Summary of Contents for Buick 2010 Enclave

  • Page 119: Table Of Contents

    Instruments and Controls Controls Steering Wheel Adjustment . . . 5-2 Steering Wheel Controls ..5-3 Horn ......5-5 Windshield Wiper/Washer .

  • Page 120: Controls

    Instruments and Controls Vehicle Personalization Vehicle Personalization ..5-40 Universal Remote System Universal Remote System . . . 5-47 Universal Remote System Programming ....5-47 Universal Remote System Operation .

  • Page 121: Steering Wheel Controls

    Push the control forward or rearward to move the steering wheel toward the front or rear of the vehicle. To set the memory position, Steering Wheel Controls Vehicles with audio steering wheel controls could differ depending on the vehicle's options. Some audio controls can be adjusted at the steering wheel.
  • Page 122 Instruments and Controls To navigate folders on an iPod or USB device for vehicles without a navigation system: 1. Press and hold while listening to a song until the contents of the current folder display on the radio display. 2. Press and hold to go back to the previous folder list.

  • Page 123: Horn

    SRCE (Source/Voice Recognition): Press to switch between the radio, CD, and for vehicles with, DVD, front auxiliary, and rear auxiliary. For vehicles with the navigation system, press and hold this button for longer than one second to initiate voice recognition. See Voice Recognition in the Navigation System manual for more information.

  • Page 124: Rear Window Wiper/Washer

    Instruments and Controls (Adjustable Interval Wipes): Turn the band up for more frequent wipes or down for less frequent wipes. 1 : Slow wipes. 2 : Fast wipes. Clear ice and snow from the wiper blades before using them. If frozen to the windshield, carefully loosen or thaw them.

  • Page 125: Compass

    Compass Your vehicle may have a compass in the Driver Information Center (DIC). See more information about the DIC. Compass Zone The zone is set to zone eight upon leaving the factory. Your dealer/ retailer will set the correct zone for your location.

  • Page 126: Calibrate Compass

    Instruments and Controls 4. Press the trip/fuel button until the vehicle heading, for example, N for North, is displayed in the DIC. 5. If calibration is necessary, calibrate the compass. See Compass Calibration Procedure following. Compass Calibration The compass can be manually calibrated.

  • Page 127: Clock

    Clock The vehicle has an analog clock and a digital radio clock. The digital radio clock can be enabled or disabled. Setting the Analog Clock The analog clock is located on the instrument panel above the radio. The clock is not connected with any other vehicle system and runs by itself.

  • Page 128: Power Outlets

    5-10 Instruments and Controls 3. Press the pushbutton located under any one of the labels to be changed. 4. To increase the time or date, do one of the following: Press the pushbutton below the selected label. Press SEEK. Press FWD.
  • Page 129 Certain accessory plugs may not be compatible to the accessory power outlet and could result in blown vehicle and adapter fuses. If a problem is experienced, see your dealer/retailer for additional information on the power accessory outlets. Adding any electrical equipment to the vehicle can damage it or keep other components from working as...

  • Page 130: Warning Lights, Gages, And Indicators

    5-12 Instruments and Controls If equipment is connected using more than 150 watts or a system fault is detected, a protection circuit shuts off the power supply and the indicator light turns off. To reset the circuit, unplug the item and plug it back in or turn the Remote Accessory Power (RAP) off and then back on.

  • Page 131: Instrument Cluster

    Instruments and Controls 5-13 Instrument Cluster United States version shown, Canada similar...

  • Page 132: Speedometer

    5-14 Instruments and Controls Speedometer The speedometer shows the vehicle's speed in both kilometers per hour (km/h) and miles per hour (mph). Odometer The odometer shows how far the vehicle has been driven, in either kilometers or miles. This vehicle has a tamper-resistant odometer.

  • Page 133: Engine Coolant Temperature

    Engine Coolant Temperature Gauge United States Canada This gauge shows the engine coolant temperature. Under normal driving conditions the gauge will read 210°F (100 °C) or less. If the gauge pointer is near 260°F (125 °C), the engine is too hot. It means that the engine coolant has overheated.

  • Page 134: Safety Belt Reminders

    5-16 Instruments and Controls Safety Belt Reminders Driver Safety Belt Reminder Light The driver safety belt reminder light on the instrument panel cluster. When the engine is started this light and the chime come on and stay on for several seconds to remind the driver to fasten the safety belt.

  • Page 135: Passenger Airbag Status Indicator

    If the airbag readiness light stays on after the vehicle has been started or comes on when while driving, the airbag system may not work properly. Have the vehicle serviced right away. WARNING If the airbag readiness light stays on after the vehicle is started or comes on while driving, it means the airbag system might not be working properly.

  • Page 136: Charging System Light

    5-18 Instruments and Controls If, after several seconds, both status indicator lights remain on, or if there are no lights at all, there may be a problem with the lights or the passenger sensing system. See your dealer/retailer for service. WARNING If the airbag readiness light ever comes on and stays on, it means...

