The belt forces would be there, not at the pel- vic bones.
Page 27 What’s wrong with this? A: The belt is twisted across the body. To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way.
Page 28 PRINTED IN U.5.A Supplemental lnfhtable Restraint System (Air Bags) This section explains the Supplemental Inflatable Restraint (SIR), or “air bag,” system. Your Chevrolet has an air bag for both the driver and the right-front passenger. SAFETY BELT, EVEN WITH AN BAG.
Page 29 air bag, or, worse, it could cause inju- r y . kir Bag Readiness Light ’here is an air bag readiness light on the xtrument panel, which shows “AIR LAG” on it. The system checks for lectrical malfunctions, and the light tells ou if there is a problem.
Page 30 Seats and Restraint Systems The right-front passenger’s air bag is located in the instrument panel on the passenger’s side. ’ * When is an air bag expected to inflate? The air bag is designed to inflate in moderate to severe frontal or near-frontal crashes.
Page 31 How does an air bag restrain? In moderate to severe frontal or near-frontal collisions, even belted occupants can contact the steering wheel or the instrument panel. The air bag supplements the protection provided by safety belts. Air bags distribute the force of the impact more evenly over the occupant’s upper body, stopping the occupant more gradually.
Page 32: Part 7 Maintenance
Servicing Your Air Bag-Equipped Chevrolet Air bags affect how your Chevrolet should be serviced. There are parts of the air bag system in several places around your vehicle. You don’t want the system to inflate while someone is working on your vehicle.
Page 33 Safety Belt Use during Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they don’t wear safety belts. pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible rhroughout the pregnancy.
Page 34 Seats and Restraint Systems 1. Pick up the latch plate and pull the belt across you. Don’t let twisted. Push the latch plate into the buckle until it clicks. If the belt stops before reaches the buckle, tilt the latch plate and keep pulling until you can buckle it.
Page 35 To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder part. 'he lap part of the belt should be worn 3w and snug on the hips, just touching he thighs.
Page 36 Seats and Restraint Systems To unlatch the belt, just push the button on the buckle. Children Everyone in a vehicle needs protection! That includes infants and all children smaller than adult size. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.
Page 37 will. suddenly 240-pound (1 baby become would be almost impossible hold. in an infant Secure the baby r e g i n t . force on your-arms. The baby Child Restraints Be sure follow the instructions for the restraint. You may find these instructions on the restraint itself or in a booklet, or both.
Page 38 If your child restraint has a top strap, it should be anchored. If you need to have an anchor installed, you can ask your Chevrolet dealer to put in for you. If you want to install an anchor yourself, your dealer can tell you how to do it.
Page 39 For cars first sold Canada, child restraints with a top strap must be anchored according to Canadian Law. Your dealer can obtain the hardware kit and install it for you, or you may install it yourself using the instructions provided with the kit.
Page 40 Seats and Restraint Systems 4. Buckle the belt. Make sure the release button is positioned you would be able to unbuckle the safety belt quickly if you ever had to. 5. To tighten the belt, pull up on the shoulder belt while you push down on the child restraint.
Page 41 You can get a locking clip where child restraints are sold, or from your Chevrolet dealer (GM Part No. 94844571). The locking clip must be the same as the one shown here.
Page 42 Seats and Restraint Systems Until you have this clip, secure a child restraint only in the rear seat. See the earlier section about securing a child restraint in the rear seat. Once you have the clip, follow these instructions: Because the vehicle has a right-front passenger's air bag, always move the seat as far back as will go before...
Page 43 CAUTION: If a locking clip is not used or is not installed properly, the child restraint may move or tip over when your vehicle turns or stops quickly. The child or others could be injured. When you secure a child restraint with a lap-shoulder belt, always thread both the lap and shoulder belt portions through a locking clip.
Page 44 Seats and Restraint Systems Larger Children Children who have outgrown child restraints should wear the vehicle's safety belts. Accident statistics show that children are safer if they are restrained in the rear seat. But they need use the safety belts properly.
Page 45 Q. What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? A: Move the child toward the center of the vehicle, but be sure that the shoulder belt still is on the child’s shoulder, so that in a crash the child’s upper body would have the restraint...
Page 46 Seats and Restraint Systems Replacing Safety Belts after a Crash If you’ve had a crash, do you need new belts? After a very minor collision, nothing may be necessary. But if the belts were stretched, as they would be if worn during a more severe crash, then you need new belts.
Page 47 H e r e you can learn about the nany standard and optional eatures on your Chevrolet. and nformation on starting. shifting md braking Also explained are he instrument panel and the varning systems that tell you if tverything is working properly...
Page 48 Features and Controls Keys reasons. A child or others many codd be badly injured or even killed. They operate power windows could other controls or even make the vehicle move. Don't leave the keys in vehicle with young children. The ignition keys are for the ignition only. The door keys are for the doors and all other locks.
Page 49 In an emergency, call Chevrolet Roadside Assistance at 1 -800-CHEV-USA. NOTICE: Your Chevrolet has a number of new features that can help prevent theft. But you can have a lot of trouble get- ting into your vehicle if you ever lock your keys inside.
Page 50 Features and Controls ’here are several ways to lock and unlock ‘our vehicle: ?om the outside: Use your door key. . 4 8 From the inside: To lock the door, move the lock control on the door back. To unlock the door, move the lock control on the door forward.
Page 51 Remote Lock Control (Option) If your Chevrolet has this option, you can lock and unlock your doors or unlock your hatch from about 30 feet (9 m) using the key chain transmitter supplied with your vehicle. Your Remote Lock Control operates on a...
Page 52 7. Check that all the buttons on both transmitters work correctly. [f the transmitters don’t work, or if you’d rather not match the transmitters yourself, see your Chevrolet dealer. Battery Replacement Under normal use, the batteries in your key chain transmitter should last about :wo years.
Page 53 To replace batteries in the Remote Lock Control: 1. Pop the cover off by inserting a dime (or similar object) in the slot between the covers and twisting. 2. Lift off the front cover, bottom half first. Remove and replace the batteries. Use two Duracell@ batteries, type DL2016, or a similar type.
Page 54 Features and Controls I‘ \ Remote Hatch Release (Option) Press the switch in your glove box to unlock the hatch from inside your vehicle. If you have an automatic transmission, must be in your shift lever (Park) or “ P ’ “N”...
Page 55 When you park your Chevrolet and open the driver’s door, you’ll hear a tone reminding you to remove your key from the ignition and take it with you. Always do this.
Page 56 If your vehicle does start, the first ignition key may be faulty. See your Chevrolet dealer or a locksmith who can service the PASS-KeyaII. If you accidentally use a key that has a damaged or missing resistor pellet, the starter won’t work and the security light...
Page 57 New Vehicle “Break-In” NOTICE: Your modern Chevrolet doesn’t need an elaborate “break-in.” But it will perform better in the long run if you follow these guidelines: Keep your speed at 55 mph (88 km/h) or less for the first 500 miles (804 km).
Page 58 Features and Controls Key Release Button: If you have a manual transmission, your ignition lock has a key release button. You must press the button before you can take your key out of the ignition lock. NOTICE: If your key seems stuck in “Lock” and you can’t turn be sure is all...
Page 59 “N’ (Neutral) only. NOTICE: Don’t try to shift to (Park) if your “ P ’ Chevrolet is moving. If you do, you could damage the transmission. Shift to “P” (Park) only when your vehicle is stopped. Manual Transmission: The gear selector should be in neutral.
