- Page 1 ＰＡＴＲＩＯＴ ＭＷ５０ LA type soldering iron controller Instruction manual（QSS-4000） Date prepared: March 2019 The 6 edition JAPAN BONKOTE CO., LTD.
-
Page 2: Table Of Contents
Contents Preface ·················································································································· ·· １ Notes for safety ·········································································································· １ Recommendation of Auto-tuning before use ···································································· １ Notes for installation and use ····················································································· ·· ２ How to use MW50 Controller (A) Contents ··············································································································· ３ (B) Name of the body ··································································································· ３ (C) How to assemble ·································································································... -
Page 3: Preface
1. Preface Thank you very much for purchasing [MW50 Controller]. Please read Notes for safety before use, and use this machine properly, keep this manual after read. 2. Notes for safety ！ ＣＡＵＴＩＯＮ！ Be sure to read this manual before using this machine. ・... -
Page 4: Notes For Installation And Use
4. Notes for installation and use ・ This machine is designed with earth specification. For safety, be sure to use an earth-quipped receptacle. (If you do not have such receptacle, install an earth separately.) ・ For surrounding conditions, use this machine on a neat work bench on which a conductive mat is put. ・... -
Page 5: How To Use Mw50 Controller
5. How to use MW50 controller (A) Contents ① MW50 Controller ② 3P Power Cable ① ② ※100V with 3PCHI-plug cable, 220V with 3EPV-plug cable will be attached. (B) Name of the body 《 Front 》 ① 5P Connector ② Power switch ③... -
Page 6: (C) How To Assemble
(C) How to assemble ① Insert the Power cable into 3P inlet. ② Connect the soldering iron to 5P connector at the front, and lock it with rotating to right. Please make sure the voltage of the soldering iron unit is applicable to the input-voltage of MW50 controller. -
Page 7: (D) How To Use
(D) How to use ① Turn on Power Insert the power plug into the receptacle and confirm the input voltage of soldering iron and the one of this controller are same , then set the power switch to ON. ※If use 100V type of soldering iron with 220 input voltage in oversea, it makes heater damaged. ②... - Page 8 ～How to set the sensor type and temperature indication～ Ⅰ：At the operation mode, press key approx. 3 seconds with pressing ▽key. is indicated at PV screen. Ⅱ：Input suitable sensor type by △ or ▽key, and push key 8 times to return to operation mode. Operation mode Operation mode ⇒...
- Page 9 Temperature Sensor type input Operation mode compensation Operation mode screen screen ⇒ ⇒ ⇒ How to calculate the compensation value by Standard measurement instrument Example: Temperature instruments indicates : 350℃ Controller indicates : 355℃ Set the compensation value as －5 The compensation value＝Standard measurement instrument indication－Controller indication ⇒350－355＝－5 ⑤...
-
Page 10: Optional Setting
6. Optional setting MW50 has various functions. Please use the function with your convenience. (A) Alarm function Upper limit setting ① Set the upper limit alarm of soldering temperature Initial setting: 50℃ Ⅰ：At the operation mode, press key with pressing △ key. is indicated at PV screen. Ⅱ：Push ... -
Page 11: (E) Monitor Indication Of Operation Output Amount
(C) Speed Setting ① Control the recovery speed to setting temperature Setting range：1.0 ～ 10.0 Initial setting：4.0 Ⅰ：At the operation mode, push □ key once. is indicated at PV screen. Ⅱ：Input suitable value by △ or ▽ key at SV screen. Ⅲ：After input the value, push □... -
Page 12: (F) Lock Function
operation output amount Operation mode Operation mode screen ⇒ ⇒ (F) Lock function ① Lock setting value prevention from error setting Initial setting：Non-lock Ⅰ At the operation mode, press key with pressing ▽ key about 3 seconds. is indicated at PV screen. Ⅱ... -
Page 13: (H) Auto-Power Down/Auto-Power Off Setting
Anti-reset wind-up Operation mode ＡＴ Setting screen Operation mode setting screen ⇒ ⇒ ⇒ It is recommendable NOT to change the initial setting value. Setting lower value could restrain from overshooting, however, there is possibility unable to recover to the setting temperature. (H) Auto-Power Down／Auto-Power Off setting （1）... - Page 14 Input type setting Auto-Power down time Operation mode Operation mode screen setting screen ⇒ ⇒ ⇒ About Auto-Power Down time: e.g.: set value 30 minutes No fluctuation in the temperature of iron tip during stand-by mode for more than 30 minutes, the decline in temperature will start automatically.
-
Page 15: (I) Pid Value Manual Setting
Input type setting Auto-Power down time Operation mode Operation mode screen range setting screen ⇒ ⇒ ⇒ About Auto-Power Off time: e.g.: Setting value 「30 minutes」 During Auto-Power Down operation ( is blinking at SV value), no fluctuation within the temperature range while「30 minutes」, the controller recognizes that soldering iron is not using, and automatically turn off the power. - Page 16 derivative time become longer. This value will be set or adjusted after P value and I value is set. ① Setting of Proportional band Setting range：0 ～ 1000℃ Initial setting：88℃ Ⅰ：At the operation mode, push key with pressing △ key. is indicated at PV screen. Ⅱ：Push ...
-
Page 17: (J) Device Number Setting
(J) Device Number Setting (1) Device Number Setting is required under the condition of QSS-4000 Concentrated temperature management System for soldering iron. ① Setting of Device Number Initial Setting: 1 Setting Range: 1 ~ 95 : At the operation mode, push ... -
Page 18: Character List
７．Character list All character setting of M50 listed. △key ＋ key ▽key ＋ key ↓ ↓ Auto-tuning Input type setting ↓ ↓ Proportional band setting Lock function selection Operation mode ↓ ↓ ↓ Integration time setting Upper temperature setting ↓... -
Page 19: How To Maintenance
8. How to maintenance ①Loosen the fuse holder and remove it. Check the fuse if need change, and replace to a new fuse. Model No. Specification Fuse 3A Glass fuse 250V 3A(φ5.2×20mm） 9. Standard specification Input voltage AC100～240V Temperature range 0～500℃（At shipment）... -
Page 20: (B) Guarantee
When you think the product does not operate properly, read this manual again to check. If still troubles are not solved, please contact with your dealer or us. JAPAN BONKOTE CO., LTD. 600-14 Kasahara, Mito, Ibaraki 310-0852 JAPAN TEL : +81 29-241-2725 FAX: +81 29-241-2726 http://bonkote.co.jp...
