  • Page 1 SATATYA NVR Quick Start...
  • Page 2 S E C U R I T Y S O L U T I O N S Matrix SATATYA PARAM NVR Video Surveillance Solution Quick Start...
  • Page 3 Neither Matrix Comsec nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs or expenses incurred by the buyer or third parties as a result of: accident, misuse or abuse of this product or unauthorized modifications, repairs or alterations to this product or failure to strictly comply with Matrix Comsec's operating and maintenance instructions.

  • Page 5: Table Of Contents

    Contents Know Your SATATYA NVR ................1 Naming Convention ................... 2 The Interfaces ....................3 NVRX Panel ...................... 4 The User Interface ..................... 8 Installing SATATYA NVR ................10 What Your Package Contains ................. 10 Things You Will Need ..................11 Preparing for Installation .................

  • Page 6: Know Your Satatya Nvr

    Know Your SATATYA NVR Thank you for choosing the Matrix SATATYA NVRX Series. This Quick Start is meant to help you get familiar with SATATYA NVRX Series, install the device and configure its basic parameters. To view or download the documents related to this product, scan the QR Code printed on the Product Label/Packaging Label.

  • Page 7: Naming Convention

    This is a common document for all the configurations of SATATYA NVRX series. The terms NVRX, NVR, Satatya NVR, SATATYA NVR, Matrix SATATYA NVR and Network video recorder are used interchangeably. The configurations for specific variant of NVRX is mentioned explicitly.

  • Page 8: The Interfaces

    The Interfaces Matrix SATATYA NVR Quick Start...

  • Page 9: Nvrx Panel

    NVRX Panel NVR0801X/NVR1601X NVR1602X/NVR3202X Matrix SATATYA NVR Quick Start...
  • Page 10 ALARM OUT Yes (1) To connect an alarm sounding relay (Terminal Block Plug) device such as a hooter or siren. To connect a high definition digital Yes (1) HDMI 2.0 monitor or TV for Main view. Matrix SATATYA NVR Quick Start...
  • Page 11 • User Settings • General Settings General Specifications NVR0801X, NVR1601X, NVR1602X, Parameters NVR3204X, NVR6404X, NVR6408X NVR3202X Power supply 12VDC, 5A SMPS Operating Temperature 0°C to +50°C (32°F to 122°F) Humidity 5% to 95% RH Non-Condensing Matrix SATATYA NVR Quick Start...
  • Page 12 1000 ON–1000 OFF Trigger from Event N.A. 3000 - ON and 1000 – OFF Backup Device full N.A. 1000 - ON and 2000 – OFF No Backup Device N.A. 1000 - ON and 3000 – OFF Matrix SATATYA NVR Quick Start...

  • Page 13: The User Interface

    NVR settings on the Monitor connected to your NVR. You can operate the device using a USB mouse and USB Keyboard. Remote View SATATYA NVR offers you two options for Remote View: A Device Client and SATATYA SIGHT. Matrix SATATYA NVR Quick Start...
  • Page 14 For enhanced accessibility and faster navigation, various functions in the Local Client can be performed using keyboard shortcuts. A list of available shortcut keys with the action they perform, have been broadly classified in Matrix SATATYA System Manual. Refer the same for detailed information.

  • Page 15: Installing Satatya Nvr

    • 2 HDD Power Cable • 2 HDD SATA Cable • 2 Clamps for Rack Mounting NVR3204X/NVR6404X • 1 Cable Mains 3 Pin • 16 HDD fitting screws • 4 HDD SATA Cable • 2 Clamps for Rack Mounting Matrix SATATYA NVR Quick Start...

  • Page 16: Things You Will Need

    • not expose the device to extreme heat or moisture, high voltages. • have adequate ventilation to prevent overheating. • be clear of any obstructions to the ventilation holes on the side panels of the NVR. • have a power outlet close by. Matrix SATATYA NVR Quick Start...
  • Page 17 If you choose rack mounting, fix the side clamps and then mount the device. • Refer to the following diagrams for the location of screws that you will need to remove and secure when installing the hard disks and the rack mounting side clamps. NVR0801X/NVR1601X Matrix SATATYA NVR Quick Start...
  • Page 18 NVR1602X/NVR3202X NVR3204X/NVR6404X Matrix SATATYA NVR Quick Start...
  • Page 19 Matrix SATATYA NVR Quick Start...

