AVK
P2500
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVK P2500 and is the answer not in the manual?

Questions and answers

Related Manuals for AVYCON AVK P2500

Summary of Contents for AVYCON AVK P2500

  • Page 1 P2500 Quick Start Guide...
  • Page 2 Please read this instruction carefully for correct use of the product and preserve it for reference purposes.

  • Page 3: Table Of Contents

    Table of Contents Use Precautions ..........................1 Warning ............................... 1 Caution ................................ 1 Mainenence ..............................1 Main Functions and Features ......................2 1 Summary ..............................2 2 Feature ..............................2 3 Controller Button Overview ......................3 Contents and Battery Change ......................4 1 Products ..............................

  • Page 4: Use Precautions

    Use Precautions To prevent risk or damage on the property must keep the following information, please. *Please note the "Warning" and "Caution“. "Warning" and "Caution" mean as follows. Warning: Violation of the instructions may cause death or injury. Caution: Violation of the instructions may cause personal injury or property damage. WARNING •...

  • Page 5: Main Functions And Features

    Main Functions and Features 1. Summary This product is a system integrated controller which can control up to 255 units such as speed dome, DVR, multiplexer, receiver…etc. It is excellent system compatibility with a variety of protocol implementations. An array of buttons, user convenience easy connection with other products, and fine control make this unit a market needful product.

  • Page 6: Contents And Battery Change

    Contents and Battery Change 1. Products AVK-P2500 (Controller) User Manaual Communication connector DC12V Adaptor(optional) USB cable 2. Battery Change DC9V Battery (Purchased separately) Battery cover...

  • Page 7: Hardware Overview

    Hardware Overview 1. MOUSE 4. PTZ Function Keys 2. ESC/POWER 5. LCD Display 3. Numbers 6. Joystick 7. Controller Function Keys 8. Camera Focus Control 9. Camera Zoom Control Button Function MOUSE Mouse function ON/OFF button Power on and clear the entered value, or Pre-move is used. Enter the numbers or Set up camera ID/PTZ.

  • Page 8: Part Name & Function

    Part Name & Function 1. DC12V Input 2. USB Port 3. RS-485 / RS-422 4. Program Update Port 5. DC9V Battery Item Function Power input (DC 12V, 140mA) USB connecting terminal Use Tx1,2 or 3 for RS-485 /RS-422 connection RS-485 / RS-422 Program update port Program Update Port DC9V battery part...

  • Page 9: Connection

    Connection INTEGRATED Controller WTX-1200A Keyboard can be used to connect & control DVR, MULTIPLEXER, and other external devices. RS-485/422 Connection The external device’s RS-485/422 port is connected to this Keyboard’s RS-485/422 terminal block. When RS-485/422 connection, be careful +, - polarity not be changed.
  • Page 10 AVK-P2500 Quick Start Guide 1. DVR must be PC compatible. (Device driver required) 2. DVR Power ON 3. WTX-1200A Power ON 4. Mouse speed setting in the main setup (WTX-1200A 2 + 5. WTX-1200A and DVR connected. 6. If you press and hold button, you can see the phrase (MOUSE) flashing on the screen.

  • Page 11: System Configuration

    AVK-P2500 Quick Start Guide Single system configuration (PTZ connected directly) Max 16 CAM ERA Multi Port Multi Port Max 16 Multi Port Multi-system configuration Max 16 Rx + Rx - Rx + Rx - CAM ERA Tx+ Tx- Tx+ Tx- Tx+ Tx- Multi Port Max 16...

  • Page 12: Ptz Control

    PTZ Control 1 .Power On This device has two types of power use. 1) Connect provided adaptor to power. 2) Insert 9V batteries inside. (Do not connect adaptor.) 3) Power on external devices which are connected to this device before power on of this device. 4) Turn on the power by pressing button.

  • Page 13: Controller Control / Setup

    Controller Control / Setup Instructions and Setting up the MAIN SETUP Connect the power adapter to the back of the keyboard and pressing button, the following display appears on the LCD screen. Main MENU Setup If you press button 2 + for 2~3 seconds, you can enter into the MAIN SETUP.
  • Page 14 AVK-P2500 Quick Start Guide MAIN SETUP : OFF/ 1Min/ 5MIn /10Min / 30Min /1 (Hour) 8. SLEEP : OFF Setting to save power in the standby mode MAIN SETUP : OFF / ON Select BUZZER ON/ OFF 9. BUZZER : ON MAIN SETUP : OFF / ON Select TERMINATION ON/ OFF 10.

