Summary of Contents for Siemens Nixdorf D1156
- Page 1 ...
- Page 2 Is there ..any technical problem or other ... anything you want to tell us question you need clarified? about this manual? Please contact: Please send us your comments quoting • the order number of the manual. Our Hotline: Mo-Fr: 8 a.m.
- Page 3 Your training needs? The Siemens Training Centers offer you a wide range of training courses in information technology and on IT products and other subjects - onsite near to your workplace or offsite at one of our training centers. Contact us for information on consulting, course schedules and selfstudy material - Either fax (which is the fastest way): Fax: ..49 89 636-42945 Or write to:...
- Page 4 ! " # $ % &' ()*+, -. / 0 1 2 ' &' +33 +433 A26361-D1156-Z180-1-7619...
- Page 5 English System board D1156 Additional Technical Manual September 1999 edition...
- Page 6 Intel, Pentium and Celeron are registered trademarks and MMX and OverDrive are trademarks of Intel Corporation, USA. Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation. PS/2 and OS/2 Warp are registered trademarks of International Business Machines, Inc. All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged.
-
Page 7: Table Of Contents
Functions controlled by the switch block ................. 10 Power............................10 Power requirement ......................10 Power loadability ......................10 Documentation..........................11 Installing drivers..........................11 Upgrades ............................11 Main memory .......................... 11 Troubleshooting ..........................12 Message BIOS update ......................12 The screen stays blank ......................12 A26361-D1156-Z180-3-7619... -
Page 9: Introduction
Utility" or "ServerStart" CD. For detailed information please look at chapter "Installing drivers". The latest BIOS version or drivers can be found on the internet under http://www.siemens.de/computer/service. Features Function D1156-A Chipset 440 ZX100 DIMM sockets ISA slots PCI slots ISA/PCI shared... -
Page 10: Mechanics
Some of the following connectors are optional and may therefore not be included on your system board. Slot 1 1 = Serial port 1 4 = Parallel port 2 = PS/2 mouse port 5 = USB connection 2 3 = PS/2 keyboard port 6 = USB connection 1 2 - English A26361-D1156-Z180-3-7619... - Page 11 4 = IDE drives 3 and 4 (secondary) 9 = DIP switch 5 = Wake On LAN 10 = Fan 1 (e. g. for the processor) The components and connectors marked do not have to be present on the system board. English - 3 A26361-D1156-Z180-3-7619...
-
Page 12: Connectors And Jumpers
Power supply ATX connector Signal Signal +3.3 V +3.3 V +5 V +5 V Powergood (high asserted) +5 V Auxiliary +12 V +3.3 V -12 V PS on (low asserted) -5 V +5 V +5 V 4 - English A26361-D1156-Z180-3-7619... -
Page 13: Wake On Lan (Wol) Connector
Mechanics Wake on LAN (WOL) connector Signal +5 V Auxiliary Wake pulse (high asserted) Power on switch connector (ON/OFF switch) Signal Power on pulse (low asserted) English - 5 A26361-D1156-Z180-3-7619... -
Page 14: Front Panel Connector (Version 1)
Cathode PON_LED (GND) Anode Message LED Cathode Message LED Key pin Anode HD_LED Cathode HD_LED GND (for Reset and Power button) Not connected Power Button SCSI LED Input Not connected SCSI LED Input Reset Button Not connected 6 - English A26361-D1156-Z180-3-7619... -
Page 15: Front Panel Connector (Version 2)
Cathode PON_LED (GND) Key pin Anode Message LED Cathode Message LED Not connected SCSI LED Input Anode HD_LED SCSI LED Input Cathode HD_LED Not connected GND (for Reset and Power button) Power Button Not connected Reset Button English - 7 A26361-D1156-Z180-3-7619... -
Page 16: Usb Chipcard Reader Connector
VCC Auxiliary P3V3P Power OK (low asserted) Chipcard reader On (low pulse) Fan 1 connector for CPU fan or system fan (if external temperature sensor is in use) Signal 6 - 12 V; 0 V Fan sense 8 - English A26361-D1156-Z180-3-7619... -
Page 17: Configuration
Switch 5 Switch 6 Switch 7 Switch 8 350 MHz 400 MHz 450 MHz Pentium III with 100 MHz Front Side Bus: Processor Switch 5 Switch 6 Switch 7 Switch 8 450 MHz 500 MHz 550 MHz English - 9 A26361-D1156-Z180-3-7619... -
Page 18: Functions Controlled By The Switch Block
Power loadability Fuse Maximum Fuse Function Maximum function current number current 750 mA Universal serial bus (USB) Port A 500 mA Keyboard Not specified Mouse Not specified 750 mA Universal serial bus (USB) Port B 500 mA 10 - English A26361-D1156-Z180-3-7619... -
Page 19: Documentation
The EEPROM of PC100 modules contains a number of critical timing parameters and data regarding the chip and the module vendor. Due to this the system board will properly recognize the module by reading all important timing parameters specified in the EEPROM via the Serial Presence Detect interface. English - 11 A26361-D1156-Z180-3-7619... -
Page 20: Troubleshooting
This system board is fully compliant for ACPI S4. Therefore it is PC98 certified by Microsoft. If you have any problems with ACPI please ensure that all of your components are supporting ACPI S4. − Operating System − Hardware and drivers of controllers (e. g. VGA, audio, LAN, SCSI controllers). 12 - English A26361-D1156-Z180-3-7619...