  • Page 20: Installing The Hard Disk

    NVRX series supports maximum eight Hard disks. The storage capacity of each hard disk is upto 10 Terabytes. Following table shows Hard disk support in each variant. NVRX variants Number of supported SATA interfaces NVR0801X/NVR1601X NVR1602X/NVR3202X NVR3204X/NVR6404X NVR6408X Matrix SATATYA NVR Quick Start...
  • Page 21 Fix four screws in the HDD (Do not fit the screws completely, turn just two - three rounds). NVR0801X/NVR1601X Place the HDD in accordance with the four holes in the bottom of the enclosure as shown. Matrix SATATYA NVR Quick Start...
  • Page 22 Turn the device upside down and then turn the screw using a magnetic screw driver to fix the HDD firmly as shown below. Maximum torque to be applied for tightening the screws is 3 kgf.cm. Applying more than specified torque will cause a damage to the HDD and the emboss. Matrix SATATYA NVR Quick Start...
  • Page 23 Inside the package you will find one SATA cable in NVR0801X and NVR1601X and two in NVR1602X and NVR3202X for each hard disk. Plug the SATA cables and power cables into the respective connectors on the hard disk as shown below. NVR0801X/NVR1601X Matrix SATATYA NVR Quick Start...
  • Page 24 Loosen the screws at the side panel to remove the top cover. Take the clamp and Place the Hard Disk inside the clamp. Secure the HDD inside the Clamp with the four screws provided using the magnetic screw. Matrix SATATYA NVR Quick Start...
  • Page 25 Now place the Clamp fitted with the Hard Disks on the bottom plate. NVR3204X/NVR6404X Cover Hard Disk Clamp Bottom Plate Side Panel Screws Front Cover Matrix SATATYA NVR Quick Start...
  • Page 26 Maximum torque to be applied for tightening the screws is 3 kgf.cm. Applying more than specified torque will cause a damage to the HDD and the clamp. Similar alignment can be done in NVR6408X with the eight Hard Disks as shown below. NVR6408X Matrix SATATYA NVR Quick Start...
  • Page 27 NVR6408X for each hard disk. Plug the SATA cables and power cables into the respective connectors shown below on the hard disk. Similar connection can be done in NVR6408X. Connectors are shown below. SATA Connectors(1-8) Matrix SATATYA NVR Quick Start...

  • Page 28: Connecting Devices

    Alarm In • You can connect upto 2 sensors to all the variants of NVRX. Connect the wires from the Sensor device you have installed into the SENSOR IN/ALARM IN port on the rear panel. Matrix SATATYA NVR Quick Start...
  • Page 29 • Connect the Ethernet cable from your computer/LAN Switch to the Ethernet port on the rear panel. • To connect SATATYA NVR to the Internet, connect its Ethernet port either directly to the DSL Modem or Router or over a LAN Switch. Matrix SATATYA NVR Quick Start...

  • Page 30: Connecting Power Supply

    Supply (UPS) for continuous operation. • If you have completed all the connections you want to make, plug the power adapter into the power outlet. Switch on power supply. Wait for the reset cycle to complete. Matrix SATATYA NVR Quick Start...

  • Page 31: Accessing The Satatya Nvr

    • Select the Input for the monitor you have connected. • Switch on power supply to your NVR. • The Matrix corporate logo will appear on your screen. • The default monitoring layout (4x4) will appear on your monitor screen.

  • Page 32: Accessing The Remote View

    You can access the Remote view in two ways, using: • Device Client • SATATYA SIGHT. Instructions for accessing the Device Client are provided in this document. To know how to use SATATYA SIGHT, read its respective product documentation. Matrix SATATYA NVR Quick Start...
  • Page 33 • If your network has dynamic IP Address assignment, it would be difficult to know the current IP Address of the NVR. You may use the Matrix DNS Server or the Dynamic DNS to assign a domain Name to the NVR. Each time you want to access the NVR from a remote location, you can use the name instead of the IP Address.

  • Page 34: Accessing The Satatya Device Application

    • Click the Go button the address bar of the browser or press the Enter key on your keyboard. • Click on Download button to download the “.exe” file of the device.The page appears as shown: • Save the File and Run Device_Client_Setup.exe. The following installation window appears. Matrix SATATYA NVR Quick Start...
  • Page 35 • Select the option Auto start application on system boot, if you want the application to get launched at the time of system boot. If enabled the user will get logged in to the device client Matrix SATATYA NVR Quick Start...
  • Page 36 • Click Next button and the following installation window appears as shown below. • Click on Finish to complete the installation.The Device Client application will launch as shown below. Matrix SATATYA NVR Quick Start...
  • Page 37 • SATATYA supports three access levels - Administrator, Operator, Viewer. The default user names and passwords for these three levels are: Access Level Default User Name Default Password Administrator admin admin Operator operator operator Viewer viewer viewer Matrix SATATYA NVR Quick Start...
  • Page 38 • Log in as Administrator. • The NVR display screen will open, with the default display layout (2x2). • click the Connect All button from the right pane of the window. Matrix SATATYA NVR Quick Start...
  • Page 39 NVRX like Date and Time, Network, Storage, Camera Configuration and Search Camera quickly as explained below: User can change the Login password by clicking on the Change Password option. Matrix SATATYA NVR Quick Start...
  • Page 40 See “Status” on page 47. To know more about the NVR controls and configuration settings available on the Device client, read the ‘SATATYA System Manual’. SATATYA NVR allows nine simultaneous login sessions on the Device Client. Matrix SATATYA NVR Quick Start...