  • Page 137: Malfunction Indicator Lamp

    Malfunction Indicator Lamp A computer system called OBD II (On-Board Diagnostics-Second Generation) monitors operation of the fuel, ignition, and emission control systems. It ensures that emissions are at acceptable levels for the life of the vehicle, helping to produce a cleaner environment. This light comes on when the ignition is on, but the engine is not running, as a check to show it is...
  • Page 138 5-20 Instruments and Controls The following can prevent more serious damage to the vehicle: Reduce vehicle speed. Avoid hard accelerations. Avoid steep uphill grades. If towing a trailer, reduce the amount of cargo being hauled as soon as it is possible. If the light continues to flash, when it is safe to do so, stop the vehicle.

  • Page 139: Emissions Inspection And Maintenance Programs

    Emissions Inspection and Maintenance Programs Some state/provincial and local governments have or might begin programs to inspect the emission control equipment on the vehicle. Failure to pass this inspection could prevent getting a vehicle registration. Here are some things to know to help the vehicle pass an inspection: The vehicle will not pass this inspection if the check engine...

  • Page 140: Antilock Brake System (Abs) Warning Light

    5-22 Instruments and Controls When the ignition is on, the brake system warning light will also come on when the parking brake is set. The light will stay on if the parking brake does not release fully. If it stays on after the parking brake is fully released, it means there is a brake problem.

  • Page 141: Stabilitrak ® Indicator Light

    ® StabiliTrak Indicator Light This light comes on briefly while starting the engine. If it does not, have the vehicle serviced by your dealer/retailer. If the system is working normally the indicator light goes off. If it stays on, or comes on while driving, there could be a problem with the StabiliTrak system and the vehicle might need service.

  • Page 142: Engine Oil Pressure Light

    5-24 Instruments and Controls loading information label. See for more information. When the Light Flashes First and Then is On Steady This indicates that there may be a problem with the Tire Pressure Monitor System. The light flashes for about a minute and stays on steady for the remainder of the ignition cycle.

  • Page 143: Fog Lamp Light

    Fog Lamp Light The fog lamp light comes on when the fog lamps are in use. The light goes out when the fog lamps are turned off. See for more information. Instruments and Controls Cruise Control Light This light comes on whenever the cruise control is set.
  • Page 144 5-26 Instruments and Controls The outside air temperature and compass, if equipped, also display on the DIC when viewing the trip and fuel information. The outside air temperature automatically appears in the top right corner of the DIC display. If there is a problem with the system that controls the temperature display, the numbers will be replaced with dashes.

  • Page 145: Park Assist

    When the remaining oil life is low, the CHANGE ENGINE OIL SOON message will appear on the display. See CHANGE ENGINE OIL SOON under . You should change the oil as soon as you can. See . In addition to the engine oil life system monitoring the oil life, additional maintenance is recommended in the Maintenance...
  • Page 146 5-28 Instruments and Controls If a low tire pressure condition is detected by the system while driving, a message advising you add air to a specific tire will appear in the display. See for more information. If the tire pressure display shows dashes instead of a value, there may be a problem with your vehicle.
  • Page 147 To switch between English and metric measurements, see UNITS earlier in this section. TRIP A and TRIP B Press the trip/fuel button until TRIP A or TRIP B displays. This display shows the current distance traveled in either miles (mi) or kilometers (km) since the last reset for each trip odometer.
  • Page 148 5-30 Instruments and Controls AVG (Average) ECONOMY Press the trip/fuel button until AVG ECONOMY displays. This display shows the approximate average miles per gallon (mpg) or liters per 100 kilometers (L/100 km). This number is calculated based on the number of mpg (L/100 km) recorded since the last time this menu item was reset.

  • Page 149: Vehicle Messages

    Vehicle Messages Messages are displayed on the DIC to notify the driver that the status of the vehicle has changed and that some action may be needed by the driver to correct the condition. Multiple messages may appear one after another. Some messages may not require immediate action, but you can press any of the DIC buttons on the...

  • Page 150: Brake System Messages

    5-32 Instruments and Controls Brake System Messages SERVICE BRAKE SYSTEM This message displays along with the brake system warning light if there is a problem with the brake system. See . If this message appears, stop as soon as possible and turn off the vehicle.

  • Page 151: Engine Cooling System Messages

    RIGHT REAR DOOR OPEN This message displays and a chime sounds if the passenger side rear door is not fully closed and the vehicle is shifted out of P (Park). Stop and turn off the vehicle, check the door for obstructions, and close the door again.

  • Page 152: Engine Oil Messages

    5-34 Instruments and Controls Engine Oil Messages CHANGE ENGINE OIL SOON This message displays when the engine oil needs to be changed. When you change the engine oil, be sure to reset the CHANGE ENGINE OIL SOON message. See information on how to reset the message.

  • Page 153: Key And Lock Messages

    TIGHTEN GAS CAP This message may display along with the check engine light on the instrument panel cluster if the vehicle's fuel cap is not tightened properly. See . Reinstall the fuel cap fully. See . The diagnostic system can determine if the fuel cap has been left off or improperly installed.

