- Page 1 40/40 Air Shield P/N 777650 Installation Guide Document Ref: TM777650, Rev. (7) June 2017 www.acornfiresecurity.com...
- Page 2 www.acornfiresecurity.com www.acornfiresecurity.com...
-
Page 3: Legal Notice
SPECTREX agrees to extend to Purchaser/Distributor a warranty on the SPECTREX supplied components of the SharpEye products. SPECTREX warrants to Purchaser/Distributor that the products are free from defects in materials and workmanship for a period of five (5) years, commencing with the date of delivery to Purchaser/Distributor. -
Page 4: Release History
Eric Zinn March 2014 Fifth Release Ian Buchanan Eric Zinn May 2014 Sixth Release Ian Buchanan Eric Zinn March 2016 Seventh Release Ian Buchanan Eric Zinn June 2017 Eighth Release Jay Cooley Shaul Serero SharpEye 40/40 Air Shield Installation Guide www.acornfiresecurity.com... -
Page 5: Table Of Contents
Figure 2: Air Shield Assembly, Rear View ............9 Figure 3: Air Shield Assembly, Front View ............9 Figure 4: Locking the Screw ................10 Figure 5: Quick-Fit Air Connection ..............10 Figure 6: Air Shield Filter Replacement .............. 12 SharpEye 40/40 Air Shield Installation Instructions www.acornfiresecurity.com... - Page 6 www.acornfiresecurity.com www.acornfiresecurity.com...
-
Page 7: General Description
This document describes the installation instructions for the Air Shield P/N 777650. The air shield is suitable for use with the SharpEye 40/40 Series Optical Flame Detectors (40/40I, 40/40R, 40/40L, 40/40LB, 40/40L4, 40/40L4B, 40/40UFL, 40/40U, 40/40UB, and 40/40UFI), for both the aluminum and St.St. -
Page 8: Air Shield Installation Instructions
Air Shield Installation Instructions Surface Preparation Verify that all connection surfaces (1) are clean. Verify that the lock screw (2) is open. The screw is a captive screw. Figure 1: Surface Preparation SharpEye 40/40 Air Shield Installation Guide www.acornfiresecurity.com... -
Page 9: Air Shield Assembly
www.acornfiresecurity.com Air Shield Installation Instructions Air Shield Assembly Assemble the air shield (3) on the detector (4). Verify that the guard (5) fits into the appropriate groove (6). Figure 2: Air Shield Assembly, Rear View Figure 3: Air Shield Assembly, Front View TM777650 Rev (7), June 2017 www.acornfiresecurity.com... -
Page 10: Figure 4: Locking The Screw
Air Shield Installation Instructions Lock the screw (2). The air shield is now mounted. Figure 4: Locking the Screw Attach the air pressure hose to the quick-fit air connection (7). Figure 5: Quick-Fit Air Connection SharpEye 40/40 Air Shield Installation Guide www.acornfiresecurity.com... -
Page 11: Technical Specifications
www.acornfiresecurity.com Technical Specifications Air pressure source: Clean, dry, and oil-free air Pressure: 2─3bar (30−45psi) Fitting: 7/16” – 20UNF-2A Operation temperature: -55°C/85°C / -67°F/185°F Warning: The temperature of the air supply to the air shield should never exceed 60°C/140°F. TM777650 Rev (7), June 2017 www.acornfiresecurity.com... -
Page 12: Air Shield Filter Replacement
Remove the smaller gasket (Item 4 - P/N 777656), and replace it with a new one. Mount the new filter into the air shield. Fit the new larger gasket (Item 2). Close the air shield and lock the screws (Item 1). SharpEye 40/40 Air Shield Installation Guide www.acornfiresecurity.com... - Page 13 www.acornfiresecurity.com www.acornfiresecurity.com...