Page 60 Features and Controls To start your V8 engine: 1. Without pushing the accelerator pedal, turn the ignition key to “Start.” When the engine starts, let go of the key. The idle speed will go down as your engine gets warm. NOTICE: Holding your key in “Start”...
Page 61 Instead of trying to list everything here, we ask that you contact a Chevrolet dealer in the area where you'll be parking your vehicle. The dealer can give you the best advice for that particular area.
Page 62 . . 6 0 “P’ Ensure the shift lever is fully in :Park) range before starting the engine. Your Chevrolet has a brake-transmission shift interlock. You have to fully apuly your regular brakes before you can shift From (Park) when the ignition key is “...
Page 63 R (Reverse) $e this gear to back up. NOTICE: Shifting to “R’ (Reverse) while your vehicle is moving forward could damage your transmission. Shift to only after your vehicle is “ R ’ stopped. To rock your vehicle back and forth to get out of snow, ice or sand without damaging your transmission, see “Stuck: In Sand, Mud, Ice or Snow, If You’re’’...
Page 64 Features and Controls 2 (Second Gear) This position gives you more power but lower fuel economy. You can use “2” on hills. It can help control your speed as you go down steep mountain roads, but then you would also want to use your brakes off and on.
Page 65 2 (Second Gear) Press the clutch pedal as you let up on the accelerator pedal and shift into “2.” Then, slowly let up on the clutch pedal as you press the accelerator pedal. 3,4 and 5 (Third, Fourth and Fifth Gears) Shift into “3,”...
Page 66 Features and Controls 2 (Second Gear) Press the clutch pedal as you let up on the accelerator pedal and shift into “2.” Then, slowly let up on the clutch pedal as you press the accelerator pedal. 3,4,5 and 6 (Third, Fourth, Fifth and Sixth Gears) Shift into “3,”...
Page 67 When this light is on, the gear shift lever will let you shift from “1” (First) gear to “4”(Fourth) gears only. Once you are “4” (Fourth) gear, you can press the clutch again and shift into another gear. Follow the shift speeds in this chart when the “SKIP SHIFT”...
Page 68 Features and Controls NOTICE: If you skip more than one gear when you downshift, or if you race the engine when you downshift, you can damage the clutch or transmission. Limited-Slip Rear Axle [f you have this feature, your rear axle :an give you additional traction on snow, mud, ice, sand or gravel.
Page 69 release the parking brake: Hold the rake pedal down. Pull the parking brake zver up until you can push in the release wtton. Hold the release button in as you nove the brake lever all the way down. NOTICE: Driving with the parking brake on can cause your rear brakes to over- heat.
Page 70 Features and Controls 1. Hold the brake pedal down with your right foot and set the parking brake. 2. Move the shift lever into (Park) “ P ’ position like this: Hold in the button on the lever, and push the lever all the way toward the front of your vehicle.
Page 71 Shifting out of P (Park) [AUTOMATIC TRANSMISSION) Your Chevrolet has a brake-transmission to fully shift interlock. have apply your regular brake before can shift from (Park) when the ignition is in “ P ’ “Run” position. See “Automatic Transmission” in the Index.
Page 72 Features and Controls Things that can burn could touch hot exhaust parts under vehicle and ignite, Don’t park over papers, leaves, other things burn. dry grass t h & Engine Exhaust CAUTION: Engine exhaust can kill. It contains the gas carbon monoxide you can’t see or smell.
Page 73 Running Your Engine While You’re Parked (AUTOMATIC TRANSMISSION) It’s better not to park with the engine running. But if you ever have to, here are some things to know. Follow the proper steps to be sure your vehicle won’t move. See “Shifting Into (Park)”...
Page 74 Features and Controls The switch for the driver's window has an Down Express feature. Quickly press release the switch for the driver's window and the window will lower completely. You can also open the driver's window any amount by pressing the switch again while the window is in the Express Down mode when it has lowered to the position you want.
Page 75 The Turn Signal’Headlight Beam Lever The lever on the left side of the steering column includes your: Turn Signal and Lane Change Indicator Headlight HighLow Beam and Passing Signal Windshield Wipers Windshield Washer Cruise Control (Option) rurn Signal and Lane Change hdicator :he turn signal has two upward (for tight) and two downward (for Left)
Page 76 Features and Controls feadlight HighLow Beam ’0 change the headlights from low beam high or high to low, pull the turn signal :ver all the way toward you. Then :lease it. When the high beams are on, blue light on the instrument panel Is0 will be on.
Page 77 Windshield Washer At the top of turn signal lever there’s a paddle with the word “PUSH” on spray washer fluid on the windshield, just push the paddle. The washer will continue to spray until you release the paddle. The wipers will clear the window and wipe a few more times before stopping or returning to the previous setting.
Page 78 Features and Controls bise Control (OPTION) Vith Cruise Control, you can maintain a peed of about 25 mph (40 km/h) or lore without keeping your foot on the ccelerator. This can really help on long ips. Cruise Control does not work at peeds below about 25 mph (40 km/h).
Page 79 2. Get up to the speed you want. Push in the button at the end of the lever and release it. 4. Take your foot off the accelerator pedal. Resume a Set Speed suppose you set your Cruise Control at desired speed and then you apply the )rake.
Page 80 Features and Controls lere’s the second way to go to a higher peed: Move the Cruise switch from “ON” to “R/A.” Hold it there until you get up to the speed you want, and then release the switch. To increase your speed in very small amounts, move the switch to “WA”...
Page 81 To Get Out of Cruise Control There are several ways to turn off the Cruise Control: 1. Step lightly on the brake pedal or push the clutch pedal, if you have a manual transmission; 2. Move the Cruise switch to “OFF.” T o Erase Speed Memory When you turn off the Cruise Control or the ignition, your Cruise Control set speel...
Page 82 Features and Controls vlain Light Control ’he main light control is a knob that vorks these lights: Headlights Taillights Parking lights License lights Sidemarker lights Instrument panel lights rurn the knob to to turn on your leadlights and ot&?operating lights. rurn the knob to to turn on your larking lights without your headlights.
Page 83 ?og Lights (Option) Jse your fog lights for better vision in oggy or misty conditions. Your parking ights must be on or your fog lights won7 work. T o turn the fog lights on, push the switch tbove Push the bottom of the ;witch to turn the fog lights off.
Page 84 Features and Controls Mirrors Inside Daymight Rearview Mirror An inside rearview mirror is attached to your windshield. The mirror has pivots so that you can adjust it up and down or side to side. You can adjust the mirror for day or night driving.
Page 85 Twin Lift-off Roof Panels (OPTION) If you have this option, can remove one or both lift-off roof panels. The door key unlocks the panels. The lock is above the door window. Turn the key to the left to unlock the panel. Then push up on the release handle to unlatch the panel.
Page 86 Features and Controls Open the close-out panel completely. Place the panel in the correct slot (“DRIVER” or “PASSENGER’) in the rear area of your vehicle. Make sure the handle is open and facing you when you put it in the storage slot. ’ush’the handle closed to secure the pane the slot.
Page 87 T-Top Sunshades 1. Start with the panel marked “DRIVER FRONT.” Unlatch the driver-side T-top, raise halfway and close the latch handle. 2. With the top raised and resting on the center roof rail, slide the flat edge of the sunshade panel the vinyl (with side to the glass) between the glass...
Page 88 Features and Controls .:*:;r You can store the sunshades two different ways: 1. When the T-tops are in use, store the sunshades in their storage area in the rear of the vehicle and make sure the close-out panel is in its closed, upright position.
