Introduction
This description applies for the system board D1025 with PCI bus (Peripheral Component
Interconnect).
This system board is available in different configuration levels. Depending on the
i
hardware configuration of your device, it may be that you cannot find several options in
your version of the system board, even though they are described.
You may find further information in the description "BIOS Setup".
Further information to drivers is provided in the readme files on hard disk or on the supplied drivers
diskettes or on the "Drivers & Utility" or "ServerStart" CD.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
Pay particular attention to texts marked with this symbol. Failure to observe this warning
!
endangers your life, destroys the system, or may lead to loss of data.
This symbol is followed by supplementary information, remarks and tips.
i
Texts which follow this symbol describe activities that must be performed in the order shown.
This symbol means that you must enter a blank space at this point.
This symbol means that you must press the Enter key.
Texts in this typeface are screen outputs from the PC.
Texts in this bold typeface are the entries you make via the keyboard.
Texts in italics indicate commands or menu item.
"Quotation marks" indicate names of chapters and terms that are being emphasized.
A26361-D1025-Z120-7-7419
English - 1
Advertisement
Table of Contents
Related Manuals for Siemens Nixdorf D1025
Summary of Contents for Siemens Nixdorf D1025
-
Page 1: Introduction
Introduction This description applies for the system board D1025 with PCI bus (Peripheral Component Interconnect). This system board is available in different configuration levels. Depending on the hardware configuration of your device, it may be that you cannot find several options in your version of the system board, even though they are described. -
Page 2: Important Notes
There is a danger of burns! The warranty expires if the device is damaged during the installation or replacement of system expansions. Information on which system expansions you can use is available from your sales office or the customer service. 2 - English A26361-D1025-Z120-7-7419... - Page 3 The equipment and tools you use must be free of static charges. • Pull out the power plug before inserting or pulling out boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. English - 3 A26361-D1025-Z120-7-7419...
-
Page 4: Features
Parallel interface (ECP- and EPP-compatible) • 1 serial port (16C550 compatible with FIFO) • PS/2 mouse port • PS/2 keyboard port • Security functions • Prepared for Siemens system monitoring • Prepared for Rainbow Runner video module 4 - English A26361-D1025-Z120-7-7419... - Page 5 Connector for remote-on (fax/modem board), chipcard reader and infrared interface • Connector for CD-line in, Game/Midi, Voice-Modem, AUX IN • Microphone jack • Audio input (Line in) • Connector for headphones or active speakers Optional Components • LAN port • C connector English - 5 A26361-D1025-Z120-7-7419...
-
Page 6: Interfaces And Connectors
4 = Audio port (Line in) 9 = Parallel interface 5 = Audio port (Microphone) 10 = LAN port 11 = Video connector The connectors marked do not have to be present on the system board. 6 - English A26361-D1025-Z120-7-7419... - Page 7 C connector 19 = IDE drives 1 and 2 (primary) 10 = Feature connector 20 = Connector for chipcard reader 21 = IrDA The connectors marked do not have to be present on the system board. English - 7 A26361-D1025-Z120-7-7419...
-
Page 8: Lan Port
Otherwise malfunctions may occur. Please contact our customer service. The onboard LAN controller may be switched off by the LAN_OFF jumper. If you want to switch off the onboard LAN controller insert a jumper to position 1-2 of the LAN_OFF jumper. 8 - English A26361-D1025-Z120-7-7419... -
Page 9: Possible Screen Resolution
1280x1024 62 to 107 64 K 1280x1024 62 to 107 16 mio. Not available; * : this value is only available with 8 MB. 64 K: high color (16 bit); 16 million: true color (24 bit) English - 9 A26361-D1025-Z120-7-7419... - Page 10 1600x1280 94 to 100 64 K 1600x1280 94 to 100 16 mio.* Not available; * : this value is only available with 8 MB. 64 K: high color (16 bit); 16 million: true color (24 bit) 10 - English A26361-D1025-Z120-7-7419...
-
Page 11: Resource Table
MPU 401 (MIDI interface). Detailed information is provided in the audio documentation on the driver and utility CD. Please note that a resource cannot be used by two applications at the same time. English - 11 A26361-D1025-Z120-7-7419... -
Page 12: Settings With Switches
Switch 1, 2, 3 and 4 = clock speed Switch 7 = reserved Switch 5 = recovering system BIOS Switch 8 = write protection for floppy disk drive Switch 6 = must be set to off 12 - English A26361-D1025-Z120-7-7419... -
Page 13: Clock Speed - Switch 1, 2, 3 And 4
BIOS setup must be disabled (in menu Security, the field Diskette Write must be set to Enabled). The floppy disk drive is write-protected. Read, write and delete floppy disks is possible (default setting). English - 13 A26361-D1025-Z120-7-7419... -
Page 14: Add-On Modules
3 = Lithium battery 8 = Flash BIOS 4 = Processor with heat sink and fan 9 = Socket for wavetable chip 5 = VCore jumper for processor core voltage All PCI slots have bus master capability. 14 - English A26361-D1025-Z120-7-7419... -
Page 15: Upgrading Main Memory
Press the lateral holders until they snap in place. Press the lateral holders firmly against the location. Removing a memory module Flip the holders to the right and left of the location outwards. Pull the memory module out of its location. English - 15 A26361-D1025-Z120-7-7419... -
Page 16: Replacing The Processor
Set the switches 1, 2 , 3 and 4 depending on the processor which is installed. Setting the processor core voltage Processor type Jumper VCore Intel not inserted AMD-K6 - 166 connected to 1-2 AMD-K6 - 200 AMD-K6 - 233 connected to 2-3 16 - English A26361-D1025-Z120-7-7419... -
Page 17: Upgrading The Video Memory
Otherwise the memory extension might be damaged. Upgrading the wavetable module If the system board is prepared for upgrading with a single-chip wavetable module (Crystal CS9236), the upgrade is carried out as shown in the figure. English - 17 A26361-D1025-Z120-7-7419... -
Page 18: Replacing The Lithium Battery
Make sure that you insert the battery the right way round. The plus pole must be on the top! Lift the contact (1) a few millimeters and remove the battery from its socket (2). Insert a new lithium battery of the same type in the socket (3). 18 - English A26361-D1025-Z120-7-7419... -
Page 19: Table Of Contents
Write protection for floppy disk drive - switch 8 ............... 13 Add-on modules..........................14 Upgrading main memory ......................15 Replacing the processor ......................16 Upgrading the video memory ....................17 Upgrading the wavetable module .................... 17 Replacing the lithium battery ....................18 A26361-D1025-Z120-7-7419... - Page 20 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright © Siemens Nixdorf Informationssysteme AG 1998. All rights, including rights of translation, reproduction by printing, copying or similar methods, even of parts are reserved.
