  • Page 5 Deutsch English System board D1042 System board D1042 Technical Manual Technical Manual Ausgabe Juni 1998 June 1998 edition...
  • Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright © Siemens Nixdorf Informationssysteme AG 1998. Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

  • Page 7: Table Of Contents

    ..........12 Add-on modules..................... 13 Upgrading main memory ................15 Replacing the processor................. 16 Setting the processor core voltage ..............16 Upgrading the video memory ................. 17 Upgrading the wavetable module ..............17 Replacing the lithium battery ................18 A26361-D1042-Z120-5-7419 English...

  • Page 9: Introduction

    Introduction This description applies for the System board D1042 with PCI bus (Peripheral Component Interconnect). This system board is available in different configuration levels. Depending on the hardware configuration of your device, it may be that you cannot find several options in your version of the system board, even though they are described.

  • Page 10: Important Notes

    The warranty expires if the device is damaged during the installation or replacement of system expansions. Information on which system expansions you can use is available from your sales office or the customer service. 2 - English A26361-D1042-Z120-5-7419...
  • Page 11 The equipment and tools you use must be free of static charges. • Pull out the power plug before inserting or pulling out boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. English - 3 A26361-D1042-Z120-5-7419...

  • Page 12: Features

    1 serial port (16C550 compatible with FIFO) • PS/2 mouse port • PS/2 keyboard port • Security functions • USB (Universal Serial Bus) • Energy saving functions • Loudspeaker • Connector for remote-on (fax/modem board), chipcard reader and infrared interface 4 - English A26361-D1042-Z120-5-7419...
  • Page 13 Connector for CD-line in, Game/Midi, Voice-Modem, AUX IN • Microphone jack • Audio input (Line in) • Connector for headphones or active speakers • Connector for Wake On LAN (WOL) • C connector • Prepared for Siemens Nixdorf system monitoring English - 5 A26361-D1042-Z120-5-7419...

  • Page 14: Interfaces And Connectors

    2 = MIDI/Game port 6 = USB ports 3 = Monitor port 7 = PS/2 keyboard port 4 = Parallel port 8 = PS/2 mouse port The connectors marked do not have to be present on the system board. 6 - English A26361-D1042-Z120-5-7419...
  • Page 15 20 = Voice modem 10 = Connector 1 for control panel 21 = AUX IN 11 = ON/OFF button 22 = CD Line in The connectors marked do not have to be present on the system board. English - 7 A26361-D1042-Z120-5-7419...

  • Page 16: Possible Screen Resolution

    1280x1024 62 to 107 64 K 1280x1024 62 to 107 16 mio. Not available; * : this value is only available with 8 MB. 64 K: high color (16 bit); 16 million: true color (24 bit) 8 - English A26361-D1042-Z120-5-7419...
  • Page 17 1600x1280 94 to 100 64 K 1600x1280 94 to 100 16 mio.* Not available; * : this value is only available with 8 MB. 64 K: high color (16 bit); 16 million: true color (24 bit) English - 9 A26361-D1042-Z120-5-7419...

  • Page 18: Resource Table

    MPU 401 (MIDI interface). Detailed information is provided in the audio documentation on the driver and utility CD. Please note that a resource cannot be used by two applications at the same time. 10 - English A26361-D1042-Z120-5-7419...

  • Page 19: Settings With Switch Block

    Switch 1, 2, 3 and 4 = clock speed Switch 7 = reserved Switch 5 = write-protection for system BIOS Switch 8 = write protection for floppy disk Switch 6 = must be set to off drive English - 11 A26361-D1042-Z120-5-7419...

  • Page 20: Clock Speed - Switch 1, 2, 3 And 4

    To write and delete floppy disks, the write-protection in BIOS setup must be disabled (in menu Security, the field Diskette Write must be set to Enabled). The floppy disk drive is write-protected. Read, write and delete floppy disks is possible (default setting). 12 - English A26361-D1042-Z120-5-7419...

  • Page 21: Add-On Modules

    The connectors marked do not have to be present on the system board. Modules can become very hot during operation. Make sure you do not touch modules when adding components to the system board. There is a danger of burns! English - 13 A26361-D1042-Z120-5-7419...
  • Page 22 Settings - Control Panel - Display - tab Settings - PowerDesk Settings - Performance: there must then be no tick in the box next to Use Bus Mastering. Further information is provided in the online help of the VGA driver. 14 - English A26361-D1042-Z120-5-7419...

  • Page 23: Upgrading Main Memory

    Press the lateral holders until they snap in place. Press the lateral holders firmly against the location. Removing a memory module Flip the holders to the right and left of the location outwards. Pull the memory module out of its location. English - 15 A26361-D1042-Z120-5-7419...

  • Page 24: Replacing The Processor

    Set the switches 1, 2 , 3 and 4 depending on the processor which is installed. Setting the processor core voltage Processor type Jumper VCore Intel not inserted AMD-K6 - 166 connected to 1-2 AMD-K6 - 200 AMD-K6 - 233 connected to 2-3 16 - English A26361-D1042-Z120-5-7419...

  • Page 25: Upgrading The Video Memory

    Otherwise the memory extension might be damaged. Upgrading the wavetable module If the system board is prepared for upgrading with a single-chip wavetable module (Crystal CS9236), the upgrade is carried out as shown in the figure. English - 17 A26361-D1042-Z120-5-7419...

  • Page 26: Replacing The Lithium Battery

    Make sure that you insert the battery the right way round. The plus pole must be on the top! Lift the contact (1) a few millimeters and remove the battery from its socket (2). Insert a new lithium battery of the same type in the socket (3). 18 - English A26361-D1042-Z120-5-7419...