Page 89 Front Console To use the storage area, pull up on the front end of the console. There is a cupholder and light and may be a coinholder in the console. Cassette and Compact Disc Storage You have a storage area for cassette tapes If you have a compact disc player, you have a storage area for compact discs will...
Page 90 Features and Controls Close-Out Panel The close-out panel can be closed for hidden storage in the rear area of your vehicle. To remove the close-out panel: 1. Close the panel. If the close-out panel is not closed and resting on the trim panel, it cannot be removed.
Page 91 15 amps. Exceeding this limit will result in a blown fuse. Floor Mats Your Chevrolet’s t’loor mats are custom-fitted to the foot wells. Be sure the driver’s floor mat is in place. If it I isn’t, could interfere with the accelerator or brake pedals.
Page 92 Features and Controls...
Page 93 Instrument Panel 1. Upper Air Vent 2. Main Light Control 3. Side Upper Air Vent 4. Instrument Cluster 5. Comfort Controls Audio System 7. Side Window Defogger Vent 8. GloveBox Remote Hatch Release 10. Cassette Tape Storage 11. Shift Lever 12.
Page 94 UNLEADED FUEL ONLY U.S. shown, Canada similar You may wonder what happens if your Chevrolet needs a new odometer installed. If possible, the new one has to be set to the same reading the old one had. If it can't be, then it's set at zero, but...
Page 95 Trip Odometer The trip odometer can tell you how far your vehicle has been driven since you last set the trip odometer to.zero. set the trip odometer to zero, press the h o b . Tachometer The tachometer displays the engine speed in thousands of revolutions per minute (rpm).
Page 96 “E.” BRAKE Brake System Warning Light Your Chevrolet’s hydraulic brake system is divided into two parts. If one part isn’t working, the other part can still work and stop you. For good braking, though, you need both parts working well.
Page 97: Index
If the light comes on while you are driving, pull off the road and stop carefully. You may notice that the pedal is harder to push. Or, the pedal may go closer to the floor. It may take longer to stop.
Page 98 Then start the engine again to reset the system. If the light still stays on, or comes on again while you’re driving, your Chevrolet needs service. If the light is on but not flashing and the regular brake system warning light isn’t on, you still have brakes, but you don’t have...
Page 99 When this warning light is on, the system will not limit wheel spin. Adjust your driving accordingly. LOW TRAC Low Traction Light When your anti-lock system is adjusting brake pressure to help avoid a braking skid, the “LOW TRAC” light will appear on your instrument cluster.
Page 100: Part 3 Comfort Controls & Audio Systems
Features and Controls Toltmeter ! o u can read battery voltage on your ,oltmeter. If it reads less than 11 volts or nore than 16 volts while your engine is unning, and it stays there, you may have problem with the electrical charging ystem.
Page 101 NOTICE: If you keep driving your vehicle with this light on, after a while the emis- sion controls won’t work as well, your fuel economy won’t be as good and your engine may not run as smoothly. This could lead to costly repairs not covered by your warranty.
Page 102 Features and Controls CHECK GAGES Check Gages Light This light will come on briefly when you are starting the engine. the light comes on and stays on while you are driving, check your gages to see if they are in the warning areas.
Page 103 You may need to add coolant. See the Index under “Engine Coolant.” NOTICE: Driving with the “LOW COOLANT” light on could cause your Chevrolet to overheat. See “Engine Overheat- ing” in the Index. Your Chevrolet could be damaged, and wouldn’t be covered by your warranty.
Page 104 Features and Controls or a manual transmission into “R” (Reverse). The ignition must be in the “ACC” or “Run” position. Lower bott sun visors. NOTICE: Don‘t lower the top if is damp or wet. When the top is down, trapped water can cause stains, mildew and damage to the inside of your vehicle.
Page 105 Open the trunk and remove the two side covers from the storage bag. Install the two side covers by engaging the tab into the front seatbelt cover. Lower covers onto vehicle. Install middle section of cover by sliding tabs into slots on right side cover.
Page 106 Features and Controls 2. Open the trunk. Remove the middle piece of the cover by pushing i n on the latch and lifting up on the cover. . l o 4 Remove the two side pieces of the cover by lifting rear of cover and boot sliding them out of their slots.
Page 107 5. Push and hold “UP” or on the convertible top switch. 6. Pull down on the latches and align hooks with holes. Push forward on the larger part of the latch until it clicks. Do not force the latch. If it is hard to lock, the top is not properly aligned.
Page 108 Notes .IO6...
Page 109 In this part you’ll find out how to )perate the comfort control systems and audio systems lffered with your Chevrolet sure to read about the particular system supplied with your rehicle Comfort Controls & Audio ..........
Page 110 Comfort Controls and Audio Systems Comfort Controls With this system, you can control the heating and ventilation in your Chevrolet. If you have the air conditioning option, you can also control cooling. Your vehicle also has the flow-through ventilation system described later in this section.
Page 111 During initial start-up only, if your vehicle is equipped with an optional engine coolant heater, you can use it in cold weather (around +2OoF/-8”C or lower) to heat the passenger area better than without it. Because an engine coolant heater warms the engine coolant, your vehicle’s heating system can more efficiently provide heat for the passenger area of your vehicle.
Page 112 Comfort Controls and Audio Systems Air Conditioner Controls (OPTION) The air conditioning system uses the same controls as the heating system, except that the air control knob has two extra settings, described below. For an explanation of all the controls, see “Heater Controls”...
Page 113 :/ow-Through Ventilation ;ystem lour Chevrolet’s flow-through ventilatiol ystem supplies outside air into the ehicle when it is moving. Outside air vlill also enter the vehicle when the heatel l r the air conditioning fan is running.
Page 114 Comfort Controls and Audio Systems Ventilation Tips Keep the hood and front air inlet free of ice, snow, or any other obstruction (such as leaves). The heater and defroster will work far better, reducin the chance of fogging the inside of your windows.
Page 115 Setting the Clock AM/FM Stereo with Cassette Tape Player 1. Press “SET.” 2. Within five seconds, press and hold V’’ “SEEK until the correct hour appears. A’’ Press and hold “SEEK until the correct minute appears. Delco/Bose AM/FM Stereo with Compact Disc Player 1.
Page 116 Comfort Controls and Audio Systems VOLUME TREB PROG-RCL TUNE FADE BASS AM-FM Scan The scan function uses the same two buttons as the seek function. To go to the next higher station and stay there for a few seconds, press and hold A’’...
Page 117 Adjusting the Speakers Balance: Turn the balance control behind the upper knob to move the sound between the right and left speakers. Fade: Turn the fade control behind the lower knob to move the sound between the front and rear speakers. The Delco/Bose premium speaker system only includes three speakers.
Page 118 Comfort Controls and Audio Systems VOLOBAL POWER TUNE FADE AM-FM ‘ c AM!FM Stereo with Compact Disc Player To Play the Radio Turn the upper knob to turn the system on or off. Volume Turn the upper knob to adjust the volume. AM-FM Press the lower knob to get AM, FMl or FM2.
Page 119 POWER ST-PL COMP A M - F M r z Setting the Tone Bass: Press “BASS or “BASS ’’ ” hear more or less bass. Treble: Press “TREB or “TREB ” to hear more or less treble. For the clearest sound, keep both of these adjusted all the way up.
Page 120 Comfort Controls and Audio Systems To Play the Next Selection Press “NEXT” to hear the next track now (instead of waiting until the present track is finished). If you press and hold this button or press it more than once, the disc will advance further.
Page 121 5. Press “SET” and “000” will appear on the display. 6. Press “SEEK 4 or “SEEK b ” ” hold until the first digit of your code appears. Release the button. T u r n the lower knob to make the second and third digits appear.
