  • Page 2 NSX-T96 SERVICE MANUAL COMPACT DISC BASIC TAPE MECHANISM :2ZM-3MK2 YPR4NM STEREO CASSETTE RECEIVER BASIC CD MECHANISM : 6ZG-1 YZRNDM • Replace this Service manual with “Revision Publishing” when it is issued. S/M Code No. 09-005-426-5T3...

  • Page 3: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST - 1/8 NOTE: The characters in the suffix column indicate the part usage. LHSK2M ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-040 CAP,E 100-16 A....87-010-186-080 CAP,CHIP 4700P A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-320-080 CHIP CAP 68P A....
  • Page 4 ELECTRICAL MAIN PARTS LIST - 2/8 87-033-213-080 CLAMP, FUSE A....87-033-213-080 CLAMP, FUSE A....87-026-682-080 PROTECTOR,10A 60V491 A....87-026-682-080 PROTECTOR,10A 60V491 A....87-A90-195-080 PROTECTOR 7A 125V 49 A....87-A90-195-080 PROTECTOR 7A 125V 49 A....8A-NF8-662-010 PT,SUB ANF-8 (E) A....87-026-245-080 TR,DTC114ES A....
  • Page 5 ELECTRICAL MAIN PARTS LIST - 3/8 87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-076-080 C-TR,2SC3052F A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-107-070 C-TR,CMBT5401 A....87-A30-190-080 TR,CC5551 A....87-A30-190-080 TR,CC5551 A....87-A30-097-010 TR,FN 1016 A....87-A30-097-010 TR,FN 1016 A....
  • Page 6 ELECTRICAL MAIN PARTS LIST - 4/8 83-XM1-617-080 C-COIL,BK2125HM601 ....87-A50-333-010 COIL,OSC 9.43MHZ A....LED 315 87-A40-380-180 LED,SEL6510C-TP5 GRN A....LED 311 87-A40-380-180 LED,SEL6510C-TP5 GRN A....LED 312 87-A40-380-180 LED,SEL6510C-TP5 GRN A....LED 314 87-A40-380-180 LED,SEL6510C-TP5 GRN A....LED 313 87-A40-380-180 LED,SEL6510C-TP5 GRN A....
  • Page 7 ELECTRICAL MAIN PARTS LIST - 5/8 87-007-342-010 COIL,OSC 85K BIAS A....87-026-609-080 TR,KTA1266GR A....87-026-610-080 TR,KTC3198GR A....87-026-610-080 TR,KTC3198GR A....87-A30-063-080 C-TR,KRA104S A....87-A30-076-080 C-TR,2SC3052F A....87-A30-087-080 C-FET,2SK2158 A....87-A30-087-080 C-FET,2SK2158 A....87-A30-087-080 C-FET,2SK2158 A....SFR 302 87-024-355-080 SFR,33K DIA6 H A....
  • Page 8 ELECTRICAL MAIN PARTS LIST - 6/8 87-010-182-080 C-CAP,S 2200P-50 B A....87-A10-592-080 C-CAP,S 0.015-50 J B A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-405-080 CAP, ELECT 10-50V A....87-010-407-080 CAP, ELECT 33-50V A....87-A10-592-080 C-CAP,S 0.015-50 J B A....87-010-198-080 CAP, CHIP 0.022 A....
  • Page 9 ELECTRICAL MAIN PARTS LIST - 7/8 87-012-368-080 C-CAP,S 0.1-50 F A....87-010-990-080 CAP,E 33-100 SME A....87-010-990-080 CAP,E 33-100 SME A....87-010-990-080 CAP,E 33-100 SME A....87-010-990-080 CAP,E 33-100 SME A....87-016-035-090 CAP, E 6800-35 VR A....87-016-035-090 CAP, E 6800-35 VR A....
  • Page 10 ELECTRICAL MAIN PARTS LIST - 8/8 87-A10-307-080 CAP,M 0.1-50 J A....87-A10-307-080 CAP,M 0.1-50 J A....87-010-401-080 CAP, ELECT 1-50V A....87-010-401-080 CAP, ELECT 1-50V A....87-010-197-080 CAP, CHIP 0.01 DM A....87-010-322-080 C-CAP,S 100P-50 CH A....87-010-322-080 C-CAP,S 100P-50 CH A....

  • Page 11: Mechanical Parts List

    MECHANICAL PARTS LIST - 1/2 NOTE: The characters in the suffix column indicate the part usage. LHSK2M ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-NF3-090-010 RING,FOOT AB....8A-NF3-017-010 CABI,REAR GSM ....8A-NF3-028-010 BOX,CASS L AB....8A-NF3-029-010 BOX,CASS R AB....8A-NF3-031-010 PANEL,FR U ....
  • Page 12 MECHANICAL PARTS LIST - 2/2 87-067-641-010 UTT2+3-8(W/O SLOT)BL A....87-067-689-010 TAPPING SCREW, BVTT+3-8 A....87-067-703-010 TAPPING SCREW, BVT2+3-10 A....87-067-758-010 BVT2+3-12 W/O SLOT AB....87-067-761-010 TAPPING SCREW, BVT2+3-10 AB....87-067-975-010 S-SCREW,IT+4-8 AB....87-591-095-410 TAPPING SCREW, QIT+3-8 (GLD) AB....87-721-096-410 QT2+3-10 GLD A....

  • Page 13: Accessories / Package List

    ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. LHSK2M ....XX........B....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8A-NF3-901-010 IB,H (ECA) M ....8A-NF3-902-010 IB,LH (ESP) M ....8A-NF3-905-010 IB,K (E) M ....8A-NF3-906-010 IB,EZ (9L) M A....
  • Page 14 SCHEMATIC DIAGRAM _ 1 (MAIN 1/3)
  • Page 15 SCHEMATIC DIAGRAM _ 2 (MAIN 2/3 : DECK SECTION)
  • Page 16 SCHEMATIC DIAGRAM _ 3 (MAIN 3/3 : TUNER SECTION)
  • Page 17 SCHEMATIC DIAGRAM _ 4 (CONTROL)
  • Page 18 SCHEMATIC DIAGRAM _ 5 (DISPLAY)
  • Page 19 SCHEMATIC DIAGRAM _ 6 (AMP)
  • Page 20 SCHEMATIC DIAGRAM _ 7 (PT)
  • Page 21 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9620450 Printed in Singapore...
