SMC Networks SMCSM01-Z User Manual

SMCSM01-Z Smoke Sensor User Manual
Congratulations on purchasing your SMCSM01-Z Smoke Sensor.
The SMCSM01-Z Smoke Sensor is a low-profile wireless smoke detector designed to provide reliable smoke or fire detection. The SMCSM01-Z is ideal for difficult-to-wire
residential or commercial applications. This user manual has all the information to get your SMCSM01-Z Smoke Sensor up and running quickly.
1

Unpacking

Your SMCSM01-Z package includes the following items:
One SMCSM01-Z Smoke Sensor
One dust cover
Two CR123A batteries
Mounting bracket
This user manual
If any items are missing or damaged, contact your place of
purchase. Keep the carton, including the original packing
material, in case you need to store or return the product.
2

Specifications

The SMCSM01-Z specifications are:
Voltage: 3VDC
®
Battery type1 3V Lithium, Duracell 123, Sanyo
®
Panasonic CR123A
Sensitivity 2.25 % ± 1.35 %
Drift compensation adjustment 0.5%/ft. max
Operating temperature: 40° to 100° F (4.4° and 37.8° C)
Compatible control panel: RB5701-Z SMA Gateway
The SMCSM01-Z specifications heat alarm specifications are:
Rate-of-rise: 15°F/min >105°F (8.3°C/min > 40.6°C)
Fixed: 135°F ± 5°F (57.2°C ± 2.8°C)
Note: Constant exposures to high or low temperatures or
high humidity may reduce battery life.
I/M SMCSM01-Z rev. 1.0
8/19/10
3

NFPA Guidelines

NFPA 72, 2-1.4.2.1 Total (Complete) Coverage
If required, total coverage shall include all rooms, halls,
storage areas, basements, attics, lofts, spaces above
suspended ceilings, and other subdivisions and accessible
spaces; and the inside of all closets, elevator shafts, enclosed
stairways, dumbwaiter shafts, and chutes. Inaccessible areas
shall not be required to be protected by detectors. (For
exceptions, refer to NFPA 72.)
NFPA 72, 2-1.4.2.2 Partial Coverage
If required, partial detection systems shall be provided in all
common areas and work spaces, such as corridors, lobbies,
storage rooms, equipment rooms, and other tenantless spaces
in those environments suitable for proper detector operation in
accordance with this code.
NFPA 72, 2-1.4.2.3 Selective Coverage
Where codes, standards, laws, or authorities having
jurisdiction require the protection of selected areas only, the
specified areas shall be protected in accordance with this
®
code.
, and
NFPA 72, 2-1.4.2.4 Supplementary (Non required)
Coverage
Where installed, detection that is not required by an
applicable law, code, or standard, whether total (complete),
partial, or selective coverage, shall conform to the
requirements of this code. (For exceptions, refer to NFPA 72
Chapter 2 Spacing Requirements.)
NFPA 72, 2-1.4.3
Where non required detection devices are installed for a
specific hazard, additional non required detection devices shall
not be required to be installed throughout an entire room or
building.
©
Copyright 2010 SMC Networks
All Rights Reserved
NFPA 72, 2-2 Heat-Sensing Fire Detectors
Heat-sensing fire detectors shall be installed in all areas where
required by the NFPA codes and standards or by the authority
having jurisdiction.
NFPA 72, 8-1.4.1.3.2 Detection in New Apartment
Buildings
Approved, single-station smoke alarms shall be installed in
accordance with 7-6.2.10 of NFPA 101 outside every sleeping
area in the immediate vicinity of the bedrooms and on all
levels of the dwelling unit including basements. (101: 18-
3.4.4.2) (For exceptions, refer to this section of NFPA 72.)
NFPA 72, 8-1.4.1.4.2 Detection in Existing Apartment
Buildings Approved, single-station smoke alarms shall be
in-stalled in accordance with 7-6.2.10 of NFPA 101
outside every sleeping area in the immediate vicinity of
the bedrooms and on all levels of the dwelling unit
including basements. (101: 19-3.4.4.1) (For exceptions,
refer to this section of NFPA 72.)
4

Technical Bulletin

SMCSM01-Z is a member of SMC Networks' family of reliable,
high-quality products using the latest technology available.
Please review the information in this section to ensure you
get the most out of your new SMCSM01-Z Smoke Sensor.

Pre-installation Considerations

Install the SMCSM01-Z in accordance with the National Fire
Protection Association's (NFPA) Standard 72, Chapters 2 and
8. Depending on the application, you may need to reference
other chapters of NFPA 72 or NFPA 101.
continued on next page
Page 1