Page 122 Comfort Controls and Audio Systems 6. Turn the lower knob until the fifth and sixth digits your code appear, 7. Press the lower knob. The clock display will appear and the unit will work. If “LOC” shows, the numbers did not match and the unit is still locked.
Page 123 improvement in sound quality, clean the tape player. Clean your tape player with a wiping-action, non-abrasive cleaning cassette, and follow the directions provided with it. Cassettes are subject to wear and the sound quality may degrade over time. Always make sure that the cassette tape is in good condition before you have your tape player serviced.
Page 124 Comfort Controls and Audio Systems .I22...
Page 125 H e r e you’ll find information about driving on different kinds of roads and in varying weather conditions. We’ve also included many other useful tips on driving. Your Driving and the Road ..........DefensiveDriving .
Page 126 The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your Chevrolet: Buckle up. (See “Safety Belts” in the Index.) Defensive driving really means “be ready for anything.” On city streets, rural roads, or freeways, it means “always expect the...
Page 127 According to the American Medical Association, a 180-pound (82 kg) person who drinks three 12-ounce (355 bottles of beer in an hour will end up with a BAC of about 0.06 percent. The person would reach the same BAC by drinking three 4-ounce (1 20 ml) glasses of wine or three mixed drinks if each had 1-1/2 ounces...
Page 128 Your Driving and the Road There’s something about else drinlcing md driving that many people don’t know. Medical research shows that alcohol person’s system make crash injuries for brain, That’s especially worse. true card and spinal heart injuries. That means i f anyone drinking that...
Page 129 Once the power assist is used it may take longer to stop and the brake pedal will be harder to push. inti-Lock Brakes (ABS) tour Chevrolet has an advanced klectronic braking system that will help revent sludding. INOP ?his light on the instrument panel will go m when you start your vehicle.
Page 130 Your Driving and the Road Here’s how anti-lock works. Let’s say the road is wet. You’re driving safely. Suddenly an animal jumps out in front of you. You slam on the brakes. Here’s what happens with ABS. A computer senses that wheels are slowing down.
Page 131 ‘I If your vehicle is in cruise control when the ASR system begins to limit wheel spin, the cruise control will automaticallq disengage. When road conditions allow you to safely use it again, you may re-engage the cruise control. (See “Cruise Control”...
Page 132 But sometimes you can’t; there isn’t room. That’s the time for evasive action steering around the problem. Your Chevrolet can perform very well in emergencies like these. First apply your brakes. It is better to remove as much speed as you can from a possible...
Page 133 to the left or right depending on the space available. An emergency like this requires close attention and a quick decision. If you are holding the steering wheel at the recommended 9 and o’clock positions, you can turn it a full 180 degrees very quickly without removing either hand.
Page 134 “overdriving” those conditions. But skids are always possible. The three types of skids correspond to your Chevrolet’s three control systems. In the brakmg skid your wheels aren’t rolling. In the steering or cornering skid, too much speed or steering in a curve causes tires to slip and lose cornering force.
Page 135 much throttle causes the driving wheels to spin. A cornering skid is best handled by easing your foot the accelerator pedal. If you have the ASR system, remember: It helps avoid only the acceleration skid. If you do not have traction control, or if the system is off, then an acceleration skid is also best handled by easing your foot off the accelerator pedal.
Page 136 Your Driving and the Road Slow down, especially higher speed roads. Your headlights can light up only so much road ahead. In remote areas, watch for animals. If you’re tired, pull off the road in a safe place and rest. Night Vision No one can see as well at night as in the daytime.
Page 137 It’s wise to keep your wiping equipment in good shape and keep your windshield washer tank filled. Replace your windshield wiper inserts when they show signs of streaking or missing areas on the windshield, or when strips of rubber start to separate from the inserts.
Page 138 Your Driving and the Road Hydroplaning usually happens at higher speeds. There just isn’t a hard and fast rule about hydroplaning. The best advice is to slow down when it is raining. Some Other Rainy Weather Tips Turn on your low-beam headlights not just your parking lights to help make you more visible to others.
Page 139 If it needs service, have it done before starting out. Of course, you’ll find experienced and able service experts in Chevrolet dealerships all across North America. They’ll be ready and willing to help if you need it.
Page 140 Your Driving and the Road Wiper Blades: Are they in good shape? Fuel, Engine Oil, Other Fluids: Have you checked all levels? Lights: Are they all working? Are the lenses clean? Tires: They are vitally important to a safe, trouble-free trip. Is the tread good enough for long-distance driving? Are the tires all inflated to the recommended pressure?
Page 141 Be alert to these and take appropriate action. Winter Driving Here are some tips for winter driving: Have your Chevrolet in good shape for winter. Be sure your engine coolant mix is correct.
Page 142 Your Driving and the Road ; i ” i i i ’ ;i7: , , : : You may want to put winter emergency supplies in your vehicle. Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, a red cloth, and a couple of reflective...
Page 143 Slip Regulation (ASR) System” in the Index. If you don’t have the traction control system, accelerate gently. Try not to break the fragile traction. you accelerate too fast, the drive wheels will spin and polish the surface under the tires even more. Your anti-lock brakes improve your ability to make a hard stop on a slippery road.
Page 144 To pull a trailer correctly, follow the advice in this section, and see your Chevrolet dealer for important information about towing a trailer with your vehicle. Your vehicle can tow a trailer if it is equipped with the proper trailer towing equipment.
Page 145 I that you have on your vehicle. You can ask your dealer for our trailering information or advice, or you can write Chevrolet Motor Division Customer Assistance Department P.O. Box 7047 Troy, MI 48007-7047 In Canada, write to:...
Page 146 Your Driving and the Road Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total capacity weight of your vehicle. The capacity weight includes the curb weight of the vehicle, any cargo you may carry in it.
Page 147 Trailer Brakes If your trailer weighs more than 1,000 pounds (450 kg) loaded, then it needs its own brakes and they must be adequate. Be sure to read and follow the instructions for the trailer brakes so you’ll be able to install, adjust and maintain them properly.
Page 148 Your Driving and the Road Driving on Grades Reduce speed and shift to a lower gear before you start down a long or steep downgrade. If you don’t shift down, you might have to use your brakes so much that they would get hot and no longer work well.
Page 149 H e r e you'll find what to do about some problems that can occur on the road . Hazard Warning Flashers ........... . Jumpstarting .
Page 150 Problems on the Road Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lights will flash on and off. ,148 ’ress the button in to make your front ant ear turn signal lights flash on and off.
Page 151 Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your Chevrolet. But please follow the steps below to do it safely. NOTICE: Ignoring these steps could result in costly damage to your vehicle that wouldn’t be covered by your war-...
Page 152 Problems on the Road Find the positive and negative (+> terminals on each battery. .150 5. Check that the jumper cables don’t have loose or missing insulation. If they do, you could get a shock. The vehicles could be damaged, too. Before you connect the cables, here some basic things you should know.
Page 153 Use a remote positive terminal the vehicle has one. But don’t use the junction block on your Chevrolet. Now connect the black negative cable to the good battery’s negative terminal. Don’t let the other end touch anything until the next step.
Page 154 Dead Battery Towing Your Vehicle ?y to have a GM dealer or a professional ]wing service tow your Chevrolet. The sua1 towing equipment is a sling-type or a wheel-lift (B) or car carrier 3w truck. your vehicle has been changed or...
Page 155 When you call, tell the towing service: That your vehicle cannot be towed from the front or rear with sling-type equipment. That your vehicle has rear-wheel drive. The make, model, and year of your vehicle. Whether you can still move the shift lever.