  • Page 15: Ptz Setup

    PTZ Setup PTZ Setup If you press button 2 + for 2~3 seconds, you can enter into the PTZ SETUP menu. PTZ SETUP [ PTZ SETUP : Input password (Factory set:0000) PASSWORD [ **** ] [ PTZ SETUP : Input camera address by using joystick 1.

  • Page 16: Basic Function Setting And Control

    Basic Function Setting and Control 1. PRESET Users can set the camera position where the user wants to see. 1+PSET 3+PSET 2+PSET PSET PSET PRESET setting : PRESET NO. + 3sec PRESET operating : PRESET NO. + 1sec PSET 2. TOUR When the Tour function runs, the camera moves from the preset assigned as the 1st point to the preset assigned as the last point in the sequence.

  • Page 17: Pattern

    AVK-P2500 Quick Start Guide 3. PATTERN The camera memorizes the path (mostly curve path) by joystick of the controller for assigned time and revives the path exactly as it memorized. Consecutively operating ° ° PATT PATT PATTERN setting : PATTERN NO. + 3sec PATTERN operating : PATTERN NO.

  • Page 18: Wtx-1200A Protocol

    WTX - 1200A Protocol 1. Serial Communication Format Data Communication: RS485 / RS-422 Data bit: 8bit Stop bit: 1bit Parity bit: None Transmission speed : 2400, 4800, 9600, 19200, 38400, 57600 bps 2. DATA Format(binary 5bytes) STX: 0xA0 ET: 0xAF ADDR: 0x01 ~ 0xFF(Address Change : address value + ENT + long) byte 1 byte 2...
  • Page 19 AVK-P2500 Quick Start Guide 3. Controller Button Overview WTX-1200A...
  • Page 20 System Configuration Single system configuration (Camera 1, keyboard 1, DVR 1) DVR PORT Rx + Rx - Tx1+ Tx1- Tx2+ Tx2- Tx3+ Tx3- Trx+ Trx- DVR PORT Rx + Rx - Tx1+ Tx1- Tx2+ Tx2- Tx3+ Tx3- Trx+ Trx-...
  • Page 21 Joystick Calibration It is for the keyboard to set the max movement of joystick. If you press button 3 + for 2~3 seconds, you can enter into the JOYSTICK CALIBRATION menu. [ JOYSTICK CALI. ] Show the joystick center value. 1.
  • Page 22 AVK-P2500 Quick Start Guide Joystick DATA Action Value Action Value Action Value Wide 0x87 Left 0x7n 0xn7 0x86 0x6n 0xn6 0x85 0x5n 0xn5 0x84 0x4n 0xn4 0x83 0x3n 0xn3 0x82 0x2n 0xn2 0x81 0x1n 0xn1 Stop 0x80 Stop 0x0n Stop 0xn0 0x88 0x9n...
  • Page 23 AVK-P2500 Quick Start Guide DATA DATA short 0x01 short 0x01 0x01 0x11 shitf + short 0x03 long 0x02 short 0x01 shift + short 0x03 0x02 shitf + short 0x03 short 0x01 0x12 short 0x01 long 0x02 0x03 shitf + short 0x03 shift + short 0x03...

  • Page 24: Specification

    Specification AVK-P2500 MODEL Pan/Tilt interface : RS-485/422 Interface : RS-485/422 Keyboard Pan/Tilt operating distance : 4700FT (1029m) on 24 AWG wire communication Protocol : Multiple (Pelco-D, Pelco-P , WONWOO, Etc.) (Baud rate selectable) Connector Type Data TERMINAL BLOCK(8p) Rubber button Keyboard button Numberic keypad and camera function key Joystick...
  • Page 25 Copyright © AVYCON. All rights reserved. Specifications and pricing are subject to change without notice. phone: 949-752-7606 email: info@avycon.com social: @avycon_aivo website: avycon.com...

  • Page 26: Drawing

    Drawing 180mm 280mm 100mm...