  • Page 41: Quick Setup

    Click on the Next button to start configuring the parameters, which are explained as below: “Time and Language” “Network” “Storage” “Configure Camera” “Search Camera” “Status” Matrix SATATYA NVR Quick Start...
  • Page 42 Synchronize NVR Time Zone to ONVIF cameras: Enable the checkbox to sync Time Zone as well as date & time of NVVRX with the connected cameras. The ‘Synchronize NVR Time Zone to ONVIF Cameras’ option can not be updated if Local Time is selected to be synchronized with Camera. Matrix SATATYA NVR Quick Start...
  • Page 43 Device client to make them available in Language drop-down list for selection. •The updated language will be reflected in the Device Client or vise-versa after next login. •The Language feature is available only for SATATYA NVRX variants. Matrix SATATYA NVR Quick Start...
  • Page 44 DHCP: On selecting the DHCP option, the DHCP server automatically assigns an IP address to the NVRX when it comes on the network and thus no physical IP address is to be assigned to the NVRX by the administrator. Matrix SATATYA NVR Quick Start...
  • Page 45 The Configuration of selected option (LAN 1 or LAN 2) will be saved once it is switched from LAN 1 to LAN 2 or vice versa. LAN 2 Select the LAN 2 from the LAN drop-down list. Matrix SATATYA NVR Quick Start...
  • Page 46 SATATYA NVRX Series variants supports RAID 0, RAID 1, RAID 5 and RAID 10 HDD modes. Among all the NVRX variants, there is difference in number of available SATA interfaces and Ethernet ports. So based on SATA interfaces, RAID level can be configured. Matrix SATATYA NVR Quick Start...
  • Page 47 The below page will appear on the screen as ‘No Disk Found’ if the Hard Disks are not connected with the device. Once the HDDs are found connected then you can configure the storage for your NVRX as described below: Matrix SATATYA NVR Quick Start...
  • Page 48 Storage management mode. Format option is available to initialize the disks and create a new volume. Configure Camera This page allows the user to configure the parameters for the cameras to be added in the NVRX. Matrix SATATYA NVR Quick Start...
  • Page 49 This options enables the user to set the streaming parameters for the defined cameras. Configure the parameters for the Main Stream and Sub Stream as described below: Video Encoding: Select the video encoding mode from the pull down list. Matrix SATATYA NVR Quick Start...
  • Page 50 The custom resolution of minimum 64pixels and maximum 8192pixels can be played into the Live View. The VGA resolution, that is 640x480 is supported in all Matrix Cameras supported by NVR/NVRX, except the following: • SATATYA CIBR13FL40CW • SATATYA CIDR13FL40CW •...
  • Page 51 If the Camera is already added, then the Add column will show status as added with symbol . There will be Test button against the added camera. Click on the Test button to test the Camera. If the Camera is not added, then click on Add button to add the Cameras. Matrix SATATYA NVR Quick Start...
  • Page 52 Once all parameters are attended, you can also switch to the particular parameter to be re- configured by clicking on to the respective one. You can also access the Quick Setup from the Device Client, refer to the Matrix SATATYA System Manual for details.
  • Page 53 Matrix SATATYA NVR Quick Start...

  • Page 54: Configuring Satatya Nvr

    From Remote View • Make sure the computer you are using has the Device Client installed. • Open the Matrix Device Client on your computer. • In NVR Address, type the current IP Address of the NVR you want to access.
  • Page 55 • Click Network Settings and then click either LAN 1 or LAN 2. From Remote View • Open the Matrix SATATYA NVR Device Client on your computer. • In NVR Address, type the current IP Address of the NVR you want to access.
  • Page 56 When you click/select the User Name and Password field, the Virtual Keypad will appear, enabling you to enter alphanumeric characters. • Click the Save button. • Close the configuration window to return to the display. Matrix SATATYA NVR Quick Start...
  • Page 57 By Clicking LAN2 in Network Settings, the LAN2 Settings page appears as shown below: • Configure IP Address, the Subnet Mask and the Gateway address of LAN 2 on the LAN 2 Settings page similar to LAN1 Settings. For detailed description refer to the Matrix SATATYA System Manual. Matrix SATATYA NVR Quick Start...
  • Page 58 S E C U R I T Y S O L U T I O N S MATRIX COMSEC Head Office: 394-GIDC, Makarpura, Vadodara - 390010, India. Ph: (+91)1800-258-7747 E-mail: Support@MatrixComSec.com www.matrixvideosurveillance.com...