Page 156 Problems on the Road When your vehicle is being towed, have the ignition key off. The steering wheel should be clamped in a straight-ahead position, with a clamping device designed for towing service. Do not use the vehicle’s steering column lock for this, The transmission should be in “Neutral”...
Page 157 NOTICE: Do not tow with sling-type equip- ment or fascia/fog light damage will occur. Use wheel lift or car carrier equip- ment. Additional ramping may be required for car carrier equipment. Use safety chains and wheel straps. Attach a separate safety chain around outboard end of each lower control arm.
Page 158 Problems on the Road Rear Towing Hook-Ups Attach T-hook chains in front of rear wheels in bottom of frame rail on both sides. NOTICE: Do not attach winch cables or "J" hooks to suspension components when using car carrier equipment. Always use T-hooks inserted in the T-hook slots.
Page 159 Engine Overheating will find a coolant temperature gage Dn your Chevrolet’s instrument panel. may also find a low coolant warning light on your Chevrolet instrument panel. If Steam Is Coming from Your Engine:...
Page 160 Problems on the Road NOTICE: If your engine catches fire because you keep driving with no coolant, your vehicle can be badly damaged. The costly repairs would not be covered by your warranty. If No Steam Is Coming from Your Engine: If you get the overheat warning but see or hear no steam, the problem may not be...
Page 161 On the V8 engine you’ll see this: 1. Coolant recovery tank 2. Radiator pressure cap Electric engine fans CAUTION: An electric fan under the hood can start up even when the engine is not you. running and can injure Keep hands, clothing and tools away from underhood electric fan.
Page 162 Problems the Road Add Coolant Coolant Recovery Bank .haven’t found problem yet, but level isn’t at ur above COOhint “FULL COLD” mark, add a 50/50 mixture of clew wata (preferably distilled) and a proper antifreeze (see “~nginef coolant‘rtyxwery ta&. in the more infor- Coolant”...
Page 163 How to Add Coolant to the Radiator (3.4L L32 (Code S) Engine) 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap ant upper radiator hose, is no longer hot. Turn the pressure cap slowly to the left until it first stops.
Page 164 Problems on the Road 5. Put the cap back on the coolant 4. Then fill the coolant recovery tank 3. Fill the radiator with the proper mix, recovery tank, but leave the radiator “FULL COLD.” up to the base of the filler neck. pressure cap off.
Page 165 6. Start the engine and let it until you can feel the upper radiator hose getting hot. Watch out for the engine fan(s). this time the coolant level inside the radiator filler neck may be lower. If the level is lower, add more of the proper mix through the filler neck until the level reaches the base of the filler neck.
Page 166 Problems on the Road 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap anc upper radiator hose, is no longer hot. Turn the pressure cap slowly left until it first stops. (Don’t press down while turning the pressure cap.) If you hear a hiss, wait for that to stop hiss means there is still some...
Page 167 4. Fill with the proper mix. Add coolant until you see a steady stream of coolant coming from the bleed valves. 5. Close the bleed valves. 6. Continue to fill the radiator up to the base of the filler neck. 7.
Page 168 ,166 10. Then fill the coolant recovery tank to the proper level. complete drain, flush and refill, see your Chevrolet dealer or a Chevrolet Camaro Service Manual. To purchase a service manual, see “Service Publications’’ in the Index. Tire Flat Goes It’s unusual for a tire to “blow out”...
Page 169 Changing a Flat lire If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. T u r n on your hazard warning flashers. The following steps will tell you how to use the jack and change a tire. The equipment you’ll need is in the rear area.
Page 170 Problems on the Road To remove the jack and wheel wrench, loosen and remove the bolt and remove the plastic cover. .I68 ' . . Remove the wing nut and adapter and pull out the spare. Start with the jack (A) and wheel wrench (B).
Page 171 The jack has a bolt at the end. Attach the wheel wrench to the jack bolt. Turn the wheel wrench to the right to raise the lift head a little. If your wheel has a center cap, pry it using the wheel wrench. If your vehicle has a bolt-on wheel cover, loosen the plastic caps using the wheel wrench and remove the wheel cover.
Page 172 Problems on the Road your vehicle has optional alloy wheels, each wheel may have one locknut in place of the standard wheel nut. A special wheel lock key (removal tool) and instructions are located center in the console. Attach the wheel lock key to the socket of the wheel wrench.
Page 173 Stay away from the moldings or fender flanges to avoid damaging them. NOTICE: Raising your vehicle with the jack improperly positioned will damage the vehicle or may allow the vehicle to fall the jack. Be sure to fit the jack lift head into the proper location before raising your vehicle.
Page 174 Problems on the Road Remove all the wheel nuts and take off the flat tire. .172 CAUTION: or dirt Rust wheel, or on the parts to which it is fastened, can make the wheel nuts become loose come after a time. The wheel could off and cause an accident.
Page 175 Replace the wheel nuts with the rounded end of the nuts toward the wheel. Tighten each nut by hand until the wheel is held against the hub. Lower the vehicle by rotating the wheel wrench counterclockwise. Lower the jack completely. Tighten the wheel nuts firmly in a criss-cross sequence as shown.
Page 176 Problems on the Road ,174 Don’t try to put a wheel cover on your compact spare tire. It won’t fit. Store the wheel cover in the rear area until you have the flat tire repaired or replaced. NOTICE: Wheel covers won’t fit on your com- pact spare.
Page 177 Replace the jack, wheel wrench and flat tire using the storage instructions. When you replace the trim panel, be sure to tuck under the weatherstrip. Trim Panel 2. Bolt 3. Cover 4. Jack 5. Wing Nut Adapter 7. Compact Spare Tire Full-Size Tire Carpet Flap 10.
Page 178 Problems on the Road Compact Spare Tire Although the compact spare was fully inflated when your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 Wa). After installing the compact spare on your vehicle, you should stop as soon as possible and make sure your spare tire is correctly inflated.
Page 179 If You’re Stuck: In Sand, Mud, Ice or Snow What you don’t want to do when your vehicle is stuck is to spin your wheels. The method known as “rocking” can help you get out when you’re stuck, but you must use caution.
Page 180 Problems on the Road...
Page 181: Service & Appearance Care
H e r e you will find information about the care of your Chevrolet This part begins with service and fuel information. and then it shows how to check important fluid and lubricant levels . There is also technical information about your vehicle.
Page 182 Chevrolet Service Manual. It tells you much more about how to service your Chevrolet than this manual can. To order the proper service manual, see “Service Publications” in the Index. Your vehicle has an air bag system.
Page 183 NOTICE: If you try to do your own service work without knowing enough about it, your vehicle could be damaged. Fuel The 8th digit of your Vehicle Identification Number (VIN) shows the code letter for your engine. You will find the VIN at the top left of your instrument panel.
Page 184 Service and Appearance Care All Engines What about gasoline with blending materials that contain oxygen (oxygenates), such as MTBE or alcohol? MTBE is “methyl tertiary-butyl ether.” Fuel that is no more than 15% MTBE is fine for your vehicle. Ethanol is ethyl or grain alcohol. Properly-blended fuel that is no more than 10% ethanol is fine for your vehicle Methanol is methyl or wood alcohol.
Page 185 Be careful not to spill gasoline. Clean gasoline from painted surfaces as soon as ?ossible. See “Cleaning the Outside of Your Chevrolet” in the Index. When you put the cap back on, turn it to the right until you hear at least three :licks.
