Autonics APC-1011 Quick Start Manual

TCD210151AB
Panel PC
APC-1011
For your safety, read and follow the considerations written in the instruction
manual, other manuals and Autonics website.
The specifications, dimensions, etc. are subject to change without notice for product
improvement. Some models may be discontinued without notice.
Features
• Familiar to user with the Microsoft Windows 10 OS
• Equipped with Quad core processor
• Fan less type with low noise, low heat and no need to replacing fan component
• Equipped with 10 inch wide IPS TFT LCD of 16,777,216 colors for realizing True color
• Possible to be touched with not only hand but also glove, pen tip or etc. with resistive
type touch screen
• Lesser restrictions on place with display and system all-in-one panel PC
• Supporting various types of interface
: HDMI, USB, VGA, Ethernet, Audio, Serial (RS232C / RS485 / RS422)
• Various methods of installation
: installing on panel, installing with holder (VESA standard 100 × 100 mm)
ᜢ ᜣ
Safety Considerations
• Observe all 'Safety Considerations' for safe and proper operation to avoid hazards.
• ᜸ symbol indicates caution due to special circumstances in which hazards may occur.
᜸ Warning
Failure to follow instructions may result in serious injury or death.
01. Fail-safe device must be installed when using the unit with machinery that
may cause serious injury or substantial economic loss.(e.g. nuclear power
control, medical equipment, ships, vehicles, railways, aircraft, combustion
apparatus, safety equipment, crime/disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or fire.
02. Do not use the unit in the place where flammable/explosive/corrosive gas,
high humidity, direct sunlight, radiant heat, vibration, impact or salinity
may be present.
Failure to follow this instruction may result in explosion or fire.
03. Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or shortening the life cycle of the
product.
04. Do not connect, repair, or inspect the unit while connected to a power
source.
Failure to follow this instruction may result in fire.
05. Check 'Power Wiring' and 'Serial Interface' before wiring.
Failure to follow this instruction may result in fire.
06. In preparation for product damage, communication error, or malfunction,
install external emergency stop circuit, forward/reverse interlock circuit,
limit switch, emergency stop switch, or other protection circuit.
Failure to follow this instruction may result in personal injury, economic loss or fire.
07. Since Lithium battery is embedded in the product, do not disassemble or
burn the unit.
Failure to follow this instruction may result in fire.
08. Do not disassemble or modify the unit.
Failure to follow this instruction may result in fire.
09. Please contact to us for battery replacement.
᜸ Caution
Failure to follow instructions may result in injury or product damage.
01. Use a dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in fire.
02. When connecting the power input, use AWG 23 cable or over, and tighten the
terminal screw with a tightening torque of 0.5 to 0.8 N·m.
Failure to follow this instruction may result in fire or malfunction due to contact
failure.
03. Keep the product away from metal chip, dust, and wire residue which flow
into the unit.
Failure to follow this instruction may result in fire or product damage.
04. Do not push over 2 point at the same time.
Failure to follow this instruction may result in malfunction.
