SERVICE MANUAL
STEREO CAR CASSETTE RECEIVER
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-997-334-8T1).
All manuals and user guides at all-guides.com
BASIC TAPE MECHANISM : CDS-36SCH-94
S/M Code No. 09-997-334-8R1
CT-X4019
CT-X4059
YL
YL