Page 186 Service and Appearance Care Checking Things under the Hood Hood Release To open the hood, first pull the handle inside the vehicle. . I 8 4 Then go to the front of the vehicle and pull up on the hood release. Lift the hood.
Page 187 When you open the hood you'll see: 1 . Battery 2. Engine Coolant Reservoir Engine Oil Dipstick 4. Automatic Transmission Dipstick (if equipped) Air Cleaner 3 . 4 L L32 (Code Oil Fill Cap 7. Brake Fluid Reservoir 8. Power Steering Reservoir Windshield Washer Reservoir 10.
Page 188 Service and Appearance Care Vhen you open the hood you’ll see: 1. Battery 2. Engine Coolant Reservoir Engine Oil Dipstick 4. Automatic Transmission Dipstick (if equipped) 5. Air Cleaner .186 5.7L LT1 (Code Oil Fill Cap 7. Brake Fluid Reservoir 8.
Page 189 LOW OIL Engine Oil If the “LOW OIL” light on the instrument panel comes on, it means you need to check your engine oil level right away. For more information, see “Low Oil Light” in the Index. You should check your engine oil level regularly;...
Page 190 Service and Appearance Care ” , To Check Engine Oil (3.4L L32 (Code S) Engine) Pull out the dipstick and clean it with a paper towel or cloth, then push it back in all the way. Remove it again, keeping the tip lower, and check the level.
Page 191 NOTICE: Don’t add too much oil. If your engine has so much oil that the oil level gets above the cross-hatched area that shows the proper operating range, your engine could be damaged. 5.7L (Code lust fill enough to put level some- where in the proper operating range.
Page 192 GM Goodwrench@ oil (in Canada, GM Engine Oil) meets all the requirements for your vehicle. Engine Oil Additives: Don’t add anything to your oil. Your Chevrolet dealer is ready to advise if you think something should be added.
Page 193: Part 7 Maintenance Schedule
When to Change Engine Oil: you: See if any one of these is true for Most trips are less than miles (6 km). It’s below freezing outside and most trips are less than 10 miles (1 6 km). The engine is at low speed most of the time (as in door-to-door delivery, or in stop-and-go traffic).
Page 194 Service and Appearance Care 5.7L (Code .192 NOTICE: If the air cleaner is off, a backfire can cause a damaging engine fire. And, dirt can easily get into your engine, which will damage it. Always have the air cleaner in place when you’re driving.
Page 195 2. Disconnect the plastic clamp on the 4. Open the air cleaner and remove the Pull the air cleaner straight up. duct. Pull apart the connection. Unclamp the metal clips. filter.
Page 196 Maintenance Services” in the Index. How to Check: Because this operation can be a little difficult, you may choose to have this done at a Chevrolet dealership Service Department. If you do yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick.
Page 197 3.4L (Code Then, without shutting off the engine, follow these steps: 1. Pull out the dipstick and wipe it with a clean rag or paper towel. 5.7L 2. Push it back in all the way, wait three seconds and then pull it back out again.
Page 198 Manual Transmission Fluid How to Check: Because this operation can be difficult, you may choose to have this done at a Chevrolet dealership Service Department. If you do yourself, be sure to follow all the instructions here, or you could get a false reading.
Page 199 Hydraulic Clutch The hydraulic clutch in your vehicle is self-adjusting. The clutch master cylinder reservoir is filled with hydraulic clutch fluid. It isn’t a good idea to “top off’ your clutch fluid. Adding fluid won’t correct a leak. A fluid loss in this system could indicate a problem.
Page 200 If you have a problem with engine overheating or if you need to add coolant to your radiator, see “Engine Overheating” in the Index. The proper coolant for your Chevrolet will: Give freezing protection down to -34°F (-37°C). Give boiling protection up to 262°F (128°C).
Page 201 Adding Coolant To Check Coolant: When your engine is cold, check the dipstick on the cap of the coolant recovery tank. The coolant level should be at “COLD,” or a little higher. When your engine is warm, the level on the dipstick should be up to “HOT,”...
Page 202 Service and Appearance Care CAUTION: Turning the radiator pressure cap when the engine and radiator can allow steam and scalding liquids to blow and burn badly. Never turn the pressure cap even a little when the engine and radiator hot. Add coolant mix at the recovery tank, bul be careful not to spill it.
Page 203 5.7L LTl (Code When the engine compartment is hot, the level should be at the “H” or “HOT” mark. When the engine compartment is cool, the level should be at the “C” or “FULL COLD” mark. to Add: fer to the Maintenance Schedule to :ermine what kind of fluid to use.
Page 204 Service and Appearance Care NOTICE: When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready-to-use washer fluid. Water can cause the solution to freeze and damage your washer fluid tank and other parts of the washer system.
Page 205 If you do, wash it off immediately. See ”Appearance Care” in the Index. Brake Wear Unless you have the four-wheel disc brake option, your Chevrolet has front disc brakes and rear drum brakes. Disc brake pads have built-in wear indicators that make high-pitched warning sound when the brake pads are worn and new pads are needed.
Page 206 Vehicles we design and test have top-quality GM brake parts in them, as your Chevrolet does when it is new. When you replace parts of your braking system for example, when your brake...
Page 207 Contacr your dealer to learn how to prepare your vehicle for longer storage periods. Bulb Replacement For the proper type of replacement bulb, see “Replacement Bulbs” in the Index. Halogen Bulbs Headlights Headlight Aiming Your vehicle has a mini-quad headlight system.
Page 208 Service and Appearance Care There are four headlights. Each one has its own vertical and horizontal aim position indicators. Each indicator has its own aiming screw. A. Vertical Indicator B. Horizontal Indicator C. Vertical Aiming Screw D. Horizontal Aiming Screw .206 Start with the horizontal (left and right) headlight aim.
Page 209 To replace a headlight: Before replacing a headlight that does not light, check to make sure that the wiring connector is securely fastened to it. See “Replacement Bulbs” in the Index to check the size and type of headlight you need to use before you begin to replace the headlight.
Page 210 Service and Appearance Care 2. The aiming ring will swing open like gate. Remove the aiming ring from thl assembly. Place face down, with the aim indicator up. Be careful not to damage aiming bubble. .208 Pull the headlight out of the assembly. Remove the wiring connector from thl headlight socket by lifting the plastic locking tabs on the connector and...
Page 211 Headlight Aim” in the Index. If your vehicle is damaged in an accident and the headlight aim seems to be affected, see your Chevrolet dealer. Headlights on damaged vehicles may require recalibration of the horizontal aim by your Chevrolet dealer.
Page 212 Service and Appearance Care Using a remove the screwdriver, plastic from screws deflector under the vehicle. Move the deflector of the way. .210 Turn and pull out the socket and the bulb. Pull out the buib. 4. Reverse the steps with bulb.
Page 213 Remove the wing nut 4. Pull the assembly off from the outside. 5. To remove a socket with a tab, press the tab and turn the socket counterclockwise. To remove a socket without a tab, turn the socket counterclockwise. 6. To remove the bulb, push in and turn it counterclockwise, then pull it out.
Page 214 Service and Appearance Care Turn counterclockwise and pull out the socket and the bulb. 1. Reverse the steps with a new bulb. .212 TIRE-LOADING INFORMATION OCCUPANTS VEHICLE CAP. WT. FRT. CRT. TOTAL 1199 MAX. LOADING GVWR SAME AS VEHICLE CAPACITY WEIGHT TIRE SIZE INFORMATION Loading Your Vehicle...
