Installation Instructions – LED Retrofit Kit – CBRK CooperKit

Instructions d'installation – Ensemble de modernisation à

DEL – CBRK CooperKit

Instrucciones de instalación – Kit de acondicionamiento

LED – CooperKit CBRK

Risk of Fire, Electrical Shock, Cuts or other Casualty Hazards- Installation and maintenance of this

product must be performed by a qualified electrician. This product must be installed in accordance with

the applicable installation code by a person familiar with the construction and operation of the product

and hazards involved.

Risk of Fire and Electric Shock- Make certain power is OFF before starting installation or attempting any

maintenance. Disconnect power at fuse or circuit breaker.

Risk of Fire- Minimum 90°C supply conductors.

Risk of Burn- Disconnect power and allow fixture to cool before handling or servicing.

Risk of Personal Injury- Due to sharp edges, handle with care.

Failure to comply with these instructions may result in death, serious bodily injury and property damage.

DISCLAIMER OF LIABILITY: Cooper Lighting Solutions assumes no liability for damages or losses of any kind that may

arise from the improper, careless, or negligent installation, handling or use of this product.

IMPORTANT: Read carefully before installing fixture. Retain for future reference.

NOTICE: Green ground screw provided in proper location. Do not relocate.

NOTICE: Fixture may become damaged and/or unstable if not installed properly.

Specifications and dimensions subject to change without notice.

ote:

ATTENTION Receiving Department: Note actual fixture description of any shortage or noticeable damage on delivery

receipt. File claim for common carrier (LTL) directly with carrier. Claims for concealed damage must be filed within 15

days of delivery. All damaged material, complete with original packing must be retained.
