Operating Instructions
Winterhalter Gastronom Glass washing machine GS 29
1. Application
The Winterhalter Gastronom glasswashing machine GS 29 is designed for cleaning all kinds
of glasses used in the catering trade. The machine may only be used for this purpose and
must be operated in accordance with these operating instructions.
Any deviation from the machine's intended purpose or alteration of its design without our writ-
ten consent shall exempt us from all guarantee and product liability.
2. Installation and initial start-up
The machine must be installed and connected to the customer's water supply and waste pipes
in accordance with the "Installation Instructions for Winterhalter Gastronom Glass and Dish
Washers".
The initial start-up and staff briefing must be performed by the Winterhalter Gastronom after-
sales service team according to the "Start-up Instructions for Winterhalter Gastronom Glass-
washing Machines". You should therefore contact the responsible Winterhalter Gastronom
factory representative once the machine has been correctly connected to your supply pipes.
•
Your dishwasher is not ready for start-up until all connections have been completed.
89000867
05/00
Summary
1. Application
2. Installation and initial start-up
Winterhalter Gastronom GmbH
Postfach 1152
D-88070 Meckenbeuren
W
H K
ZLQ
U O
W
H
U
1
Advertisement
Table of Contents
Related Manuals for Winterhalter Gastronom GS 29
Summary of Contents for Winterhalter Gastronom GS 29
- Page 1 12. Optional extras 1. Application The Winterhalter Gastronom glasswashing machine GS 29 is designed for cleaning all kinds of glasses used in the catering trade. The machine may only be used for this purpose and must be operated in accordance with these operating instructions.
- Page 2 Extremely tall, thin glasses are always more difficult to clean than normal-sized glasses. Important features of glass racks Winterhalter Gastronom glass racks are designed in such a way that the glasses are washed at a slight angle. This intensifies the rinsing effect and enables the water to run out of the dimple in the base more easily.
- Page 3 You can also clean the glasses in the machine. For this purpose, add 50 ml of "GASTRONOM Reiniger F-8400“ detergent to the tank water and wash the rack containing the glasses three times. Then take the glasses out of the machine to dry. Winterhalter Gastronom GmbH 89000867 Postfach 1152...
- Page 4 Top up if necessary. • Make sure that no detergent gets into the clear rinse container when filling and refilling. Never mix up the detergent and clear rinse containers! Winterhalter Gastronom GmbH 89000867 Postfach 1152 05/00...
- Page 5 In the case of cold water connec- tions, the main wash cycle is not completed until the rinse water has reached the required operating temperature of 65°C. The wash cycle is completed when the "Programme“ button is extinguished. Winterhalter Gastronom GmbH 89000867 Postfach 1152 05/00...
- Page 6 Thus also the remainig tank inside is cleaned. &OHDQ WKH VXUIDFH VWUDLQHUV FKHFN WKH FRDUVH VLHYH DQG DOVR FOHDQ LW ,QVHUW WKH FRDUVH VLHYH DQG WKH VXUIDFH VWUDLQHUV DJDLQ LQWR WKH ZDVK WDQN Winterhalter Gastronom GmbH 89000867 Postfach 1152 05/00...
- Page 7 Then activate a new filling process by turning the power switch (1) off and on again. Should the low-water alarm continue to flash, please contact your Winterhalter after-sales service representative. Winterhalter Gastronom GmbH 89000867 Postfach 1152 05/00 D-88070 Meckenbeuren...
- Page 8 By pressing the "rinse temperature" button (5), it is possible to select a lower temperature for the rinse water (indicator lamp lights up accordingly). If the button is pressed again, the machine switches back to 65°C, and the indicator lamp is extinguished. Winterhalter Gastronom GmbH 89000867 Postfach 1152...