Page 215 NOTICE: Your warranty does not cover parts or components that fail because of over- loading. yoti put things inside your vehicle like suitcases, tools, packages, or anything else they will go as fast as the vehicle goes. you have to stop or turn quickly, or if there is a crash, they’ll keep going.
Page 216 These tires are warranted by the tire manufacturers and .eir warranties are delivered with every new Chevrolet. If your spare tire is a fferent brand than your road tires, you will have a tire warranty folder from each ’...
Page 217 Inflation Tire Pressure The Tire-Loading Information label which is on the driver’s door shows the 2orrect inflation pressures for your tires, when they’re cold. “Cold” means your vehicle has been sitting for at least three hours or driven no more than a mile.
Page 218 Service and Appearance Care When to Check: Check your tires once a month or more. Don’t forget your compact spare tire. It should be at 60 psi (420 kPa). How to Check: Use a good quality pocket-type gage to check tire pressure. Simply looking at the tires will not tell you the pressure, especially if you have radial tires...
Page 219 When It’s Time for New Tires One way to tell when it’s time for new tires is to check the treadwear indicators, which will appear when your tires have only 2/32 inch (1.6 mm) or less of tread remaining. You need a new tire if: You can see the indicators at three or more places around the tire.
Page 220 Service and Appearance Care Uniform Tire Quality Grading The following information relates to the system developed by the United States National Highway Traffic Safety Administration which grades tires by treadwear, traction and temperature performance. (This applies only to vehicles sold in the United States.) Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire...
Page 221 If the wheel leaks air out, replace (except some aluminum wheels, which can sometimes be repaired). See your Chevrolet dealer if any of these conditions exist. Your dealer will know kind of wheel you need.
Page 222 ]me are dangerous you breathe eir fumes in a closed space. When )u use anything from a container to ean your Chevrolet, be sure to follow the manufacturer‘s warnings and instructions. And always open your doors or windows when you’re :leaning the inside.
Page 223 Use a vacuum cleaner often to get rid of dust and loose dirt. Wipe vinyl or leather with a clean, damp cloth. Your Chevrolet dealer has two GM cleaners a solvent-type spot lifter and a foam-type powdered cleaner. They will clean normal spots and stains very well.
Page 224 Service and Appearance Care Fabric Protection Your Chevrolet has upholstery and carpet that has been treated with Scothgardm Fabric Protector, a 3M product. Scotchgard- protects fabric by repelling oil and water, which are the carriers of most stains. Even with this protection,...
Page 225 Don’t use abrasive cleaning materials. Cleaning the Outside of Your Chevrolet The paint finish on your vehicle provides beauty, depth of color, gloss retention and durability. Washing Your Vehicle The best way to preserve your vehicle’s...
Page 226 These brushes can take off the protective coating. Tires Your Chevrolet dealer has a GM White Sidewall Tire Cleaner. You can use a stiff brush with the cleaner. When applying a tire dressing always takt care to wipe off any overspray or splash from painted surfaces.
Page 227 Although no defect in the paint job causes this, Chevrolet will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000 km) of purchase, whichever comes first.
Page 228 Service and Appearance Care Appearance Care and Maintenance Materials PART NUMBER SIZE 1051516 (0.946 L) 10501 72 (0.473 *Not recommended for pigskin suede leather. See your General Motors Dealer for these products. See the Index under "Recommended Fluids and Lubricants" .226 DESCRIPTION Washer gotvent and Gas Liner De-lcer...
Page 229 Vehicle Identification Number (VIN) This is the legal identifier for your Chevrolet. It appears on a plate in the front corner of the instrument panel, on the driver’s side. You can see it if you look through the windshield from outside your vehicle.
Page 230 Service and Appearance Care Fuses and Circuit Breakers The wiring circuits in your vehicle are protected from short circuits by a combination of fuses, circuit breakers, and fusible thermal links in the wiring itself. This greatly reduces the chance of fires caused by electrical problems.
Page 231 Main Fuse Block Air Bag: SIR Components Amp.) Backup Lights; Daytime Running Lights Module (Canada); Turn Flasher (20 Amp.) HVAC Selector Switch (Heater/Air Conditioner); Rear Defogger (25 Amp.) Powertrain Control Module; Instrument Cluster; PASS-Keys11 Decoder Module (10 Amp.) Powertrain Control Module; PASS-Keys11 Decoder Module;...
Page 232 Service and Appearance Care Jnderhood Electrical Center 'uses Electronic Brake Control Module (5 Amp.) Fog Lamps (20 Amp.) Not Used Not Used Anti-Lock Brake System (5 Amp.) Coolant Fan Relays; EVAP Canister Purge Solenoid; Exhaust Gas Recirculation; Low Coolant Relay; Reverse Lockout Solenoid 10 Amp.) .230 Air Injection Pump Assembly;...
Page 233 Replacement Bulbs ............Ashtray* .
Page 234 Service and Appearance Care Capacities and Specifications Engine T Y Pe ..........VINEngineCodeS VINEngineCodeP .
Page 235 Replacement Parts ..........AirCleanerFilter .
Page 236 If the air conditioning system in your vehicle needs refrigerant, be sure the proper refrigerant is used. If you’re not sure, ask your Chevrolet dealer. *Recheck fluid level after filling. See “Automatic Transmission Fluid” or “Manual Transmission Fluid”...
Page 237 Crankcase Engine Code S Engine Code P Without Filter Change With Filter Change ......... . . Fuel Tank Manual Transmission .
Page 238 Service and Appearance Care Ielt Routing LT1 (Code P) Engine Belt Routing L32 (Code S) Engine .236...
Page 239 KEEP THE ENGINE OIL AT THE PROPER LEVEL AND CHANGE AS RECOMMENDED T h i s part covers the maintenance required for your Chevrolet Your vehicle needs these services to retain its safety. dependability and emission control performance . Section...
Page 240 Maintenance Schedule Introduction: A Word about Maintenance We at General Motors want help keep your vehicle in good working Condition, But we don’t h o w exactly how you’ll drive it. may drive very short distances only a few times a week. Or you may drive long distances all the weather.
Page 241 This section tells you the maintenance services you should have done and when you should schedule them. Your Chevrolet dealer knows your vehicle best and wants you to be happy with it. If you go to your dealer for your service needs, you’ll know that GM-trained and...
Page 242: Schedule 1
Maintenance Schedule Section A: Scheduled Maintenance Services Schedule 1 MAINLY driven under one or more of the following conditions: When most trips are less than 4 miles (6 km). When most trips are less than 10 miles (16 km) and outside temperatures remain below freezing.
Page 243 The services shown in this schedule up to 48,000 miles (80 000 48,000 miles (80 000 km) at the same intervals. MILES (000) 3 1 6 1 2 1 1 2 4 1 1 2 1 1 5 KILOMETERS (000) should be performed after 1 2 7 1 4 2 1 4 5...
Page 244 Maintenance Schedule Section A: Scheduled Maintenance Services Schedule 1 1 Follow Schedule I1 ONLY if none of Jhe driving: conditions specified in Schedule I a p p l ~ An Emission Contsol Ses\:icc. i l - U S . Envisonmental Psotection Agency Calijosrtia Ais Bousd has Resousces...
Page 245 The services shown in this schedule up to 45,000 miles (75 000 km) should be performed after 45,000 miles (75 000 km) at the same intervals. MILES (000) 22.5 KILOMETERS (000) 37.5 243.
Page 246 Maintenance Schedule Section A: Scheduled Maintenance Services Explanation of Scheduled Maintenance Services Following are explanations of the services listed in Schedule I and Schedule 11. The proper fluids and lubricants to use are listed in Section D. Make sure whoever services your vehicle uses these.
