Prepare The T6000 Spray Gun - Apollo Mini-Mist PRO Instruction Manual

If you have just finished spraying, the connector may be hot. Allow the T100 Turbo unit to cool down for about 10
minutes before disconnecting the air hose from the turbo unit. Use Caution!
3

Prepare the T6000 Spray Gun

1. Follow the diagram to prepare the Spray Gun
a. Unscrew the plastic cup from the Spray Gun. Pour tanning solution into the cup. Do not fill more than ¾ full.
b. Carefully screw the cup back onto the main body of the Spray Gun. Screw the cup on firmly but DO NOT
over tighten. Over tightening will cause the cup to "pop" and damage the threads. Leakage can
then occur requiring replacement of the cup.
c. Locate the air cap (#2) on the T6000 diagram. Slightly turn the air cap ring (#1) anti or counter clockwise to
loosen the air cap. Notice that you can now rotate the air cap freely.
d. Look at Mist Applicator Patterns diagram below. Note the position of the air cap and the direction of the
spray pattern. Pattern 1 is for spraying across from side to side. Pattern 2 is for spraying up and down.
Pattern 3 will produce a spot or circle. Patterns 1 and 2 are the most common positions for applying
tanning solutions.
e. Turn the air cap (#2) to the position you want. Turn the air cap ring (#1) clockwise to lock the air cap in
place.
2. Next, position the T100 Turbo Unit as far away as practical and possible from the area where you will spray.
3. Attach the remaining end of the hose to the T6000 Spray Gun as follows:
a. Locate the coupler at the bottom of the handle on the T6000 Spray Gun.
See T6000 diagram.
b. Pull back on the collar of the black connector on the air hose.
c. Push the connector over the coupler and release.
d. d. Your Spray Gun should now be firmly attached to the air hose.
SPRAY GUN PATTERNS
1. Misting across from side to side
2. Misting up and down.
3. Misting in a spot or circle
6
