Rover PrimeDigital Easy Meter Quick Reference Manual

Turn ON/OFF - HOME ____________________________
• Press to turn ON
• Keep pressed 2" to turn OFF
• Press to go to HOME MENU
Hardware reset __________________________________
• Press and hold for more than 10" to RESET, then turn ON
Software reset ___________________________________
• POWER ON and immediately after press VOLUME and hold until it beeps
Navigation wheel _________________________________
• Rotate to navigate
• Press (ENTER) to select
ENTER
Main MENU measurements ______________________
• First select the signal type: or or
• Then repeatedly press the keys: or or
to get various measurements: Power, BER, MER, PER, Constellation
Volume & Configuration Menu ____________________
• Press for the IMPORTANT SETTINGS:
VIDEO EXT input __________________________________
• Press and select VIDEO IN and select EXT (only where available)
Memory plans ____________________________________
• Press to select the required memory plan
Spectrum mode __________________________________
• Press to enable spectrum analyzer mode
• Press again to enable the MAX HOLD function (max peak)
Select: ___________________________________________
Chan, Transp, Freq, Ref.Level, Span, etc. in MEAS & SPECT.
• Select
CHAN
or TRANSP
• Navigate
Frequency direct selection ________________________
• Select FREQ or MRK.FR
• Keep ENTER pressed 2"
QUICK REFERENCE GUIDE
• Select CHAN or TRANSP
CHAN
• Keep ENTER pressed 2"
or
41
• Select from a drop-down list
• Press ENTER
• Key in a new value e.g.
• Press ENTER to confirm
- BATTERY SAVING = ON or OFF
- CONFIGURATIONS = SAT, TV & CABLE
TR
TR
in MEAS & SPECT.
TRANSP
TR
AN.SAT
30 11656.0
DigSAT
31 11671.0
8 4 2 . 0
26
0
