SERVICE MANUAL
STEREO CAR CASSETTE RECEIVER
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
CT-X430 YU(ST)(S/M Code No.09-003-339-1T1),
CT-R430M YZ(ST)/R410 YZ(ST)/R420 YZ(ST)/X430 YZ(ST),YH(ST)/X4300 YL(ST)
(S/M Code No.09-003-339-2T2).
All manuals and user guides at all-guides.com
CT-X430M
CT-X4300M
CT-R430M
CT-R420
CT-R410
CT-RV425
BASIC TAPE MECHANISM : CDS-363AG1-A
S/M Code No. 09-003-339-1R1
YU,YZ,YH(ST)
YL(ST)
YZ(ST)
YZ(ST)
YZ(ST)
YZ(ST)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-X430M and is the answer not in the manual?

Questions and answers

Related Manuals for Aiwa CT-X430M

Summary of Contents for Aiwa CT-X430M

  • Page 1 All manuals and user guides at all-guides.com CT-X430M YU,YZ,YH(ST) CT-X4300M YL(ST) CT-R430M YZ(ST) CT-R420 YZ(ST) CT-R410 YZ(ST) CT-RV425 YZ(ST) SERVICE MANUAL STEREO CAR CASSETTE RECEIVER BASIC TAPE MECHANISM : CDS-363AG1-A This Service Manual is the “Revision Publishing” and replaces “Simple Manual”...

  • Page 2: Specifications

    HLDR,REAR MTG TYPE MODEL NAME SUFFIX CT-R430M 4 8Z-KT1-231-010 HLDR,HALF -T CT-R410 CT-R420 5 8Z-KT1-625-010 CONN ASSY,16P SOC016<E,G,H> CT-RV425 CT-X430M 6 8Z-KT1-030-010 CASE,DFP -T CT-X430M 7 8Z-KT1-232-010 KEY,REMOVE -T CT-X430M 8 87-B10-141-010 NUT,5 TYPE-2 CT-X4300M 9 8Z-KT1-251-010 S-SCREW,5*6 TH+ TAPPING ST...

  • Page 3: Electrical Main Parts List

    All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C202 87-010-178-080 CHIP CAP 1000P C203 87-010-498-040 CAP,E 10-16 GAS 8Z-KT1-622-010 C-IC,LC75374E C204 87-010-498-040 CAP,E 10-16 GAS 8Z-KTG-622-010 IC,TA8259H C205...
  • Page 4 J901 87-A61-224-010 JACK,PIN 4P XR-401<G,H> CT-R430M L101 87-003-143-080 COIL 4.7 UH CT-R410 L102 8Z-KT1-619-010 COIL,68MH K7-D CT-R420 CT-RV425 L301 87-003-143-080 COIL 4.7 UH CT-X430M L701 87-003-149-080 COIL,47UH L801 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE CT-X430M LED701 87-027-262-010 LEDE,TLR-124(RED) CT-X430M SFR101 87-024-437-080 SFR,100K<A,B,C,D> CT-X4300M...

  • Page 5: Ic Block Diagram

    All manuals and user guides at all-guides.com IC BLOCK DIAGRAM-1 CHIP RESISTOR PART CODE IC, KIA6225S IC, SAA6579T Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Wattage Type Tolerance Symbol Resistor Code Form 1/16W 1005 0.35 1/16W...
  • Page 6 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-1 (MAIN SECTION) [CT-R430M YZ, CT-R410 YZ, CT-R420 YZ, CT-RV425 YZ] 2.1 4.9 E-VOL RDS VOLTAGE ADJ.
  • Page 7 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-2 (MAIN SECTION) [CT-X430M YU,YZ, YH, X4300M YL] CON801 CN801 (3/4) WHITE W801 CN802 BLACK CON801...

  • Page 8: Difference Table

    R531 CN802 R532 D401 R704 D402 R705 D403 R710 D404 R720 D405 R816 D406 R817 D707 R1101 D710 R1102 D713 R1103 IC1101 SFR101 J401 IC, LC75854W X1101 Q401 TYPE MODEL NAME SUFFIX CT-R430M CT-R410 CT-R420 CT-RV425 CT-X430M CT-X430M CT-X430M CT-X4300M...
  • Page 9 All manuals and user guides at all-guides.com WIRING-1 [YZ] [EXCEPT YZ] (F/R)
  • Page 10 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-3 (FRONT SECTION)
  • Page 11 All manuals and user guides at all-guides.com WIRING-2 [Except for CT-RV425 YZ] WIRING-3 [CT-RV425 YZ] R1012...
  • Page 12 All manuals and user guides at all-guides.com IC DESCRIPTION IC, µPD178006AGC-538/IC, µPD178018AGC-555 Pin No. Pin Name Description Pin No. Pin Name Description AM/FM S-M AF signal input during RDS AF operation and FM S meter signal input MAIN M CONT Main motor control output LEVEL-M Level meter signal input...

  • Page 13: Lcd Display

    All manuals and user guides at all-guides.com LCD DISPLAY ELECTRICAL ADJUSTMENT [CT-R430M, R410, R420, RV425] MAIN C.B L102 TUN101 SW702 SFR101 TEST POINT FRONT SIDE 1. RDS Voltage Adjustment Settings: • Test point: Center pin of SFR101 • Adjustment location: SFR101 Method: Set AM/FM Signal generation to 98 MHz, 30 dBV and adjust SFR101 so that the output becames 2.0 V ±...

  • Page 14: Mechanical Exploded View

    All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1/1 CDS-363AG1-A (A,B,C,D,F only) 43 (E,G,H only) (B,C,D only) 47 (A,E,F,G,H only) CHAS,SIDE-L FRONT C.B CHAS,FRONT F HT-SINK LCD1001 MAIN C.B AUX C.B CHAS,SIDE-R SH,PWB...

  • Page 15: Color Name Table

    HLDR,LCD F<EXCEPT D> 26 8A-KTB-203-010 HLDR,LCD B<D> 27 8A-KTB-202-010 LENS,LCD B<D> TYPE MODEL NAME SUFFIX CT-R430M CT-R410 CT-R420 CT-RV425 CT-X430M CT-X430M CT-X430M CT-X4300M COLOR NAME TABLE Basic color symbol Color Basic color symbol Color Basic color symbol Color Black Cream...

  • Page 16: Mechanism Exploded View

    All manuals and user guides at all-guides.com MECHANISM EXPLODED VIEW 1/1...
  • Page 17 All manuals and user guides at all-guides.com MECHANISM MAIN PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 S1-013-810-100 HOLDER CASS(X) 49 S1-036-360-100 FLYWHEEL ASSY(F) CPL 2 SX-003-610-190 EJECT CAM LOCK ASSY 50 S1-036-360-110 FLYWHEEL ASSY(R) CPL 3 S1-003-220-070 TAPE HOOKER...
  • Page 18 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 931196...

This manual is also suitable for:

Ct-x4300mCt-r430mCt-r420Ct-r410Ct-rv425

Table of Contents