  • Page 154: Object Detection System

    5-36 Instruments and Controls Object Detection System Messages PARK ASSIST OFF If your vehicle has the Ultrasonic Rear Parking Assist (URPA) system, after the vehicle has been started and shifted out of P (Park), this message displays to remind the driver that the URPA system has been turned off or to notify the driver that the system has turned itself off.

  • Page 155: Anti-Theft Alarm System

    Anti-Theft Alarm System Messages SERVICE THEFT DETERRENT SYSTEM This message displays when there is a problem with the theft-deterrent system. The vehicle may or may not restart so you may want to take the vehicle to your dealer/retailer before turning off the engine. for more information.

  • Page 156: Service Tire Monitor System

    5-38 Instruments and Controls This message also displays LEFT FRT (left front), RIGHT FRT (right front), LEFT RR (left rear), or RIGHT RR (right rear) to indicate the location of the low tire. The low tire pressure warning light will also come on. See If a tire pressure message appears on the DIC, stop as soon as you can.

  • Page 157: Vehicle Reminder

    SERVICE ALL WHEEL DRIVE If your vehicle has the All-Wheel Drive (AWD) system, this message displays if there is a problem with this system. If this message appears, stop as soon as possible and turn off the vehicle. Restart the vehicle after 30 seconds and check for the message on the DIC display.

  • Page 158: Vehicle Personalization

    5-40 Instruments and Controls Vehicle Personalization Your vehicle may have customization capabilities that allow you to program certain features to one preferred setting. Customization features can only be programmed to one setting on the vehicle and cannot be programmed to a preferred setting for two different drivers.

  • Page 159: Auto Door Lock

    NO CHANGE: No change will be made to this feature. The current setting will remain. To select a setting, press the set/ reset button while the desired setting is displayed on the DIC. AUTO DOOR LOCK This feature allows you to select when the vehicle's doors will automatically lock.

  • Page 160: Remote Door Lock

    5-42 Instruments and Controls To select a setting, press the set/ reset button while the desired setting is displayed on the DIC. REMOTE DOOR LOCK This feature allows you to select the type of feedback you will receive when locking the vehicle with the Remote Keyless Entry (RKE) transmitter.

  • Page 161: Exit Lighting

    DELAY DOOR LOCK This feature allows you to select whether or not the locking of the vehicle's doors and liftgate will be delayed. When locking the doors and liftgate with the power door lock switch and a door or the liftgate is open, this feature will delay locking the doors and liftgate until five seconds after the last door is...

  • Page 162: Approach Lighting

    5-44 Instruments and Controls APPROACH LIGHTING This feature allows you to select whether or not to have the exterior lights turn on briefly during low light periods after unlocking the vehicle using the Remote Keyless Entry (RKE) transmitter. Press the customization button until APPROACH LIGHTING appears on the DIC display.

  • Page 163: Easy Exit Seat

    for this feature. Then press the customization button to scroll through the following settings: OFF (default): Neither outside mirror will be tilted down when the vehicle is shifted into R (Reverse). DRIVER MIRROR: The driver's outside mirror will be tilted down when the vehicle is shifted into R (Reverse).

  • Page 164: Remote Start

    5-46 Instruments and Controls Press the customization button until MEMORY SEAT RECALL appears on the DIC display. Press the set/ reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: OFF (default): No remote memory seat recall will occur.

  • Page 165: Universal Remote System

    To select a setting, press the set/ reset button while the desired setting is displayed on the DIC. EXIT FEATURE SETTINGS This feature allows you to exit the feature settings menu. Press the customization button until FEATURE SETTINGS PRESS TO EXIT appears in the DIC display. Press the set/reset button once to exit the menu.
  • Page 166 5-48 Instruments and Controls Do not use the Universal Home Remote with any garage door opener that does not have the stop and reverse feature. This includes any garage door opener model manufactured before April 1, 1982. Read the instructions completely before attempting to program the Universal Home Remote.
  • Page 167 2. Hold the end of your hand-held transmitter about 3 to 8 cm (1 to 3 inches) away from the Universal Home Remote buttons while keeping the indicator light in view. The hand-held transmitter was supplied by the manufacturer of your garage door opener receiver (motor head unit).
  • Page 168 5-50 Instruments and Controls 7. Firmly press and release the Learn or Smart button. After you press this button, you will have 30 seconds to complete Step 8. 8. Immediately return to the vehicle. Firmly press and hold the Universal Home Remote button, selected in Step 3 to control the garage door, for two seconds, and then release...

  • Page 169: Universal Remote System Operation

    Universal Remote System Operation Using Universal Remote Press and hold the appropriate Universal Remote button for at least half of a second. The indicator light will come on while the signal is being transmitted. Erasing Universal Remote Buttons All programmed buttons should be erased when the vehicle is sold or the lease ends.
  • Page 170 5-52 Instruments and Controls NOTES...