Page 247 ITEM NO. SERVICE Transmission Service manual transmissions, fluid doesn’t require changing. See “Periodic Maintenance Inspections.” For automatic transmissions, change both the fluid and filter every 15,000 miles (25 000 km) if the vehicle is mainly driven under one or more of these conditions: In heavy city traffic where the outside temperature regularly...
Page 248 Maintenance Schedule Section B: Owner Checks and Services Listed below are owner checks and services which should be performed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Whenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones, as shown in Section D.
Page 249 At Least Once a Year CHECK OR SERVICE Lubricate the key lock cylinders with the lubricant specifiedin Section D. Lubricate all body door hinges. Also lubricate all hinges and latches, including those for the hood, rear compartment, glove box door, console door and any folding seat hardware. Section D tells you what to use.
Page 250 Maintenance Schedule Section B: Owner Checks and Services Least Once a Year (CONT.) CHECK OR SERVICE While parked, and with the parking brake set, try to turn the key to “LOCK” in each shift lever Steering Column Lock position. With an automatic transmission, the key should turn to “LOCK” only when the shift lever is in “P”...
Page 251 Section C: Periodic Maintenance Inspections Listed below are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You should let your GM dealer’s service department or other qualified service center do these jobs. Make sure any necessary repairs are completed at once.
Page 252 Maintenance Schedule Section C: Periodic Maintenance Inspections INSPECTION OR SERVICE Check the transmission fluid level; add if needed. See “Manual Transmission” in the Index. A fluid loss may indicate a problem. Check the system and repair if needed. Rear Axle Service Check the gear lubricant level in the rear axle and add if needed.
Page 253 Section D: Recommended Fluids NOTE: Fluids and lubricants identified below by name, part number or specification may be obtained from your GM Dealer. USAGE Engine Oil API service SH or SG Energy Conserving I1 oils of the proper viscosity. The “SH” designation may be shown alone or in combination with others, such as “SH/CD,”...
Page 254 Maintenance Schedule Section D: Recommended Fluids & Lubricants USAGE Engine oil. Floor Shift Linkage Chassis lubricant (GM Part No. 1052497 or equivalent) or lubricant meeting requirements of Chassis Lubrication NLGI Grade 2, Category LB or GC-LB. Axle Lubricant (GM Part No. 1052271) or SAE SOW-90 GL-5 Gear Lubricant. Rear Axle (Standard Differential) Rear Axle (Limited-...
Page 255 Section E: Maintenance Record After the scheduled services are performed, record the date, odometer reading and who performed the service in the columns indicated. When completing the Maintenance Performed column, insert the numbers from the Schedule I or Schedule I1 maintenance charts which correspond to the maintenance performed.
Page 256 Maintenance Schedule Section E: Maintenance Record (Cont.) ODOMETER MAINTENANCE PERFORMED DATE SERVICED BY READING ,254...
Page 257 DATE ODOMETER READING SERVICED BY MAINTENANCE PERFORMED 255.
Page 258 Maintenance Schedule Section E: Maintenance Record (Cont.) ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING .256...
Page 259: Customer Assistance Information
H e r e you will find out how to contact Chevrolet if you need assistance. This part also tells you how to obtain service publications and how to report any safety defects..
Page 260: Part 8 Customer Assistance Information
Nature of concern We encourage you to call the toll-free number listed previously in order to give your inquiry prompt attention. However, you wish to write Chevrolet, write to: Chevrolet Customer Assistance Center P. 0. Box 7047 Troy, MI 48097-7047...
Page 261 GM Participation in BBB AUTO LINE Alternative Dispute Resolution Program Both Chevrolet and your Chevrolet dealer are committed to making sure you are completely satisfied with your new vehicle. Our experience has shown that, if a situation arises where you feel your...
Page 262 Roadside Assistance Program To enhance Chevrolet/Geo’s strong commitment to customer satisfaction, Chevrolet/Geo excited to provide the services of the Chevrolet/Geo Roadside Assistance Center. Roadside Assistance is available 24 hours a day, 365 days a year, by calling -800-CHEV-USA 1-800-243-8872). This toll-free number will provide you over-the-phone roadside assistance with minor mechanical problems.
Page 263 BUMPER TO BUMPER New Vehicle Limited Warranty retail and retail lease purchasers of 1994 Chevrolet/Geo passenger car and light-duty trucks. Courtesy Transportation includes: One-way SHUTTLE RIDE for any wap-anty repair completed during the same day.
Page 264: Part 9 Index
What You’ll Find in the Index: A list of all PSP’s published by Chevrolet in a model year ( I 990 or later). PSP’s covering all models of Chevrolet cars or light trucks (less...
Page 265 These PSP’s are meant for technicians. They are not meant for the “do-it-yourselfer.” Technicians have the equipment, tools, safety instructions, and know-how to do job quickly and safely. Chevrolet Service Publications You can get these by using the order form: 263..
Page 266 Customer Assistance Information CHEVROLET SERVICE PUBLICATIONS ORDER FORM NOTE: Please complete form below (Print or Type) and MAIL TO: Dealers and Companies please provide dealer NOTE: also the name of the person For purchases outside U.S.A. please write to the above address for quotation.
Page 267 ....For subscription information call Helm, Incorporated. CURRENT & PAST MODEL ORDER FORMS Service Publications are available for current and past model Chevrolet vehicles. To request an order form, please specify year and model vehicle.
Page 268 Customer Assistance Information ,266...
Page 269 How the System Works Servicing Your Air Bag-Equipped ....Chevrolet ....Readiness Light Air Cleaner .
Page 270 Fabric Glass ..Inside of Your Chevrolet ..Instrument Panel. Top of .....
Page 271 Cruise Control ..To Erase Speed Memory ....To Get Out of To Increase Speed While Using To Reduce Speed While Using .
Page 272 ..Four-Way Manual Seat ....Freeway Driving Front Ashtray Console ....Map Lights .
Page 273 Lights ..Brake System Warning ... . Bulb Replacement ....Check Gages Courtesy .
Page 274 Road. Your Driving and the ..Roads. Hill and Mountain Roadside Assistance. Canadian Roadside Assistance. Chevrolet Rocking Your Vehicle to Get Roof Panels. Twin Lift-off ....
Page 276 Index ....T T o p Sunshades Tachometer ....Tank. Filling Your ..Temperature Control Knob Theft Theft Deterrent Feature/...
Page 277 ..Washer Fluid. Windshield ... . Washers. Windshield ... Washing Your Vehicle Water. Driving Through .
Page 278 Notes .276...
Page 280 Notes .278...
Page 282 Notes ,280...
Page 284 Notes .282...
Page 286 0...
Page 287 285..
Page 288 . , ? . . Notes .286...
Page 289 2 8 7 .
Page 290 Service Station Information Hood Release See Page 184 Engine Oil Dipstick and- Fill Cap (3.4L L32 (Code S) Engine) See Page 188 Engine Oil Dipstick and Fill Cap (5.7L LTl (Code P) Engine) See Page 188 Cold Tire Pressure See Tire-Loading Information label on the inside of the rear edge of the driver’s door.
Page 292 SUPPORT VOLUNTARY TECHNICIAN CERTIFICATION THROUGH National Institute for AUTOMOTIVE SERVICE EXCELLENCE...

Chevrolet 1994 Camaro Owner's Manual

Table of Contents

Related Manuals for Chevrolet 1994 Camaro

Summary of Contents for Chevrolet 1994 Camaro

Table of Contents
