2SHUDWLQJ LQVWUXFWLRQV
IRU :LQWHUKDOWHU *DVWURQRP XWHQVLO ZDVKHU *6 *6 *6
&RQWHQWV
1
Intended use .................................................................................................................................... 1
2
Installation and commissioning ........................................................................................................ 1
3
Safety instructions............................................................................................................................ 2
4
Operating panel................................................................................................................................ 3
5
Functions of the utensil washer ....................................................................................................... 4
6
Wash programmes........................................................................................................................... 4
7
Before washing ................................................................................................................................ 5
8
Washing ........................................................................................................................................... 8
9
Changing from normal programme to special programmes ............................................................ 9
10 Changing the programme setting................................................................................................... 11
11 After washing ................................................................................................................................. 12
12 Maintenance and care ................................................................................................................... 14
13 Faults ............................................................................................................................................. 16
14 Emission values ............................................................................................................................. 17
89007105
W
H K
ZLQ
U O
W
H
U
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winterhalter Gastronom GS 640
Summary of Contents for Winterhalter Gastronom GS 640
-
Page 1: Table Of Contents
2SHUDWLQJ LQVWUXFWLRQV IRU :LQWHUKDOWHU *DVWURQRP XWHQVLO ZDVKHU *6 *6 *6 &RQWHQWV Intended use ............................ 1 Installation and commissioning ......................1 Safety instructions..........................2 Operating panel..........................3 Functions of the utensil washer ....................... 4 Wash programmes........................... 4 Before washing ..........................5 Washing ............................ -
Page 3: Intended Use
Installation of the utensil washer and connection to the customer’s water inlet, waste water drainage and electricity connections are to be carried out in accordance with national and local criteria by qualified en- gineers in accordance with the “Installation instructions for Winterhalter Gastronom utensil washer“. Main fuses and main switch to be provided by customer. -
Page 4: Safety Instructions
Only use detergent and rinse additive which are suitable for industrial utensil washers. We recommend the products developed by Winterhalter Gastronom. These are specially developed to suit Winterhalter Gastronom utensil washers. All quantities given refer to Winterhalter Gastronom products. Observe danger instructions printed on packaging. -
Page 5: Operating Panel
• 7KH XWHQVLO ZDVKHU LV KRVHSURRI ,3 ; +RZHYHU GR QRW VSUD\ WKH RXWVLGH ZLWK D KLJK SUHVVXUH RU VWHDP MHW FOHDQHU • Check the customer’s required FI-residual current operated device for faults regu- larly according to the regulations by pressing the test button. •... -
Page 6: Functions Of The Utensil Washer
)XQFWLRQV RI WKH XWHQVLO ZDVKHU After the machine is switched on, the boiler and tank are filled and heated up to operating temperature. The programme button (6) is lit red during the heating up phase. As soon as the pre-set target temperatures (tank: approx. 60°C, boiler : approx. 85°C) have been reached, the machine is ready for operation. -
Page 7: Before Washing
%HIRUH ZDVKLQJ 7XUQ water stop valve to open position. 6ZLWFK RQ customer’s main switch &KHFN level in rinse additive container and detergent container (only with auto- matic detergent dosage). Replace or fill up empty containers. Observe safety instructions on packaging. &KHFN whether the flat filters, the basket filter and the filter in the floor of the tank (drainage filter) are installed. - Page 8 Pour detergent powder into basket filter with cup. We recommend Winterhalter Gastronom detergent powder. Observe the recommended dosage printed on the instruction label. Observe safety instructions on the detergent packaging. 3UHGRVDJH WDEOH when using the Winterhalter Gastronom 'HWHUJHQW 3 : :LQWHUKDOWHU 7DQN YROXPH 'RVDJH TXDQWLW\ ...
- Page 9 When manually adding detergent, add the quantity of detergent powder according to the table into the basket filter. Then start the wash pro- gramme. 7DEOH IRU PDQXDO DGGLWLRQ when using the Winterhalter Gastronom 'HWHUJHQW 3 : )UHVK ZDWHU :LQWHUKDOWHU...
-
Page 10: Washing
:DVKLQJ Before the washing items are loaded into the machine, they should be scraped clean of the largest lefto- vers and scraps: pour off leftover gravy, soak dried on leftovers. Do not use steel sponges to do this, be- cause the machine could be contaminated with rust thereby. Wash items such as buckets, pots, cauldrons, ham roasting dishes etc. -
Page 11: Changing From Normal Programme To Special Programmes
&KDQJLQJ IURP QRUPDO SURJUDPPH WR VSHFLDO SURJUDPPHV Before changing from normal programme to special programmes (short programme, intensive programme or normal programme with reduced rinse temperature), the button area with the special programmes must first be activated. this also displays the tank and boiler tempera- tures (however not during the programme). - Page 12 Please note that the concentration of detergent in the wash water diminishes more rapidly when the re- duced temperature rinse is used. Therefore add somewhat more detergent when this facility is continually in use. $GGLWLRQ WDEOH when using Winterhalter Gastronom 'HWHUJHQW 3 : )UHVK ZDWHU :LQWHUKDOWHU...
-
Page 13: Changing The Programme Setting
&KDQJLQJ WKH SURJUDPPH VHWWLQJ Changing the programme setting for the special programmes and for the normal pro- gramme can be carried out with the door open or closed. = &KDQJLQJ EHWZHHQ WKH VSHFLDO SURJUDPPHV 6HOHFW desired programme (press button). The previously selected programme is thus cancelled. -
Page 14: After Washing
$IWHU ZDVKLQJ = 7DQN GUDLQDJH VHOIFOHDQLQJ With the cleaning programme, the interior of the utensil washer is cleaned. The wash pump operates for 30 sec. The dirty wash water is pumped off. The utensil washer switches off automatically after the cleaning programme has finished. - Page 15 • Clean the outer walls of the utensil washer with cleaning products for high grade stainless steel. We recommend Winterhalter Gastronom high grade stainless steel cleaner and Winterhalter high grade stainless steel protection. = 6ZLWFKLQJ RII After the cleaning programme has finished, the control of the dishwasher is switched off.
-
Page 16: Maintenance And Care
Clean the supply filter after the water stop valve. Clean the outer walls of the utensil washer with special cleaning products for high grade stainless steel. We recommend Winterhalter Gastronom high grade stain- less steel cleaner and Winterhalter high grade stainless steel protection. - Page 17 = 'HVFDOLQJ 'UDLQ machine. ,QWHUUXSW detergent supply: 5HPRYH suction pipe from the detergent canister. 5HILOO machine. $GGLWLRQ of the descaling solution according to manufacturer’s instructions. 2EVHUYH WKH SULQWHG VDIHW\ LQVWUXFWLRQV 7ULJJHU intensive programme once or twice (max. 10 minutes circulation). This loosens the coating of scale.
-
Page 18: Faults
)DXOWV If the symbol for a fault lights up, the utensil washer must be switched off (press On/Off switch). Following this, the (UU sign lights up with the fault code. For information on faults, see following table. 'LVSOD\ )DXOW &DXVH(IIHFW 5HPHG\ Utensil washer... -
Page 19: Emission Values
= (UURU DODUP YLD SURJUDPPH NH\ This key lights up or flashes in UHG whenever a temperature exceeds the set- point value: • &RQWLQXRXV OLJKW: Temperature in boiler or tank is below the setpoint value (only during initial heating). As soon as the setpoint values are reached, the key lights up in green.
