Walther Systemtechnik TBV-H-01 Operating Manual

Operating Manual Table-top Greasing Device TBV-H-0x-xx
Rev. 1.5
Operating Manual
Table-top Greasing Device Horizontal
Article Numbers:
Figure TBV-02(H) with cover
TBV-H-01(H) / TBV-H-01-SW(H) /
TBV-H-01-S(H) / TBV-H-01-S-SW(H)
Table-top Greasing Device
Dosing Volume
0,001 - 0,020 cm³
(1 - 20 mm³)
TBV-H-03(H) / TBV-H-03-SW(H)
Table-top Greasing Device
Dosing Volume
0,100 - 2,000 cm³
(100 - 2000 mm³)
NOTE
Please read this Operating Manual carefully before first using the device and strictly
adhere to the instructions!
This device may only be worked with and worked on by persons who are familiar with
this Operating Manual and the current regulations for industrial safety and accident
prevention.
Always keep the "Original Operating Manual" at the device!
TBV-H-01(H); TBV-H-01-SW(H)
TBV-H-01-S(H) ; TBV-H-01-S-SW(H)
TBV-H-02(H); TBV-H-02-SW(H)
TBV-H-02-S(H) ; TBV-H-02-S-SW(H)
TBV-H-03(H); TBV-H-03-SW(H)
TBV-H-04(H); TBV-H-04-SW(H)
Figure TBV-03-SW(H) with cover
The manual has to be available anytime!
Figure TBV-02-S(H) with cover
TBV-H-02(H) / TBV-H-02-SW(H) /
TBV-H-02-S(H) / TBV-H-02-S-SW(H)
Table-top Greasing Device
Dosing Volume
0,010 - 0,200 cm³
(10 - 200 mm³)
TBV-H-04(H) / TBV-H-04-SW(H)
Table-top Greasing Device
Dosing Volume
1,000 - 6,000 cm³
(1000 - 6000 mm³)
