Aura AR-40-101 Quick Operation Manual

The AR-40-101 is a great point-to-point extender set for 4K and IR signals; this kit supports
4K/UHD video @ 60Hz with 4:2:0 Chroma sampling, as well as HDMI data rates up to
10.2Gbps, HDCP2.2 compliant; It provides HDMI transmission up to 164 feet (50 meters) for
4K@30Hz 4:4:4 and 262 feet (80 meters) for 1080p over single CAT 6 cable.

Features

▪ Supports 4K@30Hz 4:4:4, 1080p@60Hz 4:4:4, HDCP 1.4.
▪ Extends signal up to 164 feet (50 meters) for 4K@30Hz 4:4:4 and 262 feet (80 meters)
for 1080p, over single CAT 6 cable.
▪ HDMI loop out on transmitter for monitor.
▪ PoC enables Rx powered by Tx.
▪ Two way IR pass through.
▪ Smart EDID management.

EDID Setting

▪ EDID COPY RX: Press EDID button to learn EDID from receiver display.
▪ EDID COPY LOOP: Press and hold EDID button 3 seconds to learn EDID from
transmitter loop display, or to learn inbuilt EDID(1080p 2CH) if no display on transmitter
loop.

Packing List

▪ 1x Transmitter
▪ 1x Receiver
▪ 1x IR Kit
▪ 2x Velcro Strips
▪ 1x Power Adaptor (5V1A)
▪ 1x Quick Operation Guide
Quick Operation Guide
4K
HDMI Extender over CAT6
2021V1.1
